D-Link DSL-526E Manual de usuario

QUICK

INSTALLATION

GUIDE

USB / ETHERNET ADSL2+ MODEM ROUTER

DSL-526E

ENGLISH

CONTENTS OF

PACKAGING

CONTENTS

POWER ADAPTER

AU/NZ PIN ADAPTER

ETHERNET CABLE (CAT5 UTP)

CONNECT THE ROUTER TO YOUR PC / DEVICE

If any of these items are missing from your packaging contact

your reseller

RJ-11 PHONE CABLE

XDSL MICROFILTER / SPLITTER

USB / ETHERNET ADSL2+ MODEM ROUTER

DSL-526E

DSL-526E 3

ENGLISH

PRODUCT

SETUP

WEB BROWSER SETUP WIZARD

To congure DSL-526E you will need to connect your computer to the DSL-526E using the Ethernet

cable provided. Then connect the power cable to the DSL-526E. The power light will appear solid.

Then simply open a browser window and enter the IP address in the browser address eld:

IP ADDRESS: http://192.168.1.1

USERNAME: admin

PASSWORD: admin

SETUP WIZARD

- Click the Setup Wizard button to commence

- Follow the on-screen prompts

- Enter your ISP Username and Password

- Save and Apply changes

Congratulations you are now connected to the Internet.

DSL-526E

ENGLISH

TROUBLESHOOTING

SET-UP AND CONFIGURATION PROBLEMS

1. How do I configure my DSL-526E router via a web browser?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the address http://192.168.1.1

- The default username is ‘admin’. The default password is ‘admin’.

- If you have changed the password and can not remember it, you will need to reset the router to

the factory default setting (steps in question 2), which will set the password back to ‘admin’.

2. How do I reset my router to factory default settings?

- Ensure the router is powered on.

- Press and hold the reset button on the rear of the device for 5-8 seconds.

Note: Resetting the router to factory default will erase the current conguration settings. To re-

congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.

3. What can I do if my router is not working correctly?

- The manual contains a full troubleshooting section and can be downloaded from the D-Link

website (see below), however there are a few quick steps you can take to try and resolve any

issues:

- Check the LED’s on the front of the router.The Power LED should be on, the Status LED should

ash, and the DSL and LAN LED should be on as well.

- Check that all the cables are rmly connected at both ends.

- Power the router off for 20 seconds, and then power it back on.

4. Why can I not get an Internet Connection?

- For ADSL ISP users, please contact your ISP to make sure the service has been enabled/

connected by your ISP and that your ISP username and password are correct.

TECHNICAL SUPPORT

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

DSL-526E 5

ENGLISH

NOTES

Ver. 1.00(AU) 2014/09/11
