D-Link DSL-502T Manual de usuario

Before You Begin

Make sure you have all the necessaryinformation and equipment on hand before beginning

the installation.

CheckYourPackageContents

This product

can beset

up using any currentweb

browser, i.e.,Internet

Explorer 6or Netscape

Navigator 6.2.3.

DSL-502T

ADSLRouter

specificationssubject to change without notice.

DSL-502T ADSL Router

CD-ROM(containingManual and USB Driver)

Ethernet (CAT5 UTP) Cable

Telephone Cable

Power Adapter

USB Cable

Ifanyoftheabove items are missing, please contact your reseller

Using a power supply

with a different voltage

rating will damage and void

the warrantyfor this product.

Connecting the Routerto YourComputer

Please read the User s Manual for instructions on how to use

the USB port.

A. First, connect the power adapter to the receptor at the back panel ofthe

DSL-502Tand then plug the other end of the power adapter to a wall outlet or

power strip. The Power LED will turn ON to indicate proper operation.

B. Insert one end of the cable into the Ethernet port on the back panelofthe

DSL-502Tand the other end ofthe cable to an Ethernet Adapter or available

Ethernet port on your computer.

ADSL port -

connect to

ADSL line

USB port,

con

nect USB

cable here

and install

Ethernet port -

connect to

Ethernet cable

Factory

Reset

button

Power input -

connect to power

adapter

Configuring the Router

To use your Web browser to access the web pages used to setup the Router, your computer

must be configured to Obtain an IPaddress automatically”, that is, you must change the

IPnetwork settings ofyour computer so that it is a DHCPClient. Ifyou are using Windows

XP and do not knowhowto change your network settings, skip ahead to Appendix A and

read the instructionsprovided. You mayalso read the User Manual for instructionson

changing IPsettings for computers running Windows operating systems.

Open your Web browser and type

http://192.168.1.1”into the URLaddress

box.Then pressthe Enter or Return key.

The Login pageappears.

Type admin”for the

admin”in the

Password field.

Click Login

Configuring the Router(continued)

Once you havelogged in, the Home screen will appear.Click the Setup tab to go to the Setup

menu and configure the Router.

Click Setup

Configuring the Router(continued)

In the Setup menu, click the Connection 1 button to go to the configuration menu for the

Internet connection.

Click Connection 1

Configuring the Router(continued)

In the Connection 1 menu, type the Username and Password used to verifythe identityof

your ISPaccount. It maybe necessaryto change the PPPencapsulation Type used for your

connection. You mayalso need to change the VPI or VCI value. YourISPwill give these

settings to you if theyneed to be changed. Click the Apply button when you have entered all

the information. Tosavethe changes made to Connection 1, click the Tools tab and follow the

instructions on the next page.

A. Type the Username

and Password used for

your account.

D. Click Tools when

you have applied the

newsettings.

C. Click the Apply button

after you have entered the

account information.

B. Check the PPP

encapsulation Type,

VPI: and VCI: - ifthese

values are not correct,

change these according

to the instructions of

your ISP.

Configuring the Router(continued)

Nowsave the changesyou have just made. The Save function is accessed from the System

Commands menu. Click the System Commands button to viewthat menu.

Click System Commands to

viewthe menu used to save

changes.

Configuring the Router(continued)

To save the newsettings, click the SaveAll button in the System Commands menu. Aftera

fewseconds, the changes will be saved. The Router will automaticallyestablish the Internet

connection after a fewmore seconds.

Wait a fewseconds forthe Internet connection to be established and proceed to access the

Internet via your web browser.

Click SaveAll to save

the newsettings.

Appendix

For additional settings or information, refer to the Advanced, Tools, or Status tabs on the

web-management interface; or to the manual located on the CD-ROM.

Configuring IPSettings in Windows XP

Use the following steps to configure a computer running Windows XPto be a DHCPclient.

1. From the Start menu on your desktop, go to Settings, then click on Network

Connections.

2. In the Network Connections window, right-click on LAN (Local Area Connection),

then click Properties.

Right-click on the Local Area

Connection icon and Select the

Properties option from the pull-

down

menu.

3. In the General tab of the Local Area Connection Properties menu, highlight Internet

Protocol (TCP/IP) under “This connection uses the following items:”byclicking on it

once. Click on the Properties button.

4. Select “Obtain an IPaddress automatically”byclicking once in the circle. Click the

OK button.

Your computer is nowreadyto use the Router s DHCPserver.

Click Properties

Select Obtain an IPaddress

automatically in the Internet

Protocol (TCP/IP) Properties window

Otros manuales para DSL-502T
