D-Link DGS-2208 - Desktop Switch Manual de usuario

2D-Link DGS-2208 User Manual

Table of Contents

Safety Instructions ...................................................... 3

Safety Cautions ....................................................... 3

Protecting Against Electrostatic Discharge.............. 6

Product Overview........................................................7

Package Contents ................................................... 7

Setup ....................................................................... 7

Introduction.............................................................. 8

Features ................................................................ 11

Hardware Overview ............................................... 12

Front Panel (LEDs) .......................................... 12

Rear Panel (Connections) ............................... 14

Installation..................................................................15

Before You Connect to the Network ......................15

Mounting the Switch on the Wall ........................... 16

Mounting on a cement wall .............................. 16

Mounting on a wood wall .................................16

Connecting the Switch...........................................17

DGS-2208 to End Node...................................17

Hub/Switch to DGS-2208.................................17

Connecting To Network Backbone or Server .. 17

Troubleshooting ........................................................18

Glossary .....................................................................19

Networking Basics ....................................................24

Check your IP address .......................................... 24

Windows®XP/2000 Users................................ 24

Windows Vista™Users..................................... 24

Statically Assign an IP address ............................. 25

Windows®XP/2000 Users................................ 25

Windows Vista™Users..................................... 26

Technical Specications........................................... 27

DGS-2208 Specications ...................................... 27

Contacting Technical Support ................................. 29

Warranty..................................................................... 30

Registration................................................................35

Table of Contents

3D-Link DGS-2208 User Manual

Section 1 - Safety Instructions

Use the following safety guidelines to ensure your own personal safety and to help protect your system from potential

damage.

Safety Cautions

To reduce the risk of bodily injury, electrical shock, re, and damage to the equipment, observe the following

precautions.

Observe and follow service markings. Do not service any product except as explained in your system documentation.

Opening or removing covers that are marked with the triangular symbol with a lightning bolt may expose you to an

electrical shock. Only a trained service technician should service components inside these compartments.

If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact

your trained service provider:

– The power cable, extension cable, or plug is damaged.

– An object has fallen into the product.

– The product has been exposed to water.

– The product has been dropped or damaged.

– The product does not operate correctly when you follow the operating instructions.

• Keep your system away from radiators and heat sources. Also, do not block cooling vents.

• Do not spill food or liquids on your system components, and never operate the product in a wet environment. If

the system gets wet, see the appropriate section in your troubleshooting guide or contact your trained service

provider.

Safety Instructions

4D-Link DGS-2208 User Manual

Section 1 - Safety Instructions

• Do not push any objects into the openings of your system. Doing so can cause a re or an electric shock by

shorting out interior components.

• Use the product only with approved equipment.

• Allow the product to cool before removing covers or touching internal components.

• Operate the product only from the type of external power source indicated on the electrical ratings label. If you

are not sure of the type of power source required, consult your service provider or local power company.

• To help avoid damaging your system, be sure the voltage selection switch (if provided) on the power supply is

set to match the power available at your location:

– 115 volts (V)/60 hertz (Hz) in most of North and South America and some Far Eastern countries such

as South Korea and Taiwan.

– 100 V/50 Hz in eastern Japan and 100 V/60 Hz in western Japan.

– 230 V/50 Hz in most of Europe, the Middle East, and the Far East.

• Also be sure that attached devices are electrically rated to operate with the power available in your location.

• Use only approved power cable(s). If you have not been provided with a power cable for your system or for

any AC-powered option intended for your system, purchase a power cable that is approved for use in your

country. The power cable must be rated for the product and for the voltage and current marked on the product’s

electrical ratings label. The voltage and current rating of the cable should be greater than the ratings marked

on the product.

• To help prevent an electric shock, plug the system and peripheral power cables into properly grounded electrical

outlets. These cables are equipped with three-prong plugs to help ensure proper grounding. Do not use adapter

plugs or remove the grounding prong from a cable. If you must use an extension cable, use a 3-wire cable with

properly grounded plugs.

5D-Link DGS-2208 User Manual

Section 1 - Safety Instructions

• Observe extension cable and power strip ratings. Make sure that the total ampere rating of all products plugged

into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit for the extension

cable or power strip.

• To help protect your system from sudden, transient increases and decreases in electrical power, use a surge

suppressor, line conditioner, or uninterruptible power supply (UPS).

• Position system cables and power cables carefully; route cables so that they cannot be stepped on or tripped

over. Be sure that nothing rests on any cables.

• Do not modify power cables or plugs. Consult a licensed electrician or your power company for site modications.

Always follow your local/national wiring rules.

• When connecting or disconnecting power to hot-pluggable power supplies, if offered with your system, observe

the following guidelines:

– Install the power supply before connecting the power cable to the power supply.

– Unplug the power cable before removing the power supply.

– If the system has multiple sources of power, disconnect power from the system by unplugging all power

cables from the power supplies.

• Move products with care; ensure that all casters and/or stabilizers are rmly connected to the system. Avoid

sudden stops and uneven surfaces.

6D-Link DGS-2208 User Manual

Section 1 - Safety Instructions

Static electricity can harm delicate components inside your system. To prevent static damage, discharge static electricity

from your body before you touch any of the electronic components, such as the microprocessor. You can do so by

periodically touching an unpainted metal surface on the chassis.

You can also take the following steps to prevent damage from electrostatic discharge (ESD):

1. When unpacking a static-sensitive component from its shipping carton, do not remove the component

from the antistatic packing material until you are ready to install the component in your system. Just

before unwrapping the antistatic packaging, be sure to discharge static electricity from your body.

2. When transporting a sensitive component, rst place it in an antistatic container or packaging.

3. Handle all sensitive components in a static-safe area. If possible, use antistatic oor pads, workbench

pads, and an antistatic grounding strap.

Protecting Against Electrostatic Discharge

7D-Link DGS-2208 User Manual

Section 2 - Product Overview

• D-Link DGS-2208 8-port Switch

• Manual and Warranty on CD

• Four (4) Rubber Feet

• Wall Mount Kit

• Power Adapter

Setup

The setup of the DGS-2208 can be performed using the following steps:

• The power outlet should be within 1.82 meters (6 feet) of the Switch.

• Visually inspect the DC power jack and make sure that it is fully secured to the power adapter.

• Do not cover the ventilation holes on the sides of the Switch, and make sure there is adequate ventilation

around it.

• Do not place heavy objects on the switch.

Product Overview

Package Contents

8D-Link DGS-2208 User Manual

Section 2 - Product Overview

Introduction

D-Link Green Ethernet Technology

D-Link Green Ethernet Technology implements special power-saving features under speed at 1000Mbps that detect

cable length and link status and adjust power usage accordingly.

Green Ethernet Technology saves energy in two specic ways:

1. If there is no link on a port (when there is no connection or the device connected is turned off) the port(s)

will enter a “sleep mode” which will drastically reduce the amount of power used.

2. D-Link Green Ethernet Technology detects the length of connected Ethernet cable and adjusts power

usage accordingly without affecting performance. This way, a port connected to a 10m cable only uses

as much power as it needs, instead of using full power, which is only needed for 100m cables.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need

for high performance networks. 100BASE-TX (Fast Ethernet) provides a cost-effective and high-performance solution for

small workgroups, SMBs (Small to Medium Businesses), and any network supporting bandwidth-intensive applications.

Fast Ethernet technology operates at 10 times the speed of traditional Ethernet, offering maximum performance and

enhanced capability for existing Ethernet-based networks.

100Mbps Fast Ethernet is a standard specied by the IEEE 802.3 LAN committee. It is an extension of the 10Mbps

Ethernet standard with the ability to transmit and receive data at 100Mbps, while maintaining the CSMA/CD Ethernet

protocol. Since the 100Mbps Fast Ethernet is compatible with all other 10Mbps Ethernet environments, it provides

a straightforward upgrade and takes advantage of the existing investment in hardware, software, and personnel

training.

9D-Link DGS-2208 User Manual

Section 2 - Product Overview

Gigabit Ethernet Technology

Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support

for CSMA/CD protocol, full duplex, ow control, and management objects, but with a tenfold increase in theoretical

throughput over 100Mbps Fast Ethernet and a one hundred-fold increase over 10Mbps Ethernet. Since it is compatible

with all 10Mbps and 100Mbps Ethernet environments, Gigabit Ethernet provides a straightforward upgrade without

wasting a company’s existing investment in hardware, software, and trained personnel.

The increased speed and extra bandwidth offered by Gigabit Ethernet are essential to coping with the network bottlenecks

that frequently develop as computers and their busses get faster and more users use applications that generate more

trafc. Upgrading key components, such as your backbone and servers to Gigabit Ethernet can greatly improve network

response times as well as signicantly speed up the trafc between your subnetworks.

Gigabit Ethernet enables fast optical ber connections to support video conferencing, complex imaging, and similar

data-intensive applications. Likewise, since data transfers occur 10 times faster than Fast Ethernet, servers outtted

with Gigabit Ethernet NIC’s are able to perform 10 times the number of operations in the same amount of time.

In addition, the phenomenal bandwidth delivered by Gigabit Ethernet is the most cost-effective method to take advantage

of today and tomorrow’s rapidly improving switching and routing internetworking technologies.

Switching Technology

Switching is a cost-effective way of increasing the total network capacity available to users on a LAN. If an Ethernet

network begins to display symptoms of congestion, low throughput, slow response times, and high rates of collision,

installing a switch to a network can preserve much or all of the existing network’s cabling and workstation interface card

infrastructure, while still greatly enhancing the throughput for users. A switch is a viable solution even if demanding

applications, such as multimedia production and video conferencing, are on the horizon. The most promising techniques,

as well as the best return on investment, could well consist of installing the right mixture of Ethernet switches.

A switch increases capacity and decreases network loading by dividing a local area network into different LAN

segments. Dividing a LAN into multiple segments is one of the most common ways of increasing available bandwidth.

If segmented correctly, most network trafc will remain within a single segment, enjoying the full-line speed bandwidth

of that segment.

10D-Link DGS-2208 User Manual

Section 2 - Product Overview

Switches provide full-line speed and dedicated bandwidth for all connections. This is in contrast to hubs, which use

the traditional shared networking topology, where the connected nodes contend for the same network bandwidth.

When two switching nodes are communicating, they are connected with a dedicated channel between them, so there

is no contention for network bandwidth with other nodes. As a result, the switch reduces considerably, the likelihood

of trafc congestion.

For Ethernet networks, a switch is an effective way of eliminating the problem of chaining hubs beyond the “two-repeater

limit.” A switch can be used to split parts of the network into different collision domains, making it possible to expand

your Ethernet network beyond the 205-meter network diameter limit for 100BASE-TX networks. Switches supporting

both 10Mbps Ethernet and 100Mbps Fast Ethernet are also ideal for bridging between existing 10Mbps networks and

newer 100Mbps networks.

Switching LAN technology is a marked improvement over the previous generation of network hubs and bridges, which

were characterized by higher latencies. Routers have also been used to segment local area networks, but the cost of

a router, the setup and maintenance required, make routers relatively impractical. Today switches are an ideal solution

to most kinds of local area network congestion problems.

802.1p Priority Tagging

802.1p places a tag in a frame to indicate the priority of the frame. A tag will represent a priority of 0-7 and an 802.1p

compliant switch can read this tag and prioritize trafc accordingly. In 802.1p a port can receive frames with varying

priority tags and classify them based on these tags. A VoIP phone that supports 802.1p can assign a priority to its

VoIP trafc and when it enters the switch the switch can give it a higher priority so that voice trafc is always clear and

jitter free. The DGS-2208 supports the 802.1p feature with 4 precongured priority queues. When a frame tagged with

an 802.1p priority bit is received by the switch it places the frame into one of 4 queues prioritized according to its tag

number. For example, trafc tagged with a priority bit of 7 will have a higher priority then trafc tagged with a priority

bit of 6 and so forth.

Jumbo Frame Support

The DGS-2208 switch supports Jumbo Frames up to (9720 Bytes) in size. Jumbo Frame support is designed to improve

network throughput and signicantly reduce the CPU utilization of large le transfers such as multimedia les or large

data les by enabling more efcient larger payloads per packet.

Otros manuales para DGS-2208 - Desktop Switch

Tabla de contenidos

Otros manuales de Enrutador de red de D-Link

D-Link

D-Link xStack DES-3200 Series Manual de usuario

D-Link

D-Link DSL-G604T Manual de usuario

D-Link

D-Link Air Premier DAP-2695 Manual de usuario

D-Link

D-Link Express EtherNetwork DI-604 Manual de usuario

D-Link

D-Link DIR-457U Manual de usuario

D-Link

D-Link VoIP Wireless Router DVG-G5402SP Manual de usuario

D-Link

D-Link DI-824VUP+ 2.4GHz Wireless VPN Router and Print... Manual de usuario

D-Link

D-Link DWP-1010KT Manual de usuario

D-Link

D-Link DSL-200 Manual de usuario

D-Link

D-Link DES-1005D Manual de usuario

D-Link

D-Link myPocket DIR-457 Manual de usuario

D-Link

D-Link DIR-810L Manual de instalación y operación

D-Link

D-Link DSL-504T Manual de usuario

D-Link

D-Link DIR-822K Manual de usuario

D-Link

D-Link DIR-600 Manual de usuario

D-Link

D-Link DSL-2790U Manual de usuario

D-Link

D-Link DSL-2751 Manual de usuario

D-Link

D-Link DIR-625 Router Manual de usuario

D-Link

D-Link DIR-821 Manual de usuario

D-Link

D-Link DWR-922 Manual de usuario

D-Link

D-Link DSL-2640U Manual de usuario

D-Link

D-Link DGS-1008P Manual de usuario

D-Link

D-Link PowerLine DHP-P601AV Manual de usuario

D-Link

D-Link DSL-2640BT Manual de usuario

Manuales populares de Enrutador de red de otras marcas

Allnet

Allnet ALL0333AU Manual de usuario

HomeSeer

HomeSeer HT-SEL Manual de usuario

Sercomm

Sercomm Genesis OC3505D Manual de usuario

Billion

Billion BIPAC 5102 Series Manual de usuario

TP-Link

TP-Link TD-8817 Manual de usuario

Motorola

Motorola MR1900 Manual de usuario

Digi

Digi IX14 Manual de usuario

Cisco

Cisco NCS 540 Manual

XAVi

XAVi X8821e Manual de usuario

BEC

BEC 6200WZL Manual de usuario

MikroTik

MikroTik hAP ac3 Series Manual de usuario

Korenix

Korenix JetNet 5428G Series Manual de usuario

NETGEAR

NETGEAR FS526T - Switch Manual de usuario

Korenix

Korenix JetNet 5710G Series Manual de usuario

Automated Logic

Automated Logic ZN551 Manual del propietario

Cisco

Cisco ASR 1000 Series Manual del operador

EnGenius

EnGenius ESR-9710 Manual de usuario

Cisco

Cisco 805 Series Instrucciones de funcionamiento y seguridad
