D-Link DWA-110 Manual de usuario

Manual

Building Networks for People

802.11g (2.4GHz)

Wireless USB 2.0 Adapter

DWA-110

D-Link Wireless G

01

After you have completed the installation of the DWA-110 into your

Macintosh computer (please refer to the Quick Installation Guide included

with the product), follow the steps below to access the configuration settings.

From the Apple pull-down menu select System Preferences.

How to configure DWA-110 in

Macintosh OS

Double-click on the DWA-110 icon.

D-Link DWA-110 MAC OSX drivers supports OS 10.3.x & 10.4.x

2

Using the Configuration Utility with Macintosh OS

(continued)

This window will ap-

pear displaying the

Network Name,

BSSID; Link State;

Network Type ;

Channel and

Signal Strengh.

SSID;BSSID;Signal ;

Channel;

Authentication;

Encryption

Advanced：Wireless Mode;11 B/G Protection ; TX Rate

Info: Configuration Utility Version; MAC Address; Driver Version;

EEPROM Version

following:

Current Wireless

Network settings:

Available Wireless

Networks including:

Start Scan:

Click Start Scan to

rescan for an avail-

able wireless net-

work at your current

location.

Connect: Highlight a network profile and click Connect to connect

to that net-work profile.

Wireless Adaptor Settings:

Click Open Profile Drawer to manage your network profiles.

3

Using the Configuration Utility with Macintosh OS

(continued)

My Networks

ADD: Click ADD to creat a new network profile manually.

EDIT: Highlight a network profile and click EDIT to configure that network

profile .

DELETE: Highlight a network profile and click DELETE to remove that network

from the profile list.

ACTIVATE: Highlight a network profile and click ACTIVATE to connect to

that network profile.

4

Using the Configuration Utility with Macintosh OS

(continued)

Connect Order >

ADD or EDIT

Select the Authentication Type. In the

example, WPA-PSK was chosen.

Select the Encryption Type. In the

example, TKIP was chosen.

Enter WPA Pre-Shared Key. In this

case 8 digits of 1 have been entered.
