D-Link DUB-E100 Manual de usuario

Softwareandspecificationssubjecttochangewithoutnotice.DUB-E100.006152004

If any of the above items are missing, please contact your reseller.

CD-ROM (Software, Manual and Warranty)

Before You Begin:

DUB-E100 USB 2.0 Fast Ethernet Adapter

Check Your Package Contents

USB 2.0 Fast

Ethernet Adapter

This product can be used with:This product can be used with:

This product can be used with:

WinWin

Windd

dows XPows XP

ows XPows XP

ows XP, Win, Win

, Win, Win

, Windd

dows 2000,ows 2000,

ows 2000,ows 2000,

ows 2000,

WinWin

Windd

dows Mows M

ows Mows M

ows Mee

e, an, an

, an, an

, and Wind Win

d Wind Win

d Windd

dows 98SEows 98SE

ows 98SEows 98SE

ows 98SE

Youwillneedthefollowing:

•WindowsXP,2000,Me,or98SE,200MHzorabovebasedcomputerwith

aminimumof32MB RAM,aCD-ROMdrive, andanavailableUSB port.

DUB-E100

Connecting the DUB-E100 to Your

Computer

PlugtheDUB-E100’sUSBcableinto

an available USB port on your

computer.

Windows will detect new hardware

andpromptyouforthedrivers.Follow

the steps below and then proceed

to the Driver Installation section on

thefollowing pages.

Attach an Ethernet cable to the

Ethernetportonthe DUB-E100.

Attachthe other endofthe Ethernet

cable to your network switch, hub,

orrouter.

Theinstallationprocess varies slightlyforeachWindows operating system.Proceedto

the appropriate installation section for your Windows operating system.

Installing the Drivers

Select Search for the best driver

in these locations.

Click Include this location in the

search:andtype D:\Drivers\WINXP

(where D: represents your CD-ROM

driveletter).

Select Install from a list or

specific location (Advanced)

Click Next

Click Finish

Windows XP driver installation is complete. Please proceed to page 10.

Windows XP

Installing the Drivers (continued)

Select Search for a suitable driver

for my device (recommended)

Click Next

Select CD-ROM drives

Windows 2000

Installing the Drivers (continued)

Click Next

Click Finish

Windows 2000 driver installation is complete. Please proceed to page 10.

Installing the Drivers (continued)

Select Specify a location: and type

D:\Drivers\Win98ME (where D:

representsyourCD-ROMdriveletter).

Click Next

Select Search for the best driver

for your device (Recommended)

Select Specify the location of

the driver (Advanced)

Click Next

Windows Me

Click Finish

If prompted, restart your computer to complete the installation.

Windows Me driver installation is complete. Please proceed to page 10.

Installing the Drivers (continued)

Select Search for the best driver

foryour device(Recommended)

Click Next

Select Specify a location: and type

D:\Drivers\Win98ME (where D:

representsyourCD-ROMdriveletter).

Click Next

Windows 98SE

Click Next

Click Finish

Installing the Drivers (continued)

If prompted, restart your computer to complete the installation.

Windows 98 driver installation is complete.

Windowsbeginscopyingthenecessary

files onto your computer. You may be

promptedtoprovidetheoriginalWindows

98SECD-ROM.Ifso,inserttheCD-ROM

and click OK. If necessary, provide the

pathtothe CD-ROM, suchasD:\WIN98

(whereD: isyour CD-ROM driveletter).

Installation is Complete!

InstallationoftheDUB-E100iscomplete.TheLINKLEDshouldbesolidgreen, indicating

a good physical connection between the DUB-E100 and the network. The TX/RX LED

indicateswhendataisbeingtransmittedorreceived.IfbothLEDsareunlit,theremaybe

aproblem withthephysical connection.Checkthe cablesbetweenyour DUB-E100,the

computer,andthenetwork.Verifythatyournetworkswitch,hub,orrouterispoweredon.

LINK LED:

Lightsupsolidgreen when the

DUB-E100hasagoodphysical

connection to the network.

TX/RX LED:

Flashes green when data is

transmitted/receivedat 100Mbps.

Whendatais transmitted/received

at10MbpstheLEDflashesamber.
