MB95560H/570H/580H Series

8-bit Microcontroller

8FX Family Starter Kit MB2146-510-01-E

Setup Guide

Doc. # 002-05587 Rev. *A

Copyrights

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 2

Copyrights

and its subsidiaries, including Spansion LLC ("Cypress"). This document, including any software or firmware included or refer-

enced in this document ("Software"), is owned by Cypress under the intellectual property laws and treaties of the United

States and other countries worldwide. Cypress reserves all rights under such laws and treaties and does not, except as spe-

cifically stated in this paragraph, grant any license under its patents, copyrights, trademarks, or other intellectual property

rights. If the Software is not accompanied by a license agreement and you do not otherwise have a written agreement with

Cypress governing the use of the Software, then Cypress hereby grants you a personal, non-exclusive, nontransferable

license (without the right to sublicense) (1) under its copyright rights in the Software (a) for Software provided in source code

form, to modify and reproduce the Software solely for use with Cypress hardware products, only internally within your organi-

zation, and (b) to distribute the Software in binary code form externally to end users (either directly or indirectly through resell-

ers and distributors), solely for use on Cypress hardware product units, and (2) under those claims of Cypress's patents that

are infringed by the Software (as provided by Cypress, unmodified) to make, use, distribute, and import the Software solely

for use with Cypress hardware products. Any other use, reproduction, modification, translation, or compilation of the Software

is prohibited.

TO THE EXTENT PERMITTED BY APPLICABLE LAW, CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR

IMPLIED, WITH REGARD TO THIS DOCUMENT OR ANY SOFTWARE OR ACCOMPANYING HARDWARE, INCLUDING,

BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PUR-

POSE. To the extent permitted by applicable law, Cypress reserves the right to make changes to this document without fur-

ther notice. Cypress does not assume any liability arising out of the application or use of any product or circuit described in

this document. Any information provided in this document, including any sample design information or programming code, is

provided only for reference purposes. It is the responsibility of the user of this document to properly design, program, and test

the functionality and safety of any application made of this information and any resulting product. Cypress products are not

designed, intended, or authorized for use as critical components in systems designed or intended for the operation of weap-

ons, weapons systems, nuclear installations, life-support devices or systems, other medical devices or systems (including

resuscitation equipment and surgical implants), pollution control or hazardous substances management, or other uses where

the failure of the device or system could cause personal injury, death, or property damage ("Unintended Uses"). A critical

component is any component of a device or system whose failure to perform can be reasonably expected to cause the failure

of the device or system, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and you shall and

hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress

products. You shall indemnify and hold Cypress harmless from and against all claims, costs, damages, and other liabilities,

including claims for personal injury or death, arising from or related to any Unintended Uses of Cypress products.

Cypress, the Cypress logo, Spansion, the Spansion logo, and combinations thereof, PSoC, CapSense, EZ-USB, F-RAM, and

Traveo are trademarks or registered trademarks of Cypress in the United States and other countries. For a more complete list

of Cypress trademarks, visit cypress.com. Other names and brands may be claimed as property of their respective owners.

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 3

Contents

1. Product Overview 7

1.1 Objective and Deliverable............................................................................................7

1.2 System Block ...............................................................................................................7

1.3 Handling Precautions...................................................................................................8

1.4 Feature ........................................................................................................................8

1.5 Hardware Setup...........................................................................................................8

2. BGMA Manual 9

2.1 BGMA Overview ..........................................................................................................9

2.2 Function List ..............................................................................................................10

2.3 IDC10 Interface Description.......................................................................................10

2.4 BGM Adapter USB Configuration ..............................................................................10

2.5 LED description .........................................................................................................14

3. EV board Introduction 16

3.1 EV board Overview....................................................................................................16

3.2 Function List .............................................................................................................17

3.3 EV-board Schematic..................................................................................................18

3.4 HW Module Description and Jumper settings............................................................19

4. Sample Code Manual 25

4.1 Topic List ...................................................................................................................25

4.2 Project Structure ........................................................................................................25

4.3 Source Code File Description ....................................................................................26

5. Development Platform Quick Start 29

5.1 Tools Setup Sequence ..............................................................................................29

5.2 Open Project and Start Debug...................................................................................29

5.3 Operation Precautions ...............................................................................................29

6. Additional Informations 30

Revision History 31

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 4

Preface

Thank you for purchasing the New 8FX Family Starter Kit: MB2146-510-01-E*1.

This product is a starter kit for New 8FX MB95560H/570H/580H series, which comes with MB2146-

07-E (New 8FX Family All Series MCU BGM Adaptor)*2, MB2146-510-E (New 8FX Family

MB95560H/570H/580H Series Evaluation Board)*3, and F2MC8L/8FX Family SOFTUNE

Professional Pack Evaluation Version*4.

This manual explains how to use the Starter Kit. Be sure to read this manual before using the

product.

For mass production/evaluation MCUs for this product, consult with sales representatives or support

representatives.

*1Referred below as the “Starter Kit”.

*2Referred below as the “BGMA”.

*3Referred below as the “EV-Board”.

*4Referred below as the “SOFTUNE”.

SOFTUNE is a trademark of Cypress Semiconductor Limited, Japan.

■Handling and use

Handling and use of this product and notes regarding its safe use are described in the manuals for

products bundled with the Starter Kit.

Follow the instructions in the manuals to use this product.

Keep this manual at hand so that you can refer to it anytime during use of this product.

■European RoHS compliance

Products with a -E suffix on the part number are European RoHS compliant products.

■Notice on this document

All information included in this document is current as of the date it is issued. Such information is

subject to change without any prior notice.

Please confirm the latest relevant information with the sales representatives.

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 5

Preface

■Caution of the products described in this document

The following precautions apply to the product described in this manual.

WARNING

Indicates a potentially hazardous situation which could result in death or

serious injury and/or a fault in the user’s system if the product is not used

correctly.

Electric shock,

Damage

Before performing any operation described in this manual, turn off all the

power supplies to the system.

Performing such an operation with the power on may cause an electric

shock or device fault.

Electric shock,

Damage

Once the product has been turned on, do not touch any metal part of it.

Doing so may cause an electric shock or device fault.

CAUTION

Indicates the presence of a hazard that may cause a minor or moderate

injury, damages to this product or devices connected to it, or may cause

to loose software resources and other properties such as data, if the de-

vice is not used appropriately.

Cuts, Damage

Before moving the product, be sure to turn off all the power supplies and

unplug the cables. Watch your step when carrying the product. Do not

use the product in an unstable location such as a place exposed to strong

vibration or a sloping surface.

Doing so may cause the product to fall, resulting in an injury or fault.

Cuts

The product contains sharp edges that are left unavoidably exposed,

such as jumper plugs.

Handle the product with due care not to get injured with such pointed

parts.

Damage Do not place anything on the product or expose the product to physical

shocks. Do not carry the product after the power has been turned on.

Doing so may cause a malfunction due to overloading or shock.

Damage

Since the product contains many electronic components, keep it away

from direct sunlight, high temperature, and high humidity to prevent con-

densation. Do not use or store the product where it is exposed to much

dust or a strong magnetic or electric field for an extended period of time.

Inappropriate operating or storage environments may cause a fault.

Damage Use the product within the ranges given in the specifications.

Operation over the specified ranges may cause a fault.

Damage

To prevent electrostatic breakdown, do not let your finger or other object

come into contact with the metal parts of any of the connectors. Before

handling the product, touch a metal object (such as a door knob) to dis-

charge any static electricity from your body.

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 6

Preface

Damage

When turning the power on or off, follow the relevant procedure as de-

scribed in this document.

Before turning the power on, in particular, be sure to finish making all the

required connections. Furthermore, be sure to configure and use the

product by following the instructions given in this document.

Using the product incorrectly or inappropriately may cause a fault.

Damage

Always turn the power off before connecting or disconnecting any cables

from the product. When unplugging a cable, unplug the cable by holding

the connector part without pulling on the cable itself. Pulling the cable it-

self or bending it may expose or disconnect the cable core, resulting in a

fault.

Damage

Because the structure of the MCU socket does not allow an evaluation

MCU to be mounted in the incorrect orientation, be very careful of the ori-

entation of the evaluation MCU when mounting it.

Inserting the evaluation MCU in the wrong orientation may damage the

MCU, causing the MCU to become faulty.

Damage

Because the product has no casing, it is recommended that it be stored

in the original packaging. Transporting the product may cause a damage

or fault. Therefore, keep the packaging materials and use them when re-

shipping the product.

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 7

1. Product Overview

This product is a set of Starter Kit of MB95560H/570H/580H series. It is composed of a BGMA and

an EV-board. Combining the SOFTUNE Workbench on PC, the Starter kit enables the quick start of

development before the user system is ready.

1.1 Objective and Deliverable

The Starter kit provides users a complete development platform. Before start using the Starter Kit,

make sure that the following devices are placed in the package:

■BGMA : 1

■EV-board : 1

■USB cable: 1

■CD-ROM (SOFTUNE user manuals, sample code): 1

■Hardcopy (China RoHS report, quick start guide) : 1

1.2 System Block

To setup a debugging system, connect a PC, a BGMA and an EV-board together as shown below:

Figure 1-1. BGMA overview

SOFTUNE

IDE

USB

MB95560H/570H/580H

MCU

Sample

code

Easy design and study MB95560/

570H/580H MCU with BGMA and

SOFTUNE

Target Board

BGMA

Host PC

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 8

Product Overview

1.3 Handling Precautions

The Starter Kit can be used in connection with its bundled products. To ensure correct use of this

product in a proper environment, observe the following guideline:

Follow the instructions described in each manual for the bundled product to use this product.

1.4 Feature

The MB95560H/570H/580H Series starter kit is the best for a performance and functional evaluation,

and a check of operation before including MB95560H/570H/580H Series in a user's system.

Below, the feature of the BGM debugger for MB95560H/570H/580H Series is shown.

■Microcomputer operation voltage. It corresponds to +2.4V to +5.5V.

(The maximum and minimum of microcomputer operation voltage and frequency of operation dif-

fers with each MCU. refer to the documents (a data sheet, hardware manual, etc.) of each device

relation for the operation voltage and frequency of MCU of operation.)

■Compact development environment, a light and small BGM Adaptor.

■Since a monitor program is performed in exclusive memory space, it does not consume user

memory space.

■Continuation execution, step execution and break correspondence.

■It connects with a host computer by the USB interface.

1.5 Hardware Setup

In the hardware setup procedure, you configure and connect the hardware products. This chapter

includes the configuring and connecting procedure for each product in order. Check the contents and

complete the hardware setup.

■Configuring EV-Board

■Connection of each product

❐Connecting BGMA and EV-board

❐Connecting EV-Board power supply

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 9

2 BGMA Manual

2.1 BGMA Overview

Below is the close look of the BGMA.

It provides a debug platform for the New 8FX MCU (except MB95200H/210H/220H) in a small size

(58mm (W) 90mm (D) 20mm (H)) .

Figure 2-1. BGMA overview

BGM Adaptor Power LED BGM Adaptor status LED

BGM Adaptor

BGM Adaptor: MB2146-07-E

MB95560H/570H/580H Series MB2146-510-01-E Setup Guide, Doc. # 002-05587 Rev. *A 10

BGMA Manual

2.2 Function List

*1The value varies depending on the operating frequency, the machine clock or the analog guaranteed range.

*2The value is 2.88 V when the low-voltage detection reset is used.

2.3 IDC10 Interface Description

2.4 BGM Adapter USB Configuration

The BGMA is provided with a USB cable. Connect the BGMA to a PC with a USB cable. If the con-

nection is right, the following window will pop up. Follow the instructions displayed, and then click

“Next”,

Function description Remarks

Support MB95560 Series MCU MCU MAX machine clock: 16.25 MHz

MCU power voltage: 2.4V*2to 5.5V*1

Break pointer 256 software breakpoints

3 hardware breakpoints

USB interface to PC/SOFTUNE Compatible to USB protocol version 2.0

1-Line UART interface to the MB95560

Series MCU

The Baud rate is 62,500 bps, and can be up to

500kbps (set in SOFTUNE)

Support the MCU flash programming for

engineering development

The MAX program and read speed can be arrived to

4000B/s | 5000B/s roughly.

Pin Number Pin Name Description

1 UVCC Target MCU Vcc

2 GND Target MCU Vss

3 RSTIN Target MCU reset input

4 RSTOUT Target MCU reset output

5RSV Reserved

6 POUT3V Supply 3V power out, when this function enabled

7RSV Reserved

8 DBG Target MCU debug pin

9RSV Reserved

10 RSV Reserved

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Cypress

Cypress

Cypress WirelessUSB CY3635 N:1 Manual de usuario

Cypress

Cypress EZ-USB NX2LP-Flex CY3686 Manual de usuario

Cypress

Cypress MB2146-301A-E Manual de usuario

Cypress

Cypress CY3641 Manual de usuario

Cypress

Cypress PSoC 4000 Series Manual de uso y cuidado

Cypress

Cypress CY8CKIT-042 Manual de usuario

Cypress

Cypress CapSense Plus CY3280-CPM1 Manual de usuario

Cypress

Cypress CY3650 Manual de usuario

Cypress

Cypress PERFORM MB96630 Series Manual de usuario

Cypress

Cypress Perform PSOC 5LP PROTOTYPING KIT Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

Cypress

Cypress CY8C28623-24LTXI Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

Cypress

Cypress FR81S CY91F52 Series Instrucciones de funcionamiento

Cypress

Cypress CY14NVSRAMKIT-001 Manual de usuario

Cypress

Cypress MB966B0 Series Manual de usuario

Cypress

Cypress PSoC CY8CKIT-062-WiFi-BT Manual de usuario

Cypress

Cypress CY3664-EXT Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

Cypress

Cypress MB95710M Series Manual de usuario

Cypress

Cypress CY8CKIT-147 Manual

Cypress

Cypress EZ-PD CY4502 Manual de usuario

Cypress

Cypress enCoRe III CY3664-EXT Manual de instrucciones

Cypress

Cypress EZ-PD CY4502 Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F800 Manual de usuario
