Cypress FM4 S6E2H Series Manual de usuario

FM4 S6E2H-Series

Starter Kit Guide

Doc. No. 002-11387 Rev. **

Cypress Semiconductor

198 Champion Court

San Jose, CA 95134-1709

Phone (USA): 800.858.1810

Phone (Intnl): +1 408.943.2600

www.cypress.com

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 2

subsidiaries, including Spansion LLC (“Cypress”). This document, including any software or firmware included or

referenced in this document (“Software”), is owned by Cypress under the intellectual property laws and treaties of the United

States and other countries worldwide. Cypress reserves all rights under such laws and treaties and does not, except as

specifically stated in this paragraph, grant any license under its patents, copyrights, trademarks, or other intellectual property

rights. If the Software is not accompanied by a license agreement and you do not otherwise have a written agreement with

Cypress governing the use of the Software, then Cypress hereby grants you under its copyright rights in the Software, a

personal, non-exclusive, nontransferable license (without the right to sublicense) (a) for Software provided in source code

form, to modify and reproduce the Software solely for use with Cypress hardware products, only internally within your

organization, and (b) to distribute the Software in binary code form externally to end users (either directly or indirectly through

resellers and distributors), solely for use on Cypress hardware product units. Cypress also grants you a personal, non-

exclusive, nontransferable, license (without the right to sublicense) under those claims of Cypress’s patents that are

infringed by the Software (as provided by Cypress, unmodified) to make, use, distribute, and import the Software solely to

the minimum extent that is necessary for you to exercise your rights under the copyright license granted in the previous

sentence. Any other use, reproduction, modification, translation, or compilation of the Software is prohibited.

CYPRESS MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARD TO THIS DOCUMENT OR

ANY SOFTWARE, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND

FITNESS FOR A PARTICULAR PURPOSE. Cypress reserves the right to make changes to this document without further

notice. Cypress does not assume any liability arising out of the application or use of any product or circuit described in this

document. Any information provided in this document, including any sample design information or programming code, is

provided only for reference purposes. It is the responsibility of the user of this document to properly design, program, and

test the functionality and safety of any application made of this information and any resulting product. Cypress products

are not designed, intended, or authorized for use as critical components in systems designed or intended for the operation

of weapons, weapons systems, nuclear installations, life-support devices or systems, other medical devices or systems

(including resuscitation equipment and surgical implants), pollution control or hazardous substances management, or other

uses where the failure of the device or system could cause personal injury, death, or property damage (“Unintended Uses”).

A critical component is any component of a device or system whose failure to perform can be reasonably expected to cause

the failure of the device or system, or to affect its safety or effectiveness. Cypress is not liable, in whole or in part, and

Company shall and hereby does release Cypress from any claim, damage, or other liability arising from or related to all

Unintended Uses of Cypress products. Company shall indemnify and hold Cypress harmless from and against all claims,

costs, damages, and other liabilities, including claims for personal injury or death, arising from or related to any Unintended

Uses of Cypress products.

Cypress, the Cypress logo, Spansion, the Spansion logo, and combinations thereof, PSoC, CapSense, EZ-USB, F-RAM,

and Traveo are trademarks or registered trademarks of Cypress in the United States and other countries. For a more

complete list of Cypress trademarks, visit cypress.com. Other names and brands may be claimed as property of their

respective owners.

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 3

Contents

1. Introduction.................................................................................................................................................................4

1.1 Kit Contents........................................................................................................................................................5

1.2 Board Details......................................................................................................................................................6

1.3 Jumper and Connector.......................................................................................................................................8

1.4 Getting Started ...................................................................................................................................................9

1.5 Additional Learning Resources...........................................................................................................................9

1.6 Technical Support...............................................................................................................................................9

1.7 Acronyms..........................................................................................................................................................10

2. Installation and Test Operation...............................................................................................................................11

2.1 Install Software.................................................................................................................................................11

2.2 Uninstall Software.............................................................................................................................................14

2.3 Test Operation..................................................................................................................................................15

3. Hardware...................................................................................................................................................................22

3.1 System Block Diagram.....................................................................................................................................22

3.2 Hardware Features...........................................................................................................................................22

3.3 Hardware Details..............................................................................................................................................23

4. Software Development.............................................................................................................................................28

4.1 Tool Options.....................................................................................................................................................28

4.2 Example Projects..............................................................................................................................................33

4.3 Flash Programming..........................................................................................................................................43

A. Appendix...................................................................................................................................................................49

A.1 Schematic.........................................................................................................................................................49

A.2 Bill of Materials.................................................................................................................................................56

Revision History................................................................................................................................................................59

Document Revision History ........................................................................................................................................59

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 4

1. Introduction

Thank you for your interest in the FM4-120L-S6E2HG FM4 S6E2H-Series Starter Kit. The FM4

S6E2H-Series Starter Kit enables customers to evaluate and develop projects using the FM4

device family. Flexible MCU4 (FM4) is a portfolio of high-performance ARM®Cortex®-M4 MCUs

that includes hardware support for digital signal processing and floating-point operations,

designed for safety-critical, industrial systems and home appliance applications. There are

multiple series of device families in this portfolio. The S6E2C-Series, S6E2H-Series and S6E2G-

Series are few of the prominent series of device families. This kit uses a device from the S6E2H-

Series.

Devices in the S6E2H-Series are highly integrated 32-bit microcontrollers with high performance

at a competitive cost. This series is based on the ARM® Cortex®-M4 processor, including

floating point instructions, with on-chip flash memory and SRAM. The series has peripherals

such as motor control timers, A/D converters, and communications interfaces like CAN, UART,

CSIO, I2C and LIN. The S6E2H-Series of FM4 devices offers up to a 160-MHz CPU, 512 Kbytes

Main Flash, 32 KbytesWork Flash, 64KB SRAM, 100 GPIOs, 24 digital peripherals and 2 analog

peripherals.

The FM4 S6E2H-Series Starter Kit routes all pins out, which provides limitless options for

application development. It is intended to aid the customer to evaluate the featured peripherals

of the S6E2H-Series. In order to properly enable our customers, the FM4 S6E2H-Series Starter

Kit is aligned to our low cost development systems, aligning this kit with our successful line of

Starter Kits in form, price and flexibility.

Introduction

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 5

1.1 Kit Contents

The FM4 S6E2H-Series Starter Kit contains the following, as shown in Figure 1-1.

FM4 S6E2H-Series Starter board

USB Standard-A to Micro-B cable

Quick Start Guide

Figure 1-1: Kit Contents

Inspect the contents of the kit; if you find any part missing, contact your nearest Cypress sales

office for help: www.cypress.com/support.

Introduction

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 6

1.2 Board Details

Figure 1-2: FM4 S6E2H-Series Starter Kit Markup

Introduction

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 7

1. Cypress FM4 MCU S6E2HG6A0J

2. Non-Maskable Interrupt pin (NMIX) switch (SW3)

3. User button (SW2)

4. Reset LED

5. Reset button

6. MB9AF312K Programmer and Debugger (CMSIS-DAP)

7. 20-pin JTAG interface (CN2)

8. VBUS selection jumper for CMSIS-DAP (J2)

9. Programmer and debugger enable jumper (J3)

10. Programming mode jumper of MB9AF312K (J5)

11. Jumper to connect SW3 to NMIX (J10)

12. On-board voltage select (J15)

13. Select power from CMSIS-DAP (J7)

14. Select power from peripheral (J6)

15. Power supply LED

16. RGB LED

17. Potentiometer (R11)

18. Jumper for Pin56 multifunction select (J21)

19. Jumper to connect S6E2HG SIN0 to CMSIS-DAP (J19)

20. Programming mode (MD0) jumper of S6E2HG (J18)

21. Battery connector (CN1)

22. Jumper to connect S6E2HG SOT0 to CMSIS-DAP (J20)

Introduction

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 8

1.3 Jumper and Connector

Table 1-1: Connector Description

Connector

Description

CN1

Battery connector

CN2

20-pin JTAG interface

CN3

USB port of CMSIS-DAP

CN5

SD card interface

Table 1-2: Jumper Description

Jumper

Function

Setting

VBUS detection of CMSIS-DAP

Used for VBUS detection function (pin

60) of MB9AF312K on board

Open: For on-board voltage is 3.3V

Closed: For on-board voltage is 5.0V

Programmer and Debugger select

Open: Enable CMSIS-DAP unit

Closed: Disable CMSIS-DAP unit

Pull down the MD0 of MB9AF312K

Open: Run mode

Closed: Serial programming mode

J6, J7,

Power supply source select

Select only one power source!

Closed J6: Powered by peripheral at J16

Closed J7: Powered by CN3 (USB port of CMSIS-DAP)

Closed J8: Powered by CN2 (20-pin JTAG interface)

J10

SW3 connect

Open: SW3 is disconnected from the S6E2HG

Closed: SW3 is connected to the S6E2HG

J15

On-board voltage select

Pin1 to Pin2: Sets MCU voltage at 3.3V

Pin 2 to Pin3: Sets MCU voltage at 5V

J18

Pull down the MD0 of S6E2HG

Open: Run mode

Closed: Serial programming mode

J19

CMSIS-DAP virtual COM connect

Open: SIN0_0 is disconnected from CMSIS-DAP

Closed: SIN0_0 is connected with CMSIS-DAP

J20

CMSIS-DAP virtual COM connect

Pin1 to Pin2: SOT0_0 is connected with CMSIS-DAP

Pin2 to Pin3: Pull down the P22 of MB9AF312K

J21

MD1/PE0 function select

Pin1 to Pin2: Pull down MD1 (Programming-Mode)

Pin2 to Pin3: PE0 drives the blue LED

Introduction

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 9

1.4 Getting Started

This guide will help you get started with the FM4 S6E2H-Series Starter Kit:

The Installation and Test Operation chapter describes the kit installation and test

operation. This includes the CMSIS-DAP driver to enable the CMSIS-DAP debugger,

Serial Port Viewer Tool to view the serial port communication, Flash MCU programmer

and Flash USB Direct programmer to program the hex files on the device.

The Hardware chapter describes the major features of the FM4 S6E2H-Series Starter

Kit and functionalities such as CMSIS-DAP debugger, RGB LED, and buttons.

The Software Development chapter describes the available software resources and

tools, and how to create a project based on the Peripheral Driver Library (PDL).

The Appendix provides the kit schematics, and the bill of materials (BOM).

1.5 Additional Learning Resources

Cypress provides a wealth of data at www.cypress.com to help you to select the right MCU

device for your design, and quickly and effectively integrate the device into your design. The

following is an abbreviated list for FM4 family resources:

Overview: S6E2H-Series fact sheet

Device Selector : Microcontroller Select Guide

Datasheets: S6E2H-Series datasheet and Handling precautions.

FM4 Peripheral Manual: Main Section, Communication Macro Section, Analog Macro

Section, Timer Section.

The documents listed above can be accessed from the kit’s webpage at

www.cypress.com/FM4-120L-S6E2HG.

1.6 Technical Support

For assistance, visit Cypress Support or contact customer support at +1(800) 541-4736 Ext. 2

(in the USA) or +1(408) 943-2600 Ext. 2 (International).

Introduction

FM4 S6E2H-Series Starter Kit Guide, Doc. No. 002-11387 Rev. ** 10

1.7 Acronyms

Table 1-3. Acronyms Used in this Document

Acronym

Description

ADC

Analog-to-Digital Converter

CMSIS-DAP

Debug Access Port

GPIO

General Purpose Input/Output

I2C

Inter-Integrated Circuit

IDE

Integrated Development Environment

LDO

Low Drop Out (voltage regulator)

LED

Light-Emitting Diode

INT

Interuppt

RGB

Red Green Blue

JTAG

Joint Test Action Group

MFS

Multi Function Serial

PDL

Peripheral Driver Library

SWD

Serial Wire Debug

UART

Universal Asynchronous Receiver Transmitter

USB

Universal Serial Bus

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Cypress

Cypress

Cypress CY8CKIT-001 Manual de usuario

Cypress

Cypress EZ-USB NX2LP-Flex CY3686 Manual de usuario

Cypress

Cypress CY3280-BSM Manual de usuario

Cypress

Cypress PSoC Manual de usuario

Cypress

Cypress PSoC 4 CY8CKIT-049-4 Series Manual de usuario

Cypress

Cypress PERFORM MB96630 Series Manual de usuario

Cypress

Cypress Traveo II Manual de usuario

Cypress

Cypress PSoC 5 FIRSTTOUCH CY8CKIT-014 Manual de usuario

Cypress

Cypress MB96640 Series Manual de usuario

Cypress

Cypress CY15FRAMKIT-002 Manual de usuario

Cypress

Cypress CY8CKIT-042-BLE-A Manual de usuario

Cypress

Cypress MB9BF564K Manual de usuario

Cypress

Cypress CY8CKIT-042-BLE-A Manual de usuario

Cypress

Cypress F2MC-8L Series Manual de usuario

Cypress

Cypress CY3668 Manual de usuario

Cypress

Cypress MB96300 Series Manual de usuario

Cypress

Cypress FR MB91460 Series Manual del propietario

Cypress

Cypress CY3250-PLC20QFN Manual de usuario

Cypress

Cypress CY8CKIT-030 Manual de usuario

Cypress

Cypress CY3641 Manual de usuario

Cypress

Cypress S6J3200 Series Manual de usuario

Cypress

Cypress S6J3200 Series Manual de instrucciones

Cypress

Cypress FM4-U120-9B560 Manual de usuario

Cypress

Cypress PSoC CY8CKIT-048 Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F800 Manual de usuario
