Yamaha Stryker TruWrapz® Installation Instructions.

1) Using a suitable motorcycle frame jack support the motorcycle until the front wheel is

just barley touching the ground and all weight has been removed from it by following

jack manufacturers instructions for proper jack usage.

2) Once properly supported remove the headlight by removing the screws on each side of

the head light bucket

3) Following the instructions contained within the TrueWrapz package, install the

TruWrapz® onto each fork tube and route their wires inside the headlight bucket.

4) Once installed and the wires are routed, locate the connector for the right side turn signal

and use the supplied Posi-Tap connector to tap into the right side turn signal wire. This

wire should be a GREEN WIRE WITH YELLOW DOTS ON IT. If there is any

confusion use a test light to confirm which wire is the turn signal wire. (see pic #23)

5) Next repeat this procedure for the left side turn signal wire which should be a BROWN

WIRE WITH YELLOW DOTS on it.

6) Next using ether turn signal connector harness attaches a Posi-Tap connector onto the

blue wire and a Posi-Tap onto the black wire.

7) Using one of the 2 supplied Eclipze™units, take the orange wire from the 3 wire end of

the Eclipze unit and hook it into the Posi-Tap connector going to the right side turn signal

wire.(green wire with yellow dots) (see pic #23)

8) Next take the same orange wire from the remaining Eclipze™and hook it into the Posi-

Tap connector going to the left side Turn signal wire (brown with yellow dots)

9) Take the two red wires from the 3 wire end of both the Eclipze™units and twist them

together then attach them to the Posi-Tap connector going to the running light circuit

which is the BLUE wire. (see pic# 24)

10)Then take the two black wires coming from the 3 wire end of the 2 Eclipze™units twist

them together and attach them to the Posi-Tap connector going to the black wire. (see pic

# 25)

11)Next, take the two wires coming from the TruWrapz® on the left side and hook them

onto the two output wires coming from the Eclipze™unit hooked to the left side turn

signal connector as follows. Yellow wire from TruWrapz® to the red output wire from

Notice: This product is designed and intended for use as auxiliary lighting on motorcycles only. This

product is NOT intended to replace any original equipment lighting installed on the motorcycle and

should not be used for that purpose. This product must be wired such that it does not interfere with any

original equipment lighting.

Eclipze™unit. The black wire from the TrueWrapz to the black wire from the output

side of the Eclipze™unit. Repeat this procedure for the right side wires as needed. (see

pic # 26)

12)Turn on the bike and check the operation of both the running light function and turn

signal function. (see pics #37 & #38)

13)Reinstall headlight into bucket once proper operation is observed.

Picture #23

Picture #24 Picture #25

Picture #26 Picture #37

Picture #38
