- 1 -

MPK4050

Portable MP3 Player

User's Guide

- 2 -

1. Introduction - 3 -

2. Install the MP3 Player - 4 -

3. MP3 Player Controls - 4 -

4. Screen Display - 5 -

5. Transfer data to and from the MP3 Player - 5 -

6. Turn on/off the player - 5 -

7. Listen to WMA/MP3 music with the MP3 Player - 6 -

8. Begin to play your music - 7 -

9. Video - 8 -

10. Voice Recorder - 10 -

11. Hold Function - 11 -

12. Photo - 12 -

13. E-Book - 12 -

14. Advanced Settings - 13 -

15. About - 14 -

17. Remove the MP3 Player from your computer - 14 -

18. Trouble Shooting - 15 -

19. MP3 Player Specifications - 17 -

20. Safety - 18 -

- 3 -

1. Introduction

This device incorporates a portable WMA/MP3 Player, Video player, Photo Viewer,

E-Book Viewer, Voice Recorder and USB Mass Storage Device. It will bring you

pleasure and enjoyment in this digital era.

MP3 Player Features:

¾WMA/MP3 player.

¾WMA DRM9

¾Video player

¾Photo viewer

¾Synchronous lyric display with WMA/MP3 music.

¾Voice recorder.

¾E-Book Viewer.

¾USB mass storage device.

¾Integrated USB connector.

¾Backlit display.

¾Superb audio quality.

System support:

•Supports Windows Me/2000/XP.

•To Windows 2000 users, Windows Service Pack 3 must be installed.

•Supports Windows 98 SE after installation of drivers (please consult the latter

part of this instruction).

•Supports Mac OS X (version 10.2.6 or above) without driver.

Battery management

•Battery: Built-in 520mAh Rechargeable Li-ion battery.

•Charge: Connect the MP3 Player to the computer. A few seconds later, a

battery icon blinks on the top of the MP3 Player's screen, indicating the battery

is being charged. If the battery is not charged automatically, please press Play

button briefly. It stays fully to indicate the battery is fully charged. It must be

charged for 4 hours for the first time. And the subsequent charge will take

about 2 to 3 hours.

Note:

9To minimize damage from static electricity, do not operate the player in an

extremely dry environment. The product may get malfunction and requires to be

reset.

- 4 -

2. Install the MP3 Player

zWindows Me/2000/XP users need to install the MP3 player driver if they want to

upgrade the firmware.

zWindows 98 SE users need to install the MP3 Player on their system for

connection:

1. Insert the CD attached in the package to the CD-ROM.

2. Open the folder "Driver" bundled on the CD which contains the MP3 Player

installation program.

3. Click on the Setup icon to begin the installation.

4. Follow the Wizard to complete the installation.

3. MP3 Player Controls

A. Power On /Play / Pause / Enter button

B. Power Off / Stop button

C. Skip Previous / Fast Rewind button

D. Skip Next / Fast forward button

E. Reset Hole

F. USB Port

G. Microphone

H. Menu button / A-B button

I. Volume up button

J. Volume down button

K. Hold Switch

L. Earphone jack

Note:

9Please recharge the battery when the screen displays:

9Please fully charge the battery every two or three months when the player is

not used for a long time. Otherwise, the battery voltage may be too low to

support the player’s power on. It takes about four hours for fully charge.

Note for Windows 2000 users:

9Windows Service Pack 3 must be installed.

- 5 -

4. Screen Display

1. Play / Pause / Stop

2. Equalizer

3. ID3 Tag

4. Volume level

5. Process bar

6. Elapsed Time/ Track Time

7. Locked

8. A-B repeat / Play mode

9. Battery Indicator

10. Current track number / Total

track number

11. Music information

5. Transfer data to and from the MP3 Player

1) Make sure that the MP3 Player is off.

2) Remove the USB port cover of the player. Disconnect

the earphone.

3) Connect the MP3 Player to your computer through USB

cable. The screen will display "USB Connected",

indicating that the player is in USB mode. The player is

automatically recognized (in 'My Computer')

as removable media devices afterward.

4) Then the MP3 Player can be used as an external disk for

you to transfer files.

5) After removing the MP3 Player from your computer, WMA/MP3 files can be

listened to and all data within the unit can be transferred to another computer.

6. Turn on/off the player

zTo turn on the player, press the Power On button once.

zTo turn off the player, press and hold the Power Off button until the screen motion

disappears.

Note:

9Other types of data such as Word, Excel, PowerPoint, JPEG, etc. can be stored and

transferred by this unit.

9When transfer data to the player, please pay attention that two to three Megabytes

must be reserved for system files. Otherwise, the player may not be properly turned

on.

- 6 -

7. Listen to WMA/MP3 music with the MP3 Player

1) Copy WMA/MP3 music files to the MP3 Player (please take the reference of

"Transferring data to and from the MP3 Player").

2) Connect with supplied headphones.

3) Press the Power On button to turn on the player.

4) Press the Play button to play the music.

5) Use the MP3 Player controls to play back and adjust volume level to listen to

the WMA/MP3 music.

7.1 A-B Repeat function

•If you want to listen to one section of the music

repeatedly, you can use A-B repeat function.

•In playing mode, press and hold the A-B button to

set the starting point (point A) of the music and

press and hold the A-B button again to set the

ending point (point B). The A-B section will be

played repeatedly on the player.

•Press and hold A-B button again to cancel the

repeat.

7.2 Lyric display function

The MP3 Player supports lyric files in LRC format.

1) Prepare the MP3 or WMA music as you like, for example, happymusic.mp3;

2) Download a lyric file from internet. The lyric file must have an extension file

name LRC. For example, happymusic-2004.lrc.

3) Rename the lyric file. For example, happymusic.lrc. It is to make sure the

lyric filename is the same as the corresponding music filename.

4) Copy the lyric file & music file to the MP3 player.

5) Disconnect the MP3 player from your computer.

6) Use Skip buttons to select the music file which has the related lyric files, for

example, happymusic.mp3. Press Play button to play.

7) Then the music is played and lyric is displayed synchronously on screen.

Note:

9The interval between

oint A and

oint B must be more than 3 seconds.

- 7 -

8. Begin to play your music

In the main menu, select Music and press Play button to enter

the submenu, you can use Skip buttons to select one option and

press Play button to confirm your selection or enter the

submenu. Use Menu button to back to previous menu.

•Music

Select Music and press Play button to play the music.

•Browse

You can find and play the music as you want quickly by using

browse function. Only music files in MP3 or WMA format can

be recognized and played in Browse mode.

1) Select Browse and press Play button to enter the

browse menu.

2) Press Skip buttons to select a file or folder and press

Play button to play the music or enter the folder.

3) Select the Back option in Browse Menu or press Menu

button to backward to upper level.

Note:

9The MP3 player supports LRC format only.

9If the lyric does not synchronize with the music, please download one better

lyric file from internet and try again.

9Make sure the MP3 music files and LRC file are located in the same folder

and their filenames are the same. Otherwise, the MP3 player can not

recognize the lyric file.

Note:

9When a folder is selected in browse mode, press Menu button, and a sub-menu

window will pop up. To enter the folder, select Enter. To play music located in

the folder, select Play. Press Play button to confirm your selection.

9When a file is selected in Browse mode, press Menu button, a sub-menu

window will pop up. To play this file, select Play. To erase, select Delete.

Press Play button to confirm your selection.

- 8 -

•Repeat settings

The available repeat modes are:

oNormal

oRepeat One

oRepeat All

oRandom

oRandom All

1) Select Repeat and press Play button to enter.

2) Select one option and press Play button to confirm.

•Equalizer settings

The equalizer settings is to adjust the music playback

effect .Six equalizer presets are available: Normal , XBass ,

Rock , Jazz , Classical , Pop.

1) Select Equalizer and press Play button to enter.

2) Select one option and press Play button to confirm.

9. Video

You can play Video files with this player after converting AVI, WMV, MPG video

files to SMV video files by the software within the product CD.

How to convert files:

1) Insert the CD into CD-ROM.

2) Click “Transcoder “button on the CD autorun screen to open transcoder.

(Note: You can copy the folder "transcoder" bundle on the CD to your computer, and

run "video2smv.exe" under it to open the transcoder.)

3) Set up the value of the video quality. To acquire high quality of motion, you

are recommended to configure the settings as follows:

Note:

9Only SMV files can be played by this MP3 player.

9Make sure Microsoft DirectX 9.0 or above version have been installed on your

computer. Otherwise, an error message will appear while converting, or the

converted files may be not played correctly on your player.

9SMV files must be put into the MVIDEO folder of the player.

9Do not put songs and other data into MVIDEO folder.

- 9 -

4) Select the source video file and specify the name and location of the output

file.

5) Click Convert.

6) The converting will be finished when the Input Video window shows “Job

Completed ".

7) After converting, copy the SMV file to the MVIDEO folder of the player.

8) Turn on your player and press Menu button to enter into the main menu.

9) Select Video and press Play button to enter the list of video files.

10) UseSkip buttons to select a file.

11) Press Play button to play the video.

12) Press Menu button to back to the Video menu.

Note:

9When a file is selected in Video menu, press Menu button, and a sub-menu window

will pop up. To play this file, select Play. To erase, select Delete. Press Play

button to confirm your selection.

- 10 -

10.Voice Recorder

•Record Setting

1) Select Record in the main menu and press Play button to

enter.

2) Select Record Settings and press Play button to enter the

submenu.

3) Press Skip buttons to choose a record setting: Source, Format,

or rate.

4) Press Play button to enter the submenu and choose one option

as your current settings.

5) Press Play button to confirm and back to the previous menu.

6) Press Menu button again can back to the upper menu.

•Start Record

After record settings have been done, you

can start record.

1. Select Start Record and press Play

button to begin recording.

2. Press Pause button to pause recording

and press Play button again to continue

record.

3. Press Menu button to stop recording

and back to the Record menu.

4. The voice record will be saved as a file named Vxxx.WAV (For example

V001.WAV) in the Voice folder.

Note:

9When all available memory has been used, the screen will display:

Note:

9A high record sampling frequency brings an increase in sound quality but also

a corresponding increase in memory usage.

Tabla de contenidos

Otros manuales de Reproductor de MP3 de Curtis

Curtis

Curtis MP3512B Manual de usuario

Curtis

Curtis MP3512B Manual de usuario

Curtis

Curtis MP510 Manual de usuario

Curtis

Curtis MP3257B Manual de usuario

Curtis

Curtis MPS1015 Manual de usuario

Curtis

Curtis MPS2015UKA Your pocket Manual de usuario

Curtis

Curtis MPS515 Manual de usuario

Curtis

Curtis MP4213 Manual de usuario

Curtis

Curtis MPK1066UK Manual de usuario

Curtis

Curtis MP3512 Manual de usuario

Curtis

Curtis MP128 Manual de usuario

Curtis

Curtis MPK2066 Manual de usuario

Curtis

Curtis MPK8854AUK Manual de usuario

Curtis

Curtis MPK4099UK Manual de usuario

Curtis

Curtis MPK4066UK Manual de usuario

Curtis

Curtis MP128 Manual de usuario

Curtis

Curtis MPK4099UK Manual de usuario

Curtis

Curtis MPK2066UK Manual de usuario

Curtis

Curtis MP25 Manual de usuario

Curtis

Curtis MPK8854UK Manual de usuario

Curtis

Curtis MP256 Manual de usuario

Curtis

Curtis MPS2015 Manual de usuario

Curtis

Curtis MP2021 Manual de usuario

Curtis

Curtis MP2012UK Manual de usuario

Manuales populares de Reproductor de MP3 de otras marcas

Blaupunkt

Blaupunkt Compact Drive MP3 Manual de usuario

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manual de usuario

Meizu Electronic Technology

Meizu Electronic Technology E5 Manual de usuario

Naxa

Naxa NMV-173NX Manual de usuario

Philips

Philips PSA250 Manual de usuario

Zipy

Zipy go! Waving Manual de usuario

Sylvania

Sylvania SMPK4068 Manual de usuario

Sony

Sony NW-MS7 - Memory Stick Walkman Manual de usuario

Irradio

Irradio RF-42UC Manual de usuario

NABAIJI

NABAIJI SWIM MUSIC 100 Manual de usuario

Laser

Laser MP3-A9-4GB Manual de usuario

Samsung

Samsung YP-T7F Manual de usuario

Savant

Savant SMS-1001-00 Guía de referencia rápida

Trevi

Trevi XP 71 BT Manual de usuario

AGPtek

AGPtek C2 Manual de usuario

MobiBlu

MobiBlu DAH-1500i Manual de usuario

Denver

Denver MPS-201 Manual de usuario

Steren

Steren MP3-002 Manual de usuario
