Curtis GEM-120A Manual de usuario

The Gemini System 120A conveniently and

automatically brews 12 or 24 cups of rich, full-

bodied coffee per cycle into a 36-cup insulated

Satellite Server. A brew-ready light signals when

water temperature is ready for the next brewing

cycle. Timer can also be set to brew 24 cups at

atimewithout refilling the brew basket. This

full-featured brewer conveniently plugs into a

conventional 115V wall outlet.

Gemini Coffee Brewing System

MODEL: GEM-120A

•Brews automatically in 12- or 24-cup

increments.

•Automatic timer allows brewing of

24 cups without brew basket reloading.

•Hot water faucet lets you draw steaming hot

water for tea, soups or cup meals — even

during brewing.

•High-efficiency, double-wall insulation in

each Satellite Server maintains coffee

temperature for extended periods without

warming. Coffee cannot deteriorate, but

maintains its rich, full-bodied flavor.

•Locking Satellite lids guard against

accidental spills.

•Color coded satellite faucets available for

regular or decaffeinated coffee, tea.

FEATURES AT AGLANCE

•2.5„adjustable plastic legs.

•Oversize Stainless Steel Brew Basket

(Recommended when soft water is used,

decaffeinated coffee, high altitude locations, or

other conditions which may cause standard brew

basket to overflow.)

OPTIONS

ITEM NO

PROJECT

DATE

Dimensions ............9”W x 9”D x 9.75”H

Power................................115V/100W

GEM-5 HEATED

SATELLITE SERVING STAND

Raises Satellite to 9.75” for decanter service.

Dimensions ........9”W x 9”D x 5.375”H

Power ............................115V/100W

GEM-8 HEATED

SATELLITE SERVING STAND

Raises thesatellite 5.375” for cup service.

Dimensions ....................................9”W x 9”D x 11”H with handle

GEM-3 INSULATED SATELLITE SERVERS

Expand your coffee service by placing extra Satellite Servers in strategic

locations away from brewer. Serving stands are available in two heights

to provide extraconvenience.

DT-08 ....................8”W x 5”D x .75”H

STAINLESS STEEL DRIP TRAYS

Perfect for Gemini Systems and stands.

WC-3504 Legs

2.5” to 3” adjustable black

plasticlegs.

WILBUR CURTIS COMPANY, INC.

6913 Acco Street, Montebello, CA 90640-5403

Telephone: 800-421-6150 • 323-837-2300 •

Fax: 323-837-2406

www.wilburcurtis.com

GEM-120A

16.5"

(41.9 cm)

21.5"

(54.6 cm)

4.5"

(11.4 cm)

(22.9 cm)

0.5"

(1.3 cm)

(5.1 cm)

20"

(50.8 cm)

6.5"

(16.5 cm)

1.5"

(3.8 cm)

1.5"

(3.8 cm)

12.5"

(31.8 cm)

(22.9 cm)

26.5"

(67.3 cm)

SPECIFICATIONS

Brew Cycles Finished Brew

Capacity Dimensions

(HxWxD) Voltage Power

Requirements Water

Inlet Shippng

Weight (lbs) Cube

(cu. ft.)

GEM-120A 12 or 24 Cup 36 Cups 26.5” x 9” x 16.5” 120VAC/60Hz* 1775W/14.8A .25” Flare 48 lbs. 3.53 cu. ft.

GEMINI ACCESSORIES

*Optional Dual Voltage 120/220VAC; Export voltage available - contact factory
