Curtis VR223 Manual de usuario
0
1
Contents
Function Description……………………………………………………………………………………2
Notice for Use……………………………………………………………………………………………2
System Requirements…………………………………………………………………………………4
Basic operation…………………………………………………………………………………………7
ArcSoft PhotoImpression, VideoImpression and MediaImpression………………………………12
Product Specifications…………………………………………………………………………………28
Standard accessories…………………………………………………………………………………29
2
Function Description:
Welcome! Thank you for purchasing the CURTIS VR223
With this digital video camera, you can take 640 x 480 resolution (VGA format) videos and
300,000 pixels of still photos. With the playback function you can play back the taken
video or photos with this digital video camera. In addition, you can download the videos
and photos from the VR233 to your PC. The illustrations in this user manual are to
visually detail the operation of the VR223.
Notice for use:
General:
1. Never open the housing of the digital video camera as some parts may cause electric
shock.
2. Moisture, pressure, collision and heat may damage this digital video camera.
Memory and storage:
1. SD can be used, with a maximum capacity of 4GB.
2. When buying an SD card, take the digital video camera with you to ensure
compatibility.
3. SD cards have a write-protect switch, which can be used to prevent accidental deletion
of data. When this switch is pushed to the bottom and locked, the data in the card will be
protected. However, when the card is in write-protect state, it cannot be used for shooting
or deletion, etc.
4. These memory cards should not be used for permanent storage of data. Files should
be transferred and stored in your computer or an external storage device.
3
5. When storing documents onto the memory or the memory card, make sure that the
size of the documents does not exceed the capacity of the memory.
Maintenance and care:
1. To clean the lens, blow away the dust on its surface, then use proper cloth or tissue for
optical devices to clean the lens. If necessary, use lens cleanser.
2. Never touch the lens with fingers.
3. When left idle for long periods of time, take out the battery and keep in a dry and dark
place.
Other notes:
1. When switching image output between LCD display and video devices, be sure to exit
from the play or record state.
2. Never keep the digital video camera in an extremely hot or damp environment.
3. TV programs, movies, music, images and other resources may be protected by
copyright; therefore, without prior permission, the shooting/use of these resources may
violate copyright laws and regulations related. Please note that the resources under the
protection of copyright can be used within the permission of related laws and regulations.
4
Systemrequirements:
Below are the minimum requirements that your computer needs to operate files for the
software included:
Operation System Microsoft Windows Me, 2000,XP, Vista*
CPU Above Intel PIII667 or CPU of equal performance
Memory Above 128 MB
Sound card and display card DirectX8 or above
CD-ROM 4× speed or above
Hard Disk 300 MB or more useable space
Other One standard USB 1.1 or USB 2.0 port
* The VR223 is compatible with all Mac OS.
5
USB Connector
Power Ke
y
TV Out Port
Resolution
Switch
SD
Card Slot Speaker
Strap Holder
Microphone
LED Light
Len
s
Battery Cover
Tripod
USB Switch
6
2. Basic operation
LCD
Delete Key
Mode key
Up(+) Key
Right Key
Left Key
Down(-) key
Shutter/Record
Key
7
2.1 Battery Installation
Slide down the Battery Cover and insert two new AA alkaline batteries. Align with
correct polarity of battery terminals. Close Battery Cover.
2.2 Use SD card
Insert the SD memory card into the SD card slot. Push it down until the card stays
latched. Do not force – check card’s position according to the position
mark on the camera.
Push and release inserted card if you wish to remove or replace the
card.
Turn your camcorder OFF before inserting / removing the SD Card.
- Note that the SD Card has a tiny LOCK switch on the side. Set the
switch to un-LOCK position to be able to record videos and take still pictures.
2.3 Power on/off
In power-off state, press and hold the power key ( ) to power ON the camera.
In power-on state, press the power key ( ) to power OFF the camera.
In power-on state, if you leave the camera idle for 1 minute it will power off
automatically.
8
In power-on state, when battery level is very low, the red icon on the bottom left of
the screen will flash and the camera will turn off after one second. You must replace
the batteries.
2.4 Change mode
After powering on, the camera will always enter video record mode, press mode key to
change mode between video record and capture.
In video record or capture mode, press left key or right to enter playback mode.
Press Mode key to exit playback mode and return preview mode
2.5 Change resolution
You can select High or Low resolution for recording videos or taking still pictures.
Slide the Resolution Switch located on camcorder’s side and select desired position.
LCD screen will display “Hi” or “Lo” indicating selected resolution.
2.6 Record Video
In video record mode, press shutter key ( ) to begin video recording, press the
shutter key again to stop recording.
Press up key or down key to zoom in or zoom out the image.
In playback mode, press Shutter key to start or stop video.
9
2.7 Take a Picture
In capture mode, press the shutter key to take a photo.
2.8 Play back videos and photos
In playback mode, press left or right key ( ) to select a file.
Press Shutter key to begin/stop play video, and press up key or down key to on a
photo.
2.9 TV output
After the camera is powered on, insert the terminal of the
TV cable into the TV output port of the camera, and yellow
port of the other terminal should be connected to VIDEO IN
zWhen the inserted memory card is full, the LCD will display "Memory Full," then the camera
will stop recording automatically.
zIf the SD card is locked, when you press the Shutter key, the LCD will display “Card
Locked” and the camera will not record.
zBefore insertion or removal of card, please turn off the camera first. In power-on state, the
camera will automatically shut down if the memory card is removed.
