Cuisinart GR4CU Manual de usuario

Griddle & Grill

GR4CU

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed, including the following:

1. The appliance is not intended to be operated by means of external

timer or separate remote-control system.

2. This appliance is not intended for use by persons with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety.

3. Children should always be supervised to ensure that they do not play

with this product.

4. Not for use by children. Keep out of reach of children during and

after use.

5. Once you have ﬁnished cooking, turn the selector control to the

‘OFF’ position, unplug the power cord from the mains and allow the

appliance to cool for at least 30 minutes before handling. The griddle

& grill plates can be washed by hand or in the dishwasher. Do not

use metallic objects such as knives when cleaning. This will damage

the non-stick coating. Use wooden or heatproof plastic utensils only.

The housing base, cover and control knob can be wiped clean with a

soft, dry cloth. For tough stains dampen cloth. Never use an abrasive

cleaner or harsh pad.

6. The temperature of all surfaces marked with this symbol

will be very hot when the appliance is in use. DO NOT TOUCH

these surfaces as possible injury could occur. Allow to cool

completely before handling this appliance.

7. The outer surface may get hot when the appliance is in use.

8. Always inspect the appliance before use for noticeable signs of

damage. Do not use if damaged, or if the appliance has been dropped.

Do not use this appliance if the lead is damaged. In the event of

damage, or if the appliance develops a fault, contact the Cuisinart

Customer Care Line (refer to “UK After Sales Service section“ for

further information).

Congratulations on your purchase of the Cuisinart Griddle & Grill.

For over 30 years Cuisinart’s aim has been to produce the very ﬁnest kitchen

equipment. All Cuisinart products are engineered for exceptionally long

life, and designed to be easy to use as well as to give excellent performance

day after day.

To learn more about our products and recipe ideas visit our website

www.cuisinart.co.uk

Contents

Product Description ..........................................................................................................5

Safety Cautions ................................................................................................................6

UK Wiring Instructions ....................................................................................................8

Instructions for Use

A Selecting and ﬁtting the plates................................................................................................... 9

B Selecting the cooking position ..................................................................................................10

C Using the integrated drip tray ................................................................................................... 11

D Cooking with the Griddle & Grill............................................................................................... 11

Cooking Guide ................................................................................................................ 12

Cleaning & Maintenance ................................................................................................13

UK Guarantee & UK After Sales Service.......................................................................14

Recipes..............................................................................................................................15

Product Description

Reversible Plate

Handle

Scraping Tool

Hinge Release Lever

Plate Release Button

Housing Base

Reversible Plate

Controls

Drip Tray

Plate Release Button

Safety Cautions

Always follow these safety cautions when using this appliance to avoid personal injury

or damage to the appliance. This appliance should be used only as described within this

instruction book. Please keep this instruction book for future reference.

nBefore ﬁrst use, remove all packaging materials and any promotional labels or stickers

from the Griddle & Grill.

nAlways inspect the appliance before use for noticeable signs of damage. Do not use

if damaged, or if the appliance has been dropped. In the event of damage, or if the

appliance develops a fault, contact the Cuisinart Customer Care Line (see “UK After Sales

Service” section).

nDo not use this appliance if the lead is damaged. In the event of lead damage discontinue

use immediately. If the lead is damaged it must be replaced by a special lead available

from the manufacturer or its service agent. (See “UK After Sales Service”).

nDo not touch hot surfaces; use the handle whilst the appliance is switched on and for

30 minutes after use.

nThis appliance is not intended for use by persons with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for

their safety.

nChildren should always be supervised to ensure that they do not play with this product.

nNot for use by children. Keep out of reach of children during and after use.

nUnplug from the mains when not in use and before cleaning. Allow to cool completely

before fitting or removing parts and before cleaning the appliance.

nDo not use accessories or attachments with this appliance other than those recommended

by Cuisinart.

nDo not leave the lead hanging over the edge of a kitchen table or worktop. Avoid

contact between the lead and hot surfaces.

nDo not place on or near hot gas or electric burners or in a heated oven.

nDo not use the appliance for anything other than its intended use.

nTo disconnect, turn the control to ‘Off’ setting, and then remove the plug from the mains.

nAlways ensure that your hands are dry before removing the plug from the mains socket.

nTo protect against fire, electric shock or personal injury, do not immerse the cord, plug

or housing base in water or other liquids.

nNo repair should be carried out by the user. Return the appliance to the Cuisinart UK

After Sales Services for inspection or repair/replacement (see “UK After Sales Service”).

nFor indoor, domestic use only.

nDo not connect this appliance to an external timer or remote control system.

nThis appliance complies with the basic requirements of Directives 2004/108/EC

(Electromagnetic Compatibility) and 2006/95/EC (Safety of domestic electrical

appliances).

WARNING: Polythene bags over the product or packaging may be dangerous.

To avoid danger of suffocation, keep away from babies and children. These

bags are not toys.

The temperature of all surfaces marked with this symbol will be very hot when

the appliance is in use. DO NOT TOUCH these surfaces as possible injury could

occur.

nThe symbol on the product or on its packaging indicates that this product may

not be treated as household waste. Instead it should be handed over to the applicable

collection point for the recycling of electrical and electronic equipment.

By ensuring this product is disposed of correctly, you will help prevent potential negative

consequences for the environment and human health, which could otherwise be caused

by inappropriate waste handling of this product. For more detailed information about

the recycling of this product, please contact your local council office or your household

waste disposal service.

UK Wiring Instructions

nYour Cuisinart Griddle & Grill includes a BS 13 amp moulded (fused) mains plug on the

supply cord.

nShould it be necessary at any stage to remove this moulded plug and replace it with

a re-wireable BS 13 amp mains plug, the re-wiring should be completed as follows:

(NB: The moulded plug should be disposed of safely)

Class I (1) Earthed Appliance

The wires in the mains lead are coloured in accordance with the following code:

GREEN & YELLOW = EARTH

BLUE = NEUTRAL BROWN = LIVE

nThe wire which is coloured GREEN & YELLOW must be connected to the terminal in the

plug which is marked with the letter E or .

nThe wire which is coloured BLUE must be connected to the terminal which is marked

with the letter N.

nThe wire which is coloured BROWN must be connected to the terminal which is marked

with the letter L.

With this appliance, if a 13 amp plug is used, a 13 amp fuse should be fitted. If any other

type of plug is used, a 10 amp fuse must be fitted at the distribution board.

WARNING: A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard.

Ensure that the cut off plug is disposed of safely.

Instructions for Use

A Selecting and ﬁtting the plates

The Griddle & Grill is a really versatile piece of kitchen equipment. There are many different

ways to use the Griddle & Grill, depending on the food you are cooking.

The ﬁrst thing you need to do before using the Griddle or Grill is to select which side of

the plates you wish to cook with. The ﬂat griddle plates are ideal for pancakes and French

toast. The ribbed grill plates are ideal for steaks, kebabs and paninis.

You can use both grill plates together, both griddle plates together or a combination of

one grill plate and one griddle plate.

To ﬁt the plates:

1. Ensure the product is switched off.

2. Select the plate you intend to cook with.

3. Position the Griddle & Grill so that the controls are facing towards you. Lift the handle

to open to grill.

4. Align the two cut outs at the back of the plate (See Fig. 1) with the brackets on the

bottom of the housing base (See Fig. 2). Tilt the plate and slide it underneath the bracket.

Push down the front end of the plate until it locks into place.

5. Repeat with the second plate.

To remove the plates:

1. Ensure the product is switched off and is fully cooled down. Always allow the appliance

to cool for at least 30 minutes before removing the plates.

2. Locate the plate release buttons which can be found on the right side of the units upper

and lower housing. Press the upper release button ﬁrmly, and the upper plate will pop

up slightly from the base. Lift the plate up and slide out from under the brackets in the

centre. Repeat by pressing the lower release button and releasing the lower plate.

3. The plates can be hand washed or cleaned in the dishwasher after use.

Fig. 1 Fig. 2

B Selecting the cooking position

Once you have ﬁtted the cooking plates you intend to use, you need to select the cooking

position.

Fully open position

The Griddle & Grill can be used in the fully open position to

create a double cooking surface.

To adjust the Griddle & Grill to the fully open position, lift the

handle using your left hand, then use your right hand to push the hinge lock located on

the right side of the product upwards. As you do this, push the handle back, until it is

resting on the work surface and the upper and lower plates are level.

Half Open Position

The Griddle & Grill can be used in the half open position. To adjust

the appliance to this position, simply lift the handle until it comes

into the fully upright position. The unit will stay in this position

until you close the cover or continue to open it to the fully open

position.

Closed Position

The Griddle & Grill can be used in the closed position as a contact

grill/panini press and is is ideal for quick cooking as the heat

comes from both sides of the plates.

The ﬂoating hinge design means that the space between the top

and bottom plate adjusts to the thickness of your food. When

cooking more than one item at a time, try to ensure the thickness

of the food is consistent to ensure even cooking for each piece

of food.

To achieve this position simply place food on the bottom plate, place your left hand on the

handle, use your right hand to push up the hinge lock with light pressure and push down

on the lid until the lid is level with the base unit and is resting on your food. You can apply

light pressure using the handle to press whilst cooking to lock in ﬂavour.

Otros manuales para GR4CU

Tabla de contenidos

Otros manuales de Plancha de Cuisinart

Cuisinart

Cuisinart Griddler Express GR-2 Manual de servicio

Cuisinart

Cuisinart Griddler GR-4N Manual de usuario

Cuisinart

Cuisinart Griddler GR-4N Manual de usuario

Cuisinart

Cuisinart CGG-501 Manual de usuario

Cuisinart

Cuisinart CGG-0036 Manual de usuario

Cuisinart

Cuisinart CGG-200 Manual de usuario

Cuisinart

Cuisinart Griddler GC-17 Manual de instalación y operación

Cuisinart

Cuisinart GRIDDLER PARTY Manual de usuario

Cuisinart

Cuisinart Griddler CGR-4C Manual de usuario

Cuisinart

Cuisinart GR-1 - Griddler Panini & Sandwich Press Manual operacional

Cuisinart

Cuisinart GRIDDLER Manual de usuario

Cuisinart

Cuisinart Griddler GR-4N Manual de servicio

Cuisinart

Cuisinart Griddler GR40E Manual de usuario

Cuisinart

Cuisinart CGG-501G Manual de usuario

Cuisinart

Cuisinart CGG-0028 Manual de usuario

Cuisinart

Cuisinart GRID-8N Manual de usuario

Cuisinart

Cuisinart Grill & Griddle Manual de servicio

Cuisinart

Cuisinart Griddler CGR-4NC Manual de usuario

Cuisinart

Cuisinart GR4CU Manual de usuario

Cuisinart

Cuisinart Goodful GG1500GF Manual de usuario

Cuisinart

Cuisinart Griddler Elite Manual de usuario

Cuisinart

Cuisinart GR-4 - Flat Griddler Grill Manual de usuario

Cuisinart

Cuisinart CSG-100 Manual de usuario

Cuisinart

Cuisinart Griddler JR. GR-3 Manual de usuario

Manuales populares de Plancha de otras marcas

Proctor-Silex

Proctor-Silex 25340 Manual de usuario

New House Kitchen

New House Kitchen NH33-C Manual de usuario

Magikitch'n

Magikitch'n 24 Manual de usuario

Black Stone

Black Stone 1650 Manual de usuario

Anvil

Anvil FTA7116 Manual de usuario

Presto

Presto 07030 Manual de usuario

Pit Boss

Pit Boss PB2BGT1 Manual

Dyna-Glo

Dyna-Glo DGL260SNP Manual de usuario

Char-Broil

Char-Broil 19952085 Manual de usuario

APW Wyott

APW Wyott HMG-2424 Manual de usuario

Pit Boss

Pit Boss Ultimate Griddle PB2BGD2 Manual de usuario

Airxcel

Airxcel Suburban Elite SOP-1005A Manual de usuario

Keating Of Chicago

Keating Of Chicago MIRACLEAN PRE-2000 Manual de usuario

Nexgrill

Nexgrill 720-0786A Manual de usuario

Outwell

Outwell FH-3047C Manual de usuario

Rankam

Rankam Member's Mark GR2298901-MM-02 Guía de referencia rápida

Black Stone

Black Stone 1972 Manual de usuario

Star

Star Ultra Max 760TA Manual de usuario
