Cuisinart DBM8U Manual de usuario

Professional Burr Mill

DBM8U

Congratulations on your purchase of the Cuisinart Professional Burr Mill.

For over 30 years Cuisinart’s aim has been to produce the very nest kitchen equipment

so that cooks at home as well as professional chefs have the tools to express their

creativity.

All Cuisinart products are engineered for exceptionally long life, and designed to be

easy to use as well as to give excellent performance day after day.That is why they have

come to be regarded as the dening machines in their eld by chefs across the world.

Whatever you cook, cook it better with Cuisinart.

Contents

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Safety Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Instructions for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Hints & Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

UK After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Product Description

Bean Hopper

Hopper Lid

Start Button

18 Position Grind Selector

Removable Grind Chamber with Lid

Burr Grinding Plates

(not shown)

Housing Base

Cup Quantity Selector

Cord Wrap (not shown)

Read all the instructions thoroughly before using the appliance and keep in a safe place for future

reference

Safety Cautions

Always follow these safety cautions when using this appliance to avoid personal injury or damage to the

appliance.This appliance should be used only as described within this instruction book.

ßDo not immerse motor unit in water or any other liquid or put in a dishwasher.

ßAlways disconnect the appliance immediately after use and before cleaning.

ßNever leave the appliance unattended when plugged in.

ßNever pull the plug out of the mains socket by the lead.

ßDo not allow the lead to overhang the kitchen table or worktop.

ßAvoid contact between the lead and hot surfaces.

ßDo not use this appliance if the lead is damaged. In the event of damage, discontinue use immediately. If the

lead is damaged it must be replaced by a special lead available from the manufacturer or its service agent.

(See “UK After Sales Service”section).

ßDo not use the appliance if it has fallen, shows signs of damage or cuts out in use. Discontinue use

immediately and contact Cuisinart (See “UK After Sales Service”section).

ßNo repair can be carried out by the user. Return the appliance to ‘Cuisinart Service Centre’ for inspection

or repair / replacement (See “UK After Sales Service” section).

ßUse this appliance for grinding coffee beans as described within the instructions for use which accompany

it. Please retain these for future reference.

ßFor indoor use only.

ßFor domestic use only.

ßAlways ensure that your hands are dry before removing the plug from the mains socket.

ßThis appliance complies with the requirements of Directives 04/108/EEC (Electromagnetic Compatibility)and

06/95/EEC (Electrical Safety of Domestic Appliances) amended by Directive 93/68/EEC (CE Marking).

ßAlways ensure the voltage to be used corresponds with the voltage on the appliance, which is indicated on

the bottom of the motor unit.

ßDo not use any attachments other than those recommended or sold by Cuisinart.

ßDo not touch moving parts whilst in use.

ßThis appliance should not be used by adults or children whose lack of experience, product knowledge or

disability might cause a hazard, unless they have been correctly instructed and are adequately supervised.

ßChildren should always be supervised to ensure that they do not play with this product.

ßWARNING: A cut off plug inserted into a 13 amp outlet is a serious safety (shock) hazard. Ensure the cut

off plug is disposed of safely.

ßWARNING: Polythene bags over the product or packaging may be dangerous. To avoid danger of

suffocation, keep away from babies and children. These bags are not toys.

ßThe symbol on the product or on its packaging indicates that this product may not be treated as

household waste. Instead it should be handed over to the applicable collection point for the recycling of

electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent

potential negative consequences for the environment and human health, which could otherwise be caused

by inappropriate waste handling of this product. For more detailed information about the recycling of this

product, please contact your local council ofce or your household waste disposal service.

Instructions for Use

ßRemove all packaging and plug the appliance into a suitable mains socket.

ßRemove the bean hopper lid and ensure that the bean hopper is securely in place.

ßFill bean hopper to top, making sure that the lid closes securely. (Maximum ll is 250g).

ßSet the grind selector to the desired setting by twisting in a clockwise or anticlockwise direction.

The ‘I’ mark on the hopper base should be aligned with the desired grind setting.

ßSlide the cup quantity selector to the desired number of cups, between 4 and 18.

ßPress and release start button to begin grinding.

N.B. If the bean hopper and grind chamber are not properly in place, the grinder wil not operate

ßGrinding will automatically stop once the pre-set quantity of beans have been ground.

ßTo manually stop the operation, slide the cup quantity selector all the way to the left to the ‘Off’ position

and the appliance will stop. To restart, reposition the cup quantity selector to the desired number of cups

and press and release the start button.

ßTo remove the grind chamber, simply pull away form the mains unit. Always ensure the motor has stop-

ped completely before removing any parts. The coffee can be used or stored with the grind chamber lid

tted, ready for use.

Hints & Tips

ßThe following table highlights the general grind settings required for basic types of coffee. As there are 6

settings per grind type, you will have to experiment with different grind settings to determine the right

consistency to suit your taste.

ßWhen choosing ne settings, you may need to set the cup selector at a higher number of cups to get

the desired amount of coffee, as ne grinds are very compact. The opposite is true for coarse settings.

You may need to set the cup selector at a lower number of cups to get the desired amount of coffee, as

coarse grinds are very loose.

ßYou may also vary the strength of the coffee by increasing or decreasing the quantity of cups, i.e. select a

greater quantity than actually required for a stronger avour and vice versa.

Grind Position Grind Result

Coarse Percolator/Cafetière

Medium Filter

Fine Espresso

Cleaning &Maintenance

ßAlways ensure the plug has been removed from the mains before cleaning.

ßThe bean hopper and grind chamber are dishwasher safe, and we recommend washing them on the top

rack of the dishwasher. Due to high water temperature, washing these parts on the bottom rack may cause

damage over time.

ßNever immerse the housing base in water or other liquid.

ßDo not use abrasive cleaners on the housing base. To clean, simply wipe with a damp cloth and dry thorou-

ghly. Apply any cleaning agent to the cloth, not directly to the housing base.

ßUse the cleaning brush provided to clean the grind release area.

ßUse the cord wrap on the underside of the housing base to store excess cord.
