Cudy MF4 Manual de usuario
MF4
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
2
English
3 –12
Čeština
13 –22
Slovenčina
23 –32
Magyar
33 –42
Deutsch
43 –52
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
Install the SIM Card and Battery
a. Remove the back cover.
b. Install your SIM card.
c. Install the provided battery.
5
Connect to the Internet
a. Press and hold the Power button to power on the Mobile Wi-Fi.
d. Note down the default SSID and Wireless Password. Then
replace the cover
SIM card requirement
Nano SIM card
Micro SIM card
Nano SIM adapter
Micro SIM adapter
Standard SIM card
Standard SIM card
6
b. Connect your wireless device to the Mobile Wi-Fi using the SSID and the wireless
Password you have noted down.
Note:
If you cannot access the internet, refer to FAQ > Q1.
1. By default, Power Saving is enabled, and the Mobile Wi-Fi will turn off Wi-Fi when no
wireless devices are connected to it for 5 minutes.
2. To resume the Wi-Fi connection, press the Power button.
Enjoy the internet!
7
Customize the 4G LTE Router
1. Make sure your computer is connected to the router.
2. Launch a web browser and enter http://192.168.10.1/ in the address bar. Use admin
for account and password to log in
3. Follow the step-by-step instructions of the Wizard to complete the initial
configuration.
Button and Interface
Signal LED
Wi-Fi LED
SMS LED
Power LED
WPS Button
Power Button
USB Port
Reset Button
Micro SD Slot
SIM Card Slot
8
LED and Interface
LED
Status
Explanation
Solid Blue
Internet connection over LTE.
Blinking Blue
Registered on an LTE network but not yet
connected.
Solid Green
Internet connection over 3G.
Blinking Green
Registered on a 3G network but not yet
connected.
Solid Purple
Internet connection over 2G.
Flashing Purple
Registered on a 2G network but not yet
connected.
Red
No Server/Device Error.
Off
Power is off.
Solid Blue
Wi-Fi Active.
Blinking Blue
Active Link.
Fast Blinking Blue
WPS pairing in progress.
Blinking Blue
New SMS message.
Green
Power-on in progress.
Blue
Fully charged or normal operation with battery
about 60%.
Blinking Amber
Charging.
Solid Amber
Battery between 60% and 15%
Blinking Red
Battery less than 15%
Note:
1. The LEDs will turn off automatically after idling for 30 seconds. To check the LED
status, press the Power button to turn them on again.
2. If the Battery LED blinks red when the battery level is enough or when charging,
make sure the device is being used within 0-35 °C and the battery is inserted.
9
Frequently Asked Questions
Q1. What should I do if I cannot access the internet?
A. Visit the web management page (http://192.168.10.1) on your phone, enter admin to
log in, then check the following:
Check PIN status
If the current SIM card status is PIN Locked, your SIM card is PIN protected, and you
need to unlock it using the PIN code provided by your mobile carrier. Go to WAN > PIN
to verify if PIN is required. If it is, enter the correct PIN provided by your ISP, and click
Apply.
Verify the mobile carrier parameters
Go to WAN > APN setting to verify the parameters provided by your ISP are correctly
entered. If the parameters are incorrect, select Add New and enter the correct
parameters, then select the new profile from the Profile list.
Check the data Roaming setting
If your SIM card is operated in a roaming service area, go to WAN > Connections to
enable Data Roaming.
Check Data Limit
Contact your mobile carrier to check whether your data usage has exceeded the
Total/Monthly allowance.
Q2. How do I restore the Mobile Wi-Fi to its factory default settings?
A. With the Mobile Wi-Fi powered on, remove the cover, then use a pin to press and hold
the Reset button for 5s before release.
Note: Restoring the device to its factory defaults will clear all your settings.
10
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
