-6-
STM32F765 (32 Bit Arm® Cortex®-M7, 216MHz,2MBflash, 512KB RAM)
STM32F100(32 Bit Arm® Cortex®-M3, 24MHz,8KB SRAM)
三路电源输入冗余 Three-way power input redundancy
多旋翼/固定翼/直升机/VTOL垂直起降/无人船/无人车等 Copter/Plane/Helicopter/VTOL/unmanned vehicle/Rover, etc.
GPS / Radio/Debug, etc.
Compass / Airspeed meter / Ultrasonic, etc.
External sensor
GPS / Smart battery, etc.
AD signal detection
Signal output of Steering Gear / ESC
Signal input such as Encoder / Hot shoe feedback
Remote control signal
Remote control signal/Signal strength input
Power input&Voltage and electricity AD detection
Power input&
Smart battery
Unlock switch
Buzzer warning
USB power supply debugging
Store log information
4.5 ~ 5.5 V
5V +- 0.25v
0-36v
Working environment
PM工作电压 PM working voltage
USB工作电压 USB voltage
伺服输入电压 Servo Rail Input
工作温度 Operating temperature -40 ~ 85°c
重量 Weight 91g
