Crystal Image Technologies Cat5-IP08 Manual de usuario

Cat5-08 / 16 / 32

Cat5-IP08 / 16 / 32

dedicated KVM switch and rackmount screen technology

Combo Cat6 KVM

Cat5-08R / 16R/ 32R

Combo Cat6

2-console KVM

UM-CV-UKVM-Q411V3 www.austin-hughes.com

4.1 KVM Button

4.2 Password

4.3 KVM OSD

4.4 KVM Hotkey & Remote Console Hotkey

4.5 DC power 12V, 24V, 48V Input

Contents

< Part 1 > Combo Cat6 2-console KVM

Cat5-IP08 /-IP16 /-IP32

1.1 Package contents

1.2 KVM port & Cat6 dongle connection

1.3 IP & Local console connection

1.4 IP console setting

1.5 KVM Cascade

1.6 IP Multi-port connection to remote PDU

1.7 Speciﬁcations

< Part 2 > Combo Cat6 2-console KVM

Cat5-08R / -16R / -32R

2.1 Package contents

2.2 KVM port & Cat6 dongle connection

2.3 Remote & Local console connection

2.4 KVM Cascade

2.5 Speciﬁcations

P. 1

P. 2

P. 3

P. 4

P. 5

P.6 - 7

P. 8

P. 9

P.10 - 11

P.12 - 13

P.14

P.15

P.20

P.21

P.22

P.23

P.24

< Part 4 > Usage

< Part 3 > Combo Cat6 KVM

Cat5-08 / -16 / -32

3.1 Package contents

3.2 KVM port & Cat6 dongle connection

3.3 KVM Cascade

3.4 Speciﬁcations

.16

P.17

P.18

P.19

UM-CV-UKVM-Q411V3 www.austin-hughes.com

Combo Cat6 2-console KVM

< 2.1 > Package Content

P. 9

Part 2. Combo Cat6 2-console KVM

y r

ei w

KVM unit

• Combo KVM unit x 1

• Mounting set w/ bracket & screws x 1

• Power cord ( for KVM ) x 1

U-802 / U-1602 / U-3202

Receiver box

for remote console

Receiver’s power adapter

w/ power cord

CE-6 KVM cable

for receiver box

X 1 set

UM-CV-UKVM-Q411V3 www.austin-hughes.com

P.10

Cat5-16R

Cascade

Cat5-08R

Local

Console

Local console x 1

Remote console x 1

Cat5-32R

2468 1357

246810121416 13579111315

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

Remote Cascade

Local

Console

Remote

Cascade

Local

Console

Remote

Combo Cat6 2-console KVM

UM-CV-UKVM-Q411V3 www.austin-hughes.com

Combo Cat6 2-console KVM

Cat5 Dongle PS/2

■To connect DB-15 connector to the computer’s video card

■To connect PS/2 keyboard connector to the computer’s keyboard port

■To connect PS/2 mouse connector to the computer’s mouse port

Cat5 Dongle USB

■To connect DB-15 connector to the computer’s video card

■To connect USB connector to the computer’s USB port

Cat5 Dongle USB/DVI

■To connect DVI-D connector to the computer’s video card

■To connect USB connector to the computer’s USB port

< 2.2 > KVM port & Cat6 dongle connection

P. 11

PS/2

VGA

VGA-PS/2 dongle

USB Servers

PS/2 Servers USB Servers

CAT 5 / 6 cable

max. 40 meters

Cat6 KVM port

USB

DVI-D

DVI-USB dongle

USB

VGA

VGA-USB dongle

CAT 5 / 6 cable

max. 40 meters

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

UM-CV-UKVM-Q411V3 www.austin-hughes.com

P.12

< 2.3 > Remote & Local console connection

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

Remote

USB console

Local

USB

console

Remote

Cat6

Console

CAT 5 / 6 cable

max. 150m

Receiver

Combo Cat6 2-console KVM

UM-CV-UKVM-Q411V3 www.austin-hughes.com

Combo Cat6 2-console KVM

How to use a receiver to connect a remote console

Receiver

K/B Mouse Local Remote

Local

Computer Monitor

Power

USB

Remote I/O

Monitor

Combo

KVM cable

Cat6 cable

up to 150m

12V DC Power

Adapter

Local computer

( Optional setup )

VGA

cable

Remote

Console

Button

KVM switch

P.13

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

The receiver provides a hotkey function for remote console. Please refer to P.23

Front

Rear

Front

Rear

UM-CV-UKVM-Q411V3 www.austin-hughes.com

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

2468

10121416 1357

9111315

2468

10121416 1357

9111315

2468

10121416 1357

9111315

2468

10121416 1357

9111315

Cascade

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

2468

10121416

1357

9111315

18202224

26283032

17192123

25272931

P.14

■Cascade up to 8 levels, 256 servers

■Cascading multiple KVM with CBC-6 cascade cable.

< 2.4 > KVM Cascade

Cat5-16

Cat5-32

Cascaded KVMs from level 2 to 8 must be the models of Cat5-08 / -16 / -32

When multiple combo Cat6 KVMs cascade together, the master KVM at level 1 will take all control of

other slave KVM switches (e.g. level 2 to 8).

Master KVM

Slave KVM

level 2

Slave KVM

level 8

Slave KVM

level 7

Slave KVM

level 6

Slave KVM

level 5

Slave KVM

level 4

Slave KVM

level 3

Cascade Cat5/USB

■6ft Combo KVM cascade cable

To console VGA port

Combo Cat6 2-console KVM

UM-CV-UKVM-Q411V3 www.austin-hughes.com

Combo Cat6 2-console KVM

P.15

< 2.5 > Speciﬁcations

-08R-16R-32R

▀KVM Port

Number of ports: 8, 16 or 32

Connector: RJ-45

Connectivity: DVI-D / VGA connector dongle up to 40 meters (132 feet) via

Cat6 / Cat5 cable

▀Local Console

Graphic connector: 1 x DB-15 VGA

Resolution: Up to 1600 x 1200

Input device: 2 x USB type A for keyboard & mouse

▀Remote Console

Connector: 1 x DB 15-pin, VGA

Resolution: Up to 1600 x 1200 (500 feet), Up to 1024 x 768 (1000 feet)

Input device: 2 x USB type A for keyboard & mouse

Remote I/O: RJ45 via Cat5 / Cat5e / Cat6 cable up to 500 feet

Compensation: Auto adjust for cable length

▀Expansion: Up to 256 servers by 8-level cascade

▀Compatibility

Multi-platform: Mix PCs, SUNs, IBMs, HPs, DELLs Server

Support: Windows Vista / 2003 / XP / 2000, Linux, Netware, Unix, DOS

▀Power

Input: 100 or 240V AC at 50 or 60 Hz via IEC type cord OR

AC / DC power adapter [email protected] (optional)

Option DC: 12V / 24V / 48V DC input

Consumption: Max. 48 Watt, Standby 5 Watt

▀Regulatory Approval: FCC, CE

▀Environmental

Operating: 0 to 50°C

Storage: -5 to 60°C

Relative humidity: 90%, non-condensing

Shock: 50G peak acceleration (11ms, half-sine wave)

Vibration: 58~100Hz / 0.98G (11ms / cycle)

▀Product Information

Dimension (W x D x H): 443 x 180 x 43.6 mm / 17.4 x 7.1 x 1.72 inch

Net weight: 3 kg / 6.5 lb

▀Packing Information

Dimension (W x D x H): 500 x 400 x 90 mm / 19.7 x 15.7 x 3.5 inch

Gross weight: 5 kg / 11 lb

UM-CV-UKVM-Q411V3 www.austin-hughes.com

4.1 KVM Button

P.20

Part 4. Usage

Power ON

■Turn off all servers and KVM switches

■Make sure all cables / connectors are properly connected

■Recommend Power ON sequence is monitor, KVM switch ﬁnally computer

Bank no. 7-Segment BANK LED indication

PC port LEDs Online : Blue LED on indicating a PC is connecting to the port

Active : Green LED on indicating a selected channel

Channel button Press to select channel from 01 to 32

Bank button Select the bank from 1 to 8

Front Panel - Port LED Indications

Bank no. PC port LEDs Channel

button

Bank

button

32 ports

8 ports

16 ports

Combo Cat6 KVM Usage
