CRS SAM52M Manual de usuario
Samsung ER-5200M Series
SAM52M
User's Manual
Version 2.3
All specifications are subject to change without notice. ©2008, CRS, Inc.
CRS, Inc.
Limited Warranty and Disclaimers of Warranty
This manual has been developed by CRS, Inc. It is intended for the use of its customers and service personnel and should be read in its
entirety before attempting to install, use or program the product(s).
Nothing contained in this manual shall be deemed to be, and this manual does not constitute, a warranty of, or representation with respect
to, the product or any of the products to which this manual applies. This manual is subject to change without notice and CRS, Inc. has no
obligation to provide any updates or corrections to this manual. Further, CRS, Inc. also reserves the right, without prior notice, to make
changes in equipment design or components as it deems appropriate. No representation is made that this manual is complete or accurate in
all respects and CRS, Inc. shall not be liable for any errors or omissions contained in this manual. In no event shall CRS, Inc. be liable for
any incidental or consequential damages relating to or arising out of the use of this manual. This document contains proprietary
information that is protected by copyright. All rights are reserved. No part of this document may be photocopied or reproduced without
prior written consent of CRS, Inc.
NOTICE
IF ANY WARRANTY IS EXTENDED TO YOU WITH REGARD TO THE PRODUCT(S) TO WHICH THIS MANUAL APPLIES, IT
IS A WARRANTY FROM THE ENTITY OR INDIVIDUAL FROM WHOM YOU DIRECTLY PURCHASED THE PRODUCT(S).
SUBJECT TO THE FOREGOING, UNLESS YOU ARE A DIRECT END USER CUSTOMER OF CRS, INC., CRS, INC. DOES NOT
EXTEND TO YOU ANY EXPRESS WARRANTY OR ANY IMPLIED WARRANTY AND EXPRESSLY DISCLAIMS ANY IMPLIED
WARRANTY OF MERCHANTABILITY, FITNESS FOR USE, OR FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY
WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY RIGHTS IN CONNECTION WITH THE PRODUCT(S)
OR ANY SOFTWARE, DRIVERS, OR PROGRAMMING PRODUCT, WHETHER EMBEDDED IN PRODUCT(S) OR PROVIDED AS
A SEPARATE PROGRAM, OR USED IN CONJUNCTION WITH THIS/THESE PRODUCT(S). CRS, INC. SPECIFICALLY DOES
NOT WARRANT THAT THE OPERATION OF ANY DRIVERS, SOFTWARE, OR PROGRAMMING PRODUCTS LICENSED
HEREUNDER, WHETHER EMBEDDED IN PRODUCTS OR PROVIDED AS SEPARATE PROGRAMS, SHALL BE
UNINTERRUPTED OR ERROR FREE OR THAT FUNCTIONS CONTAINED IN SUCH DRIVERS, SOFTWARE OR
PROGRAMMING PRODUCTS SHALL OPERATE IN COMBINATION(S) WHICH MAY BE SELECTED FOR USE BY YOU OR
OTHERWISE MEET YOUR REQUIREMENTS.
CRS, Inc. is not responsible for any damages or loss, either direct, indirect, special, incidental or consequential, which you may experience
as a result of your purchase or use of the product(s). Your sole remedy in the event that you encounter any difficulties with the product(s)
is against the entity or individual from whom you purchased the product(s).
Revision 2.0 - April 1, 2005
SAM52 User's Manual v2.3 Contents •i
Contents
Introduction 1
Overview ...................................................................................................................................1
Features .......................................................................................................................1
Requirements...............................................................................................................1
Installing......................................................................................................................2
Cash Register Settings.................................................................................................3
RS-232 Option Chart...................................................................................................3
Preparing the ER-5200M for Communicatons ............................................................4
Starting ......................................................................................................................................5
Navigating .................................................................................................................................6
Mouse and Keyboard ..................................................................................................6
Viewing Menus and Selecting Menu Items.................................................................6
Drop-Down List Boxes ...............................................................................................8
Check Boxes................................................................................................................8
Option Buttons ............................................................................................................8
Scrolling......................................................................................................................8
Interface Specifications .............................................................................................................9
Menu Functions 10
Stores.......................................................................................................................................10
Creating a New Store ................................................................................................10
Selecting the Default Store........................................................................................12
Editing Store Information..........................................................................................13
Deleting A Store........................................................................................................13
Edit ECR Data .........................................................................................................................15
PLU File....................................................................................................................16
Group.........................................................................................................................21
Tax.............................................................................................................................22
System Options..........................................................................................................23
Print Options .............................................................................................................24
Function Keys ...........................................................................................................25
Clerks ........................................................................................................................26
Logo Description.......................................................................................................27
Financial Messages....................................................................................................28
Clerk Messages..........................................................................................................29
Misc...........................................................................................................................30
Mix and Match ..........................................................................................................35
Stock..........................................................................................................................36
Communications......................................................................................................................37
Polling .......................................................................................................................37
Send Programs to ECR (Download) .........................................................................39
Receive Programs from ECR (Upload).....................................................................40
Polling Setup File......................................................................................................41
ii •Contents SAM52 User's Manual v2.3
Download Bitmap Image...........................................................................................42
Print .........................................................................................................................................45
Daily Poll File............................................................................................................46
Log Files....................................................................................................................47
PLU File ....................................................................................................................50
PLU Range ................................................................................................................51
Consolidated Store Report.........................................................................................52
Remove....................................................................................................................................53
Old Poll Files.............................................................................................................53
Log Files (Upload, Download, Poll) .........................................................................53
Utilities ....................................................................................................................................54
Copy a Store..............................................................................................................54
Copy PLU File...........................................................................................................55
After Polling..............................................................................................................56
Set Auto Poll .............................................................................................................57
Length of Polling Time .............................................................................................58
Backup Poll Data Files..............................................................................................58
Design 5200M Keyboard ..........................................................................................59
Design Generic Keyboard .........................................................................................60
Fix PLU File..............................................................................................................61
Calculate Number of PLUs........................................................................................61
View Memory Allocation..........................................................................................62
Quit..........................................................................................................................................63
Appendices 64
Structure Of Stores ..................................................................................................................64
File Definitions........................................................................................................................65
SAM52M PLU File Structure..................................................................................................65
Structure Of Polling Files........................................................................................................67
Sample Reports........................................................................................................................69
Financial Report ........................................................................................................69
Time Report...............................................................................................................70
PLU Report................................................................................................................71
Clerk Report (Data for One Clerk Only)..................................................................71
Group Report.............................................................................................................72
Troubleshooting Common Problems.......................................................................................73
Hardware...................................................................................................................73
Software.....................................................................................................................73
Samsung ER 5200M Series.......................................................................................73
SAM52M Software.....................................................................................................73
Cabling Diagrams....................................................................................................................74
Manual Revision Record 75
SAM52 User's Manual v2.3 Introduction •1
Introduction
Overview
Features
SAM52M controls the connection between a Samsung ER 5200M Series (ER-5215M,
5240M, or ER-5200M) electronic cash register and an IBM compatible PC running in a
Windows 95/98/2000 environment. Using SAM52M at your PC, you can:
•Connect directly, via telephone modem or by Internet.
•Upload program files from the register to the PC.
•Edit cash register programs.
•Download program files to the register from the PC.
•Download bitmap images for custom pre/post logos.
•Poll reports from the register, save, display or print them at the PC.
•Poll all stores, or individual stores.
•Poll unattended at a predetermined time.
•Download preamble/postamble bitmap files.
•SAM52M converts polled reports to ASCII files, ready to be used by other PC
applications.
Requirements
To use this utility, you must have:
•Pentium 100 or faster CPU.
•32 MB RAM.
•150 MB minimum hard disk space available.
•Dedicated serial port (RS-232C).
•CD ROM drive.
•VGA or SVGA display.
•Windows 95 or above operating system.
•US Robotics Sportster™Modems are recommended for remote connections (for both PC
and ECR sites.)
2 •Introduction SAM52 User's Manual v2.3
Installing
Note: SAM52M Software can also be downloaded from www.crs-usa.com.
Note: The Sam52M software can be used as Save/Load software with out installing the
software key. To edit any programming as described in this manual you will need to install
the USB or LPT key on the appropriate port on your PC.
1. Load the SAM52M program CD into your CD drive.
2. From the Windows Desktop, choose the My Computer icon.
3. Select your CD ROM drive (usually drive "D".)
4. Choose Setup, the Welcome dialog displays.
5. Click Next, the Ready to Install dialog displays.
6. Click Next, the Install Directory dialog displays.
7. Click Next, the Select Shortcut Folder dialog displays.
8. Click Next. When all files are copied, the Finished dialog displays.
9. Click Finish.
10. Click OK to restart your PC.
11. Remove the CD from the drive, your installation is complete.
SAM52 User's Manual v2.3 Introduction •3
Cash Register Settings
To communicate with your Samsung ER-5200M Series ECR, you must set the RS232C port
for the PC function.
Setting the RS232C Port Options
You must select ‘PC’ as the device that is attached to the RS-232C communications port.
1. Turn the control lock to the Sposition.
2. Enter 80(enter 81to program the second port) and press the SBTL key.
3. Enter 5and press the X/TIME key. (Refer to the chart RS-232C option chart that
follows.)
4. Enter 1(the value for PC) and press the CASH key.
5. Press CASH to exit the program.
RS-232 Option Chart
Address Option Value Selection
0 9600 BPS
1 1200 BPS
2 2400 BPS
3 4800 BPS
1 Baud Rate
4 19200 BPS
0 NONE
1 ODD
2 Parity
2 EVEN
0 8 BITS
3 Data Bits 1 7 BITS
0 1 BIT
4 Stop Bits 1 2 BIT
0 NONE
1 PC
2 SCALE
4 Receipt Printer
5 Not used
7 COIN
9 Pole Display
5 Device Function
10 PDC (Requires V6.1 or later)
6 Initial Feeding Line KP 0 - 20
7 End Feeding Line KP 0 - 20
8 Initial Feeding Line Slip 0 - 20
9 Print Line On Guest Check 0 - 50
Repeat for another
Index
XTIMEOPTIONSBTL0/18 CASHVALUE CASH
4 •Introduction SAM52 User's Manual v2.3
0 NCI
10 Scale Type 1 CAS
0 NONE
1 SAMSUNG SRP-100
2 SRP-250
3 SRP-300
4 SRP-350
5 CITIZEN 3550
6 CITIZEN 810
7 CITIZEN 230
8 EPSON TM T88-2
9 EPSON U200
10 EPSON U295
11 EPSON U300
12 EPSON U325
13 EPSON U375
14 STAR SP-200
15 STAR SP-298
16 STAR SP-300
11 Printer Type
17 STAR TSP-200
0 EPSON
12 Display Type 1 ICD
Preparing the ER-5200M for Communicatons
The register must be ready for communications:
•Connect the register directly to the PC with the appropriate cable. See “Cabling
Diagrams” on page 74.
•The register power must be on.
•A clerk must be signed on.
•The register cannot be inside of a transaction.
•The key lock can be in any position.
It is not necessary to manually place the register in PC Communications mode.
SAM52M will automatically place the register in PC Communications mode when
communications are initiated.
SAM52 User's Manual v2.3 Introduction •5
Starting
1. Click the Start button, click Programs, click SAM52M, and then click SAM52M.exe.
2. The SAM52M main screen displays.
YOU MUST DO THIS FIRST!
Before you can attempt communications or editing, you must create at least one
store. Refer to "Creating a New Store" on page 10.
After creating a store, you must Receive (Upload) information from the ECR.
Refer to "Receive Programs from ECR (Upload)" on page 40.
6 •Introduction SAM52 User's Manual v2.3
Navigating
Mouse and Keyboard
You can choose a menu, menu item, or a command by clicking on it with your mouse.
Viewing Menus and Selecting Menu Items
1. Point at a menu item with your mouse.
2. Point at your choice on the menu and click the left mouse button.
Menu Item
Menu Choices
Tabla de contenidos
