Crestron Isys TPS-12 Manual de usuario

Crestron Isys®TPS-12G/15G-QM-L

Wall Mount Touchpanels

Operations Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names and trademarks are the property of their respective owners.

Crestron Isys®TPS-12G/15G-QM-L Wall Mount Touchpanels

Contents

Crestron Isys®Wall Mount Touchpanels: TPS-12G/15G-QM-L 1

Introduction ........................................................................................................................1

Features and Functions .............................................................................................................. 1

Specifications ............................................................................................................................ 3

Physical Description .................................................................................................................. 5

Industry Compliance................................................................................................................ 14

Setup.................................................................................................................................15

Network Wiring....................................................................................................................... 15

QuickMedia Network Wiring .................................................................................................. 16

Identity Code ........................................................................................................................... 17

Configuring the Touchpanel .................................................................................................... 17

Hardware Hookup.................................................................................................................... 31

Mounting Options.................................................................................................................... 33

Touchpanel Mounting.............................................................................................................. 33

Touchpanel Removal............................................................................................................... 34

Recommended Cleaning.......................................................................................................... 34

Programming Software.....................................................................................................35

Earliest Version Software Requirements for the PC................................................................ 36

Programming with Crestron System Builder ........................................................................... 36

Programming with SIMPL Windows ...................................................................................... 37

Programming with VisionTools Pro-e ..................................................................................... 39

Hard Button Programming ...................................................................................................... 42

MultiByte International Characters.......................................................................................... 43

Uploading and Upgrading.................................................................................................43

Establishing Communications ................................................................................................. 44

Troubleshooting Communications........................................................................................... 53

Uploading a SIMPL Windows Program .................................................................................. 53

Uploading a VT Pro-e Project ................................................................................................. 55

Firmware Upgrade................................................................................................................... 57

Problem Solving ...............................................................................................................60

Troubleshooting....................................................................................................................... 60

Further Inquiries ...................................................................................................................... 61

Future Updates......................................................................................................................... 61

Software License Agreement............................................................................................62

Return and Warranty Policies...........................................................................................64

Merchandise Returns / Repair Service..................................................................................... 64

CRESTRON Limited Warranty............................................................................................... 64

Operations Guide – DOC. 6356 Contents •

Crestron Isys®TPS-12G/15G-QM-L Wall Mount Touchpanels

Crestron Isys®Wall Mount

Touchpanels: TPS-12G/15G-QM-L

Introduction

Features and Functions

The Crestron Isys®TPS-12G-QM-L and TPS-15G-QM-L lectern and wall mount

touchpanels offer high brightness and contrast combined with a super wide viewing

angle to deliver crisp, detailed images under all conditions.

The TPS-G Series provide expanded memory for demanding applications and

graphic intensive GUIs. They also incorporate support for HDTV signals up to 720p

and 1080i, and high-resolution computer graphics up to 1600 x 1200. The

touchpanel’s screens feature a dual-Window display to view full motion video and

high-resolution RGB. The TPS-G Series also includes built-in 10/100BaseT

Ethernet, two QuickMedia (QM) input ports and one QM output.

For simplicity within this guide, these touchpanels are referred to as

TPS-12G/15G-L, except where noted. These touchpanels are QuickMedia™

compatible. The features and specifications (except for screen size and resolution)

for both touchpanels are identical. The TPS-12G/15G-L touchpanels are available

with a variety of color bezels (ex. Black with silver accent, white with gray accent).

Functional Summary

• 12 and 15–inch active matrix color LCD displays.

• Screen resolutions: TPS-12G-QM-L 800 x 600, TPS-15G-QM-L 1024 x

768.

• 16.7 million colors, 24-bit non-palette graphics with color key video

window capability.

• 128 MB of DDR RAM, 64 MB of internal flash expandable to 192 via

compact flash.

• Built-in time-based and gamma correction for stable video and graphics.

• Supports composite, S-video, and component inputs in both NTSC and PAL

formats, HDTV to 720p and 1080i, hi-res computer graphics up to 1600 x

1200.

• Supports QuickMedia™ transport technology, which affords expanded AV

connectivity through a streamlined wiring solution.

• Supports Crestron's QM-based MediaManager products using Crestron

Certified Wiring.

• Dual window capability for viewing full motion video and hi-res RGB.

Continued on the following page

Operations Guide – DOC. 6356 Wall Mount Touchpanels: TPS-12G/15G-QM-L ¥

Wall Mount Touchpanels Crestron Isys®TPS-12G/15G-QM-L

Functional Summary (continued)

•

Full screen video capability.

Built-in annotation allowing presenters to write or draw over computer and

video images on the touchscreen using a finger or stylus.

• Built-in biamplified speaker system and microphone.

• Built-in biamplified audio amplifier, 5W for high frequency, 5W for low

frequency.

• Stores and plays back WAV sound files.

• Headphone jack.

• Two (2) QuickMedia inputs and a single QM output.

• 10BaseT/100BaseTX auto-switching Fast Ethernet, 802.3U compliant, full

duplex.

• Five backlit hard buttons (one reset and four programmable buttons).

TPS-12G/15G-L Block Diagram

¥Wall Mount Touchpanels: TPS-12G/15G-QM-L Operations Guide – DOC. 6356

Crestron Isys®TPS-12G/15G-QM-L Wall Mount Touchpanels

Memory

The TPS-12G/15G-L touchpanels feature 128 MB DDR RAM and 64 MB Flash,

which is expandable to 192 MB.

Sound

Audio capabilities include 5 Watts per channel biamplified audio speakers that offer

built-in volume control, a built-in microphone and built-in WAV sound file

capability. Sound can be generated by the panel by using downloaded wave files

(.WAV) or can be mixed in from two external QuickMedia inputs. The

TPS-12G/15G-L touchpanels are also equipped with a headphone jack and a

QuickMedia output for mic, sound and video.

Video

The TPS-12G/15G-L touchpanels can display two fully-scalable, full motion video

windows, each supporting standard video, HDTV and high-resolution RGB signals

from external AV and computer sources. These units use auto-detect for composite,

S-video or component RGBHV. They support SDTV (NTSC and PAL), EDTV,

HDTV and RGB (VGA) up to UXGA (1600 x 1200). Two QM inputs provide for

connectivity to QuickMedia and touchpanel graphics are available for output via the

QM OUT port.

QuickMedia™

While acting as a QuickMedia (QM) receiver, the TPS-12G/15G-L touchpanels can

be connected as an endpoint to a QM switching device or QM transmitter via

CresCAT-QM cable.

Connectivity

The TPS-12G/15G-L touchpanels feature a Cresnet®and a high-speed Ethernet port

for seamless communication with Crestron control systems, and computers. In

addition, two USB ports are provided for future applications. The bidirectional RS-

232 port transmits touch coordinates to external devices “Touch-The-PC” and other

functions.

Specifications

The following table provides a summary of specifications for the TPS-12G/15G-L.

TPS-12G/15G-L Specifications

SPECIFICATION DETAILS

Cresnet®Power Usage

TPS-12G-L 50 W (1.8 A @ 24 V) Supplied via NET port or power supply

TPS-15G-L 75 W (2.7 A @ 24 V) Supplied via NET port or power supply

Default Net ID 03

Timeout Adjustable from 0 to 120 minutes (Default = 10 min.)

Signal Join Maximums 4000 Digital, 4000 Analog, 999 Serial

Control System Update

Files 1, 2, 3

2-Series Control System

Version 3.137.CUZ or later

Touchpanel Firmware tps-12g-qm_tps-15g-qm_tps-g-tpi_1.002.00015.csf

Memory 64 MB Flash, 128 MB DDR RAM

Memory Expansion Flash memory can be expanded to 192 MB

Continued on the following page

Operations Guide – DOC. 6356 Wall Mount Touchpanels: TPS-12G/15G-QM-L ¥

Wall Mount Touchpanels Crestron Isys®TPS-12G/15G-QM-L

TPS-12G/15G-L Specifications (continued)

SPECIFICATION DETAILS

Video Full screen capable, Auto detect of composite, S-video,

component, NTSC, and PAL 16.7M colors

Time base correction & gamma correction

Supports SDTV 480i (NTSC) & 576i (PAL), EDTV 480p & 576p,

HDTV 720p & 1080i; RGB (VGA) up to UXGA 1600 x 1200

Audio Built-in microphone

Built-in biamplified speakers (5 W, high freq., 5W, low freq.)

Headphone output

Internal volume control and audio mixer

WAV file capability (8-bit PCM Mono, 8kHz sampling rate)

Connectors

NET One 4-pin 3.5 mm detachable terminal block for connection to

Cresnet Control Network. Includes Cresnet Slave Port

USB Two USB 2.0 ports provided for future applications.

RS-232 One 6-pin RJ11 female, computer console port;

Touchscreen output to PC or telestrator;

Bidirectional RS-232 up to 115.2k baud;

Hardware and software handshaking support

Headphones One 3.5 mm stereo TRS mini phone jack, output power 12 mW,

impedance 32 Ohms (nominal)

QM IN Two RJ45 QuickMedia input connectors for both video and audio.

Delay Skew Compensation of 0 to 22nS (Max) on QM Input 1 only.

QM OUT One RJ45 QuickMedia output connector for both video and stereo

audio output with two discrete channels from internal microphone.

LAN One 8-wire RJ-45 Ethernet port with link/activity LED indicators,

10BaseT/100BaseTX high-speed Ethernet, TCP/IP, UDP/IP, CIP,

DHCP, 802.3U compliant, full duplex, auto switching

Buttons Five illuminated pushbuttons, the leftmost button (SW1) is recessed

and is a hardware reset used to reboot the touchpanel, the four

other buttons are user programmable

Display

Type TFT Active Matrix Color LCD

Aspect Ratio TPS-12G-QM-L 4.3 SVGA

TPS-15G-QM-L 4:3 XGA

Resolution TPS-12G-QM-L 800 x 600

TPS-15G-QM-L 1024 x 768

Brightness TPS-12G-QM-L 400 nits

TPS-15G-QM-L 400 nits

Contrast TPS-12G-QM-L 300:1

TPS-15G-QM-L 300:1

Color Depth TPS-12G-QM-L: 18-bit 256k colors

TPS-15G-QM-L: 24-bit, 16.7M colors

Illumination Backlit fluorescent

Viewing Angle TPS-12G-QM-L ±70° horizontal, +45/-55° vertical

TPS-15G-QM-L ±85° horizontal, ±85° vertical

Enclosure Metal enclosure with molded plastic bezel

CPU 32-bit Freescale Coldfire®

Processing Speed 410 MIPS

Operating Environment Temperature: 41° to 113°F (5° to 45°C)

Humidity: 10% to 90% RH (non-condensing)

Continued on the following page

¥Wall Mount Touchpanels: TPS-12G/15G-QM-L Operations Guide – DOC. 6356

Crestron Isys®TPS-12G/15G-QM-L Wall Mount Touchpanels

TPS-12G/15G-L Specifications (continued)

SPECIFICATION DETAILS

TPS-12G-QM-L

Dimensions

Height: 11.80 in (29.98 cm)

Width: 13.61 in (34.57 cm)

Depth: 3.81 in (9.68 cm)

Weight: 8.2 lbs (3.8 kg)-without bezel4

TPS-15G-QM-L

Dimensions

Height: 13.59 in (34.52 cm)

Width: 14.17 in (35.99 cm)

Depth: 3.81 in (9.68 cm)

Weight: 9.8 lbs (4.4 kg)-without bezel4

Accessories BB-12L Pre-Construction Wall Mount Back Box

PMK-12L Pre-Construction Wall Mount Kit

TMK-12L Trim Ring

MMK-12L Mud Ring

WMKT-12L Lectern or Post-Construction Wall Mount Kit with Trim

Ring

WMKM-12L Post-Construction Wall Mount Kit with Mud Ring

RMK-12L Rack Mount Kit

BB-15L Pre-Construction Wall Mount Back Box

PMK-15L Pre-Construction Wall Mount Kit

TMK-15L Trim Ring

MMK-15L Mud Ring

WMKT-15L Lectern or Post-Construction Wall Mount Kit with Trim

Ring

WMKM-15L Post-Construction Wall Mount Kit with Mud Ring

RMK-15L Rack Mount Kit

QM-TX QuickMedia Transmitter

QM-RX QuickMedia Receiver

ST-PK Programming Cable Kit

1 The latest software versions can be obtained from the Crestron website. Refer to the NOTE

following these footnotes.

2 Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product

Catalog for a complete list of 2-Series control systems.

3 When loading VT Pro-e files or firmware through the RS-232 port of the control system, be sure that

the baud rate is at 38400 (Cresnet speed) or lower. Otherwise, Toolbox may post the “Transfer

Failed” message.

4 The TPS-12G-QM-L bezel weighs 0.49 lbs (1.10 kg) and TPS-15G-QM-L bezel weighs 0.46 lbs

(1.0 kg).

NOTE: Crestron software and any files on the website are for authorized Crestron

dealers and Crestron Authorized Independent Programmers (CAIP) only. New users

may be required to register to obtain access to certain areas of the site (including the

FTP site).

Physical Description

The electronic hardware is housed in a metal enclosure with a molded plastic bezel.

Touchpanel bezels for these models are available in black with silver accent or white

with gray accent. This touchpanel is designed for installation in a lectern or a wall.

All audio, RS-232, video, and network connections are made at the rear panel. Two

grills located at the bottom of the unit conceal two speakers. The microphone is

located at the top center, above the touchscreen. Five pushbuttons (one reset and four

programmable) are located on the front, below the touchscreen.

Operations Guide – DOC. 6356 Wall Mount Touchpanels: TPS-12G/15G-QM-L ¥

Wall Mount Touchpanels Crestron Isys®TPS-12G/15G-QM-L

TPS-12G-QM-L

TPS-15G-QM-L

¥Wall Mount Touchpanels: TPS-12G/15G-QM-L Operations Guide – DOC. 6356

Otros manuales para Isys TPS-12

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de Crestron

Crestron

Crestron TSW-560 Dibujo dimensional

Crestron

Crestron TSW-70 Series Manual de usuario

Crestron

Crestron STX-1700CXPW Manual de usuario

Crestron

Crestron SmarTouch ST-1700C Manual de usuario

Crestron

Crestron TSW-732 Manual del propietario

Crestron

Crestron TSW-730 Manual de usuario

Crestron

Crestron Isys TPMC-4SM Instrucciones de funcionamiento originales

Crestron

Crestron Prodigy PTX3 Manual de usuario

Crestron

Crestron TSS-770 Manual de usuario

Crestron

Crestron Smart Touch C2N-IRGW Manual de usuario

Crestron

Crestron Isys TPS-4000 Manual de usuario

Crestron

Crestron TS-1542 Manual de usuario

Crestron

Crestron TSW-560 Manual de usuario

Crestron

Crestron Isys TPS-4500 Manual de usuario

Crestron

Crestron TPMC-V12 & TPMC-V15 Manual de usuario

Crestron

Crestron Isys TPMC-4SM Cómo utilizar

Crestron

Crestron TPMC-3X Series Manual de usuario

Crestron

Crestron TSW-560 Manual del propietario

Crestron

Crestron TSW-550-TTK Dibujo dimensional

Crestron

Crestron STX-1700C Manual de usuario

Crestron

Crestron DTT-15V2 Manual de usuario

Crestron

Crestron Isys TPS-5000 Manual de usuario

Crestron

Crestron TST-602 Manual del propietario

Crestron

Crestron TSCW-730 Dibujo dimensional

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
