Crestron C2N-NPA8 Network Poll Accelerator

Contents

Network Poll Accelerator: C2N-NPA8 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................1

Specifications ..............................................................................................................2

Physical Description....................................................................................................3

Compatible Control Systems.......................................................................................6

Industry Compliance ...................................................................................................7

Setup ..........................................................................................................................................7

Network Wiring........................................................................................................... 7

Mounting Options........................................................................................................8

Hardware Hookup ....................................................................................................... 9

C2N-NPA8-Control System Communications..........................................................13

System Monitoring/Diagnostics with the C2N-NPA8............................................... 17

Adding a C2N-NPA8 Without a Program.................................................................18

Programming Software............................................................................................................19

Earliest Version Software Requirements for the PC .................................................19

Serial Connection Between the Control System and C2N-NPA8 .............................20

Ethernet Connection Between the Control System and C2N-NPA8 .........................21

Uploading and Upgrading........................................................................................................ 22

Communication Settings ...........................................................................................22

Uploading a SIMPL Windows Program....................................................................24

Updating the Operating System................................................................................. 26

Problem Solving ......................................................................................................................27

Troubleshooting the C2N-NPA8 ...............................................................................27

Further Inquiries ........................................................................................................ 30

Future Updates .......................................................................................................... 30

Software License Agreement................................................................................................... 31

Return and Warranty Policies ..................................................................................................33

Merchandise Returns / Repair Service ...................................................................... 33

CRESTRON Limited Warranty.................................................................................33

Operations Guide – DOC. 6087A Contents •i

Crestron C2N-NPA8 Network Poll Accelerator

Network Poll Accelerator:

C2N-NPA8

Introduction

Features and Functions

The Crestron®Network Poll Accelerator (C2N-NPA8) is a device that maintains

high data throughput and low data latency via Cresnet®when a large number of

Cresnet devices communicate with a single 2-Series control system. When connected

to select Crestron 2-Series control systems via a high speed serial or Ethernet

connection, the C2N-NPA8 can provide reliable, high-speed communications

between the control system and up to 252 Cresnet devices.

Functional Summary

• Reliable, high-speed communications between select Crestron 2-Series

control systems and up to 252 Cresnet devices

• Eight segments with four mini-Cresnet connectors per segment

• Independently operated segments provide fault tolerance should an

individual segment fail

• Communicates with select 2-Series control systems via high-speed

serial or 10/100 Base-T Ethernet (refer to “Compatible Control

Systems” on page 6 for a list of compatible control systems)

• Console function to configure device settings and monitor diagnostics

via DB-9 RS-232 connector

• Each Cresnet ID can be viewed with the Network Analyzer

Placing a large amount of Cresnet devices on a control system can slow down

polling time as each Cresnet device is polled sequentially by the control system. By

breaking down the Cresnet system into segments, multiple segments can be polled

simultaneously by the control system, hence improving response time.

Similarly, high-traffic devices such as touchpanels, camera controls, and other

devices require more network bandwidth as they transmit and receive larger amounts

of data. By placing these devices on their own segments, other segments can be used

for low-traffic devices such as wall keypads allowing Cresnet traffic to flow more

efficiently.

Operations Guide – DOC. 6087A Network Poll Accelerator: C2N-NPA8 •1

Network Poll Accelerator Crestron C2N-NPA8

The C2N-NPA8 is typically recommended for networks with 20 or more devices

(not including button panels). Consult with Crestron's True Blue Support to

determine if a C2N-NPA8 would be beneficial to your system.

The C2N-NPA8 is comprised of 32 Cresnet connectors spread over eight segments

(NET A – NET H). These segments, along with the Cresnet port on the control

system allow the connection of up to 252 Cresnet devices.

The C2N-NPA8 is powered by a 24 VDC signal (from a 2-Series control system or

Crestron power supply) applied to the 3-position mini-terminal block connector on

either the NET A or NET B segments. Power is provided to the other segments by

connecting jumper wires to each segment that requires power. Light Emitting Diodes

(LEDs) indicate power and communication activity on each segment.

For detailed information on the C2N-NPA8 input and output ports/connectors, refer

to “Physical Description”.

Specifications

Specifications for the C2N-NPA8 are provided below.

C2N-NPA8 Network Poll Accelerator Specifications

SPECIFICATION DETAILS

Power Requirements 10 Watts (0.42 Amp @ 24VDC)

Supplied from control system or Crestron power

supply

Connectors/Ports

PWR

NET

LAN

COMPUTER

COM

8 – 3-position mini-terminal block connector. Provides

24V input (from power supply or powered segment)

and 24V output (to segment on C2N-NPA8). One per

segment.

32 – Cresnet 4-position mini-terminal block

connectors, divided over 8 segments

1 – RJ45 10/100 Base-T Ethernet port

1 – DB9F PC Interface for console functions

1 – DB9F Interface for high-speed serial connection to

control system

Cresnet Devices Supported 2521

Firmware V3105.CUZ or later

Control System Update Files2,3

2-Series Control System

MP2/MP2E/MC2E/MC2W

Version C2.V3112.CUZ or later

Version MP2.V3112.CUZ or later

Environmental Temperature 41° to 113°F (5° to 45°C)

Humidity 10% to 90% RH (non-condensing)

Rack Space 3 Rack Units when used with optional C2N-RMAK

Dimensions & Weight Height: 5.19 in (13.18 cm)

Width: 13.25 in (33.66 cm)

Depth: 3.42 in (8.69 cm)

Weight: 1.91 lb (0.87 kg)

1. A control system can address 252 devices (NET IDs 03 to FE).

2. The latest versions can be obtained from the Downloads | Software Updates section of the Crestron

website (www.crestron.com). Refer to NOTE below.

3. Crestron 2-Series control systems include the AV2, PAC2, PRO2, and RACK2. For a complete list

of compatible control systems, refer to “Compatible Control Systems” on page 6.

NOTE: Crestron software and any files on the website are for Authorized Crestron

dealers and Crestron Authorized Independent Programmers (CAIP) only. New users

may be required to register to obtain access to certain areas of the site (including the

FTP site).

2 •Network Poll Accelerator: C2N-NPA8 Operations Guide – DOC. 6087A

Crestron C2N-NPA8 Network Poll Accelerator

Physical Description

The C2N-NPA8 Network Poll Accelerator is housed in a black enclosure with

labeling on the front panel. Refer to the following illustrations for a detailed view.

C2N-NPA8 Physical View

C2N-NPA8 Physical Views

12.25 in

(31.12 cm)

3.00 in

(7.62 cm)

5.19 in

(13.18 cm)

4.00 in

(10.16 cm)

12.75 in

(32.39 cm)

13.25 in

(33.66 cm)

3.42 in

(8.69 cm)

Operations Guide – DOC. 6087A Network Poll Accelerator: C2N-NPA8 •3

Network Poll Accelerator Crestron C2N-NPA8

Ports/Connectors

The ports/connectors on the top panel of the C2N-NPA8 are described in the

following paragraphs.

NOTE: Interface connectors for the PWR and NET ports are provided with the

C2N-NPA8.

NET A - H

These eight segments provide 32 standard (24 Y Z G) Cresnet connectors (in groups

of four) for Cresnet device connections. Each group of four supports 32 electrical

Cresnet connections.

NOTE: Although there are eight segments with four connectors each, a control

system can only address 252 devices (03 through FE).

POWER

These connectors (quantity eight) are used to supply 24VDC power to each segment

as well as providing a jumping point for powering another segment on the

C2N-NPA8. To power the C2N-NPA8, 24VDC power must be supplied to a Cresnet

connector or the power connector on NET A or NET B. For more details, refer to

“Power Connections” on page 12.

CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to do

so could cause equipment damage or void the Crestron warranty.

LAN

An 8-position RJ45 port is used for an Ethernet connection to a control system with

Ethernet capabilities. Refer to the following table for the Ethernet connector signals

and use an appropriate cable (not supplied). For information on connecting the LAN

port to a control system, refer to “Configuring for TCP/IP Communications” on

page 15.

NOTE: Only one C2N-NPA8 can be connected to a control system.

LAN Connector Specifications

TYPE PIN SIGNALS

1 TD+

2 TD-

3 RD+

4 Connected to pin 5

5 Connected to pin 4

6 RD-

7 Connected to pin 8

8-Position

RJ45

8 Connected to pin7

Front

Top

NOTE: To determine which is pin 1 on the cable, hold the cable so that the end of

the eight pin modular jack is facing away from you, with the clip down and copper

side up. Pin 1 is on the far left.

4 •Network Poll Accelerator: C2N-NPA8 Operations Guide – DOC. 6087A

Crestron C2N-NPA8 Network Poll Accelerator

COMPUTER

This DB9 (female) connector is used for console purposes. The C2N-NPA8’s

Ethernet configuration settings and diagnostics can be accessed through this port. The

port is modem compatible. The modem and/or PC program cable are not included.

Supports baud rate of up to 115 Kb. Use with a standard DB9 straight through cable

(Crestron cable number CNSP-587 or equivalent). Refer to the following table for the

cable pinouts. For information on establishing serial communications with the

C2N-NPA8, refer to “Establish a Serial Connection” on page 14.

Standard DB9 Pin Assignments

PIN # ABBREVIATION DESCRIPTION

1 N/A Not Connected

2 RD Receive Data

3 TD Transmit Data

4 N/A Not Connected

5 SG Signal Ground

6 N/A Not Connected

7 RTS Request To Send

8 CTS Clear To Send

9 N/A Not Connected

5 4 3 2 1

9 8 7 6

Female DB9 Connector

6 7 8 9

1 2 3 4 5

Male DB9 Connector

NOTE: DTR, pin 4 and DSR, pin 6 are not normally used.

COM

This DB9 (female) bi-directional serial port is used for high-speed serial

communication between a control system and the C2N-NPA8. Use with a DB9

straight through cable (Crestron cable number CNSP-587 or equivalent).

NOTE: Crestron has successfully tested 50-foot serial cable runs without loss of

signal quality. Cable runs in excess of 50 feet may be subject to signal degradation

or errors as cable length increases.

NOTE: Only one C2N-NPA8 can be connected to a control system.

Indicators

The C2N-NPA8 indicators are described in the following paragraphs.

NET A - H

The eight NET (A-H) activity LEDs illuminate when a device on the respective

segment transmits and/or receives data.

PWR (Power)

This LED illuminates when a segment is connected to and receives 24 VDC power

from an external power pack or a Crestron control system.

LNK

This LED illuminates when there is a connection to the LAN port.

Operations Guide – DOC. 6087A Network Poll Accelerator: C2N-NPA8 •5

Network Poll Accelerator Crestron C2N-NPA8

ACT

This LED illuminates when there is communication (activity) at the LAN port with

an Ethernet network.

ERR

This LED illuminates when an error condition is detected. This may be the result of

hardware or software failure, or a programming error. To determine the actual error

condition, examine the message available through the Viewport menu

Functions | 2-Series | Error Log | Show Error Log. Refer to the note on page 22

for a definition of Viewport.

Compatible Control Systems

The C2N-NPA8 is compatible with several Crestron 2-series control systems.

However, not all of the 2-series products are compatible with the C2N-NPA8. The

following table lists 2-series control systems (that are currently available as of this

writing) that are compatible with the C2N-NPA8 as well as the communication

methods that can be used.

Processor Compatibility

PROCESSOR SERIAL ETHERNET

AV2 YES1YES4

C2N-DVP4DI NO YES

CNX-DVP4 NO YES

CP2 YES3NO

CP2E YES3YES

MC2E YES3YES

MC2W YES3NO

MP2 YES3NO

MP2E YES3YES

PAC2 NO YES4

PRO2 YES1YES4

QM-RMC NO NO

QM-RMCRX NO NO

RACK2 NO YES4

1. COM ports C through F are poll accelerator-ready

2. COM ports A through C are poll accelerator-ready

3. COM ports A and B are poll accelerator-ready

4. Requires installation of C2ENET-1 or C2ENET-2 Ethernet card.

NOTE: Control systems cannot use a plug in serial card (i.e. a C2COM-3) to

communicate with the C2N-NPA8.

6 •Network Poll Accelerator: C2N-NPA8 Operations Guide – DOC. 6087A

Otros manuales para C2N-NPA8

Tabla de contenidos

Otros manuales de Hardware de red de Crestron

Crestron

Crestron DMC-C Manual de usuario

Crestron

Crestron 8 Channel Dimmer Module CLX-1DIM8 Manual de usuario

Crestron

Crestron QM-IEM Manual de usuario

Crestron

Crestron C2N-HBLOCK Manual de usuario

Crestron

Crestron Network Device PWE-4803RU Manual de usuario

Crestron

Crestron HDMI Input Card DMC-HD Manual de usuario

Crestron

Crestron CEN-NSP-1 Manual de usuario

Crestron

Crestron 4 Channel Dimmer Module CLX-1DIM4 Manual de usuario

Crestron

Crestron DM-TX-200-C-2G Cómo utilizar

Crestron

Crestron QM-WMC Guía de inicio rápido

Crestron

Crestron UC-CAM-UPGRD-300 Manual de usuario

Crestron

Crestron HZA-PWR-15A Manual de usuario

Crestron

Crestron C2N-NPA8 Manual de usuario

Crestron

Crestron 8 Channel Dimmer Module CLX-2DIM8 Manual de usuario

Crestron

Crestron CEN-NVS200 Cómo utilizar

Crestron

Crestron CEN-IO Manual de usuario

Crestron

Crestron NAT Manual de usuario

Crestron

Crestron 2 Channel Inductor Module CLX-2IND Manual de usuario

Crestron

Crestron RACK2 Manual de usuario

Crestron

Crestron STIRP Manual de usuario

Crestron

Crestron AV2 Manual de usuario

Crestron

Crestron STS Manual de usuario

Crestron

Crestron Zum ZUMMESH-NETBRIDGE Manual de usuario

Crestron

Crestron CNXLIR Manual de usuario

Manuales populares de Hardware de red de otras marcas

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manual de usuario

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manual de usuario

Yudor

Yudor YDS-16 Manual de usuario

D-Link

D-Link ShareCenter DNS-320L Manual de usuario

Samsung

Samsung ES1642dc Instrucciones de uso

Honeywell Home

Honeywell Home LTEM-PV Instrucciones de montaje

evertz

evertz 7700 Series Manual de usuario

D-Link

D-Link ShareCenter DNS-343 Manual de usuario

Asante

Asante AsanteBridge 1012 Manual de usuario

FireBrick

FireBrick FB2700 Manual de usuario

Audiovox Electronics

Audiovox Electronics ARWH2T Manual de usuario

ADC

ADC DSX-1 Manual

NetComm

NetComm NF2 Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 5620 Manual de usuario

Dell EMC

Dell EMC XC6420 Series Manual de usuario

Lanner

Lanner NCA-1020A Manual de usuario

Allied Telesis

Allied Telesis AT-TN121-A Manual de usuario

Arista

Arista CCA-ETM-Q12 Manual de usuario
