Crestron SR9600 Guía de configuración

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

GENERAL INFORMATION

SIMPLWINDOWS NAME: Marantz SR9600

CATEGORY: Receiver/Processor

VERSION: V1.0

SUMMARY: This module controls and provides true feedback for the Marantz SR9600.

GENERAL NOTES: This module provides control for both zones on the SR9600. It also provides true

feedback.

NOTE: IN THE PREFERENCES MENU, YOU MUST SET THE STBY MODE TO NORMAL.

IF YOU DO NOT CHANGE THIS SETTING, YOU WILL NOT BE ABLE TO TURN THE

RECEIVER ON VIA RS232.

NOTE: THIS MODULE IS FOR 2 SERIES PROCESSORS ONLY.

CRESTRON HARDWARE REQUIRED: C2COM, ST-COM

SETUP OF CRESTRON HARDWARE: RS232

Baud: 9600

Parity: None

Data Bits: 8

Stop Bits: 1

VENDOR FIRMWARE: None

VENDOR SETUP: IN THE PREFERENCES MENU, YOU MUST SET THE STBY MODE TO NORMAL. IF YOU

DO NOT CHANGE THIS SETTING, YOU WILL NOT BE ABLE TO TURN THE RECEIVER

ON VIA RS232.

CABLE DIAGRAM: CNSP-123

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

CONTROL:

RX$ S Serial signal to be routed from a 2-way serial com port.

power_on/off/toggle D Pulse to turn the receiver on and off.

input_* D Pulse to select the input.

input_mode_cyclic/auto D Pulse to set the input mode.

input_*_fixed D Pulse to set the input type to digital fixed or analog fixed.

volume_up/down D Press and hold to adjust the volume.

audio_mute_on/off/toggle D Pulse to turn the volume mute on and off.

volume_value(-80d_to18d) A Analog signal to allow for direct volume level setting.

volume_set_direct D Pulse to set the volume to the level value on volume_value(-80d_to_18d)

immediately.

volume_set_gradual D Pulse to set the volume to the level value on volume_value(-80d_to_18d)

gradually.

attenuator_on/off/toggle D Pulse to turn the attenuator on and off.

bass/treble_up/down D Pulse to adjust the bass or treble.

video_mute_on/off/toggle D Pulse to turn the video mute on and off.

display_cyclic/input/level/auto_off/off D Pulse to set the receiver’s front panel to input, surround, auto off, or off.

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

speaker_*_on/off/toggle D Pulse to turn speaker a or b on and off.

sleep_timer_off D Pulse to turn the sleep timer off.

sleep_timer_*min D Pulse to set the sleep timer for the desired number of minutes.

sleep_set_cyclic D Pulse to cycle the sleep timer.

osd_on/off/toggle D Pulse to turn the on screen display on and off.

night_mode_on/off/toggle D Pulse to turn the night mode on and off.

DC_trig1/2/3/4_on/off D Pulse to turn the DC trigger 1, 2, 3 or 4 on and off.

re-EQ_on/off/toggle D Pulse to turn the re-EQ on and off.

bilingual_main/sub/main+sub/cyclic D Pulse to set the bilingual mode.

setup_menu_on/off/toggle D Pulse to turn the set up menu on and off.

menu_cursor_enter/up/down/left/right D Pulse to control the cursor.

surr._mode_change_next/prev D Pulse to go the next or previous surround mode.

surr._* D Pulse to select the surround mode.

surr._THX_on/off/toggle D Pulse to turn the THX mode on and off.

dolby_HP_change D Pulse to select the Dolby headphone mode.

dolby_HP_* D Pulse to directly select the Dolby headphone mode.

test_tone_on/off/toggle D Pulse to turn the test tone mode on and off.

test_tone_channel_next/prev D Pulse to change the test tone oscillation channel.

channel_select_disp._on/off/toggle D Pulse to turn the channel select display on and off.

lip_sync_off D Pulse to turn the lip sync adjustment off.

lip_sync_up/down D Pulse to adjust the lip sync delay by 10 msec.

tuner*_mode_auto_stereo/mono/toggle D Pulse to set the FM tuner to auto stereo or mono.

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

tuner*_freq_up/down D Press and hold to adjust the tuner frequency.

tuner*_auto_* D Pulse to start and stop the tuner auto tune function.

tuner*_preset_up/down D Pulse to step to the next or previous tuner preset.

tuner*_preset_scan_start/stop D Pulse to start and stop the tuner preset scan function.

tuner*_key* D Pulse to enter either the tuner frequency or tuner preset number. You must pulse

the tuner_freq_num_direct_set input or the tuner_preset_num_call input.

tuner*_preset_num_call D Pulse to select the preset number entered using the tuner_key* inputs.

tuner*_freq_num_direct_set D Pulse to select the tuner frequency entered using the tuner_key* inputs.

tuner*_rds_disp(only_EU_Ver.) D Pulse to turn the rds on and off. Only available on European models.

tuner*_rds_pty(only_EU_Ver.) D Pulse to turn the rds pty function on and off. Only available on European models.

mr*_power_on/off_toggle D Pulse to turn the mutli-room power on and off.

ms*_power_on/off/toggle D Pulse to turn the multi-room speaker on and off.

mr*_input_* D Pulse to select the multi-room input.

mr*_volume_up/down D Press and hold to adjust the multi-room volume.

mr*_audio_mute_on/off/toggle D Pulse to turn the multi-room volume mute on and off.

mr*_osd_on/off D Pulse to turn the multi-room on screen display on and off.

mr*_sleep_timer_off D Pulse to turn the multi-room sleep timer off.

mr*_sleep_timer_*min D Pulse to set the multi-room sleep timer for the desired number of minutes.

mr*_sleep_set_cyclic D Pulse to cycle the sleep timer.

mr*_tuner*_mode_auto_stereo/mono/toggle D Pulse to set the multi-room FM tuner to auto stereo or mono.

mr*_tuner*_freq_up/down D Press and hold to adjust the multi-room tuner.

mr*_tuner*_auto_* D Pulse to start and stop the tuner auto tune function.

mr*_tuner*_preset_up/down D Pulse to step to the next or previous preset.

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

mr*_tuner*_preset_scan_start/stop D Pulse to start and stop the preset scan function.

mr*_tuner*_preset_num_call D Pulse to call the tuner preset number.

mr*_tuner*_freq_num_direct_set D Pulse to directly set the tuner frequency.

auto_status_on/off D Pulse to turn the auto status function on and off.

FEEDBACK:

TX$ S Serial signal to be routed to a 2-way serial com port.

power_on/off_fb D High to indicate the current power state for the main zone.

video_input_*_fb D High to indicate the currently selected video input.

audio_input_*_fb D High to indicate the currently selected audio input.

input_mode_analog/digital_autoselected_fb D High to indicate the currently auto selected input type.

input_analog/digital_fixed_fb D High to indicate the currently manually selected input type.

volume_bar A Analog value indicating the current volume level. To be displayed using a bar

graph on a touch panel.

volume$ S Serial signal indicating the current volume level in dB. This is the same as the

front panel of the receiver.

audio_mute_on/off_fb D High to indicate the current state of the volume mute.

attenuator_on/off_fb D High to indicate the current state of the attenuator function.

bass/treble_bar A Analog values indicating the current bass or treble level. To be displayed using

bar graphs on a touch panel.

bass/treble$ S Serial signal indicating the current bass and treble level. This is the same as the

front panel of the receiver.

video_mute_on/off_fb D High to indicate the current state of the video mute.

display_input/level/auto_off/off_fb D High to indicate the currently selected front panel display mode.

speaker_*_on/off_fb D High to indicate the current state for speakers a and b.

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

sleep_timer_off_fb D High to indicate that the sleep timer is off.

sleep_timer_bar A Analog value indicating the time remaining before the sleep mode will turn the

receiver off. To be displayed using a bar graph on a touch panel.

sleep$ S Serial signal indicating the sleep time remaining.

osd_on/off_fb D High to indicate the current state of the on screen display.

night_mode_on/off_fb D High to indicate the current state of the night mode.

DC_trig1/2/3/4_on/off_fb D High to indicate the current state of the DC triggers 1, 2, 3 & 4.

re-EQ_on/off_fb D High to indicate the current state of the re-EQ.

bilingual_main/sub/main+sub_fb D High to indicate the current state of the bilingual function.

setup_menu_on/off_fb D High to indicate the current state of the setup menu.

surr._*_fb D High to indicate the currently selected surround mode.

dolby_HP_*_fb D High to indicate the currently active headphone mode.

test_tone_on/off_fb D High to indicate the current state of the test tone.

test_tone_auto/manual_mode_fb D High to indicate the current test tone mode.

test_tone_ch_*_fb D High to indicate the current channel of test tone.

channel_select_disp._on/off_fb D High to indicate the current state of the channel select display.

lip_sync_off_fb D High to indicate that the lip sync function is currently off.

lip_sync_bar A Analog value indicating the current lip sync delay. To be displayed using a bar

graph on a touch panel.

lip_sync$ S Serial signal indicating the current lip sync delay.

tuner*_stereo/mono_fb D High to indicate the current stereo/mono mode of the tuner.

tuner*_frequency_fm A Analog value indicating the currently tuned FM channel. To be display using a

digital gauge in the format XXX.XX.

tuner*_frequency_am A Analog value indicating the currently tunes AM channel. To be displayed using a

digital gauge in the format XXXX.

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

tuner*_freq.$ S Serial signal indicating the current tuner frequency.

tuner*_preset_number A Analog value indicating the currently selected tuner preset number.

tuner*_keyin_value A Analog value indicating the current value entered using the tuner_key* inputs.

mr*_power_on/off_fb D High to indicate the current power state of the multi-room zone.

ms*_power_on/off_fb D High to indicate the current power state of the multi-room speaker.

mr*_video_input_*_fb D High to indicate the currently selected video input for the multi-room zone.

mr*_audio_input_*_fb D High to indicate the currently selected audio input for the multi-room zone.

mr*_volume_bar A Analog value indicating the current volume level for the multi-room zone. To be

displayed using a bar graph on a touch panel.

mr*_volume$ S Serial signal indicating the current volume level for the multi-room zone. This is

the same as on the front panel of the receiver.

mr*_audio_mute_on/off_fb D High to indicate the current state of the multi-room volume mute.

mr*_volume_variable/fixed_fb D High to indicate whether the multi-room volume is variable or fixed.

mr*_osd_on/off_fb D High to indicate the current state of the multi-room zone on screen display.

mr*_sleep_timer_off_fb D High to indicate that the multi-room sleep timer is off.

mr*_sleep_timer_bar A Analog value indicating the time remaining before the sleep mode will turn the

multi-room zone off. To be displayed using a bar graph on a touch panel.

mr*_sleep$ S Serial signal indicating the sleep time remaining for the multi-room zone.

mr*_tuner*_stereo/mono_fb D High to indicate the current multi-room tuner stereo/mono mode.

mr*_tuner*_frequency_fm A Analog value indicating the currently tuned FM channel for the multi-room tuner.

To be display using a digital gauge in the format XXX.XX.

mr*_tuner*_frequency_am A Analog value indicating the currently tunes AM channel for the multi-room tuner.

To be displayed using a digital gauge in the format XXXX.

mr*_tuner*_freq.$ S Serial signal indicating the current tuner frequency.

mr*_tuner*_preset_number A Analog value indicating the currently selected tuner preset number for the multi-

room tuner.

Partner: Marantz

Model: SR9600

Device Type: Surround Receiver

tuner*_busy__fb D High to indicate that the selected tuner is busy.

auto_status_on/off_fb D High to indicate the current state of the auto status function.

signal_*_fb D High to indicate the type of digital audio signal received.

sampling_*_fb D High to indicate the sampling rate of the received digital signal.

ch_status_*_fb D High to indicate the active channels for the received digital signal.

TESTING:

OPS USED FOR TESTING: PRO2: 3.137

COMPILER USED FOR TESTING: 2.06.20

SAMPLE PROGRAM: Marantz SR9600 Demo PRO2

REVISION HISTORY: V. 1.0

Este manual sirve para los siguientes modelos

Otros manuales de Cables y conectores de Crestron

Crestron

Crestron SmartPresenter SPC-124 Manual de usuario

Crestron

Crestron SP-CBL Manual de instrucciones

Crestron

Crestron ZUMLINK-CONV-CN Manual de usuario

Crestron

Crestron ST-SPL Manual de usuario

Crestron

Crestron FT-PWR Cómo utilizar

Crestron

Crestron SmartPresenter SPC-121 Manual de usuario

Crestron

Crestron CBL-USB-RS232KM-6 Manual de usuario

Crestron

Crestron SmartPresenter SPC-122 Manual de usuario

Crestron

Crestron SmarTouch ST-112 Manual de usuario

Crestron

Crestron Four-Way Amplified Splitter SRD-SPL-4 Manual de usuario

Crestron

Crestron FT2-700-ELEC Series Manual de usuario

Crestron

Crestron QM-FTCMK Manual de usuario

Crestron

Crestron C2N-TXM-C50 Manual de usuario

Crestron

Crestron TPMC-CBL-T Manual de usuario

Crestron

Crestron TPSBLOCK-10 Manual de usuario

Crestron

Crestron DM-8G-CONN-100 Manual de usuario

Crestron

Crestron DigitalMedia Connectors DM-CONN-20 Manual del propietario

Crestron

Crestron FlipTop FT2A-CBLR-1T Series Manual de usuario

Crestron

Crestron FT2A-CP-USBA Manual de usuario

Crestron

Crestron SmartPresenter SPC-550 Manual de usuario

Crestron

Crestron UC-B-ACCY Manual de usuario

Crestron

Crestron FlipTop CBLR2 Series Manual de usuario

Crestron

Crestron FT2A-CP Series Manual de usuario

Crestron

Crestron FlipTop FT2 Series Manual de usuario

Manuales populares de Cables y conectores de otras marcas

Philips

Philips SWA6310 Manual de usuario

StarTech.com

StarTech.com CRJ4550PK Manual de usuario

Nohau

Nohau EMUL-IP2K-PC Manual de usuario

Foxun

Foxun SX-SP144E-HD4K2K Manual de usuario

Philips

Philips SWA3305W Manual de usuario

opticis

opticis Stretch DVIM1-1P0x Manual de usuario

Volkswagen

Volkswagen VAS 6558A Manual de usuario

NEXIBO

NEXIBO N-13 Manual de usuario

CYP

CYP PU-1H3HBTL Manual de usuario

Allen-Bradley

Allen-Bradley 1784-u2dhp Manual de usuario

Global Caché

Global Caché Flex Link Blaster Manual de usuario

Hauppauge

Hauppauge USB-Live2 Manual de usuario

Fenix

Fenix MPSV 15 Manual de usuario

BEGA

BEGA 71 085 Manual de usuario

Tesla

Tesla HPWC Manual de usuario

GAMERON

GAMERON LUXURY TV CABLE Manual de usuario

molex

molex Milli-Grid Dual row 87568 Series Manual de usuario

Burndy

Burndy Continental Industries thermOweld CRE-7 Manual de usuario
