Creda Sunplus CSP2 Manual del instalador

+44 (0) 1733 456789 www.creda-heating.co.uk

Model Reference Rating Product description Height A Width B Width C

CSP2 75 775201 2kW Sunplus outdoor patio heater 159mm 594mm 144mm

CSQAD 85 822084 Sunquartz autodriver PIR

Sunplus

Outdoor patio heaters

Product Selector

Sunplus heaters give instant heat,

are quick to install and only require

minimal maintenance, contrasting gas

patio heaters, which also have bulky and

costly gas bottles to deal with. Sunplus

heaters give heat at the flick of a switch

and heat like the sun. The radiant heat

passes through the air and heats solid

objects making it highly efficient wherever

it’s installed, making them the ideal

outdoor heating solution.

The heaters transmit harmless infra-red

radiant energy, like the sun, that turns into

heat only when it comes into contact with

a solid object such as people.

So you’re not heating the atmosphere or

having the heat blown away in the wind -

unlike outdoor gas heaters.

Key features

• Low running costs as Radiant heat heats solid

objects not the air

• Instant heat cuts the cost of outdoor heating overall

• Silent running with no moving parts or noisy

naked flames

• Low capital cost as these heaters allow you to

select fewer heaters, but place them exactly where

the heating need is

• When used with PIR sensors, further energy

savings are available

Gold finish halogen lamp

The gold quartz halogen lamp fitted to

the Sunplus runs at up to 2,200°C

and offers extended performance and

15% greater transmission.

Control options

Sunquartz autodriver

Ref: 85 822084

• Element - 2kW gold quartz halogen lamp

• Finish - high quality aluminium case in silver

• Reflector - high performance polished reflector

• Fitted guard included

• IP rating - IP24 (splashproof)

• Supply - 230/240V AC single phase

Technical Specification

“The new Sunplus outdoor

heater provides a safe,

efficient and easy answer for

outdoor heating. ”

Dimensions

Commercial

space heating

Model Reference Rating Number of lamps Height A Width B Depth C

CSQ1.5 75 771801 1.5kW 1 185mm 390mm 115mm

CSQ2.0 75 771802 2kW 1 185mm 390mm 115mm

CSQ3.0 75 771803 3kW 2 370mm 390mm 115mm

CSQ4.0 75 771804 4kW 2 370mm 390mm 115mm

CSQ4.5 75 771806 4.5kW 3 555mm 390mm 115mm

CSQ6.0 75 771807 6kW 3 555mm 390mm 115mm

CSQAD 85 822084 Sunquartz autodriver PIR

Sunquartz

Shortwave infra-red radiant heaters

Product Selector

Their uses are endless, from warehouses

to churches. These efficient sun-like

heaters can penetrate damp air with

minimum heat loss to the atmosphere.

Key features

• Up to 90% efficient at converting electricity

into energy

• Instant sensation of heat with visible glow at

switch on

• Absolutely silent in operation

• Long range heat projection

• Modular design

• Lightweight and silent

• Fitted with wire guard for safety

• 1 and 2 lamp units are suitable for a 230-240V

single phase supply

• 3 lamp units are supplied wired for single phase

supply but can be connected to a 380-415 volt

3 phase supply

Control options

PIR automatic controller senses movement

detected within its range and automatically

switch on the heater which will remain

switched on for a preset time.

The unit is suitable for 500W-6,000W

single phase operation. Soft start circuitry

is incorporated to reduce the inrush

current, allowing cables and fusegear to

be rated as for resistive loads and

extending lamp life.

The PIR range is adjustable and a

temperature hold-off facility will inhibit

operation when ambient temperatures

exceed a value selected between 10°C

and 20°C.

Sunquartz autodriver

Ref: 85 822084

• Tungsten halogen lamps, 230/240V with ruby red

quartz outer sleeve

• Reflectors bright rolled, specular 99.8%

aluminium, electro-chemically brightened

• Electro zinc coated steel casing

• High pressure die cast aluminium end castings

• Epoxy polyester powder paint finish white/grey

• Supply - 230/240V AC single phase (3 lamp units

can be connected to a 380/415V 3 phase supply)

Technical Specification

“Instant heat right where

it’s needed. Sunquartz

short wave infra-red

heaters warm people,

not the air. ”

Dimensions

Commercial

space heating

36 +44 (0) 1733 456789 www.creda-heating.co.uk

Model Reference Rating Height A Width B Depth C

CCR2 75 771701 2kW 340mm 376mm 140mm

CCR3 75 771702 3kW 340mm 376mm 140mm

CCR45 75 771703 4.5kW 440mm 376mm 140mm

Ceramic Emitters

Long wave infra-red heaters

Product Selector

Dimensions

These heaters incorporate dual ceramic

emitters to rapidly convert electrical

energy into heat energy without

producing light.

With no moving parts, these heaters are

virtually maintenance-free.

Key features

• Durable ceramic emitters which rapidly convert

electrical energy into heat energy

• Available in 2, 3 and 4.5kW versions

• No fans or moving components, so no dust

contamination to the environment

• Low maintenance

• Good vibration resistance

• Fitted with wire safety guards

• Robust fitting brackets

• Ideal for commercial and industrial

application where glare free heat is required

• Element - ceramic emitter

• Grey painted steel casing

• Supply - 230/240V AC single phase

“Long wave infra-red heaters

offer highly efficient, silent,

space heating. ”

Technical Specification

Ceiling Ceiling

Floor Floor

Wall

Heating index Applications 2kW 3kW 4.5kW

130-150W/m2Shops, meeting halls 7.2m212.0m218.8m2

150-170W/m2Offices, canteens 6.8m211.3m217.7m2

170-200W/m2Workshops, garages 6.0m210.0m215.7m2

220-240W/m2Churches 4.7m27.8m212.3m2

Rating Height A Height B Height C

2kW 1800 300 200

3kW 2500 300 300

4.5kW 3000 500 500

Area of coverage at minimum mounting height

Commercial

space heating

+44 (0) 1733 456789 www.creda-heating.co.uk

Model Reference Rating Height A Width B Depth C

CSL2 75 771601 2kW 108mm 1,215mm 71mm

CSL3 75 771602 3kW 108mm 1,671mm 71mm

Sunslim

Commercial radiant heaters

Product Selector

The Sunslim can be wall-mounted or

ceiling hung.

Key features

• Instant, directional radiant heat

• Available in 2kW and 3kW versions

• Completely silent in operation

• Lightweight and robust

• Corrosion resistant

• Suitable for bracket or chain mounting

• Easy to install

• Ideal for localised heating in large covered

areas such as factories and workshops

“Sunslim is a low cost,

robust and easy to install

radiant heater. Its tilt

mounting allows heat to be

localised, or directed to a

general area.

”

• Element - ‘black heat’ type

• Zinc coated steel body/matt black end caps

• Chrome plated steel guards

• Anodised aluminium reflector

• Supply - 230/240V AC single phase

• Minimum mounting height 2 metres

• 300mm minimum clearance above the heater

• 500mm minimum clearance on either side

• Installation notes: High temperature cable must

be used. We recommend the use of a residual

current device (RCD)

Dimensions

Technical Specification

0.3

0.1

2.0 2.0

0.5

Sunslim - Minimum

mounting distances

(metres)

Sunslim heated area

Heating index 3kW 2kW

HL WH L W

10 4.0 5.24 5.49 3.3 4.11 4.53

12 3.6 4.88 4.94 3.0 3.84 4.12

14 3.2 4.51 4.39 2.7 3.57 3.70

16 3.5 4.33 4.12 2.5 3.38 3.43

18 2.8 4.14 3.84 - - -

H = mounting height (determined by on-site requirements) L = length of the heated area W = width of the heated area

Commercial

space heating

38 +44 (0) 1733 456789 www.creda-heating.co.uk

Model Reference Guard short code* Rating Diameter A Length B Depth C

CST1 75 771501 STG1 60 Watts 52mm 410mm 75mm

CST2 75 771502 STG2 120 Watts 52mm 670mm 75mm

CST3 75 771503 STG3 180 Watts 52mm 980mm 75mm

CST4 75 771504 STG4 240 Watts 52mm 1,280mm 75mm

CST5 75 771505 STG5 300 Watts 52mm 1,590mm 75mm

CST6 75 771506 STG6 360 Watts 52mm 1,890mm 75mm

CSIK 85 731506 Interlinking kit

Suntube

Tubular heaters

Product Selector

They are highly effective as window

demisters and for horticultural use,

providing invaluable, effective heating and

frost protection in greenhouses and

conservatories.

Key features

• 60-360W outputs

• A range of 6 lengths and loadings

• Complete with universal mounting brackets

for floor or wall fixing and 1m white cable

Optional accessories

Interlinking kit

Available for multiple installations

(100mm mounting centres).

Ref: 85 731506

STG guards*

We recommend the use of guards

for additional security in sensitive

areas such as schools, hospitals and

care homes.

These can be obtained from C.Ainao Ltd.

Tel: 020 7987 1184

• Elements metal sheathed throughout

• Polyester epoxy powder coated aluminium body

• High temperature glass filled nylon end caps

and brackets

• Supply - 230/240V AC single phase

Technical Specification

“Suntubes are the perfect

answer where a steady

energy efficient source of

heat is needed, providing

gentle background warmth

and frost protection for

both domestic and

commercial applications.”Dimensions

Commercial

space heating

+44 (0) 1733 456789 www.creda-heating.co.uk

Model Reference Rating Noise level @3m Height A Width B Depth C

CSF3 75 771401 3kW 40.5dBA 229mm 267mm 260mm

CDCS 82 815906 Dual control switch

Sunfan

High level fan heater

Product Selector

Key features

• High air volume throughput of 300m3/hour

• Quiet running, totally enclosed motor

• Wall mounted with 2 part self supporting bracket

• Multi-directional adjustment of 45° vertically

and 150° horizontally with single screw locking

• High level heating/cooling - ideal for shops

and warehouses where wall space is at a premium

• Double insulated

• Supplied complete with variable thermostatic

controller

Thermostatic controller (included)

For remote switching on/off and variable

thermostatic control.

Control options

For remote switching on/off and

hot/cold air circulation.

Dual control switch (optional)

Ref: 82 815906

• Flame retardant polycarbonate/glass filled

nylon body

• Single phase, 4 pole motor

• Two tone grey (neutral colours)

• Protection - Two thermal cut-outs

• Supply - 230/240V AC single phase

• Minimum mounting height 1.8 metres

• 150mm minimum clearance above the heater

• 300mm minimum clearance on either side

Technical Specification

“Sunfan is a robust 3kW

high volume air throughput

commercial/industrial wall

mounted fan heater

designed to provide highly

efficient heating in winter,

or cool air circulation

in summer. ”Dimensions

Commercial

space heating

40 +44 (0) 1733 456789 www.creda-heating.co.uk

When mounted on the inside of an

external door they create a ‘hot air curtain’

to prevent cold draughts entering a

building. In summer they can be switched

to fan only to form a barrier against

incoming dust and provide a refreshing

breeze. Suitable for a range of doorway

applications in commercial premises such

as shops, offices, workshops and stores,

the Sunscreen and Sunspot heaters are

designed for fast installation with key

hole-slots for vertical mounting or

brackets providing complete flexibility of

adjustment from vertical to horizontal.

Easily accessible switches allow the option

to run the unit on fan only or at half or full

heat output.

Key features

• Two heat settings or cold

• High volume throughput

• Smooth running, shaded pole motor, with

‘greased-for-life’ bearings

• Integral switching for ease of installation

• Tangential blower

Sunspot 2.25kW

The Sunspot is a modular unit almost

half the width of the Sunscreen.

It can be used with a Sunscreen for

wider doorways or on its own as a high

level wall-mounted fan heater in

commercial premises.

• Element - open coil supported by

ceramic insulators

• Zinc coated steel, powder coated body

white/grey

• Shaded pole motor

• Protection - thermal safety cut-out

• Supply - 230/240V AC single phase

• Can be fixed directly to the wall using the key

slot holes provided or angled using the

brackets provided

• Mounting directly above the door at a height of

between 1.8 and 2.25m

Model Reference Rating Height A Width B Depth C

CSS3 50 813976 3kW 185mm 610mm 105mm

CSS45 50 813977 4.5kW 185mm 610mm 105mm

CSS225 50 813975 2.25kW 185mm 350mm 105mm

Wall Mount Ceiling Mount

Sunscreen

Warm air curtains

Product Selector

Dimensions

“Sunscreen and Sunspot

heaters provide the ideal

solution for draught exclusion

on external doors. ”

Technical Specification

Commercial

space heating

+44 (0) 1733 456789 www.creda-heating.co.uk

Este manual sirve para los siguientes modelos

Otros manuales de Calentador de Creda

Creda

Creda CAR 033 Manual de instrucciones

Creda

Creda TSRE050 Manual de usuario

Creda

Creda CLR5C Manual de usuario

Creda

Creda COR15TS Manual de usuario

Creda

Creda CDF2N Manual de usuario

Creda

Creda ERBT Manual de usuario

Creda

Creda CEP050E Manual de usuario

Creda

Creda Newera TSR18CW Manual de usuario

Creda

Creda CEP 500E Manual de usuario

Creda

Creda Duo300i Manual de usuario

Creda

Creda 79341S Manual de usuario

Creda

Creda NP Series Manual de usuario

Creda

Creda Newera 75772001S Manual de usuario

Creda

Creda TPRIII050E Manual de usuario

Creda

Creda CPH05T Manual de usuario

Creda

Creda Newera TSR12AW Manual de usuario

Creda

Creda CQH100 Manual de usuario

Creda

Creda Newera 79348S Manual de usuario

Creda

Creda Eco-Response ER300 Manual de usuario

Creda

Creda TSF24K Manual de usuario

Creda

Creda CLSTH050 Manual de instrucciones

Creda

Creda NEWERA 85301 Manual de usuario

Creda

Creda Arezzo ARE050 Manual de instrucciones

Creda

Creda 75773301 Manual de usuario

Manuales populares de Calentador de otras marcas

oventrop

oventrop Regucor Series Manual de usuario

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manual de usuario

ELMEKO

ELMEKO ML 150 Manual de usuario

BN Thermic

BN Thermic 830T Manual de usuario

KING

KING K Series Guía

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guía de inicio rápido

Well Straler

Well Straler RC-16B Manual de usuario

EUROM

EUROM 333299 Manual de usuario

Heylo

Heylo K 170 Manual de usuario

Eterna

Eterna TR70W Manual de usuario

Clarke

Clarke GRH15 Manual de instrucciones

IRSAP

IRSAP The Radiator Company Ovali Manual de usuario

Empire Heating Systems

Empire Heating Systems WCC65 Manual de usuario

Wetekom

Wetekom 92 86 43 Manual de usuario

Desa

Desa SPC170-F Manual de usuario

Watlow

Watlow Watrod Electric Tubular Heaters Manual de usuario

Haverland

Haverland ECO-DRY GPS Series Manual de lista de piezas

Stelpro

Stelpro ASILVC2060 Series Manual de usuario
