Craftsman 320.22305 Manual de usuario

Operator's Manual

ICRFIFTSMFIN I

BENCH TOP TOOL STAND

Model No. 320. 22305

_WARNING: To reduce the risk of injury,

the user must read and understand the

Operator's Manual before using

this product.

_WARNING: To reduce the risk of injury,

the user must always read and follow all

instructions in the bench top tool operating

manual before mounting the tool to

this stand.

•WARRANTY

•SAFETY

•ASSEMBLY

•DESCRIPTION

•OPERATION

•MAINTENANCE

•ESPANOL

Sears Brands Management Corporation, Hoffman Estates,

IL 60179 U.S.A.

www.craftsman.com

I_ _I[I]ii[II_I__I

Warranty Page 2

Safety Symbols Pages 4-5

Safety Instructions Page 6

Description Page 7

Assembly Pages 8-9

Operation Pages 10-13

Maintenance Page 14

Parts List Pages 15-16

CRAFTSMAN ONE YEAR FULL WARRANTY

FOR ONE YEAR from the date of purchase, this product is warranted

against any defects in material or workmanship. With proof of purchase,

defective product will be replaced free of charge.

For warranty coverage details to obtain free replacement, visit the web

site: www.craftsman.com

This warranty is void if this product is ever used while providing commercial

services or if rented to another person.

This warranty gives you specific legal rights, and you may also have other

rights which vary from state to state.

Sears Brands Management Corporation, Hoffman Estates, IL 60179

This bench top tool stand has many features for making its use more pleasant

and enjoyable. Safety, performance, and dependability have been given top

priority in the design of this product, making it easy to maintain and operate.

SAVE THESE INSTRUCTIONS!

READ ALL INSTRUCTIONS!

Page 2 22305 ManuaLRevised_12 0528

_WARNING: Some dust created by power sanding, sawing, grinding, drilling

and other construction activities contains chemicals known to the state of

California to cause cancer, birth defects or other reproductive harm. Some

examples of these chemicals are:

• Lead from lead-based paints,

• Crystalline silica from bricks and cement and other masonry products,and

• Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending on how often you do this type

of work. To reduce your exposure to these chemical: work in a well ventilated

area, and work with approved safety equipment, such as those dust masks that

are specially designed to filter out microscopic particles.

The purpose of safety symbols is to attract your attention to possible dangers.

The safety symbols and the explanations with them deserve your careful

attention and understanding. The symbol warnings do not, by themselves,

eliminate any danger. The instructions and warnings they give are no substitutes

for proper accident prevention measures.

22305 ManuaLRevised_12 0528 Page 3

WARNING: Be sure to read and understand all safety instructions in this

Operator's Manual, including all safety alert symbols such as "DANGER",

"WARNING", and "CAUTION" before using this stand. Failure to follow all

instructions listed below may result in electric shock, fire, and/or serious

personal injury.

SYMBOL SIGNAL MEANING

SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION; may

be used in conjunction with other symbols or pictographs.

DANGER: Indicates a hazardous situation which, if not avoided, will result in

death or serious injury.

WARNING: Indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

CAUTION: Indicates a hazardous situation which, if not avoided, could result

in minor or moderate injury.

Damage prevention and Information Messages

These inform the user of important information and/or instructions that could

lead to equipment or other property damage if they are not followed. Each

message is preceded by the word "NOTICE", as in the example below:

NOTICE: Equipment and/or property damage may result if these instructions are

not followed.

WARNING: To ensure safety and reliability, all repairs should be performed

by a qualified service technician.

_, WARNING: The operation of any power tools can result in

foreign objects being thrown into your eyes, which can result

in severe eye damage. Before beginning power tool operation,

always wear safety goggles or safety glasses with side shield

and a full face shield when needed. We recommend a Wide

Vision Safety Mask for use over eyeglasses or standard safety

glasses with side shields. Always use eye protection that is

marked to comply with ANSI Z87.1.

Page 4 22305 ManuaLRevised_12 0528

SAVE THESE INSTRUCTIONS

Some of the following symbols may be used on this tool. Please study them

and learn their meaning. Proper interpretation of these symbols will allow you to

operate the tool better and more safely.

SYMBOL NAME DESIGNATION/EXPLANATION

V Volts Voltage

A Amperes Current

Hz Hertz Frequency (cycles per second)

W Watt Power

rain Minutes Time

Alternating Current Type of current

--'_: Direct Current Type or a characteristic of current

n 0 No Load Speed Rotational speed, at no load

] Class II Construction Double-insulated construction

.../min Per Minute Revolutions, strokes, surface speed,

orbits, etc., per minute

Wet Conditions Alert Do not expose to rain or use in damp

locations.

To reduce the risk of injury, user must

Read The Operator's Manual read and understand operator's manual

before using this product.

OAlways wear safety goggles or safety

Eye Protection glasses with side shields and a ful! face

shield when operating this product.

,_ Alert Precautions that involve

Safety your safety.

Failure to keep your hands away from the

No-Hands Symbol blade will result in serious personal injury.

No-Hands Failure to keep your hands away from the

Symbol blade will result in serious personal injury.

Failure to keep your hands away from the

No-Hands Symbol blade will result in serious personal injury.

Failure to keep your hands away from the

No-Hands Symbol blade will result in serious personal injury.

To reduce the risk of injury or damage,Hot Surface avoid contact with any hot surface.

22305 ManuaLRevised_12 0528 Page 5

GENERAL SAFETY RULES

WARNING: Read all safety warnings and instructions. Failureto follow the

warnings and instructions may result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

READ AND SAVE THESE INSTRUCTIONS

JL WARNING: Do not modify this tool and/or used it for any application other

than that for which it was designed.

•Do not use for scaffolding or as ladder. Do not stand or climb on the

bench top tool stand; it could fall or tip over, causing serious injury.

•Do not overload. The maximum capacity for the bench top tool stand

is 3001bs.

•Do not apply an unbalanced load. This could cause the bench top tool

stand to tip over.

• Store the stand properly. Do not store the bench top tool stand outdoors

or in a damp location.

•Keep the work area clean, uncluttered, and well lit. Do not work on or

place the bench top tool stand legs on floor surfaces that are slippery from

sawdust, oil, water or wax.

• Keep children and bystanders away while operating a power tool.

Distractions may cause you to lose control. Visitors should wear the same

safety equipment as the operator.

• When using a power tool with the bench top tool stand, always follow

the safety instructions in the power tool's Operator's Manual.

• Always wear safety glasses or eye shields when operating power tools.

•Dress properly. Do not wear loose clothing or jewelry. Keep your hair,

clothing and gloves away from moving parts. Loose clothes, jewelry or long

hair can be caught in moving parts. Always wear non-slip footwear. Tie back

long hair. Roll long sleeves above the elbow.

• Always use clamps or other practical ways to support the workpiece

and secure it to astable platform. Holding the work by hand or against

your body is unstable and may lead to loss of control.

Page 6 22305 ManuaLRevised_12 0528

ID]=_.'_o_[[o_]

KNOW YOUR BENCH TOP TOOL STAND (Fig. 1)

This Bench Top Tool Stand is ideal for mounting most Craftsman and other

brands of bench top tools. It has a large base and is height adjustable for

working comfort. The strong, wide base provides stable support for the tool.

There are foot leveler pads on each foot for maximum stability. The 20-gauge

steel construction supports up to 300 Ibs. The durable, powder-coat finish

stands up to rugged use.

Fig. 1 Support (Long)

Support(Short)

Upper Leg

Lowerleg

support(Short)

Lower leg

Lower Foot-Leveling-Pad

Weight

Working heights

PRODUCT SEPCIFICATIONS

14.3 Ibs

34. in (Maximum)

32. in

30. in

28. in

26. in

24. in

22. in. (Minimum)

Maximum Load Capacity 300 Ibs

22305 ManuaLRevised_i2 0528 Page 7

Jk WARNING: If any parts are broken or missing, do not attempt to operate the

bench top tool stand until the broken or missing part is replaced. Failure to do

so could result in serious injury.

_WARNING: Do not attempt to modify this bench top tool stand or create

accessories not recommended for use with this bench top tool stand. Any such

alteration or modification is misuse and could result in a hazardous condition

leading to serious injury.

UNPACKING

This product has been shipped disassembled.

• Carefully remove all the parts and accessories from the carton. Make sure

that all items listed in the packing list are included.

• Inspect the parts for the bench top tool stand carefully to make sure that no

breakage or damage occurred during shipping.

• Do not discard the packing material until you have carefully inspected and

satisfactorily operated the bench top tool stand.

• If any parts are damaged or missing, please return the bench top tool stand

to the place of purchase.

PACKAGE CONTENTS

Item Description Qty.

Long Tabletop Supports

Short Tabletop Supports

Upper Leg 4

Lower Leg 4

Page 8 22305 ManuaLRevised_12 0528

Item Description Qty.

Long Lower Leg Supports

Short Lower Leg Supports

Screw M6"10 32

Nut M6 32

Foot 4

Foot-Leveling Pad 4

L Foot Screw M8"40 4

M Foot nut M8 8

N Foot Washer M8 4

22305 ManuaLRevised_12 0528 Page 9

[IY.]_/[I]][

WARNING: Do not use this tool for scaffolding or as a ladder. Make sure to

tighten all screws securely prior to use. Maximum capacity: 300 Ibs.

ASSEMBLING THE TABLETOP

SUPPORTS (Fig. 2)

Place the 2 Long Tabletop

Supports (A) and the 2 Short

Tabletop Supports (B) on a flat

work surface so they form

a rectangle.

Fig. 2 A

ASSEMBLING THE UPPER

LEGS (Fig. 3 and Fig. 4)

Connect the 4 Upper Legs

Tabletop Supports by inserting

the 16 Screws (G) through the

Tabletop Supports and then

through the 4 clearance holes

on the top of each Upper Leg.

Then attach a Nut (H) to each

screw and finger- tighten only.

NOTICE: The upper Legs must

be attached to the inside of the

Tabletop Supports.

Fig .3

Fig .4

Page 10 22305 ManuaLRevised_12 0528

Tabla de contenidos

Idiomas:

Otros manuales de Rack y soporte de Craftsman

Craftsman

Craftsman 130.16491 Manual de usuario

Craftsman

Craftsman 922210 Manual de usuario

Craftsman

Craftsman 320.16488 Manual de usuario

Craftsman

Craftsman CMXMSAJ94773 Manual de usuario

Craftsman

Craftsman 351.220200 Manual de usuario

Craftsman

Craftsman CMXMSAJ94772 Manual de usuario

Craftsman

Craftsman 50159 - 3 Manual de usuario

Craftsman

Craftsman 714.58688 Manual de usuario

Craftsman

Craftsman 695.22302 Manual de usuario

Craftsman

Craftsman 320.16490 Manual de usuario

Craftsman

Craftsman CMXMSAJ094788 Manual de usuario

Craftsman

Craftsman 351.241300 Manual de usuario

Craftsman

Craftsman 320.22335 Manual de usuario

Craftsman

Craftsman 320.16492 Manual de usuario

Craftsman

Craftsman Versatrack Manual de usuario

Craftsman

Craftsman 320.19730 Manual de usuario

Craftsman

Craftsman 320.16491 Manual de usuario

Craftsman

Craftsman 22283A Manual de usuario

Craftsman

Craftsman 315.223400 Manual de usuario

Manuales populares de Rack y soporte de otras marcas

Salamander

Salamander Acadia AC/W/L400/WH Manual de usuario

Fohhn

Fohhn VAT-09 Guía del usuario

ricoo

ricoo FS0522 Manual de usuario

AMSOIL

AMSOIL BMK-22 Guía rápida

Kargo Master

Kargo Master 48220 Manual de usuario

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manual de usuario

ricoo

ricoo S1222 Manual de usuario

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manual de usuario

VidaBox

VidaBox VB MNT FFS2 Manual de usuario

Welch Allyn

Welch Allyn 48960 Manual de usuario

Arkon

Arkon CM035-ST-2 Manual de usuario

PROEL

PROEL PLWIN60C Manual de usuario

Agilent Technologies

Agilent Technologies E2609B Manual de usuario

Mustang

Mustang MV-ARM4 Manual de usuario

Mounting Solutions

Mounting Solutions WRM-320 Manual de usuario

Pyle

Pyle PMKSPAD1 Manual de usuario

ShelterIt

ShelterIt 21208 Manual de usuario

SPL

SPL RackPack?4 1040 Manual de usuario
