CPcam CPD500W Manual de usuario

1.Makesureyourpackagecontains:

1)DigitalVideoRecorder(withHDDcartridge)*1

2)Usersmanual*1

3)Key*2

4)Accessoriespack*2

5)Poweradapterandcord*1

6)CD-ROM*1

NOTE:1)Thisadaptorisonlyforthismachine.Donotuseitforother

electronicproducts.

2)ThisadaptorisDC19V2A.Ifitisdamaged,userscanfind

replacementadaptorofthesamekind.

2.Howtomakethemachinerun?

RISKOFELECTRICSHOCK

DONOTOPEN

WARNING:TOREDUCETHERISKOFELECTRICSHOCK,

DONOTREMOVECOVER(ORBACK).

NOUSER-SERVICEABLEPARTSINSIDE.

REFERSERVICINGTOQUALIFIED

SERVICEPERSONNEL.

EXTERNALI/OLAN

ACT

LINK

USB

OUTIN

MAIN

CALL

OUT

DC19V

PIR PTZ Monitor Monitor

CAMERA

Bullet

Cam. IR

Cam. Outdoor

Cam.

Regular

CCDCam. Dome

Cam. Dome

Cam. Vari-Focal

ComeCam. Mini.

Cam.

Power

1)SituateandconnectDVR

2)SystemTimesetup:

A.Pressbuttontoentermenulist.

B.Selectandchoosedatedisplay.

C.PressortosetcorrectDateandTime,andpressor

tomovethedigitlocation.

D.Presstoexitandconfirmcurrentoperation.

SYSTEM

KEYMUTE

BUZZER

MESSAGELATCH

DATEDISPLAY

DATE

TIME

HDDFORMAT

SYSTEMRESET

LANGUAGE

UPGRADE

RECORD

CAMERA

DETECTION

DISPLAY

USER

SYSTEM

EVENT

NETWORK

PTZ

RETR

OFF

SETUP

OFF

Y/M/D

2004-NOV-25

14:55:38

ENGLISH

SETUP

SYSTEM

EVOLUTION

ForYourDemand

Internet

500WV1.1

EVOLUTION

ForYourDemand

3)InstallHDD:

Connecttheconnectorwith

theHDD. PuttheHDDintotheHDDcartridge.

Pleasenoticethebottomsideis

powerside.

ScrewtheHDDtothecartridge.

BeforeyouscrewtheHDD,please

beawarethatyoumustlevel ,

becausethescrewholeisdifferent

fromdifferentHDDbrands.Then

screwtheHDD.

pin1oftheHDDatpin1mark

Youmustprecisely

aligntheharddisktothepin

connecttoensurecorrect

installation.

ReversetheHDDandputit

intoDVR. ConnecttheHDDwithDVR

Pleaselevelpin1ofthe

HDDatpin1mark

EVOLUTION

ForYourDemand

Lockthecabinetbyturningthe

keyclockwise.Closethecap.

A(Locked)

B(Unlocked)

4)BasicOperation

POWER:PressPOWERbuttontoturnON/OFFtheDVR.

REC:PressRECbuttontostartrecording.

PLAY:PressPLAYbuttontoplaybackrecordedvideo.

ENTER+SEARCH:PressbothENTERandSEARCHbuttonstoenter

theUSBBackupMenu.

ENTER+ZOOM:PressENTERandZOOMbuttonstostartthePTZ

operationmode.

ENTER+MENU:PressENTERandMENUbuttonstoLock/Unlockthe

keyboard.

REC+STOP:PressRECandSTOPbuttonstoinactivateRETR.

REC+PLAY:PressRECandPLAYbuttonstoactivateRETR.

NOTE:Ifyouwanttostoprecording.InMENU/RECORDsetthe

MANUALRECORDasNO.

5)MotionSetup

PleaseentertheDETECTIONfunctionmenu.

A.DET(DETECTION)

ThemotiondetectiononeachchannelcanbeturnedONorOFF

individually.

B.PresstheENTERbuttontoset

target-area.Pleasemovethecursor

tothepositionthatyouwant.Press+to

markthisarea.

EVOLUTION

ForYourDemand

IPADDRESS:

NETMASK:

GATEWAY:

DNS:

PORT:

LOADDEFAULT:

061.066.138.074

255.255.255.000

061.066.138.254

168.095.001.001

00080

NETWORK

3.Networksetting

1)StaticIPinstallation:

(Softwareinstallation):

Aftertheinstallation,thereare6filesand1folderinyour

assignedpath(filefolder)asbelowpictures.

(StaticIPsetting):

InDVRMENU/NETWORKSetSERVERIP,GATEWAY,

NETMASK,DNSandWEBPORTwhichareprovidedfrom

yourlocalISP(Internetserviceprovider).

Afterallnetworksettingsarefinished,pleaseconnectDVR

withADSLcable.

(ConnectPCviatheInternet):

Clicktwiceandenteryourusername,password

(Note:Ifyouhaveneverchangedtheaccountbefore,the

usernameandpasswordareboth)andServerIP

whichyouhavesettoDVRinstep2.ThenclickOKTo

connect.

2)DynamicIPinstallation:PleaserefertoUsersManual.

Step1

Step2

Step3

admin

PleaserefertotheDVRinstructionmanualformoredetailedinformation
