Important Safeguards and Warnings
The following description is the correct application method of the device. Please read the manual carefully
before use, in order to prevent danger and property loss. Strictly conform to the manual during application
and keep it properly after reading.
Operating Requirements
•Do not expose the device to direct sunlight or heat source.
•Do not install the device in a humid or dusty area.
•Install the device horizontally at stable places to prevent it from falling.
•Do not drip or splash liquids onto the device; do not put on the device anything filled with liquids.
•Install the device at well-ventilated places and do not block its ventilation opening.
•Use the device only within rated input and output range.
•Do not dismantle the device by yourself.
•The device should be used with screened network cables.
Power Requirements
•Use recommended power cables in the region under their rated specification.
•Use power supply that meets SELV (safety extra low voltage) requirements, and supply power with
rated voltage that conforms to Limited Power Source in IEC60950-1. For specific power supply
requirements, please refer to device labels.
•Appliance coupler is a disconnecting device. During normal use, please keep an angle that facilitates
operation.
Device Update
Do not cut off power supply during device update. Power supply can be cut off only after the device has
completed update and has restarted.
Table of Contents
1. Structure .................................................................................................................................................. 5
1.1. Introduction....................................................................................................................................... 5
1.2. Features............................................................................................................................................. 5
1.3. Front Panel ........................................................................................................................................ 6
1.4. Rear Panel.......................................................................................................................................... 7
2. Installation................................................................................................................................................ 8
2.1. INDOOR ............................................................................................................................................. 8
2.2. OUTDOOR.......................................................................................................................................... 8
3. Wiring....................................................................................................................................................... 9
3.1. Preparations .................................................................................................................................... 10
3.1.1. Port Connection Rules ............................................................................................................... 10
3.1.2. Cord Specification...................................................................................................................... 10
