Cozzia OG5010 Manual de usuario
OG5010 Instruction Manual
Step 1: Open the box. Remove enclosed contents: Base×1，backrest×1，Seat pad and Backrest pad (include pillow)×1 ,
Shoulder massage×1pair, hex screw×8pcs，hex driver×1. The pictured as below:
Step 2: Open the box which attached to the base. We can get remote control×1，Power cord×1, user manual×1, screw and
screw driver×1. Put the remote control into the pocket.
Base×1
Backrest×1
Seat pad & Backrest pad×1
Shoulder Massage×1pair
Hex screws and hex
driver
Step3: Attach seat pad and backrest pad onto the base. Attach the zipper which connect seat pad and footrest. Connect
vibrate wire connector and backrest heater wire connector. (As pictured below show.)
Step 4: Remove the cable tie which fasten the backrest actuator. Remove the cotter pin and remove the bolt. Set the
cotter pin and bolt aside.
Step 5: Attach the backrest onto the base. The backrest must be in a vertical position for the pivot points to properly
engage to base. Have somebody hold the backrest and attach the backrest to the backrest actuator with the bolt and cotter
pin. Attach the backrest cable to the connectors. Attach the air hose.
Step 6: Attach shoulder massage to the backrest. There are four screw holes on each side for attaching the shoulder
Velcro on seat pad and Velcro on the base
must attached perfectly and zip the zipper.
Connect wire connecters.
Remove the cable tie.
Remove the cotter pin and
bolt
massage. Unzip the zipper of the shoulder massage. Attach the shoulder massage onto the backrest using 4pcs
hex screws. As pictured below.
Step 7: Remove the straight air hose connector. Connect the air hose to the right-angled air hose connector. Then zip the
zipper. As pictured below.
Step 8: Attach backrest pad onto backrest with zipper. Align the Velcro patches and attach backrest pad to backrest. (As
pictured below )
Step 9: Connect the chair to power supply. Turn on the power switch.
Four screw holes on each side.
Locate four hex screws on one
shoulder massage.
Take off this air hose
connector.
