Cortelco C60 Manual de usuario

WWW.CORTELCO.COM

The following items should be included with your telephone:

This telephone may be configured through the web interface or through the

keypad and LCD. A high speed connection to the internet is necessary to use

this telephone to make VoIP calls.

Key Locations and Functions

The following chart shows the letters obtained from multiple pressing of the

numeric keys. This is used to enter text on the LCD.

Phone Connection

Phone Menu Structure

The C60 may also be configured using a web browser.

Open your web browser (Internet Explorer, Firefox, etc), then type the IP address of

the phone into the address bar.

This IP address will be provided by your Internet Service Provider (ISP) if you have a

static address.

If you have DHCP, find the IP address by pressing the MENU softkey and then the OK button.

Enter the user name and password. Default value for both is “admin.”

After logon, you will see the phone web page as shown below.

Select Static as your network type if instructed to do so by your ISP.

Note that your ISP will need to furnish all the connection information.

Select DHCP if your network has a DHCP server. Ask your ISP or Network

Administrator if you are unsure which type of network to choose.

Select SIP Settings from the main menu. Enter the fields required by your SIP Service provider.

Usually Server Address, Server Port, Authentication User, Authentication Password, and SIP User

are required. Then check Enable Registration and click Apply to register to the SIP server.

IP Address (Peer-to-Peer)

1. Lift the handset or press the speakerphone button.

2. Dial the IP address of the phone to be called. Dial the # key before and after the address

and use the * key for the period. For example: To call 192.168.0.1 dial #192*168*0*1#.

SIP Number

Note that this requires registration to a SIP server.

1. Lift the handset or press the speakerphone button.

2. Dial the SIP extension number of the phone to be called.

3. Press the # key after dialing the numbers or wait for the timer to expire

to place the call.
