COOLMAY EX3G PLC/HMI All in one Programming manual
COOLMAY
EX3G PLC/HMI All in one
Programming manual
(plc part: Difference comparing with Mitsubishi FX3G)
All right belongs to Shenzhen Coolmay Technology Co.,Ltd
V8.112
COOLMAY EX3G PLC/HMI All in one Programming manual
2
Content
1. Overview......................................................................................................................................................... 1
1.1 EX3G PLC/HMI Allin one Main Advantage:...................................................................................... 1
1.2 Specification..........................................................................................................................................2
1.3 Hardware description............................................................................................................................ 3
1.3.1 EX3G-43HA/HB structure description and dimension..............................................................3
1.3.2 EX3G-43(50)KH structure description and dimension..............................................................4
1.3.3 EX3G-70KH structure description and dimension.................................................................... 5
1.3.4 EX3G-100HA structure description and dimension.................................................................. 6
1.3.5 Introduction of each interface and indicator.............................................................................. 7
2. PLC................................................................................................................................................................. 8
2.1 PLC Programming notice......................................................................................................................8
2.2 Soft element table..................................................................................................................................8
2.3 Special relay number and content....................................................................................................... 10
2.4 Special register number and content................................................................................................... 13
2.5 Applied instructions【Sequence is according to instruct variety】................................................... 17
2.6 Analog input........................................................................................................................................24
2.6.1 Analog input (temperature)...................................................................................................... 24
2.6.2 Analog input reading 1 (for software version 26210 and 26220)......................................... 26
2.6.3 Analog input reading 2 (for Main software version 26220)................................................. 27
2.6.4 Analog input reading 3 (for Main software version 26230 and above)................................ 27
2.6.5 Analog input sampling............................................................................................................. 28
2.6.6 Demo example......................................................................................................................... 29
2.7 Analog output......................................................................................................................................30
2.8 PID instruction.................................................................................................................................... 30
2.9.Application of high speed counter...................................................................................................... 30
2.10.Application of high speed pulse........................................................................................................31
2.10.1 high speed pulse output..........................................................................................................31
2.10.2 Circular interpolation............................................................................................................. 32
2.10.3 Continuous interpolation function..........................................................................................34
2.11 PLC Communication port User Manual........................................................................................... 37
2.11.1 Serial port 2: RS485(A B)/RS232..........................................................................................37
2.11.2 Serial port 3:RS485 (A1 B1)/RS232......................................................................................44
2.11.3 Modbus Communication address number..............................................................................51
2.12 Network communication...................................................................................................................55
2.13 Difference between EX3G and EX2N PLC/HMI All in one............................................................57
3. HMI............................................................................................................................................................... 61
3.1 HMI program software user introduction........................................................................................... 61
3.1.1HMI Program software installation...........................................................................................61
3.1.2 New build HMI program..........................................................................................................61
3.2 HMI Display download.......................................................................................................................62
3.2.1 Online download step (USB download line download)...........................................................62
3.2.2 U disk download step (43HB series don’t support)................................................................. 65
COOLMAY EX3G PLC/HMI All in one Programming manual
3
3.3 Introduction when HMI is with com port for MODBUS RTU protocol............................................ 66
3.3.1 HMI as master.......................................................................................................................... 66
3.3.2 HMI as slave............................................................................................................................ 68
3.4 Other HMI usage.................................................................................................................................69
COOLMAY EX3G PLC/HMI All in one Programming manual
1
1. Overview
1.1 EX3G PLC/HMI Allin one Main Advantage:
◆Powerful, compatible with FX3G/FX3U/FX3S PLC, high processing speed.
◆Upper computer programming software compatible with Works 2/GX Developer8.86
◆Military level 32 bit CPU adopted, which is faster and more adapted to industrial environment of high
electromagnetic interference.
◆Special encryption, prevent illegal reading thoroughly. 8-bit encryption, 12345678 as password can
thoroughly prevent reading of ladder logic program.
◆Clock supported, rechargeable battery adopted.
◆Default With one HMI Downloading port, two PLC programming ports: one MiniB USB port with faster
downloading speed; one Rs232 programming port with 8 mouse hole sockets.
◆Support Mitsubishi programming port protocol/Modbus protocol/Rs protocol/BD board protocol,
PLC communication with each other and other devices is easily achieved.
◆EX3G-70KH/100HA,PLC is optional to add 1 rs485 or 2rs485(one of rs485 is changed from default
rs232)/CAN/ethernet (which can’t exist to hmi ethernet port)/WIFI(which will occupy default rs232port)；
HMI is optional to add 1RS232 or RS485/ethernet (which can’t exist to plc ethernet port);
43HB(HA)/43(50)KH(A) PLC is optional to add 2 RS485；HMI is optional to add 1 RS232,used for external
hmi and inverters.
◆High speed counter.regularly single phase 6 channels 60KHz/ AB(Z) Phase 2 channels 60KHz + 1 channel
10KHz. EX3G-43HB regularly single phase 8 10KHz；
◆High speed pulse, regular as 8 channels Y0-Y3 in 100KHz,Y4-Y7 in 10KHz
Note: High speed counter+High speed pulse should be less 480KHz.
◆Support multiple types analog individually or mixed ones for analog output and input.
EX3G-70KH/100HA is up to 16AD/8DA，EX3G-43HB(HA)/43(50)KH is up to 4AD/2DA.Precision of
AD/DA is 12bit.Temperature/current/voltage for input. current/voltage for output.
◆EX3G-70KH/100HA is up to 30DI/30DO(MR:28 at most)，DO is optional to choose
MR(max:5A)/MT(max:500mA)or mixed MRT；EX3G-43HB(HA)/43(50)KH is up to 12DI/12DO，DO is
optional to choose MR(max:5A)/MT(max:2A).
◆Convenient for wiring, adopting 3.81mm pluggable terminals.
◆Easy installation. DIN-Rail (35mm width) installation and fixed hole installation.
◆32K steps program capacity, 32k registers of hold on when power off, support interrupt,linear&circular
interpolation,PID and self-tuning,high powerful.
◆Flexible, can be customized accordingly.
COOLMAY EX3G PLC/HMI All in one Programming manual
2
1.2 Specification
Artical
EX3G-43HB-24M
EX3G-43(50)KH-24M
EX3G-70KH
EX3G-100HA
Dimension
134*102*30mm
150*93*32mm
226*163*35.6mm
275*194*36mm
Cutout size
119*93mm
143*86mm
218*153mm
261*180mm
Power
Consumption
4-6W
4-6W/5-7W
6-7W
6-8W
Features
Support Interrupt,linear arc interpolation,PID auto-tuning,32k program capacity, 32k retentive register
HMI
Display
60K colors
Display size
97*56mm
97*56/108*65mm
154*87mm
222*133mm
Resolution
（pixels）
480*272
43KH：480*272
50KH：800*480
70KH:800*480
1024*600
RAM
32MB
64MB
128MB
ROM
128MB
Operation
system
without system
WINCE 5.0
WINCE 7.0
CPU
ARM9 216MHz
ARM9 400MHz
CORTEX A8
720MHz-1GHz;
COM port
1 TP download port
1 TP download port,1 USB 2.0 port
1 RS232 optional
1 RS485 or RS232 optional
Can’t coexist with PLC ethernet port
Software
CoolMayHMI V5.**(newest vesion pls see Http://coolmay.net)
PLC
Digital I/O
Up to12DI/12DO
Up to 30DI/30DO(At most 28 relay outputs)
I/O level
MT Output: NPN MR output: NO contact Input: Passive NPN, public terminal isolated
Output type
MR/MOS
Maximum load: MOS is 2A; MR is 5A
MR/MT/MRT
Maximum load: MT is 500mA; MR is 5A
High-speed
counting
Single phase 6channel
10KHz or AB(Z) 3
channel 10KHz
Normally 6 single phase 60KHz Or 2channel ABl(Z) phase 60KHz+1 channel 10KHz；
High-speed
pulse
8 channel 10KHz
8channels,Y0-Y3 is 100KHz，Y4-Y7 is 10KHz；
Note: High speed counter+High speed pulse should be less 480KHz.
Analog I/O
Analog input type is EKSTJ type thermocouple (supports
negative temperature) / PT100 / PT1000 / NTC10K /
NTC50K / NTC100K / 0 ~ 10V/0~5V/0~20mA/4~20mA
or mix type and other special specifications
Analog input type is EKSTJ type thermocouple (supports
negative temperature) / PT100 / PT1000 / NTC10K /
NTC50K / NTC100K / -5V ~ 5V / -10V ~ 10V / 0 ~
10V/0~5V/0~20mA/4~20mA or mix type and other
special specifications
AO: 0-10V/0-5V/0-20mA/4-20mA or mixed
At most 4AD/2DA
At most 16AD/8DA
COM port
2 programming ports（1 MiniB type USB port,faster downloading speed；1 Rs232 port）
2 RS485 optional
1 rs485 or 2rs485(one of rs485 is changed from default
rs232)/CAN(2.0A/B)/ethernet (which can’t exist to hmi
ethernet port)/WIFI(which will occupy default rs232port)
optional
Software
Compatible with Mitsubishi GX Developer8.86 and WORKS 2
Regular models：EX3G-43HB/43KH/50KH-16MR/24MR/24MT(-4AD2DA-485P/232H)
EX3G-70KH100HA-16MR/24MR/44MT/44MRT(-16AD8DA-485P/232H)
*EX3G-70HA/100HA: If with 30DI/30DO,the maximum analogs are 5AD/2DA;If with 24DI/20DO,the maximum analogs are
16AD/8DA；Detailed info.refer to：《Coolmay HMI/PLC All-in-on Programming Manual》 《HMI/PLC All-in-one User Manual》
《CoolMay HMI User Manual》 《EX3G PLC/HMI Programming Manual》 《EX3G PLC/HMI User Manual》
COOLMAY EX3G PLC/HMI All in one Programming manual
3
1.3 Hardware description
1.3.1 EX3G-43HA/HB structure description and dimension
PLC Run light Com port of plc and hmi Power light
* Dimension(mm)：134*102*30
* Cutout size(mm)：119*93
* Installation: Clip installation
* Display size(mm): 97*56
COOLMAY EX3G PLC/HMI All in one Programming manual
4
1.3.2 EX3G-43(50)KH structure description and dimension
PLC Run light Com port of plc and hmi Power light
* Dimension(mm)：150*93*32
* Cutout size(mm)：143*86
* Installation: Clip installation
* Display size(mm): EX3G-43KH:97*56
EX3G-50KH:108*65
COOLMAY EX3G PLC/HMI All in one Programming manual
5
1.3.3 EX3G-70KH structure description and dimension
PLC Run light Com port of plc and hmi Power light
* Dimension(mm)：226*163*35.6
* Cutout size(mm)：218*153
* Installation: Clip installation
* Display size(mm): 154*87
COOLMAY EX3G PLC/HMI All in one Programming manual
6
1.3.4 EX3G-100HA structure description and dimension
PLC Run light Com port of plc and hmi Power light
* Dimension(mm)：275*194*36
* Cutout size(mm)：261*180
* Installation: Clip installation
* Display size(mm): 222*133
COOLMAY EX3G PLC/HMI All in one Programming manual
7
1.3.5 Introduction of each interface and indicator
POWER: Power indicator, connected to the power light
RUN: PLC running status indicator. This light is on when the PLC is running.
COM: touch screen and PLC communication status indicator, when the two communicate, the light is on
Power terminal: The positive and negative terminals of the DC24V switching power supply are respectively
connected to the DC24V and 0V of the power supply terminal.
PLC programming port: two PLC programming ports (MiniB type usb port / RS232), PLC program can be
downloaded through 232 programming line or USB cable download
Touch screen programming port: download touch screen configuration program
USB interface: mainly can be directly inserted into the U disk of the file system FAT 32, can also be inserted
into the mouse.
For other hardware information, refer to "EX3G Series HMI/PLC All-in-One User Manual"
