Cooler Master CM Storm Trooper SGC-5000-KKN1 Manual de instalación y operación

The first full tower chassis with two 90 degrees

rotatable 4-in-3 HDD modules

The first with an easy-to-carry handle, and hidden

tool box for storing private goods

Removable dust filters on bottom and top intakes

A built in fan controller for cool or quit operation

Supports up to 14 hard-drives for future upgrades

Convenient external 2.5” HDD/SSD X-dock

Supports high-end hardware, includes XL-ATX

board, multiple GPUs in SLI or Crossfire

Features

Continuing with its tradition of revolutionary design and cutting edge

technology, CM Storm surpasses the competition with the Trooper

chassis. The CM Storm Trooper contains a wealth of features coveted

by most gaming enthusiasts, including USB 3.0, external 2.5”and

two 90 degree rotatable HDD cages for easier hard-drive installation.

The CM Storm Trooper is the first full tower with a carrying handle for

easy transport.

Available Color

All Black

Dimensions

250 x 605.6 x 578.5 mm (9.8 x 23.8 x 22.8 in)

Net Weight

14.4 KG / 31.7 lbs

Motherboard Type

Micro-ATX, ATX, XL-ATX

Case materials

Steel body, Front Mesh / Plastic bezel

5.25” Drive Bay

3.5” Drive Bay

8 (converted from 5.25”bay by two 4-in 3 HDD

modules)

Expansion Slot

9+1

Maximum

Compatibility

CPU cooler height: 186 mm / 7.3 in

GPU card length: 322 mm / 12.7 in

2.5”Drive Bay

13 (converted from 5.25”bay by two 4-in 3

HDD modules)

I / O panel

USB 3.0 x 2 (internal), USB 2.0 x 2, e-SATA x 1,

Audio In and Out ( Supports HD audio)

Cooling System

Front : 120 mm LED fan x2, 1200 RPM, 17

dBA

Top: 200 mm fan x 1, 1000 RPM, 23 dBA

(converted to 2 x 120 / 140 mm fan)

Rear: 140 mm fan x1, 1200 RPM, 19 dBA

(converted to 120 mm fan)

Side: 120 mm fan x 2 (optional)

Bottom: 120 mm fan x 2 (optional)

Specifications

EAN Code

4719512033951

UPC Code

884102013928

Carton Size (L x W x H)

640 x 285 x 660 mm

(25.2 x 11.22 x 25.98 in)

Pallet Size (L x W x H)

1280 x 1140 x 120 mm

(50.39 x 44.88 x 4.72 in)

Container

w/ pallet

Cnt/pallet

w/o pallet

20’

192

243

40’

432

495

40’ HQ

468

588

45’HQ

520

664

Package Information

CM Storm Trooper

USA 2 years, EU 2 years, ROW 2 years

Warranty

SGC-5000-KKN1

Two front 120 mm red LED fans provide

superior HDD/SSD cooling

Supports Liquid cooling

Cable Management

Top 200mm fan

Two 90 degree removable and rotatable

4-in-3 HDD cages

9+1 expansion Slots

Appendix

Photo taken: July 20, 2011

Note: Photos may differ slightly from the final product.
