USER MANUAL

QU-CM-5510/-2

MOTORIZEDCARD READER MODULE

Page 1 of 9

USER MANUAL

QU-CM-5510/-2

USER MANUAL

Ⅰ

.BRIEF INTRODUCTION

It is the first dual shutter protection card reader in the world. The first shutter is mechanical with

dust and foreign things prevention function, and the other one is for motor protection. The main body

is composite plastic with high temperature, abrasion and aging resistance, and two sides of card

movement channel are embedded with stainless steel metal. It makes product with advancement in

strength and precision. Module installation structure is convenient for customers to maintain product.

Elaborate design and part combination makes product with fresh appearance and its precision meets or

overpass the same product all over the world. Excellent circuit design takes multiple protection

functions into consideration. It is a card reading equipment that can read or write many types of cards,

supporting 8 pieces SIM card operation.

※

Model Name Rules

Card Type

Model Name

IC Card

（R&W）

Mag-Card

RFID Card

（R&W）（Encryption）

SIM Card

（R）

QU-CM-5510/-2-A

QU-CM-5510/-2-C

Support any one of the three types card

N.A

Support any two of the three types

Support all the three types

Or any one with

SIM card encryption

Or any two with

SIM card encryption

Support all the three types with SIM card encryption

QU-CM-5510/-2-D

※

R&W: Read&Write

Picture without SIM card slot

Picture with SIM card slot

Page 2 of 9

USER MANUAL

QU-CM-5510/-2

Ⅱ

.FEATURES& SPECIFICATIONS

Subject

Specification

Magnetic card Reading

Accordance with ISO7810 7811 standard card

IC card Reading & Writing

EMV、7816 PBOC 3.0

RF card Reading & Writing

S50、S70、ID card

SIM card operation

Card entry method

Motor shutter

8 SIM card ports

Magnetic signal, Optoelectronic signal and rear card insert

Allow or enabled card to insert

Mechanical shutter

Alert Lamp

Prevent dust and foreign things

Card entry alert, power on alert, IC card power on alert

Multiple card stop position

Card stop position

Input voltage detection

have protection alert when voltage is above 13v or below

11V

Input voltage protection in negative direction

Not above 40V

Ⅲ

.PARAMETERS

DC 12 V ( MAX CURRENT 3A, Static current 100mA),

Recommend ：12V/3A

Operation Power

Operation Te-mp.&Humi.

0 ℃～50 ℃，30～90% （Relative Humidity）

RS232 serial port ，

Support 2400～38400BPScommunication rate

Interface

Card width：54±0.5mm

Card size ：

Card length：85±0.5mm

Card thickness：0.2-2.0mm

Card material：

Weight ：

Paper card or polyester card

about 1.3kg

Magnetic card type

ISO7810 ，ISO7811 (1-6－) ，ISO7812 ，ISO7813 And ISO15457

ISO7816 normal storage card,logic encryption card,

and smart card(CPU card), reading and writing support

contact IC card type

ISO14443 TYPEA TYPEB 1、5693 contactless card reading and

writing

contactless IC card type

Dimensions

Net weight

145.5(L) x 84.1(W) x 47.4 (H) mm

1.5KG

Magnetic head:800，000 times

Lifespan

IC card contact point:500，000 times

Trans. Equipment:500，000 times

Page 3 of 9

USER MANUAL

QU-CM-5510/-2

Ⅳ

.INTERFACE EXPLANATION AND CONNECTION

NOTE: TO AVOID sudden high power damage, please do connect

the communication wire before connect the Power cable.

Communication Interface

RS232

DC12V POWER Interface

Rear of the Machine

RS232 Interface

DB9 tocomputer serial port

3PIN RS232 Socket

The other port of theMachine

Rear

T RS232 Cable

RS232-ZIP

Input

Requirement

RS232 CABLE

PIN-NO.

Pin(Right)

TXD

3PIN

CONN.

RS232 level

Pin(Middle) RXD

Pin(Left)

GND Connect with Ground

Page 3 of 9

USER MANUAL

QU-CM-5510/-2

Power supply interface

POWER CABEL

TO DC12V

POWER

TO MACHINE

POWER SOCKET

POWER-ZIP

PIN-NO.

INPUT

REQUIREMENT

（

）

PIN 2&3

GND

Connect with Ground

Black Wire

VCC

DC12V Current over 1.5A

（

）

PIN 1&4 Red Wire

Power cable connector

DC12V±5%

DNG

DC12V±5%

Page 4 of 9

USER MANUAL

QU-CM-5510/-2

Page 5 of 9

USER MANUAL

QU-CM-5510/-2

Ⅴ

.COMPONENTS AND PARTS INTRODUCTION

②

①

③

④

⑦

⑤

⑥

①

②

③

⑤

⑥

⑦

Top Part of the Main Body

Top Cover

Front transmitting wheel

Another Part of the Main Body

Card Bezel series

Back transmitting wheel

Transmitting belt

④

Page 5 of 9

USER MANUAL

QU-CM-5510/-2

Ⅵ

.OPERATION GUIDE

CARD INSERTION NOTE:

Magnetic card:

The magnetic area under the right side of the card, as picture indicated

Contact IC card: Hold the card, the chip IC at the front of the card to insert, as picture indicated.

Non-contact IC card: Both side and direction is available for reading and writing.

※CARD INSERT DIRECTION AS BELOW

Chip IC CARD

Non-contact IC

Magnetic Card

(magnetic stripe at the other side)

Page 6 of 9

USER MANUAL

QU-CM-5510/-2

Ⅶ

.INSTALLATIONAND STRUCTURE DRAWING

Page 7 of 9

USER MANUAL

Ⅷ

.CAUTION DURING OPERATION

) When connecting interface, please connect with communication interface first, then power

interface. And then power on.

) To make your product safe, the input voltage please not above 40V.

) Please set BPS rate correct. EX-work set is 9600bps.

) During operation, card insert direction should be correct

a) When inserting magnetic card, magnetic stripe should face down and insert on the right side.

b) When inserting IC card, chip should face up. If insert from the front, the end close to chip

should be inserted into card reader first. If insert from the rear, the end away from chip should

be inserted into card reader first.

c) When inserting RF card, directions are not considered. But it can only be operated at RF

position.

) When there is card in the machine, error message will be given if inserting card again. And motor

door will not open.

) When shutting off power, power interface should be shut off first, then communication interface.

) Power off during operation or other abnormal reason lead to card staying in the machine and

cannot be taken out, please take out card by pulling belts manually.

) Disassembly method Drawing

. Tap down lower

main body

Pull backward

lower main body

with right hand

. Push and open the clips

beside the card mouth to

take off card mouth

. Pull forward upper

main body with left

hand

Page 8 of 9
