Conrad-Johnson MF200 Manual de usuario
Congratulations on your purchase of the Conrad-Johnson MF200 am-
plifier.Youhaveacquiredoneofthefinerpiecesofmusicalreproduction
equipment available today. The MF200 is the result of over a decade of
research by conrad-johnson design into the application of solid-state
devices to the reproduction of recorded music. Both design and materi-
als have been carefully selected to yield years of unvarying excellence.
Each unit has been painstakingly hand-assembled and exhaustively
tested.
Please take a few minutes to read this manual so that you will better
understand the featues and capabilities of your MF200.
MF200 Owner’s Manual 1
LIMITED WARRANTY FOR THE Conrad-Johnson MF200
1. conrad-johnson design, inc.warrants to the original owner that the
MF200 will be free from defects in material and workmanship for a
period of three years from the date of original purchase.
2. During the warranty period, conrad-johnson will repair defective
unitswithoutchargeforlabororpartssubjecttothefollowingconditions:
a)The unit must not have been altered or damaged through
misuse, abuse, negligence, accident or improper operation.
b)The purchaser must provide evidence of purchase at the time
service is requested.
c) All repairs must be undertaken at the factory or other service
center designated by conrad-johnson design, inc. Units submitted
for warranty repairs must be shipped in the factory packing carton
to conrad-johnson design or its designated service center, freight
and insurance prepaid by the owner, and will be returned to the
owner, freight and insurance prepaid by conrad-johnson design.
Replacement cartons are available from the factory for a nominal
charge.
d) Normal wear and maintenance are not covered by this warranty.
3. Where permitted by law, conrad-johnson design’s liability shall be
limited to that set forth in this warranty. No other warranty of any kind,
expressed or implied, is made by conrad- johnson design, inc., and all
implied warranties, including merchantability and fitness for a particular
"purpose", which exceed the obligations and time limits set forth herein
are hereby disclaimed. conrad-johnson design, inc. shall not be liable
for incidental or consequential damages. Some states do not allow the
exclusion or limitations on how long an implied warranty lasts, so the
above limitation or exclusion may not apply to you.
4. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state. Questions about warranty
service should be addressed to:
Service Department
conrad-johnson design, inc.
2800 R Dorr Avenue
Fairfax, VA 22031
MF200 Owner’s Manual 2
REGISTERING THE WARRANTY
Please return the enclosed card to the factory within 30 days of pur-
chase to register the warranty. Proper registration of the warranty is
important! It will enable us to inform you of any alterations in the design
of a given model and of any new products we offer which are likely to be
of interest to you.
MF200 Owner’s Manual 3
INSTALLATION
Because the MF200 amplifier dissipates considerable heat it is essen-
tial that proper attention be paid to ventilation. The unit should be
mounted horizontally on a flat hard surface so that the heat sinks are
unobstructed. At least four inches of clearance should be provided
abovetheunit, and at least two inches on the sides. Thecabinetorshelf
should be open at both front and back. For more restricted installations,
cooling fans are recommended.
The front panel of the MF200 will fit in a standard 19" equipment rack
and is designed to carry the weight of the unit so that it may be rack
mounted. Again, it is important that adequate clearance be provided
above so that ventilation is not impeded. About six inches of the front of
the rack should be left open above the unit.
To minimize hum pickup, keep the unit well away from the preamplifier
and turntable and route power cords away from input cables.
THE MF200 IS TO BE OPERATED ONLY ON AC LINE VOLTAGE OF
108 TO 125 VOLTS.
The MF200 is optionally available wired for 100 volt, 120V, 220V or 240
volt, 50/60 Hz current.
CONNECTION
INPUT: Connect the preamplifier to your MF200 amplifier at the RCA
type connections located on the amplifier heat sinks.
OUTPUT: Five way binding posts are provided for connection of your
loudspeakers, with correct spacing to accept a standard "double ba-
nana" plug. They will also accept spade lugs, bare wire, or pin connec-
tors.
The two channels should be connected in correct "relative phase".This
means that when the same signal is applied to both channels, the right
and left channels speaker diaphragms should move synchronously - in
and out together. Terminals on the speakers are usually coded - one
MF200 Owner’s Manual 4
designated "C", "earth", "ground", "-" or black, the other designated "+"
or red.
"In phase" connection of the speakers can normally be achieved by
taking care to connect the wire from the red (+) amplifier terminal
marked on each channel to the red or "+" coded terminal on each
speaker.
Correct relative phase connection of the speakers can be readily ascer-
tained by ear. With the preamplifier mode switched into the MONO
position, play a record of a solo vocalist. With the speakers in phase the
voice should be clearly focused between the two speakers. With the
speakers connected out of phase, the voice will be diffuse, with no
identifiablesource.Relativephase may be reversed by switching the "+"
and "-" leads at one speaker only.
MF200 Owner’s Manual 5
GETTING THE MOST FROM YOUR
Conrad-Johnson MF200
The MF200 is a highly sophisticated music reproduction instrument, but
it cannot transform an inferior stereo system. Only the very best loud-
speaker systems will be capable of fully revealing the capabilities of this
precision instrument. On the other hand, the MF200 is highly revealing
of faults in the signal source.
Proper set-up is important in any high-fidelity system, but with state-of-
the-art components it is essential. Before attempting to evaluate the
MF200, be sure that each component in your system has been set up
carefully according to manufacturer recommendations. Adjustment of
the cartridge vertical tracking angle can be especially critical with mod-
ern stylus configurations.
Given a system of high quality components, there remain a number of
important details which must be attended to.
ABSOLUTE PHASE
Musical notes are heard through the ear’s response to waves of alter-
nating rise and fall of air pressure. Musical transients are exclusively
positive: that is, the initial effect is a rise in pressure. The ear is capable
of distinguishing these positive transients from the musically unnatural
alternative of a negative transient (an initial fall in air pressure). In your
stereo system, these transients are created by your loudspeakers. If the
speakers respond to musical transients by first moving out, they are
creating a rise in pressure, and the system is said to be "phase correct".
If they respond by moving in, they create a fall in pressure and the
system is said to be "phase inverting". Each component in the stereo
systemiseitherphasecorrectorphaseinverting(includingthecartridge
and speakers-these are normally phase correct). It is of no conse-
quence if an individual component is phase inverting, as long as the
system as a whole is phase correct. This will be the case as long as the
number of phase inversions is even (or zero).
THE MF200 IS PHASE CORRECT. If your system has an odd number
of inversions, then you must add one phase inversion. This is conven-
MF200 Owner’s Manual 6
iently done by reversing the positive and negative connections on either
your cartridge or your speakers (be sure to reverse both channels).
If you are not sure about the phase of every component in your system,
you can establish correct absolute phase by careful listening. When the
system is in correct phase, transients will be noticeably cleaner and
more sharply defined. The effect is especially apparent on plucked
string sounds. A final warning - not all records are phase correct
(including some "audiophile" recordings), so listen to several before
concluding your investigation of absolute phase.
THE IMPORTANCE OF WIRES
Interconnect and speaker wires are an important element in your stereo
system. Interconnects are available which will permit a reference quality
system to blossom and fulfill its promise of musical reality. Others will
stranglethesytemtothepointwhereit becomesnobetterthanaverage.
To complicate matters, our experience suggests that the choice of
interconnects will be system dependent-those that are ranked first on a
given system may be a poor choice for a different system. Consult your
conrad-johnson dealer for recommendations for your specific system.
QUESTIONS: If you have any questions about the installation or func-
tion of your MF200 do not hesitate to call Customer Service at (703)
698- 8581.
MF200 Owner’s Manual 7
SPECIFICATIONS:
Power: 200 watts per channel RMS both channels driven into 8 ohms
from 20Hz to 20KHz at no more than 1% total harmonic distortion or
intermodulation distortion.
Sensitivity: 2.2V to rated power.
Phase: Phase correct (non-inverting)
Frequency response: 20Hz to 20KHz +0, -.25dB
Hum and noise: 98dB below full power output.
Input impedance: 100K ohms.
Dimensions: 15.63D x 19W x 8.75H inches.
Weight: 59 lbs.
Fuses:Thereare5userreplaceablefusesinthe MF200.Thefourfuses
abovetheoutputjacksarepowersupplyfuses,type3AG5ampfast-blo.
Theaclinefuse is a type 3AG 10 amp slo-blo(7ampslow blow for 220V
or 240V amplifiers). NEVER REPLACE A FUSE WITH A VALUE OR
TYPE DIFFERENT FROM THAT ORIGINALLY SUPPLIED BY THE
FACTORY.Intheevent ofafuseblowingrepeatedly,contactyourdealer
or the conrad-johnson service department.
MF200 Owner’s Manual 8
SERVICE
In the event your conrad-johnson MF200 stereo amplifier requires
service, repack it with the original packing material and ship via United
Parcel Service (UPS) to:
conrad-johnson design, inc.
Service Department
2800R Dorr Avenue
Fairfax, VA 22031
Be sure to enclose a note explaining the problem you are having in as
much detail as possible. If the problem is intermittent, please indicate. If
you do not have the original packing material, replacements are avail-
able from conrad-johnson design at a nominal charge. If the unit is
under warranty, be sure to enclose a copy of your receipt as proof of
purchase.
MF200 Owner’s Manual 9
Tabla de contenidos
Otros manuales de Amplificador de Conrad-Johnson
Conrad-Johnson
Conrad-Johnson LP140M Manual de usuario
Conrad-Johnson
Conrad-Johnson MET1 Manual de usuario
Conrad-Johnson
Conrad-Johnson MF80 Manual de usuario
Conrad-Johnson
Conrad-Johnson ART 150 Manual de usuario
Conrad-Johnson
Conrad-Johnson LP70S Manual de usuario
Conrad-Johnson
Conrad-Johnson PV14L Manual de usuario
Conrad-Johnson
Conrad-Johnson Sonographe SA400 Manual de usuario
Conrad-Johnson
Conrad-Johnson PV8 Manual de usuario
Conrad-Johnson
Conrad-Johnson CAV50 Manual de usuario
Conrad-Johnson
Conrad-Johnson ART 300 Manual de usuario
Conrad-Johnson
Conrad-Johnson MF2100 Manual de usuario
Conrad-Johnson
Conrad-Johnson TEA2 Manual de usuario
Conrad-Johnson
Conrad-Johnson PV-3 Manual de usuario
Conrad-Johnson
Conrad-Johnson ART 108A Manual de usuario
Conrad-Johnson
Conrad-Johnson PV10A Manual de usuario
Conrad-Johnson
Conrad-Johnson MV45 Manual de usuario
Conrad-Johnson
Conrad-Johnson Sonographe SA250 Manual de usuario
Conrad-Johnson
Conrad-Johnson PV11 Manual de usuario
Conrad-Johnson
Conrad-Johnson ART 27A Manual de usuario
Conrad-Johnson
Conrad-Johnson Premier 18LS Manual de usuario
