Comtech EF Data Vipersat CDM-570 Manual de usuario

Part Number MN/CDM570L.IOM Revision 3

IMPORTANT NOTE: The information contained in this document supersedes all previously published

information regarding this product. Product specifications are subject to change without prior notice.

CDM-570/570L

Installation and Operation Manual

CDM-570 - 70/140MHz Satellite Modem

CDM-570L - L-band Satellite Modem

Optional IP Module

For Firmware Version 1.4.1 or hi

(

see New in this Release

–

Section 1.5

)

s:\tpubs\manuals\released_word\modems\cdm570-570l_rev3\addendums erratas\errata a.doc 1

Errata A

Comtech EF Data Documentation Update

Subject: Revised Table 14-1 Web Server Menu Tree

Date: March 15, 2006

Document: CDM-570/570L Installation and Operation Manual, Revision 3,

dated October 5, 2005

Part Number: MN/CDM570L.EA3

Collating Instructions: Attach this page to page 14-3

Comments:

Revised table to incorporate shaded data. This information will be incorporated into the next

revision.

Change Specifics:

Table 14-1. Web Server Menu Tree

Level 1 Level 2

Home Home

Contact

Support

Admin Access

Remote

Config Mdm Modem

Modem Utilities

AUPC

BUC (for CDM-570L only)

LNA (for CDM-570L only)

Stats Modem Status

Modem Logs

ODU (CDM570 only) Config

Status

Utilities

Maint Unit Info

s:\tpubs\manuals\released_word\modems\cdm570-570l_rev3\addendums erratas\errata b.doc 1

Errata B

Comtech EF Data Documentation Update

Subject: Revised 14.4.1 Management Information Base (MIB)

Date: March 15, 2006

Document: CDM-570/570L Installation and Operation Manual, Revision 3,

dated October 5, 2005

Part Number: MN/CDM570L.EB3

Collating Instructions: Attach this page to page 14-4

Comments:

Revised paragraph to incorporate highlighted data. This information will be incorporated into the

next revision.

Change Specifics:

14.4.1 Management Information Base (MIB) Files

MIB files are used for SNMP remote management and consist of Object Identifiers

(OIDs). Each OID is a node that provides remote management of a particular function. A

MIB file is a tree of nodes that is unique to a particular device.

There are five MIB files associated with the CDM-570 :

There are five MIB files associated with the CDM-570L :

s:\tpubs\manuals\released_word\modems\cdm570-570l_rev3\addendums erratas\errata b.doc 2

MIB File/Name Description

fw10874-2-.mib

ComtechEFData

MIB file

ComtechEFData MIB file gives the root tree for ALL Comtech EF Data

products and consists of only the following OID:

Name: comtechEFData

Type: MODULE-IDENTITY

OID: 1.3.6.1.4.1.6247

Full

path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFD

ata(6247)

Module: ComtechEFData

fw10874-4c .mib

CDM-570/570L

MIB file

MIB file consists of all of the OIDs for management of the modem functions

fw10874-5a .mib

CDM-570/570L

Traps MIB file

Trap MIB file is provided for SNMPv1 traps common for base modems.

Fw/10874-6a.mib

CDM-570L

BUC/LNB MIB

file

Provided for management of the CDM-570L BUC and LNB.

Fw/10874-7-.mib

CDM-570L

BUC/LNB

Traps MIB file

Trap MIB file is provided for SNMPv1 traps unique to CDM-570L.

FW/10874-8-.mib

CSAT-5060

MIB file

MIB file consists of all of the OIDs for management of the CSAT-5060

Transceiver connected to the CDM-570 modem through FSK.

FW/10874-9-.mib

KST-2000A/B

MIB file

MIB file consists of all of the OIDs for management of the KST-2000A/B

Transceiver connected to the CDM-570 modem through FSK.

s:\tpubs\manuals\released_word\modems\cdm570-570l_rev3\addendums erratas\errata c.doc 1

Errata C

Comtech EF Data Documentation Update

Subject: Revised 14.4.2 SNMP Community Strings

Date: March 15, 2006

Document: CDM-570/570L Installation and Operation Manual, Revision 3,

dated October 5, 2005

Part Number: MN/CDM570L.EC3

Collating Instructions: Attach this page to page 14-5

Comments:

Revised paragraph to incorporate highlighted data. This information will be incorporated into the

next revision.

Change Specifics:

14.4.2 SNMP Community Strings

The modem uses community strings as a password scheme that provides authentication

before gaining access to the modem agent’s MIBs.

In “SNMP v1/v2c”, the community string is sent unencrypted in the SNMP packets.

Caution must be taken by the network administrator to ensure that SNMP packets travel

only over a secure and private network if security is a concern. A packet sniffer can

easily obtain the community string by viewing the SNMP traffic on the network.

The community string is entered into the MIB Browser or Network Node Management

software and is used to authenticate users and determine access privileges to the SNMP

agent.

The user defines three Community Strings for SNMP access:

• Read Community default = public

• Write Community default = private

• Trap Community default = comtech

Note: Maximum number of characters for community strings shall not exceed 20.

All printable ASCII characters, except, ‘\’ and ‘~’, are allowed. No trailing spaces

for community strings.

s:\tpubs\manuals\released_word\modems\cdm570-570l_rev3\addendums erratas\errata d.doc 1

Errata D

Comtech EF Data Documentation Update

Subject: Revised 14.5 Telenet Interface for HyperTerminal

Date: March 15, 2006

Document: CDM-570/570L Installation and Operation Manual, Revision 3,

dated October 5, 2005

Part Number: MN/CDM570L.ED3

Collating Instructions: Attach this page to page 14-7

Comments:

Add paragraph and screen captures to 14.5 Telnet Interface. This information will be

incorporated into the next revision.

Change Specifics:

There is a disadvantage when using Windows DOS as Telnet Client. Since Windows DOS

cannot translate a ‘\r’ to a ‘\r\n’ for the messages coming from Telnet Server, the multi-line

command response (for example, FRW? response) will be displayed as one line, with the latter

lines overwriting the previous lines.

In order to view the full response messages, CEFD recommends using HyperTerminal

configured as Telnet Client. To do so, configure the HyperTerminal as following:

1. Connect using TCP/IP instead of COM1 or COM2;

2. ASCII setup: check both the "Send line ends with line feeds" and "Append line feeds to

incoming line ends" options.

See the following screen captures for examples.

s:\tpubs\manuals\released_word\modems\cdm570-570l_rev3\addendums erratas\errata d.doc 2
