QUICKSPECS

Overview

1DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

HAT

’

• Intel Pentium®III Xeon

700

MHz Processors (up to 4) with

1-MB, or2-MB L2 Cache

• ServerWorks Enterprise

ServerSet

III HE chipset

• 512 MB PC100 Advanced ECC

SDRAM Memory standard,

expandable to 16 GB (Advanced

ECC Memory Technology – data

protection in the eventof an

SDRAM component failure)

• Integrated Smart Array Controller

• Compaq NC3134 Fast Ethernet

NIC 64 PCI DualBase 10/100

(upgradable to Gigabit)

• 64-bit/66-MHz slots for 64-bit/

66-MHz expansion card support

• Improved Serviceability and

Intelligent Manageability

A G

LANCE

• Rack optimized (4U = 7″) 4-way

computing power for your data

center or ISP/ASP environments

• Six PCI slots, 4 Hot Pluggable:

2 64-bit/66-MHz Hot Plug

2 64-bit/33-MHz Hot Plug

1 64-bit/33-MHz Non-Hot Plug

1 32-bit/33-MHzNon-Hot Plug

• Standard Wide Ultra2/Ultra3-

ready Drive Cage (4 x 1”)

• Internal Hot Plug Drive Storageo

up to 145.6 GB with 36.4-GB 1″

Wide Ultra2/Ultra3 hard drives

• Uncompromising reliability

features:

Industry-Standard PCI Hot

Plug with push button

functionality

7 x 24 cooling provided by8

Hot Plug Redundant System

Fans

Hot Plug 450-Watt Power

Supply with optional redundant

hot plug power supplies

• Automatic Server Recovery2

(ASR-2 ), Integrated Remote

Console (IRC), Compaq Insight

Manager and SmartStart

• Toolless internal design for easy

access to system components

• Protected by Compaq Services,

including a limited three-year

parts, laborand on-site warranty

with optional four hour response.

Pre-Failure Warrantyand

Compaq Service and Support

Programsavailable on a

Worldwide basis— Certain

restrictionsand exclusionsapply.

Consultthe Compaq Customer

Support Center at 1-800-345-

1518 for details. In Canada,

consult the Product Information

Center at 1-800-567-1616 for

details.

4 x 1″Wide Ultra2/Ultra3 Drive Cage

8. High Speed IDE CD-ROM

9. Power Supplies (2 shown above, 700-MHz

Models ship standard with one Power Supply)

10. Front Panel LED Display

11. Removable Center Wall

12. Additional Hot Plug Redundant Fans

1. Six PCI I/O Slots (Two 66-MHz, 4 hot

plug)

2. Peripheral Board

3. Redundant Hot Plug Fan

4. Memory Board

5. Processors (up to 4 supported)

6. 1.44-MB Diskette Drive

QUICKSPECS

Standard Features

2DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

Processor

Intel Pentium III Xeon processor 700 MHz

(Note: One or two processors ship standard depending on Model)

Cache Memory – One of the following:

2-MB level 2 writeback cache per processor standard

1-MB level 2 writeback cache per processor standard

Upgradability

Upgradable to quad processing

Support for future processor upgrades

Memory

Standard 512 MB (PC100-MHz Advanced ECC SDRAM memory)

Maximum 16 GB

Note: Advanced ECC Memory Technology protects the data even in the event of an entire SDRAM component

failure. Embedded in the chipset design, this feature allows the use of Industry-Standard Registered DIMMs.

Network Controller

Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Base 10/100 (upgradable to Gigabit)

Expansion Slots

I/O (Total) 6, 5 available

64-bit/66-MHz PCI Hot Plug 2, 1 available

64-bit/33-MHz PCI Hot Plug 2, 2 available

64-bit/33-MHz PCI Non-Hot Plug 1, 1 available

32-bit/33-MHz PCI Non-Hot Plug 1, 1 available

Storage Controller

Integrated Smart Array Controller (supports Internal RAID 0, 1, 0+1, 5 and external tape devices)

Storage

Diskette Drives 1.44 MB

CD-ROM High Speed IDE CD-ROM Drive (slim line)

Hard Drives None

Maximum Internal Storage 145.6 GB (4 x 36.4 GB 1” drives) (internal hot plug drive cage)

Interfaces

Parallel 1

Serial 1 (Note: You can configure a second serial device to your ProLiant DL580 server

by installing the auxiliary serial connector that ships with the server. The

auxiliary connector attaches to a serial port B on the peripheral board and

exits the rear of the server through the auxiliary serial knockout located

directly above the redundant power feeds.)

Pointing Device (Mouse) 1

Graphics 1

Hot Plug Keyboard 1

External Wide Ultra2 SCSI 1

Network RJ-45 2

Graphics

Integrated 1280 x 1024, 256 color on PCI local bus, 2-MB video memory

Form Factor

Rack (4U = 7″), ships with sliding rails and cable management

ODELS

Compaq ProLiant

DL580

Available in multiple

configurations

QUICKSPECS

Standard Features

3 DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

Compaq Software

Compaq Insight Manager™

The comprehensive system management tool that monitors the operation of

Compaq servers, workstations and clients

Compaq SmartStart



The server configuration and software integration tool from Compaq

Array Configuration Utility

(ACU) with Smart Array

Controllers

Same easy to use yet powerful graphical user interface (GUI) configuration utility

and easy to navigate wizards for all Smart Array Controllers

Intelligent Manageability

Compaq Remote Insight Lights Out Edition support

Automatic Server Recovery-2 (ASR-2)

Compaq Insight Manager

Integrated Remote Console-IRC (with an internal modem)

Integrated Management Log (IML)

Server Health logging

Off-Line Backup Processor capability

Dynamic sector repairing and drive parameter tracking (with Smart Array controllers)

Redundant/adaptive load balancing NIC Support

Availability

PCI Hot Plug with push button functionality

7 x 24 cooling provided by 8 Hot Plug Redundant System Fans

Integrated Smart Array Controller for RAID data protection/performance and maximum data bandwidth

Advanced Error Checking and Correcting (ECC) SDRAM Technology

Hot Plug Ultra2/Ultra3 Drive Bays

Redundant Hot Plug Power Supplies (optional)

Redundant NIC support

Pre-Failure Warranty (covers processors, hard drives, and memory)

Serviceability

Internal Diagnostics Display (IDD) indicates specific DIMM or processor failure

LED display on front panel indicates interlock, fan, and power failures

Spring-loaded memory board release latches prevent unseating incidents

PCI Card Guide holds long PCI cards in place during transit

Customer driven interior system fan design (all system fans interior to chassis)

Removable, internal center panel eases access to the power supply and hard drive backplane boards

Optional High Voltage PDU cable exits chassis at a right angle to simplify cable management at rear of chassis

Security

Power-on password

Hot plug keyboard password

Diskette drive control

Diskette boot control

Network Server Mode

Security Provision

Parallel and serial interface control

Administrator’s password

Disk configuration lock

Hot plug access security

QUICKSPECS

Standard Features

4DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

Power Supply

One 450-Watt Hot Plug Power Supply (optional Redundant Hot Plug Power Supply Option Kit)

Required Cabling

For required cabling information, refer to the Compaq web site at

http://www.compaq.com/products/servers/proliantDL580/.

Note: This web site available in English only.

OS Support

Microsoft Windows NT Server

Microsoft Windows 2000

Novell NetWare

SCO OpenServer

SCO UnixWare

IBM OS/2 Warp Family

LINUX (RedHat, S.U.S.E., TurboLinux Server, Caldera eServer)

Sun Solaris Intel Platform Edition

Banyan VINES

Note: For a more complete and up-to-date listing of supported OS’s and versions, please visit our OS Support Matrix

at: ftp://ftp.compaq.com/pub/products/servers/os-support-matrix-310.pdf.

Note: For an up-to-date listing of the latest drivers available for the Compaq ProLiant DL580, please see:

http://www.compaq.com/support/files/server/us/index.html.

Please note these web sites are available in English only.

Service and Support

Compaq Services provides a wide range of service offerings, including a three-year, limited warranty that is fully

supported by a worldwide network of resellers and service providers, lifetime toll-free 7 x 24 hardware technical

phone support and Pre-Failure Warranty coverage of hard drives, memory and processors. Disaster recovery

services are available through partnership with Comdisco.

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center at 1-800-345-1518 for

details. In Canada, consult the Product Information Center at 1-800-567-1616 for details.

QUICKSPECS

Standard Features

5 DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

Models

DL580R01 X700-2MB,

512MB (2P)

155618-001

Processor(s) (2) Intel Pentium III Xeon 700 MHz

processors Network Controller Compaq NC3134 Fast Ethernet NIC

64 PCI Dual Base 10/100

Cache Memory 2-MB Level 2 writeback cache per

processor Storage Controller Integrated Smart Array Controller

Memory Hard Drive None

Standard 512 MB Internal Storage 145.6 GB maximum

Maximum 16 GB Optical Drive High Speed IDE CD-ROM Drive

Form Factor Rack 4U

DL580R01 X700-1MB,

512MB (1P)

155617-001

Processor(s) (1) Intel Pentium III Xeon 700 MHz Network Controller Compaq NC3134 Fast Ethernet NIC

64 PCI Dual Base 10/100

Cache Memory 1-MB Level 2 writeback cache per

processor Storage Controller Integrated Smart Array Controller

Memory Hard Drive None

Standard 512 MB Internal Storage 145.6 GB maximum

Maximum 16 GB Optical Drive High Speed IDE CD-ROM Drive

Form Factor Rack 4U

QUICKSPECS

Options

6DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

Processor

Pentium III Xeon X7002MB Processor Option Kit 174449-B21

Pentium III Xeon X700-1MB Processor Option Kit 174448-B21

Note: The increasing power of new high-performance processor technology requires increased cooling efficiency for

rack-mounted servers. The new Compaq Rack 9000 series (120663-xx1 (42U), 120664-xx1 (36U), 120665-xx1

(22U)) provides enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using

the latest processors.

When installing a server with Pentium III Xeon processors running at speeds of 550 MHz or greater in Compaq

Rack 7000 series racks (165753-xx1 (42U), and 163747-xx1 (22U)), the new processor technology requires the

installation of Compaq’s new High Airflow Rack Door Insert (327281-B21 (42U) or 157847-B21 (22U)).

Memory

4096-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 1024 MB) 189083-B21

2048-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 512 MB) 189082-B21

1024-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 256 MB) 189081-B21

512-MB PC100 Advanced ECC SDRAM Memory Kit (4 x 128 MB) 189080-B21

Hard Drives

Wide Ultra3 SCSI – Universal Hot Plug

36.4-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″) 176496-B22

18.2-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″) 142673-B22

9.1-GB Wide Ultra3 SCSI 10,000 rpm Drive (1″) 142671-B22

18.2-GB Wide Ultra3 SCSI 15,000 rpm Drive (1″) 188122-B22

9.1-GB Wide Ultra3 SCSI 15,000 rpm Drive (1″) 188120-B22

Note: Wide Ultra3 SCSI drives require the purchase and installation of Wide Ultra3 Controllers or Adapters to run at

Wide Ultra3 speeds.

Wide Ultra2 SCSI – Universal Hot Plug

18.2-GB Wide Ultra2 SCSI Drive (1″) 388144-B22

9.1-GB Wide Ultra2 SCSI Drive (1″) 123065-B22

Storage Controllers

Smart Array 431 Controller 127695-B21

Smart Array 3200 Controller 295643-B21

Smart Array 4200 Controller 295636-B21

Smart Array 5302/32 Controller 166207-B21

Smart Array 5302/64 Controller 124992-B21

Smart Array 5304/128 Controller 158939-B21

Ultra3 Channel Expansion Module for Smart Array 5300 Controller 153507-B21

64-bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter 154457-B21

64-bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter 129803-B21

Communications

Compaq NC3123 Fast Ethernet NIC PCI 10/100 WOL 174830-B21

Compaq NC3122 Fast Ethernet NIC PCI Dual 10/100 317450-B21

Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Port 10/100 138603-B21

Compaq NC3135 Fast Ethernet Module Dual 10/100 Upgrade Module for NC3134 and NC3131 138604-B21

Compaq NC6132 Gigabit Module 1000 SX Upgrade Module for NC3134 and NC3131 338456-B23

Compaq NC6133 Gigabit Module 1000 LX Upgrade Module for NC3134 and NC3131 338456-B24

Compaq NC3133 Fast Ethernet Module 100 FX Upgrade Module for NC3134 and NC3131 338456-B25

Compaq NC6134 Gigabit NIC 64 PCI 1000 SX 174818-B21

Compaq NC4621 Token Ring NIC PCI 4/16 WOL 379956-B21

IBM 16/4 Token Ring PCI Special 133749-B21

QUICKSPECS

Options

7 DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

Communications (continued)

ServerNet PCI Adapter 309833-B22

4M Cable 309834-B23

30M Cable 309834-B22

ServerNet II PCI Adapter Card Kit 174736-B21

ServerNet II 12-Port Copper Serial Switch Kit 174739-001

ServerNet II 5-meter Copper Serial Cable Kit 174737-B21

ServerNet II 10-meter Copper Serial Cable Kit 174738-B22

Redundant Options

Compaq Hot Plug Redundant Power Supply Option Kit 105739-001

Management Options

Compaq Remote Insight (PCI) LAN + NA Modem 294013-002

Compaq Remote Insight Board (PCI) LAN/Serial without modem 294013-B24

Compaq Remote Insight Board (PCI) LAN only 294013-B25

Compaq Remote Insight Lights-Out Edition 157866-001

Monitors

TFT5010 15″Flat Panel Monitor (Opal) 104741-001

TFT5010 15″Flat Panel Monitor (Carbon) 154486-001

TFT5005 15″Flat Panel Monitor (Opal) 201431-001

TFT5005 15″Flat Panel Monitor (Carbon) 201430-001

TFT5000R Flat Panel 120207-001

P700 Color 17 Monitor 380207-001

V710 Color 17 Monitor (opal) 187895-001

V500 Color 15 Monitor 325900-001

S510 Color Monitor 168636-001

S710 Color 17 Monitor 152991-001

CRT Code Key

Dash # Description

-001 NA Kit with US Power Cord

-002 Carbon model with US Power Cord

-003 Touch Screen model with US Power Cord

-004 NAFTA model with US Power Cord

(Made in Mexico)

-005 NA Kit with Powered Speakers

-006 GSA model with US Power Cord

-007 NH MPR model with US power cord

(Made in Mexico)

-B24 TCO model without power cord (Digital

Classic)

Note: All models above are NH

QUICKSPECS

Options

8DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

External Tape Drives (Note: Only External Tape Drives supported by the ProLiant DL580)

External 20/40-GB DAT DDS-4 Tape Drive 157770-001

20/40-GB DAT 8 Cassette Autoloader External 166505-001

External 40/80-GB DLT Drive 146197-B21

External 35/70-GB DLT Drive 242521-B21

External 20/40-GB DLT Drive (Opal) 340744-B22

External AIT 50-GB Tape Drive 157767-001

External AIT 35-GB Tape Drive 388507-001

DDS-4 Media (10 pack) 152842-001

20/40-GB DAT 8 Cassette Magazine with Media 171532-B21

12-GB DDS-3 DAT Cassette (10 Pack) 295515-B21

DAT Cleaning Cassette 242781-001

AIT 35-GB Data Cassette (five pack) 402371-B21

AIT 50-GB Data Cassette (five pack) 152841-001

DLT IV Drive Cartridge (single) 295194-B21

DLT IV Drive Cartridge (seven pack) 295192-B21

DLT Cleaning Cartridge 199704-001

Note: Please see the Compaq 20/40-GB DAT Drive, Compaq 20/40-GB DAT DDS-4 8 Cassette Autoloader, Compaq

40/80-GB DLT Drive, Compaq 35/70-GB DLT Drive, Compaq 20/40-GB DLT Drive, Compaq AIT 50-GB Tape

Drive, or the Compaq AIT 35-GB Tape Drive for an up-to-date listing of the latest O/S Support details, please

see the following:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note this web site is available in English only.

QUICKSPECS

Options

9 DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

External Storage - Rack

Compaq StorageWorks Enclosure Model 4214R (rack-mountable) 103381-001

Compaq StorageWorks Enclosure Model 4254R (rack-mountable) 138151-001

Compaq StorageWorks Enclosure Model 4314R (rack-mountable) 190209-001

Compaq StorageWorks Enclosure Model 4354R (rack-mountable) 190211-001

Note: The Compaq StorageWorks Enclosure 4200/4300 Family support the Wide Ultra2/Ultra3 1″Hot Plug Hard

Drives.

Rack-Mountable SCSI Storage Expander II 332607-001

Rack-Mountable ProLiant Storage System Model UE 348700-001

Rack-Mountable ProLiant Storage System Model U2 304100-B22

Note: The Compaq ProLiant Storage System Models UE and U2 support the Wide-Ultra SCSI-3 Drives.

ProLiant Storage System /U Redundant Power Supply 224206-001

StorageWorks Enclosure 4200 Redundant Power Supply Option 119826-B21

StorageWorks Enclosure 4200 Ultra2 Dual Bus I/O Module Option 119829-B21

StorageWorks Enclosure 4200 Ultra3 Single Bus I/O Module Option 190212-B21

StorageWorks Enclosure 4200 Ultra3 Dual Bus I/O Module Option 190213-B21

StorageWorks Enclosure Tower to Rack Conversion Kit 150213-B21

QUICKSPECS

Options

10 DA-10635-01-008 — 09.13.2000

Compaq ProLiant DL580

StorageWorks DLT Departmental Library

TL895 (96 slot) library unit, 2 drive 349350-B22

TL895 (96 slot) library unit, 3 drive 349350-B23

TL895 (96 slot) library unit, 4 drive 349350-B24

TL895 (96 slot) library unit, 5 drive 349350-B25

TL895 (96 slot) library unit, 6 drive 349350-B26

TL895 (96 slot) library unit, 7 drive 349350-B27

TL891 DLT library unit, 1 drive Rack, FWD 120876-B21

TL891 DLT library unit, 2 drive

Rack, FWD 120876-B22

TL881 DLT Library, 1 drive Rack, FWD 128669-B21

TL881 DLT Library, 2 drive

Rack, FWD 128669-B22

Add-On 20/40-GB Drive for TL881 128671-B21

Add-On 35/70-GB Drive for TL891 120878-B21

DLT7000 drive upgrade kit

Note: Available for TL895 DLT Library only. 349351-B21

MiniLibrary Data Unit

Note: Available for TL881, TL891 DLT Libraries only. 128670-B21

MiniLibrary Expansion Unit

Note: Available for TL881, TL891 DLT Libraries only. 120877-B21

StorageWorks Dual Channel Ultra-Wide Differential Library Host Bus Adapter

Note: The StorageWorks Dual Channel Ultra-Wide Differential Library Host Bus Adapter is

required to support FWD-based tape libraries.

157229-B21

DLT IV Data Cartridges (single pack) 295194-B21

DLT IV Data Cartridges (7 pack) 295192-B21

DLT Cleaning Cartridge 199704-001

MiniLibrary pass-through Mechanism Kit

Note: Available for TL881, TL891 DLT Libraries only. 120880-B21

10 Slot Magazine

Note: Available for TL881, TL891 DLT Libraries only. 120881-B21

MiniLibrary Table Top to Rack Mount Conversion Kit, Metric/RETMA racks

Note: Available for TL881, TL891 DLT Libraries only. 120882-B21

MiniLibrary Table Top to Rack Mount Conversion Kit, Compaq racks

Note: Available for TL881, TL891 DLT Libraries only. 120883-B21

Note: Please see the TL881, TL891, or the TL895 Automated DLT Tape Library Solution QuickSpecs for additional

information including Upgrade Kits, Accessories, ProLiant Connectivity Kits, Host Bus Adapters, SCSI Cable Kits,

and Localization Kits and additional options needed for a complete solution at:

http://www.compaq.com/products/quickspecs/North_America/10233_na.html

Please note this web site is available in English only.

Otros manuales para ProLiant DL580

Tabla de contenidos

Otros manuales de Servidor de Compaq

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Manual de referencia

Compaq

Compaq ML350 - ProLiant - G2 Manual

Compaq

Compaq 195294-001 - ProLiant - ML370R Manual de usuario

Compaq

Compaq AlphaServer GS60 Manual de usuario

Compaq

Compaq 244857-001 - TaskSmart - C4000 Model... Manual de usuario

Compaq

Compaq DL760 - ProLiant - 1 GB RAM Guía de instalación

Compaq

Compaq DL320 - ProLiant - G3 Manual

Compaq

Compaq ALPHA GS320 Manual de usuario

Compaq

Compaq t1000 - Terminal Thin Client PC Hoja de especificaciones

Compaq

Compaq 195294-001 - ProLiant - ML370R Instrucciones de funcionamiento y seguridad

Compaq

Compaq 195294-001 - ProLiant - ML370R Manual de usuario

Compaq

Compaq ProLiant 5500 Instrucciones de funcionamiento y seguridad

Compaq

Compaq BL10e - HP ProLiant - 512 MB RAM Manual de referencia

Compaq

Compaq ProLiant 400 Guía de inicio rápido

Compaq

Compaq 108164-003 - ProLiant - 800 Manual de usuario

Compaq

Compaq ProLiant ML350 (G2) Manual de usuario

Compaq

Compaq Evo Thin Client t20 Hoja de especificaciones

Compaq

Compaq AlphaServer GS160 Manual de usuario

Compaq

Compaq Proliant 800 Instrucciones de funcionamiento y seguridad

Compaq

Compaq DS10L - AlphaServer - 256 MB RAM Manual de usuario

Compaq

Compaq 6000 - ProLiant - 128 MB RAM Manual

Compaq

Compaq DL590 - HP ProLiant - 1 GB RAM Guía de referencia rápida

Compaq

Compaq 1850R - ProLiant - 128 MB RAM Manual de usuario

Compaq

Compaq 108164-003 - ProLiant - 800 Guía de inicio rápido

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario

Planet

Planet NAS-7410 Manual de usuario
