Compaq Evo N600c Instrucciones de instalación

Hardware Guide

Evo Notebook N600c Series

Document Part Number: 229045-002

November 2001

This guide identifies computer hardware features and provides

procedures for using them. It also includes instructions for setting

up the computer, information about connecting external devices,

and computer specifications.

229045-002.book Page 1 Friday, September 21, 2001 11:16 AM

Compaq and the Compaq logo Registered in U. S. Patent and Trademark

Office. Evo is a trademark of Compaq Information Technologies Group,

L.P.

Microsoft, MS-DOS, Windows, Windows NT are trademarks of Microsoft

Corporation.

All other product names mentioned herein may be trademarks of their

respective companies.

Compaq shall not be liable for technical or editorial errors or omissions

contained herein. The information in this document is provided “as is”

without warranty of any kind and is subject to change without notice. The

warranties for Compaq products are set forth in the express limited

warranty statements accompanying such products. Nothing herein should

be construed as constituting an additional warranty.

Hardware Guide

Second Edition November 2001

First Edition June 2001

Document Part Number: 229045-002

229045-002.book Page 2 Friday, September 21, 2001 11:16 AM

Hardware Guide iii

Contents

1Hardware and Software Setup

Setting Up the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 1–1

Setting Up the Software . . . . . . . . . . . . . . . . . . . . . . . . . 1–4

Installing Optional Applications. . . . . . . . . . . . . . . . 1–4

After Software Setup . . . . . . . . . . . . . . . . . . . . . . . . 1–5

2A Look at the Computer

Display Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1

Pointing Device Components (Pointing Stick Models) . 2–2

Pointing Device Components (TouchPad Models). . . . . 2–3

Pointing Device Components (Dual Models) . . . . . . . . . 2–4

Top Components: Speakers, Mini PCI Compartment. . . 2–5

Top Components: Lights. . . . . . . . . . . . . . . . . . . . . . . . . 2–6

Top Components: Buttons, Keys, Switches . . . . . . . . . . 2–8

Left Side Components. . . . . . . . . . . . . . . . . . . . . . . . . . 2–10

Right Side Components. . . . . . . . . . . . . . . . . . . . . . . . . 2–11

Front Panel Components . . . . . . . . . . . . . . . . . . . . . . . . 2–12

Rear Panel Components . . . . . . . . . . . . . . . . . . . . . . . . 2–13

Bottom Components . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–14

Additional Standard Components . . . . . . . . . . . . . . . . . 2–16

3Pointing Devices and Keyboard

Using a Pointing Device . . . . . . . . . . . . . . . . . . . . . . . . . 3–1

Using the Pointing Stick (Pointing Stick Models) . . 3–1

Using the TouchPad (TouchPad Models). . . . . . . . . 3–2

229045-002.book Page iii Friday, September 21, 2001 11:16 AM

iv Hardware Guide

Contents

Using the Dual Pointing Device (Dual Models). . . . 3–3

Setting Pointing Device Preferences . . . . . . . . . . . . 3–4

Replacing the Pointing Stick Cap. . . . . . . . . . . . . . . 3–5

Using Hotkeys and Shortcut Keys . . . . . . . . . . . . . . . . . 3–6

Hotkey and Shortcut Key Quick Reference . . . . . . . . . . 3–7

Hotkey and Shortcut Key Procedures. . . . . . . . . . . . 3–8

Turn a MultiPort Device On or Off (Fn+F2) . . . . . . 3–8

Switch Display and Image (Fn+F4) . . . . . . . . . . . . . 3–9

Adjust System Volume (Fn+F5). . . . . . . . . . . . . . . 3–10

Initiate Quick Controls (Fn+F6) . . . . . . . . . . . . . . . 3–10

Set Power Conservation Level (Fn+F7) . . . . . . . . . 3–11

View Battery Charge Information (Fn+F8) . . . . . . 3–11

Adjust Screen Brightness (Fn+F10) . . . . . . . . . . . . 3–12

Display System Information (Fn+esc) . . . . . . . . . . 3–12

Stretch Text (Fn+T) . . . . . . . . . . . . . . . . . . . . . . . . 3–12

Using the Fn Key Sequentially . . . . . . . . . . . . . . . . . . . 3–13

Using the Embedded Numeric Keypad. . . . . . . . . . . . . 3–14

Enabling the Numeric Keypad . . . . . . . . . . . . . . . . 3–14

Disabling the Numeric Keypad . . . . . . . . . . . . . . . 3–14

Using Numeric Keypad Keys as Standard Keys . . 3–15

Enabling the Numeric Keypad at Startup . . . . . . . . 3–15

Using the Easy Access Buttons. . . . . . . . . . . . . . . . . . . 3–16

Using Default Settings . . . . . . . . . . . . . . . . . . . . . . 3–16

Using Custom Assignments and Schemes . . . . . . . 3–17

4Battery Packs

Charging Battery Packs. . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

Using a New Battery Pack . . . . . . . . . . . . . . . . . . . . . . . 4–2

Replacing a Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . 4–2

Replacing a Primary Battery Pack . . . . . . . . . . . . . . 4–3

Replacing a MultiBay Battery Pack . . . . . . . . . . . . . 4–4

Storing a Battery Pack. . . . . . . . . . . . . . . . . . . . . . . . . . . 4–5

Recycling a Used Battery Pack . . . . . . . . . . . . . . . . . . . . 4–5

229045-002.book Page iv Friday, September 21, 2001 11:16 AM

Contents

Hardware Guide v

5Removable Drives

Adding a Drive to the System . . . . . . . . . . . . . . . . . . . . . 5–1

Caring for Drives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2

Removing and Inserting a Primary Hard Drive . . . . . . . 5–2

Removing and Inserting a MultiBay Drive . . . . . . . . . . . 5–6

Using a MultiBay Hard Drive Adapter. . . . . . . . . . . 5–6

Removing a Drive from the MultiBay . . . . . . . . . . . 5–9

Inserting a Drive into the MultiBay . . . . . . . . . . . . 5–11

Inserting and Removing Drive Media. . . . . . . . . . . . . . 5–12

Inserting a CD, CD-RW or DVD . . . . . . . . . . . . . . 5–12

Removing a CD, CD-RW or DVD (Power) . . . . . . 5–13

Removing a CD, CD-RW or DVD (No Power) . . . 5–14

Inserting a Diskette or Disk . . . . . . . . . . . . . . . . . . 5–15

Removing a Diskette or Disk . . . . . . . . . . . . . . . . . 5–15

Using Drive Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–15

Displaying Media Contents . . . . . . . . . . . . . . . . . . 5–15

Initiating Suspend or Hibernation. . . . . . . . . . . . . . 5–16

6Audio and Video

Using Audio Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–1

Identifying Audio Features . . . . . . . . . . . . . . . . . . . . 6–1

Using the Microphone Jack . . . . . . . . . . . . . . . . . . . 6–2

Using the Stereo Speaker/Headphone Jack . . . . . . . 6–3

Adjusting Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . 6–3

Using Video Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 6–4

Using the Composite Video-Out Jack . . . . . . . . . . . 6–4

Changing the Video Mode . . . . . . . . . . . . . . . . . . . . 6–5

7External Device Connections

Connecting a Standard Device . . . . . . . . . . . . . . . . . . . . 7–1

Connecting a Modem Cable . . . . . . . . . . . . . . . . . . . . . . 7–2

Connecting a Network Cable . . . . . . . . . . . . . . . . . . . . . 7–3

229045-002.book Page v Friday, September 21, 2001 11:16 AM

vi Hardware Guide

Contents

Connecting an External Diskette Drive Bay . . . . . . . . . . 7–4

Connecting a USB Device. . . . . . . . . . . . . . . . . . . . . . . . 7–4

Using a USB Device. . . . . . . . . . . . . . . . . . . . . . . . . 7–6

Enabling USB Legacy Support. . . . . . . . . . . . . . . . . 7–6

Linking to an Infrared Device . . . . . . . . . . . . . . . . . . . . . 7–7

Configuring the Infrared Port . . . . . . . . . . . . . . . . . . 7–8

Setting Up an Infrared Transmission . . . . . . . . . . . . 7–8

Using Suspend with Infrared . . . . . . . . . . . . . . . . . . 7–9

Planning a Docking System . . . . . . . . . . . . . . . . . . . . . 7–10

Docking Considerations . . . . . . . . . . . . . . . . . . . . . 7–10

Docking Alternatives . . . . . . . . . . . . . . . . . . . . . . . 7–10

Connecting an Optional Cable Lock . . . . . . . . . . . . . . . 7–11

8Hardware Upgrades

Adding and Using PC Cards . . . . . . . . . . . . . . . . . . . . . . 8–1

Selecting a PC Card slot . . . . . . . . . . . . . . . . . . . . . . 8–1

Configuring a PC Card . . . . . . . . . . . . . . . . . . . . . . . 8–2

Inserting a PC Card. . . . . . . . . . . . . . . . . . . . . . . . . . 8–3

Removing a PC Card . . . . . . . . . . . . . . . . . . . . . . . . 8–4

Turning Off Power to a PC Card . . . . . . . . . . . . . . . 8–5

Upgrading Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–6

Viewing Memory and Hibernation File Information 8–6

Removing or Inserting a Memory Expansion Board 8–7

9Specifications

Regulatory Agency Series Numbers . . . . . . . . . . . . . . . . 9–1

Computer Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . 9–2

Operating Environment. . . . . . . . . . . . . . . . . . . . . . . . . . 9–2

Rated Input Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9–3

Modem Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . 9–3

Index

229045-002.book Page vi Friday, September 21, 2001 11:16 AM

Hardware Guide 1–1

Hardware and Software Setup

Setting Up the Hardware

ÄCAUTION:

Setup must begin with connecting the computer to AC power.

To prevent file corruption, possible damage to components, and ensure

that the correct drivers load during initial setup:

■Do not set up the computer while it is docked in an optional

docking base.

■Do not remove the battery pack until the computer has been

connected to external AC power.

■Run the computer on external AC power, not on battery power,

throughout initial setup.

229045-002.book Page 1 Friday, September 21, 2001 11:16 AM

1–2Hardware Guide

Hardware and Software Setup

1. Place the computer on a flat surface near an electrical outlet,

then connect the computer to external AC power.

Plug the AC Adapter cable into the DC power connector 1.

Plug the power cord into the AC Adapter 2and into an

electrical outlet 3. (Power cords and outlets vary by country.)

Connecting the computer to external power

2. Open the computer by sliding the display release latch to the

right 1and raising the display 2.

Opening the computer

229045-002.book Page 2 Friday, September 21, 2001 11:16 AM

Hardware and Software Setup

Hardware Guide 1–3

3. Turn on the computer by sliding and releasing the power

switch 1.

Turning on the computer

When the computer is turned on:

■The power/suspend light 2turns on.

■The battery pack in the battery bay begins to charge and the

battery light 3turns on. The battery light remains on while

the battery pack is charging and turns off when the battery

pack is fully charged.

■You are prompted to begin software setup.

229045-002.book Page 3 Friday, September 21, 2001 11:16 AM

1–4Hardware Guide

Hardware and Software Setup

Setting Up the Software

The initial setup prompt appears on the screen as soon as the

computer is connected to external power.

Before responding to the initial setup prompt and proceeding

through the online instructions, read the following caution and

initial setup information:

ÄCAUTION: To prevent file corruption and ensure that the correct device

drivers install during initial setup:

■Do not unplug the computer from the electrical outlet.

■Do not shut down the computer.

■Do not remove or insert a drive.

■Once you begin initial software setup, you must complete the

entire process. Setup time varies by computer configuration.

■If you are prompted to select a language or operating system,

choose carefully.

❏The languages and operating system that you do not

choose will be deleted from the system and cannot be

restored during initial setup.

❏An operating system available during initial setup is

enhanced by Compaq. When an operating system is

deleted, the enhancements are also deleted.

■During the setup process, you must accept the End User

License Agreement to continue.

Installing Optional Applications

You can install third-party applications or preloaded Compaq

utilities at any time after initial setup is complete.

■To install a third-party application, refer to the documentation

included with the application.

229045-002.book Page 4 Friday, September 21, 2001 11:16 AM

Otros manuales para Evo N600c

Tabla de contenidos

Otros manuales de Computadora portátil de Compaq

Compaq

Compaq Armada 1500C series Instrucciones de funcionamiento e instalación

Compaq

Compaq Armada 1500 Manual

Compaq

Compaq Armada E500 Series Actualización de firmware

Compaq

Compaq N400c - Evo Notebook - PIII 700 MHz Instrucciones de instalación

Compaq

Compaq Presario CQ41-200 - Notebook PC Manual

Compaq

Compaq Presario X1100 - Notebook PC Manual de instrucciones y seguridad

Compaq

Compaq Compaq 311245-001 Manual de usuario

Compaq

Compaq Presario CQ20-100 - Notebook PC Manual

Compaq

Compaq Presario 1400 - Notebook PC Hoja de información del producto

Compaq

Compaq Pavilion g6-2000 Manual de usuario

Compaq

Compaq Armada M300 Series Manual

Compaq

Compaq Evo N180 Manual de usuario

Compaq

Compaq Armada E500 Series Manual de usuario

Compaq

Compaq Presario X1000 - Notebook PC Manual de usuario

Compaq

Compaq Notebook 100 Series Manual de usuario

Compaq

Compaq Presario V3300 - Notebook PC Manual de usuario

Compaq

Compaq Armada 6500 Guía de referencia rápida

Compaq

Compaq Evo N620c Instrucciones de instalación

Compaq

Compaq Presario X1000 - Notebook PC Instrucciones de funcionamiento

Compaq

Compaq EVO NOTEBOOK N410C Guía de inicio rápido

Compaq

Compaq Compaq Presario Instrucciones de instalación y mantenimiento

Compaq

Compaq 307502-001 Manual de usuario

Compaq

Compaq Deskpro 286 - Desktop PC Manual

Compaq

Compaq EVO NOTEBOOK N410C Instrucciones de uso

Manuales populares de Computadora portátil de otras marcas

HP ze2401xt - Pavilion Notebook PC Manual de usuario

Velocity

Velocity NoteMagix M10 Manual de usuario

Dell

Dell Alienware 17 R2 Manual de usuario

Toshiba

Toshiba A105-S2236 Manual de usuario

HP ENVY 17 Manual

Winbook

Winbook LM Manual de usuario

Dell

Dell Inspiron 1464 Manual de usuario

Dell

Dell Inspiron 15R 5537 Manual de usuario

HP PROBOOK 4520S Manual

Dell

Dell Latitude ATG D620 Manual de usuario

Sony

Sony VAIO PCG-FX270 Manual de usuario

Dell

Dell Latitude 7310 Manual de usuario

Dell

Dell Precision GU806 Manual de usuario

Sony

Sony VAIO PCG-R505JLK Manual de usuario

Lenovo

Lenovo THINKPAD X32 Manual de usuario

HP Compaq tc4200 Guía de inicio rápido

Toshiba

Toshiba mini NB300 Manual de usuario

Lenovo

Lenovo ThinkPad X201 Tablet Manual
