Compaq 7000 Series Manual

United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH
INFORMATION
SPECIFICATIONS
See the Notice for copyright and trademark
information, and the Preface for symbol
conventions and Technician Notes.
Click to download ZIP file of
complete MSG to hard drive
This MSG will be periodically maintained and
updated as needed.
To report a technical problem, contact your
Regional Support Center or IM Help Center.
For content comments or questions, contact Tech
Support

United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH INFORMATION
SPECIFICATIONS
PRODUCT  DESCRIPTION - INDEX
PAGE
Models and Features
CPU Controls and Lights
Side Access Panel
Internet Keyboard Controls
Rear CPU Connectors
Power Cord Set Requirements

United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT PROCEDURES
JUMPER AND SWITCH INFORMATION
SPECIFICATIONS
TROUBLESHOOTING - INDEX PAGE
Clearing CMOS
Power-On Self Test (POST)
Configuration
Preparing the computer
Setup
Accessing Compaq Utilities Option
Diagnostic Error Codes
Troubleshooting without Diagnostics
Checklist for Minor Problems
Hardware Installation
Power
USB Ports
Disk Drive
Hard Drive
CD-ROM, CD-RW, and DVD Drive
Resolving Hardware Conflicts


United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH INFORMATION
SPECIFICATIONS
ILLUSTRATED PARTS CATALOG -
INDEX PAGE
Mass Storage Devices
Cables
Standard & Optional Boards
Fax/ Modem
Keyboard
Miscellaneous Parts


United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH INFORMATION
SPECIFICATIONS
REMOVAL & REPLACEMENT
PROCEDURES - INDEX PAGE
This section provides general service information for Compaq
Series Personal Computers. Adherence to the procedures and
precautions described in this section is essential for safe and
proper service.
Electrostatic Discharge
Service Considerations
Preparation for
Disassembly
Serial Number
Side Access Panel
Graphics Card
Expansion Card
1394 Card
Memory Module
Hard Drive
Disk Drive
Removing the Top Door
Removing the CD Storage
Door
(Lower Front Panel)
Open the CD Storage Door
Optical and Mass Storage
Devices
CD, CD-RW and/or DVD Drive
Hard Drive
Disk Drive

Power Supply Assembly
Front I/O Board
System Board and
Components
RTC Battery
Microprocessor/Heatsink
Assembly


United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH INFORMATION
SPECIFICATIONS
JUMPER AND SWITCH
INFORMATION - INDEX PAGE
System Board
Hard Drives
CD and DVD Drive/ CD-RW Drive




United States
Compaq Presario Internet PC 7000 Series Computers
Models: 7PL270, 7PL273, 7PL287, 7PL290, 7PL295
PRODUCT DESCRIPTION
TROUBLESHOOTING
ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT
PROCEDURES
JUMPER AND SWITCH INFORMATION
SPECIFICATIONS
SPECIFICATIONS - INDEX PAGE
This section provides physical, environmental, and
performance specifications for Compaq Presario Internet
PC 7000 Series Computers.
CD-ROM and DVD Drive/  CD-RW Drive
Disk Drive
Fax/ Modem
Power Supply
System Board

United States
Compaq Presario Internet PC 7000 Series Computers SPECIFICATIONS
PRODUCT DESCRIPTION TROUBLESHOOTING ILLUSTRATED PARTS CATALOG
REMOVAL AND REPLACEMENT PROCEDURES JUMPER AND SWITCH INFORMATION SPECIFICATIONS
CD or DVD DRIVE/
CD-RW DRIVE
DISK DRIVE
FAX/MODEM
POWER SUPPLY
ASSEMBLY
SYSTEM BOARD

CD or DVD Drive/ CD-RW Drive
Please select a drive to view specifications:
CD Drive
DVD Drive
CD-RW Drive
CD Drive
Dimensions U.S. Metric
Width 5.75 in 15.01 cm (maximum)
Height 1.67 in 4.29 cm
Depth 8.23 in 20.80 cm
Weight 2.65 lb 1.200 kg
Modes Supported
CD-ROM Mode 1 and Mode 2
CD-DA Audio
CD-XA Mode 2, Form 1 and 2
Photo CD Multiple Session
Video-CDI Multiple Session
CD-Plus/CD-Extra/CD
Enhanced Multiple Sesssion

CD-RW Multiple Session

Block Size

CD-ROM Mode 1 and Mode 2

Form 1 (XA) 2048 bytes

CD-ROM Mode 2 2336 bytes

CD-DA 2324 bytes

CD-XA 2324 bytes

Center Hole 1.5 mm diameter

Diameter 120 mm/80mm

Thickness 1.2mm

Track Pitch 1.6mm

Laser

Divergence Angle 53.5 degrees +/- 1.5 degrees

Output Power 0.14 mW (@ objective lens)

Type Semiconductor laser GaAIAs

Wave Length 780nm +/- 25 nm

Access Time

Random < 100 ms (typical)

Full Stroke < 150 ms (typical)

Audio Output Level

Line Out 0.7 Vrms ±20%

Headphone 0.6 Vrms ±20%

Cache Buffer 256 KB

Data Transfer Rate

Mode 1 Mode 2

Sustained 4800 KB/sec 5475 KB/sec

KB.sec (32x) KB/sec (32x)

Burst MB/sec MB/sec

Startup Time < 5 sec

Stop Time < 5 sec

Return to top

DVD Drive

Dimensions U.S. Metric

Width 5.75 in 15.01 cm (maximum)

Height 1.67 in 4.29 cm

Depth 8.23 in 20.80 cm

Weight 1.80 lb 0.90 kg

Modes Supported Mode 1 and Mode 2

Block Size 2048 bytes

Center Hole 15 mm diameter

Disc Diameter 12 cm, 8 cm

Thickness 1.2 mm

Track Pitch 10.74 µm

Access Time

Random <180 ms typical

Full Stroke < 300 ms

Audio Output Level

Line Out 1.0 V (RMS) at 47 kW
