INSTALLATION AND OPERATION MANUAL

CNGE11FX3TX8MS[POE][HO]

Environmentally Hardened Managed Ethernet Switch

3 SFP + 8 Electrical Ports with Optional 30 or 60 Watt PoE

The ComNet CNGE11FX3TX8MS[POE][HO] has three 100/1000Base-FX SFP ports

and eight 10/100/1000Base-TX ports. Two of the SFP ports support 2.5 Gbps

SFPs for high speed communication in bandwidth intensive applications. All SFP

ports utilize ComNet SFP modules for fiber and connector type and distance. The

IEEE802.3-compliant unit offers multiple Ethernet redundancy protocols (MSTP/RSTP/

STP/ERPS (G.8032)) which protect your applications from network interruptions or

temporary malfunctions by redirecting transmission within the network. The switch

provides advanced IP-based management that can limit the maximum bandwidth

for each connected IP device, allowing the user to adjust usage. Two models are

available which supply Power over Ethernet (PoE). The CNGE11FX3TX8MSPOE

model provides eight electrical ports supporting up to thirty watts of power. On the

CNGE11FX3TX8MSPOEHO model, four of the eight PoE ports can support up to sixty

watts of PoE power. All PoE ports are IEEE802.3at compliant.

Rev. 11.6.17

This guide serves the following

ComNet Model Numbers:

CNGE11FX3TX8MS

CNGE11FX3TX8MSPOE

CNGE11FX3TX8MSPOEHO

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 2

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Contents

Regulatory Compliance Statement 6

Warranty 6

Disclaimer 6

Safety Information 7

Hardware Installation 8

Installing the Switch on DIN-Rail 8

Wall Mounting Installation 10

Hardware Overview 11

Power Supply 12

Front Panel LEDs 12

POEHO 60 W PoE Model 12

WEB Management 13

Configuration 17

Green Ethernet 24

Thermal Protection 26

DHCP 29

DHCP Pool Configuration 32

Security 37

Network 55

Screen 58

Aggregation 85

Loop Protection 87

Spanning Tree 88

IPMC Profile 95

MVR 98

IPMC 100

LLDP 108

PoE 110

EPS 112

Ethernet Protection Switch Configuration 113

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 3

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Ethernet Ring Protection Switch Configuration 130

MAC Table 133

VLAN Translation 134

VLANs 136

Private VLANs 139

VCL 141

Protocol-based VLAN 142

Voice VLAN 146

Mirroring & Remote Mirroring Configuration 167

UPnP 170

GVRP 171

Monitor Menu 173

Sys tem 173

CUP Load 174

Input Power Status 175

System IP Status 176

System Log 178

Port State 181

Green Ethernet 182

Thermal Protection 183

Ports 183

QoS Statistics 184

DHCP 188

Security 194

AAA 202

Aggregation Status 208

LACP 209

Loop Protection 211

MVR 216

IPMC 219

LLDP 225

PoE 230

MAC Table 231

VLANs 232

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 4

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Diagnostics Menu 235

Ping 235

Ping6 236

PHYtest 237

Maintenance Menu 238

Restart Device 238

Factory Defaults 238

Software 239

Configuration 241

Using Switch CLI 244

About CLI Management 244

CLI Management by RS-232 Serial Console 244

CLI Management by Telnet 247

Commander Groups 248

Quick Start 249

Set Device Hostname and Admin User Password 250

Set VLAN 1 IP Address 250

Display and Save Configuration to Flash 252

ICLI Basics 254

Command Structure and Syntax 255

Syntax 255

Ethernet Interface Naming 258

Using the Keyboard 260

Basic Line Editing 260

Command History 261

Context-Sensitive Help 263

Using Context-Sensitive Help 263

Long Lines and Pagination 265

Other Special Keys 266

Filtering Output 266

Understanding Modes and Sub-Modes 267

Using ‘do’ While in a Sub-Mode 270

Changing Between ICLI Modes 271

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 5

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Understanding Privilege Levels 272

Configuring Privilege Level Passwords 273

Understanding Terminal Parameters 274

Changing Terminal Parameters 275

Using Banners 277

Configuring Banners 277

Configuring the System 279

Configuration Example 279

Resetting or Removing Condiguration with “no” 281

Using “no” Forms 281

Managing Users 282

Adding, Modifying, and Deletion Users 282

Using Show Commands 283

Listing All Show Commands 284

Show running-config 287

Default vs. Non-default vs. All Defaults 287

Show running-config [all-defaults] 289

Show running-config feature feature_name [all-defaults] 289

Show running-config interface list [all-defaults] 290

Working with Configuration Files 291

Reverting to Default Configuration 292

Working with Configuration Files 293

Using Reload Commands 295

Working with Software Images 296

Appendix A 297

Ethernet Ring Protection Switching Example Configuration 297

Configuring ERPS from the Web GUI 298

Ethernet Ring Protection Switching Configuration 305

Configuring ERPS from the ICLI 310

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 6

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Regulatory Compliance Statement

Product(s) associated with this publication complies/comply with all applicable regulations. Please

refer to the Technical Specifications section for more details.

Warranty

ComNet warrants that all ComNet products are free from defects in material and workmanship

for a specified warranty period from the invoice date for the life of the installation. ComNet will

repair or replace products found by ComNet to be defective within this warranty period, with

shipment expenses apportioned by ComNet and the distributor. This warranty does not cover

product modifications or repairs done by persons other than ComNet-approved personnel, and

this warranty does not apply to ComNet products that are misused, abused, improperly installed,

or damaged by accidents.

Please refer to the Technical Specifications section for the actual warranty period(s) of the

product(s) associated with this publication.

Disclaimer

Information in this publication is intended to be accurate. ComNet shall not be responsible for its

use or infringements on third-parties as a result of its use. There may occasionally be unintentional

errors on this publication. ComNet reserves the right to revise the contents of this publication

without notice.

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 7

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Safety Information

»Only ComNet service personnel can service the equipment. Please contact ComNet Technical

Support.

»The equipment should be installed in locations with controlled access, or other means of

security, and controlled by persons of authority. When operating at temperatures above 51º C, the

equipment surfaces will be hot to the touch. Installation in restricted access location is required

for this case.

»For POE models requiring a power supply not labeled LPS, the unit should be installed in a

restricted access location using a 60950-1, 2nd Edition + Am. 1 + Am. 2 Certified power supply

rated for the ambient temperature in which it is installed. Total derated power rating should be

greater than the sum of the attached loads plus 15 W for the switch.

»Use CDRH compliant SFP modules when using fiber connectivity with this device.

»When used in Australia or New Zealand, the product is certified for intra building applications

only, and should not be directly connected to network cables with outside plant routing.

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 8

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Hardware Installation

Installing the Switch on DIN-Rail

Each switch has a Din-Rail kit on the rear panel. The DIN-Rail kit affixes the switch to the DIN-Rail.

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 9

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

It is easy to install the switch on the Din-Rail:

Mount Series on DIN-Rail

Step 1: Tilt the switch and mount the metal spring to DIN-Rail.

Step 2: Push the switch toward the DIN-Rail until you hear the spring snap into place

INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 10

INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]

TECH SUPPORT: 1.888.678.9427

Wall Mounting Installation

Each switch has another installation method for users to fix the switch. A wall mount panel can be

found in the package. The following steps show how to mount the switch on the wall:

Mounting the switch on a wall

Note: For drywall applications where no studs are available, use drywall anchors rated for 50 lbs

or more.

In order to prevent switches from being damaged, use appropriate hardware (not supplied)

for securing the unit to the wall.

#6 screws with at least ½-inch penetration into wood surface recommended.

Step 1: Remove DIN-Rail kit if it is installed.

Step 2: Remove the two screws at the top of the unit’s back panel. Remove only one pair of back

panel screws at time (these hold the back panel in place on the unit).

Step 3: Use the same two screws plus one of the included screws to attach the wall mount panel

to the top set of screw holes as shown in the diagram below.

Step 4: Repeat Steps 2 and 3 to mount the second wall mount panel on the bottom of the unit’s

back panel.

ATTENTION: Do not remove the top and bottom panel screws at the same time, or the back

panel will detach from the unit. Install the wall mount panels one at a time.

When operating at temperatures above 51ºC, the equipment surfaces will be

hot to the touch. Installation in restricted access location is required for this case.
