CommScope OmniReach FTTX Manual de usuario

300001720956 Rev C Page 1

Instruction Sheet

1 GENERAL INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

1.2 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 CABINET INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2.1 General Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2.2 Mounting Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

3 GROUNDING THE CABINET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

4 CABLE INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

4.1 Securing Cables to the Cabinet Using a Compression Fitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4.2 Securing Cables to the Cabinet by Lashing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

5 ROUTING CABLE FIBERS AND SPLICING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

6 INTERCONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

7 CUSTOMER INFORMATION AND ASSISTANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

INTRODUCTION

This publication provides a description of the 48/96-Port Indoor Fiber Distribution Terminal

(IFDT) plus procedures for installation and operation. The 48/96-Port IFDT provides splicing,

termination, and interconnect functions for fiber optic cables used in indoor applications.

Content Page

FTTX

OmniReach® FTTX Solutions

48/96-Port Indoor Fiber Distribution Terminal

ADCP-96-806

Issue 4, July 2016

ADCP-96-806 • Issue 4 • July 2016

Page 2

Revision History

List of Changes

Trademark Information

CommScope is a registered trademark of CommScope Inc.

Admonishments

Important safety admonishments are used throughout this manual to warn of possible hazards to

persons or equipment. An admonishment identifies a possible hazard and then explains what

may happen if the hazard is not avoided. The admonishments — in the form of Dangers,

Warnings, and Cautions — must be followed at all times. These warnings are flagged by use of

the triangular alert icon (seen below), and are listed in descending order of severity of injury or

damage and likelihood of occurrence.

General Safety Precautions

ISSUE DATE REASON FOR CHANGE

1 4/2009 Original.

2 5/2011 Include 96-port version of cabinet.

3 11/2011 Include grounding kit torque specs and current contact information.

4 July 2016 Rebranded for CommScope

PAGE IDENTIFIER DESCRIPTION OF CHANGE

5, 6 – Updated text and Figure 3 to include grounding kit torque specs

14 Section 7 Updated contact information.

Danger: Danger is used to indicate the presence of a hazard that will cause severe personal

injury, death, or substantial property damage if the hazard is not avoided.

Warning: Warning is used to indicate the presence of a hazard that can cause severe personal

injury, death, or substantial property damage if the hazard is not avoided.

Caution: Caution is used to indicate the presence of a hazard that will or can cause minor

personal injury or property damage if the hazard is not avoided.

Danger: Exposure to laser radiation can seriously damage the retina of the eye. Do not look

into the ends of any optical fiber. Do not assume the laser power is turned-off or that the fiber is

disconnected at the other end.

Caution:

Improper handling can damage fiber optic cables. Do not bend fiber optic cable more

sharply than the minimum recommended bend radius specified by the cable manufacturer

when

installing fiber optic cables and patch cords.

Do not apply more pulling force to the cable than

specified. Do not compress the fiber or allow it to kink.

ADCP-96-806 • Issue 4 • July 2016

Page 3

1 GENERAL INFORMATION

The 48/96-port IFDT is a wall-mounted cabinet that provides an ideal termination and splice

solution for CATV or Telco interconnect applications. The IFDT cabinet is a fully enclosed,

lockable, slim-profile, wall-mount product. The IFDT supports up to eight modular adapter

panels (equipped with SC adapters) and includes fiber routing accessories that limit bend radius

and provide strain relief.

The IFDT may be ordered either with or without parking lots. When parking is ordered, the

cabinet includes storage modules where distribution/subscriber connectors may be temporarily

“parked” until service is required. The maximum termination capacity with parking lots is 48

ports. The maximum termination capacity without parking lots is 96 ports.

The IFDT may be ordered with SC adapters only, with pigtails on the feeder/provider side, with

pigtails on both the feeder/provider and distribution/subscriber side, or with a cable stub on the

feeder/provider side. If splicing is required, the IFDT may be equipped with up to eight 12-fiber

splice trays. The termination and splice compartment is located in the rear section of the cabinet

and is isolated from the interface compartment which is located in the front section of the

cabinet.

The IFDT provides sealed cable entry ports for feeder/provider cables and distribution/

subscriber cables and gaskets to protect against dust and water spray. A drawing of a 96-port

IFDT equipped with pigtails on both the feeder/provider and distribution/subscriber side is

shown in Figure 1.

Figure 1. Typical 96-Port IFDT with Pigtails Installed

TERMINATION AND

SPLICE COMPARTMENT

INTERCONNECTION

COMPARTMENT 23115-B

ADCP-96-806 • Issue 4 • July 2016

Page 4

1.1 Description

The 48/96-port IFDT provides the following features and benefits:

• Available with pre-installed feeder stub cable

• Provides 48 ports (with parking lot) or 96 ports (no parking lot)

• Separate splice and service connection compartments

• Dual hinged access

• Multiple fiber splice trays - feeder splices/distribution splices

• Fully enclosed and lockable

• Allows for added security protection

1.2 Options

Locks are available (either factory or field installed) for the front and/or rear doors. The rear

door has a knockout that can be removed with a screwdriver.

2 CABINET INSTALLATION

This section provides instructions for mounting the 48/96-port IFDT on a wall. The following

tools and materials are required for mounting the cabinet:

• Screwdriver

• 1-inch #10 panhead screws (6)

• Drill and drill bit suitable for installing # 10 screws

• 3/4-inch plywood backer board and fasteners to secure backer board to wall studs

• Level

• Tape Measure

2.1 General Recommendations

The 48/96-port IFDT is designed for wall-mount installation. A space at least 13 inches wide by

32 inches high is required for mounting. In addition, 3 inches of free space must be provided on

the hinged side of the cabinet and 19 inches of free space must be provided in front of the

cabinet to allow for the swing of the cabinet front section.

The wall surface must be strong enough to support the weight of the cabinet. It is recommended

that a 3/4-inch plywood board be firmly secured to the wall studs and used as a backer for

mounting the cabinet.

2.2 Mounting Procedure

Use the following procedure to mount the cabinet on the wall:

1. Select a suitable mounting location for the cabinet.

2. Mount the plywood backer (not provided) on the wall and firmly secure it to the wall’s

interior studs.

3. Attach the template provided with the unit to the plywood backer. The cabinet dimensions

are shown in Figure 2.

ADCP-96-806 • Issue 4 • July 2016

Page 5

Figure 2. Cabinet Dimensions

4. Using the template as a guide, drill pilot holes for the six 3/4-inch #10 panhead screws

required for mounting the cabinet.

5. Partially install the top two #10 wood screws leaving the heads protruding about 1/4-inch

from the surface of the backer board. Do not tighten.

6. Hang the cabinet on the two installed screws using the key-hole shaped slots.

7. Level the cabinet, tighten the two top screws, and then install the remaining #10 screws.

3 GROUNDING THE CABINET

This section provides instructions for connecting a grounding wire to the cabinet. Use the

following procedure to ground the cabinet:

1. Locate the grounding components that are provided separately with the cabinet. A

grounding lug kit (consisting of two external tooth washers, two nuts, one screw and one

lug) is provided.

2. Open the hinged middle-section of the cabinet to provide access to the cabinet’s

termination and splicing compartment.

3. Threaded inserts are provided on the left and right sides of the cabinet. Select one of the

inserts for installation of the grounding components.

4. Install the required grounding components as shown in Figure 3. Tighten all nuts, screws,

and studs to 40 inch-lbs (4.5 Nm) of torque.

5. Use a #6 AWG copper wire to connect the cabinet to an approved earth ground source as

specified by local code or practice. Avoid sharp bends in the ground wire.

8IN

(20.3 CM)

15 IN

(38.1 CM)

30 IN

(76.2 CM)

13 IN

(33.0 CM)

32 IN

(81.3 CM)

BACK

CABINET

23116-A

ADCP-96-806 • Issue 4 • July 2016

Page 6

Figure 3. Typical Grounding Wire Installation

4 CABLE INSTALLATION

Four cable entry ports are provided in the splicing compartment section of the 48-port IFDT.

Figure 4 shows the location of the entry ports and cable tie plates. Cables may enter the cabinet

from any of the four openings.

Figure 4. Cable Entry Ports

SCREW

STAR

WASHER STAR

WASHER

CUSTOMER PROVIDED

COMPRESSION LUG

NUT NUT

#6 COPPER

WIRE

GROUNDING STUD

INSTALLATION

COMPRESSION

LUG

INSTALLATION

THREADED

INSERT

GROUNDING STUD

INSTALLATION

GROUNDING STUD WITH

GROUNDING LUG INSTALLATION

GROUNDING STUD WITH

COMPRESSION LUG INSTALLATION

SCREW

STAR

WASHER

NUT

THREADED

INSERT

24762-A

STAR WASHER

NUT

#6 COPPER

WIRE

GROUNDING

LUG

INSTALLATION

GROUNDING

LUG

TIGHTEN NUTSAND

SCREW TO 40 INCH-LBS

(4.5 Nm) OF TORQUE

TIGHTEN NUTSAND

SCREW TO 40 INCH-LBS

(4.5 Nm) OF TORQUE

BOTTOM CABLE

ENTRY PORTS

TOP CABLE

ENTRY PORTS

CABLE TIE

PLATES

CABLE TIE

PLATES

24763-A

ADCP-96-806 • Issue 4 • July 2016

Page 7

Both feeder/provider and distribution/subscriber cables may be installed using this procedure,

Determine the entry point that will be used for routing the cable into the cabinet and then follow

the installation procedure that is appropriate for the cable.

4.1 Securing Cables to the Cabinet Using a Compression Fitting

Multi-fiber jacketed cables with a diameter ranging from 0.5 to 0.71 inches may be secured at

the cabinet entry point using one of the compression fittings provided. Use the following

procedure to secure a cable to the cabinet using a compression fitting:

1. Remove the plastic dust cap from the selected cable entry port in the cabinet.

2. Locate one of the compression fittings that are shipped with the cabinet

3. Install the compression fitting in the cabinet as shown in Figure 5.

Figure 5. Compression Fitting Installation

4. Feed approximately 9 feet of the cable through the compression fitting and into the

enclosure.

5. Strip away approximately 8 feet of the cable jacket to expose the buffer tubes, 900 micron

fiber, or ribbon. Clean if necessary.

6. Adjust cable so approximately 2 inches of the cable sheath extends into the cabinet and

then tighten the compression fitting nut to secure the cable to the cabinet.

Caution:

Improper handling can damage fiber optic cables. Do not bend fiber optic cable more

sharply than the minimum recommended bend radius specified by the cable manufacturer. Do not

apply more pulling force to the cable than specified. Do not compress the fiber or allow it to kink.

NUT

COMPRESSION

FITTING

PLASTIC

DUST CAP

(REMOVE)

CABLE

(0.5 TO 0.71 IN)

23118-A

ADCP-96-806 • Issue 4 • July 2016

Page 8

4.2 Securing Cables to the Cabinet by Lashing

Cables that are too small to be secured with a compression fitting (all cables less than 0.5 inches

in diameter) may be lashed to the cable tie down plate with cable ties. When using the lashing

method, it is recommended that two cable ties be used for better retention capability. Use the

following procedure to secure a cable (or several small cables) to the cabinet by lashing:

1. Cut a hole in the dust cap that is installed in the selected cable entry port. The hole should

be just large enough to permit entry of the cable.

2. Feed approximately 9 feet of the cable through the entry port and into the cabinet.

3. Strip away approximately 8 feet of cable jacket to expose the buffer tubes, 900 micron

fiber, or ribbon. Clean if necessary.

4. Adjust the cable so the cable jacket extends approximately 1/2 inch beyond the cable tie

down plate.

5. Secure the cable to the cable tie down plate using two cable ties as shown in Figure 6.

Wrap strain relief material around the cable to prevent the cable from being excessively

compressed by the cable ties. Use two cable ties to secure the cable to the bracket.

Figure 6. Lashing Cables to Cable Tie Down Plate - Typical Example

ADCP-96-806 • Issue 4 • July 2016

Page 9

5 ROUTING CABLE FIBERS AND SPLICING

Fibers should be routed to the individual splice trays using the cabinet space provided around

the splice trays. Buffer tubes should be broken out near the cable strain relief at the entry port.

Fibers can then be over-tubed up to the splice trays with more pliable tubing. The splice trays

accommodate both mass fusion and individual stranded splicing.

Figure 7 shows the fully pre-wired cabinet option which includes pigtail assemblies for splicing

both the feeder/provider cable and the distribution/subscriber cable. Route the fibers from the

feeder/provider cable to the splice trays that have black protective tubing attached to them. The

pigtail fibers within the black tubing are routed to the adapter panels on the splice/termination

side of the center swing panel.

Figure 7. Routing Cable Fibers to Splice Trays

Caution:

Improper handling can damage fiber optic cables. Do not bend fiber optic cable more

sharply than the minimum recommended bend radius specified by the cable manufacturer. Do not

apply more pulling force to the cable than specified. Do not compress the fiber or allow it to kink.

23119-A

PIGTAIL ASSEMBLIESFOR

FEEDER/PROVIDER CABLE

(BLACK PROTECTIVE JACKET)

PIGTAIL ASSEMBLIESFOR

DISTRIBUTION/SUBSCIRBER CABLE

(YELLOW PROTECTIVE JACKET)

BOTTOM ENTRY

TYPICAL ROUTING

TOP ENTRY

TYPICAL ROUTING

ADCP-96-806 • Issue 4 • July 2016

Page 10

Route the fibers from the distribution/subscriber cable(s) to the splice trays that have individual

yellow jacketed pigtail fibers attached to them. The yellow jacketed fibers are routed to the

adapter/parking panels on the interconnect side of the center swing panel.

Follow local practices and procedures for splicing. Splice holders for ribbon and fusion splicing

are provided separately. Use cable ties to secure fibers to the splice tray as shown in Figure 9.

After splicing is complete manage the fiber in loops around the splice trays and secure the trays

in place with the O-rings. Use caution when closing the cabinet to avoid pinching any fibers or

tubes, especially along the hinged area.

Figure 8. Splice Tray Typical Installation

6 INTERCONNECTIONS

The IFDT may be ordered with or without parking. When the parking option is ordered, the

distribution/subscriber connectors may be temporarily “parked” until service is required.

Cabinets that do not include parking lots have twice as much termination capacity.

For cabinets that not equipped with pre-installed distribution/subscriber pigtails, four entry

ports are provided (two at the top and bottom) for routing jumpers into the cabinet front section.

Cable tie mounting blocks are provided separately for managing jumpers within the cabinet.

Punch a hole through the soft rubber material covering the selected jumper entry port and then

route the jumper into the cabinet.

Warning: Invisible infrared radiation can seriously damage the retina of your eye. Do not look

into the launching (output) end of an active fiber. A clean, protective cap or hood MUST be

immediately placed over any radiating bulkhead receptacle or optical connector to avoid

exposure to potentially dangerous amounts of radiation. This practice also helps to prevent

contamination of connectors and adapters.

FACTORY-INSTALLED

PIGTAIL ASSEMBLY

CABLE FIBERS

CABLE

TIE POINT

PIGTAIL

TIE POINT

23120-A

Tabla de contenidos

Otros manuales de Cables y conectores de CommScope

CommScope

CommScope FOSC-OC-3 Manual de usuario

CommScope

CommScope NOVUX Manual de usuario

CommScope

CommScope LC Manual de usuario

CommScope

CommScope OFDC-A4 SPLICE/PATCH Manual de usuario

CommScope

CommScope FOSC-400BG Manual de usuario

CommScope

CommScope HELIAX FiberFeed FDH1206-12M50 Series Hoja de instrucciones

CommScope

CommScope HELIAX FiberFeed HFA208 Series Hoja de instrucciones

CommScope

CommScope HELIAX FiberFeed HFE810 Series Hoja de instrucciones

CommScope

CommScope FOSC-450D Manual de usuario

CommScope

CommScope HELIAX FiberFeed FDH1210-24SE2 Series Hoja de instrucciones

CommScope

CommScope HELIAX FiberFeed HTC1006 Series Hoja de instrucciones

CommScope

CommScope FIBER INDEXING TERMINAL Manual de usuario

CommScope

CommScope SYSTIMAX 360 iPatch... Manual de usuario

CommScope

CommScope AMP NETCONNECT 1933352 Series Manual de usuario

CommScope

CommScope M2400 Series Manual de usuario

CommScope

CommScope LightCrimp Plus SC Simplex Manual de usuario

CommScope

CommScope SYSTIMAX 360 iPatch 360-iP-G2-1U-LC-FX Manual de usuario

CommScope

CommScope AMP NETCONNECT 553454-1 Manual de usuario

CommScope

CommScope FIST-RSKG-1 Manual de usuario

CommScope

CommScope OSP-CLPFEC-LG Manual de usuario

CommScope

CommScope ETHERSEAL 1479563-2 Manual de usuario

CommScope

CommScope FOSC450 C Manual de usuario

CommScope

CommScope SYSTIMAX 360 760150144 Manual de usuario

CommScope

CommScope SYSTIMAX 360 iPatch PATCHMAX Manual de usuario

Manuales populares de Cables y conectores de otras marcas

Philips

Philips SWA6310 Manual de usuario

StarTech.com

StarTech.com CRJ4550PK Manual de usuario

Nohau

Nohau EMUL-IP2K-PC Manual de usuario

Foxun

Foxun SX-SP144E-HD4K2K Manual de usuario

Philips

Philips SWA3305W Manual de usuario

opticis

opticis Stretch DVIM1-1P0x Manual de usuario

Volkswagen

Volkswagen VAS 6558A Manual de usuario

NEXIBO

NEXIBO N-13 Manual de usuario

CYP

CYP PU-1H3HBTL Manual de usuario

Allen-Bradley

Allen-Bradley 1784-u2dhp Manual de usuario

Global Caché

Global Caché Flex Link Blaster Manual de usuario

Hauppauge

Hauppauge USB-Live2 Manual de usuario

Fenix

Fenix MPSV 15 Manual de usuario

BEGA

BEGA 71 085 Manual de usuario

Tesla

Tesla HPWC Manual de usuario

GAMERON

GAMERON LUXURY TV CABLE Manual de usuario

molex

molex Milli-Grid Dual row 87568 Series Manual de usuario

Burndy

Burndy Continental Industries thermOweld CRE-7 Manual de usuario
