Commell LV-67P Manual de usuario

LV-67P

Mini-ITX Motherboard

User’s Manual

Edition 1.1

2016/08/15

LV-67P User’s Manual

-1-

The information in this document is subject to change without prior notice to make

improvements to the products.

This document contains proprietary information and protected by copyright. No part of this

document may be reproduced, copied, or translated in any form or any means without prior

written permission of the manufacturer.

All trademarks and/or registered trademarks contains in this document are property of their

respective owners.

Disclaimer

The company shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

The company does not issue a warranty of any kind, express or implied, including without

limitation implied warranties of merchantability or fitness for a particular purpose.

The company has the right to revise the manual or include changes in the specifications of

the product described within it at any time without notice and without obligation to notify any

person of such revision or changes.

Trademark

All trademarks are the property of their respective holders.

Any questions please visit our website at TUhttp://www.commell.com.twUT

LV-67P User’s Manual

-2-

1 x VGA Cable

(OALVGA-SNB-7) / (1040557)

LV-67PNT & LV-67PET ONLY

Packing List:

Please check the package content before you starting using the board.

Optional:

Printed Matters:

Driver CD x 1 (Including User’s Manual)

1 x USB2.0 cable

(OALUSBA-3) / (1040173)

1 x Dual COM cable

(OALES-BKU2NB) / (1040090)

1 x LV-67P Motherboard

2 x SATA Cable

(OALSATA3-L) / (1040529)

)

1 x DC Power Cable

(OALDC-A) / (1040433)

1 x PS/2 Keyboard & Mouse cable

(OALPS2/KMB) / (1040610)

1 x I/O Shield

(OPLATE-CDILAT) / (1270067)

(OPLATE-CDILA) / (1270068)

(OPLATE-CDILAT for LV-67PNT & LV-67PET)

1 x Power Cable

(OALATX-P3S2 / 1040058)

LV-67P User’s Manual

-3-

Index

Chapter 1 <Introduction>............................................................... 4

1.1 <Product Overview>............................................................4

1.2 <Product Specification> ......................................................5

1.3 <Mechanical Drawing>........................................................6

1.4 <Block Diagram>.................................................................7

Chapter 2 <Hardware setup>......................................................... 8

2.1 <Connector Location and Reference> ................................8

2.1.1 <Internal connectors list> ..........................................9

2.1.2 <External connectors list>.........................................9

2.2 <Jumper Location and Reference> ...................................10

2.2.1 <Jumper list> .......................................................... 10

2.2.2 <Clear CMOS and Power on type selection>.......... 11

2.3 <Installing the Memory>.................................................... 11

2.4 <I/O interface> ..................................................................12

2.4.1 <Serial ATA interface>.............................................12

2.4.2 <Ethernet interface>................................................12

2.4.3 <Display interface> .................................................13

2.4.4 <Serial Port interface> ............................................15

2.4.5 <USB interface>......................................................17

2.4.6 <Audio interface>....................................................18

2.4.7 <Expansion slot>.....................................................19

2.4.8 <Front panel switch and indicator> .........................19

2.4.9 <Other interface> ....................................................20

2.5 <Power supply> ................................................................22

2.5.1 <Power input>......................................................... 22

Appendix A <Flash BIOS> ........................................................... 23

A.1 BIOS Auto Flash Tool........................................................23

A.2 Flash Method....................................................................23

Appendix B <LCD Panel Type select> ........................................25

Appendix C <Programmable Watch Dog Timer> ....................... 26

Appendix D <Programmable GPIO > .......................................... 27

Appendix E <Setup ADP-3355>...................................................28

Contact information .....................................................................28

LV-67P User’s Manual

-4-

Chapter 1 <Introduction>

1.1 <Product Overview>

LV-67P is mini-ITX Motherboard which is design based on Intel® Pentium® Processor

N3000 Series Processor(Braswell SoC), delivering outstanding compute, graphical, and

media performance while operating in an extended range of thermal conditions. The SoC

bases on the Silvermont microarchitecture, utilizing Intel’s industry-leading 14nm process

technology with 3-D Tri-Gate transistors, which deliver significant improvements in

computational performance and energy efficiency.

New features for Intel® Pentium® N3000 Series Processor

The Intel® Pentium® N3000 Series Processor has a lower TDP 6W, it provides new HD

Graphics to support triple display, 4K resolution, maximum memory size is up to 8GB of

DDR3L, and more enhanced security that is suitable for a variety of intelligent systems the

ideal choice.

All in One multimedia solution

The board provides high performance onboard graphics, 18/24-bit single/dual channel

LVDS interface, DisplayPort, HDMI, and High Definition Audio, to meet the very requirement

of the multimedia application.

Flexible Expansion Interface

The board provides one MiniPCIe and one mSATA.

Braswell remove EHCI

When you install WIN7 with USB device(CDROM, Keyboard, Mouse...), Windows7 can not

identify your usb device. You can use SATA CD-ROM and PS/2 to install Windows7.

LV-67P User’s Manual

-5-

1.2 <Product Specification>

System

Processor

Intel® Braswell Series Processor N3710/X5-E8000,

FCBGA1170 package

Chipset

Braswell SoC

Memory

2 x DDR3L DIMM 1600 MHz up to 8GB, Support Non-ECC,

unbuffered memory only

(If you only use one DDR3L SO-DIMM, install memory on SO-DIMM1)

(if you use two DDR3L SO-DIMM, need same memory)

(Same memory means same capacity, same topology same raw card type.)

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~ 255min/s

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Expansion

1 x MiniPCIe, 1 x PCIE X16 slot, 1 x Sim slot

1 x mSATA (same signal with SATA3-2)

Graphics

Chipset

Intel® HD Graphics

Display Interface

1 x DVI, 1 x HDMI, 1 x LVDS/CRT/DisplayPort(Optional)

LAN

Chip

2 x Intel® I210-AT Gigabit LAN

I/O

Serial ATA

2 x SATA3

(SATA3-2 cannot use when JMSATA ‘s jumper cap on pin1 and pin2)

Audio

Realtek ALC262 HD Audio

Internal I/O

2 x SATA3, 4 x RS232, 4 x USB2.0, 1 x LPC 1 x GPIO ,1 x PS/2,

1 x SMBUS, 1 x LVDS(Optional), 1 x CRT(Optional),

1 x LCD inverter, 1 x Audio.

Rear I/O

4 x USB3.0, 2 x LAN, 1 x HDMI, 1 x DisplayPort(Optional) , 1 x RS232,

1 x RS232/422/485

Mechanical & Environmental

Power Requirement

Standard 24-pin ATX power supply or 4-pin 6~30V

Size & Thickness

170mm x 170mm (L x W)

Temperature

Operating within 0°C~60°C (32°F~140°F)

Storage within -20°C~80°C (-4°F~176°F)

Relative Humidity

10%~90%, non-condensing

LV-67P User’s Manual

-6-

1.3 <Mechanical Drawing>

LV-67P User’s Manual

-7-

1.4 <Block Diagram>

CPU

Braswell

SoC

DDR3L

SO-DIMM

1 x DVI

1 x HDMI

PTN3460

1 x LVDS

SIO

NCT6106D

DDI

Channel A

eDP

DDI

1 x SATA3

SATA3

4 x USB3.0

2 x USB2.0

USB3.0

USB2.0

SPI Flash

SPI

PCIe x1

I210-AT

HDA

HD Audio

LPC

1 x LPC

ALC262

5 x RS232

1 x SMBUS

SATA3

mSATA

1 x PS/2

SMBus

PCIe x1

I210-AT

1 x RS232/422/485

1 x SATA3

PCIe x1

MiniPCIe

1 x GPIO

Channel B

DDR3L

SO-DIMM

PCIe x1

1 x PCI_E16x

LV-67P User’s Manual

-8-

Chapter 2 <Hardware setup>

2.1 <Connector Location and Reference>

CN_LPC

I210-AT

COM1

CN_DIO

CN_COM5/6

CN_COM3/4

CN_AUDIO

DC_IN

ATX

CN_SMBUS

SO-DIMM1

JFRNT

SYSFAN

CPUFAN

CN_PS2

CN_SATA3-2

MINI_CARD

MSATA

CN_SATA3-1

CN_USB1

CN_USB2

SO-DIMM2

PCI_E16X

CN_I2C

CN_LVDS

CN_CRT

USB3.0

COM2

I210-AT

HDMI

DISPLAY PORT

DVI-I

AUDIO

CN_INV

LV-67P User’s Manual

-9-

2.1.1 <Internal connectors list>

Connector

Function

SO-DIMM1/2

204-pin DDR3L SO-DIMM slot

CN_SATA3-1/2

10-pin Serial ATA3 connector

CN_AUDIO

5 x 2-pin audio pin header

CN_LPC

6 x 2-pin LPC pin header

CN_DIO

6 x 2-pin digital I/O connector

CN_LVDS

20 x 2-pin LVDS connector

CN_INV

5-pin LCD inverter connector

CN_SMBUS

5-pin SMBus connector

CN_I2C

5-pin I2C connector

CN_COM 3/4 5/6

19-pin RS232 connector

CN_USB1/2

5 x 2-pin USB2.0 pin header

CN_PS2

5 x 2-pin PS/2 pin header

CPUFAN

4-pin CPU fan connector

SYSFAN

4-pin system fan connector

JFRNT

5 x 2-pin front panel switch/indicator pin header

MINI_CARD

52-pin MiniPCIe card slot

MSATA

52-pin MSATA card slot

SIMM

6-pin socket

ATX

24-pin power supply connector

DC_IN

4-pin power input Terminal Block

2.1.2 <External connectors list>

Connector

Function

DisplayPort

DisplayPort connector

DVI-I

DVI connector

HDMI

HDMI connector

USB3.0

4 x USB3.0 connector

LAN

2 x RJ45 LAN connector

AUDIO

Audio connector

COM1/2

DB9 Serial port connector
