Color Door Camera DRC-4G

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

1. Overview

LED & Sensor

Microphone

Camera Lens

Speaker

Call Button

Angle Adjustment Lever

Volume Adjuster

Monitor Connection Terminal

Door Release

Connection Line

2. Wiring and Installation

1. Match the fix the whole in the wall and the fixing

2. Match and connect monitor line as shown below

(#1: Audio, #2: GND, #3: DC12V, #4: Video)

3. Adjust camera location on the wall by checking

4. Connect the Door Release Connection Line as

5. Tighten a screw at the bottom side of the camera

fixing bracket [FIG.1]

[FIG.2]

the image on monitor screen and fix its location

shown below [FIG.2]

[FIG.1]

SCREW M3X8 (1EA)

▶Position of camera

66.5°

Screw Hole

SCREW T4X18 (2EA)

Power Source

Door Release

Wiring

Installation

[FIG.1]

[FIG.2]

▶

4. Specification

DRC-4G

DC 12V (Supplied t o monitor)

4 wires (polarity) to a monitor

2 wires (non-polarity) to a electric door lock

NTSC or PAL STANDARD.

CMOS IMAGE SENSOR

Full duplex

0.1 Lux (within 300mm)

Embedde d white LED (night working)

Horizontal 82°, Vertical 66.5 °

Upward 6°

-10℃(tested up to -40°C)~ +40℃

30 0g

101(W) x 142(H) x 32(D)

Diameter(pie) Ø

0.5

0.6

0.8

Distance(meter)

28m 50m 70m 115m

Model No.

Rated Voltage

Video Transmission Standard

Sensor Type

Transmission

Minimum Illumination

LED

Effective Viewing Angle

Angle Adjustment

Operating Temperature

Weight (g)

Dimension (mm)

Installation between a door

camera and a monitor(TIV Cable)

Wiring

5. Contents

Door camera Bracket

Camera fixing

screw

Braket fixing

screw

Volume

Sheet

Printed In Korea / 2016.04.105

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea

Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133

Web site : www.commax.com
