Comfier CF-9318 Manual de usuario
Backrest Pad
Arm Massage Unit
Shortcut Key
Casters
Pillow
Shoulder
Massage Unit
Armrest
Leg Massage Unit
Auto Interfaceӥ
On the Automatic screen, you can select
four types, and multiple auto modes for
massage.
(Note: When power on and selecting the
massage function for the first time, it will
enter body scanning automatically and the
massage will be run after the scanning is
completed )
Click "Auto mode" to enter the automatic
massage interface.
After running the program, it will jump to
the adjustment interface, massage streng-
hth and other functions can be adjusted.
Press "Back" to return to the upper menu.
Body Scanning Interfaceӥ
Manual Interfaceӥ
Click "Manual mode" to enter the interface
of manual massage.
In the "Manual" interface, you can select: 6
massage techniques for massage, and also
for adjusting: 3D, massage speed, calf
Massage, sole massage, heating and other
functions.
Press "Back" to return to the upper menu.
After scanning, you can press "" or "" to
adjust the mechanism positions and then
press "OK" to confirm.
(Note: Do not perform the above operation
within 8 seconds after the body scanning is
completed, shoulder position default
current position, run massage function and
jump Go back to the screen before
detection.)
When starting the massage chair and
selecting the massage function for the first
time, it will enter body scanning automati-
cally.
Air Interfaceӥ
Settings Interfaceӥ
Click "Air Massage" to enter the interface of
airbags massage.
On the Air Pressure interface, you can select
body parts: arm, back, Leg, shoulder for
pressure massage, at the same time these
functions are adjustable: air intensity, calf
massage, sole massage, heating and other
functions.
Press "Back" to return to the upper menu.
Click "Setting" to enter the setting
interface.
On the Settings interface, select Heat to
enable the function, Or select 1-3 heating
levels.
Press "Back" to return to the upper menu.
On the Settings interface, click "External
Device" for selecting Bluetooth function.
Press "Back" to return to the upper menu.
On the Settings interface, select Others to
adjust the volumn, key tone, screen
brightness.
Press "Back" to return to the upper menu.
On the Settings interface, select Language to
switch to a variety of languages.
Press "Back" to return to the upper menu.
Rotate clockwise to increase stage, and counterclockwise to decrease
stages. The stage are divided into 1-6 stage.
Press to switch among the automatic programs.
Aligned holes, lock screw.
Press down to align the snap.
Note: The arrow direction is towards the front of the handrail.
Press this button to pause all massage functions. Press again to resume
the massage.
Press repeatedly this button to activate one of the three zerogravity
modes.
Press and hold to bring backrest up.
Release when it reaches your desired position.
Press to bring backrest down.
Release when it reaches your desired position.
You can remove the protective cover (tab) to recharge your phone using
a USB cable (not provided).
Press this button to activate or deactivate the massage airbags.
Press this button to adjust the airbag intensity from levels 1 to 3.
Press this button to activate or deactivate the massage chair.
Shortcut Key
Armrest shortcut controls
Installation of manual bracket
Power
Rotation
Auto
Pause
Airbag
Intensity
Zero-G
Backrest
Up Button
Backrest
Down Button
USB
