Cocraft HL 10-ST Manual de usuario
ENGLISHSVENSKANORSKSUOMIDEUTSCH
Important:
Read the entire instruction manual
carefully and make sure that you fully
understand it before you use the
equipment. Keep the manual for future
reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre
deg om at du forstår dem, før du tar
produktet i bruk. Ta vare på anvisningene
for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin
alat käyttää laitetta. Säilytä ohjeet
myöhempää tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung sorgfältig
durchlesen und aufbewahren.
HL 10-ST
SELF-LEVELLING WITH CLEAR LEVEL
NOTIFICATION. HORIZONTAL AND
VERTICAL LINE PROJECTION.
41-1747
CROSS-LINE LASER LEVEL
KRYSSLASER
RISTILINJALASER
KREUZLINIENLASER
Ver. 20190424
Original instructions
Bruksanvisning i original
Originalbruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung
Art.no Model
41-1747 NLC06+LA01
ENGLISH
3
Cross-Line Laser Level
Art.no 41-1747 Model NLC06
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
Warning
• Never point thelaser beam towards people or animals and never look into thelaser
yourself even if you are not standing close to thelaser level.
• Warning: Never look into thelaser beam through optical instruments such as
binoculars or telescopes. Doing so could result in serious eye damage.
• Do not use thelaser level on or near highly reflective surfaces since thelaser beam
can be reflected back into your own or someone else’s eyes.
• Never leave thelaser level switched on unattended. Always switch it off after use.
There is always arisk that someone could be blinded by thelaser beam.
• If thelaser is directed towards your eyes, close your eyes and avert your gaze away
from thebeam.
This product is intended for indoor use only.
Laser classication
Laser class 2
Laser class 2 products
Warning: Do not stare into thelaser beam or direct it towards other people or
animals. Risk of serious damage to eyes.
Warning: Do not look directly into thebeam through optical instruments such
as binoculars or telescopes. Risk of serious damage to eyes.
ENGLISH
4
1
6
2
4
3
5
• Make sure not to remove or damage thesafety symbols and warnings found on
thelaser level.
• Never try to open thehousing, repair or modify theproduct in any way.
• Repairs must only be carried out by qualified service technicians and only using
identical replacement parts. Failure to follow this procedure could lead to serious
personal injury.
• Only use accessories that are recommended by themanufacturer or retailer.
• Never use theproduct where explosive substances are used or stored.
• Protect theproduct from becoming wet and exposure to direct sunlight.
• Store theproduct out of children’s reach.
Product description
Cross-line laser level
1. Laser window
2. Levelling warning light
3. [ON/OFF] Power on/off switch
4. Battery cover
5. Laser warning sticker
6. ¼″tripod thread
ENGLISH
5
A
Tripod
• The tripod mounting plate has adisc bubble spirit level (A). When thebubble is in
thecentre of thecircle, thetripod is level.
• Make sure that thelocking knobs and cam lever locks are tight once thetripod has
been adjusted.
ENGLISH
6
Instructions for use
Batteries
Warning
Make sure that thelaser level is switched off before
inserting batteries.
1. Never mix old and new batteries. Never mix
rechargeable and non-rechargeable batteries.
2. Remove thebattery cover (4) and insert 2 × AAA/
LR03 batteries. Refer to themarkings in thebattery
compartment to ensure correct polarity.
3. Refit thebattery cover.
Using the laser level
When thelaser level is switched on, theautomatic self-levelling system compensates
for inclines up to 3º.
The laser lines will switch off and thelevelling warning light (2) will shine red if thelaser
level is inclined more than 3° in any direction.
When thelevelling warning light shines green and theprojected laser lines have stopped
moving, thelaser level is horizontal and ready to be used.
xx
1. The laser level can be mounted onto atripod, placed on afirm flat surface, or held
against astationary vertical surface for stability.
2. When thelaser level is switched on using thepower switch (3), agreen cross line
laser beam will be projected.
3. Always switch thelaser off using thepower switch after you have finished levelling
or when moving to adifferent location.
ENGLISH
7
Important
• In theevent of vibrations and changes of position during use theinstrument will
automatically self-level. Each time thelaser level has been levelled, theaccuracy
of thehorizontal and vertical lines should be checked against aknown reference in
order to avoid errors.
• Switch thelaser level off before transporting it. This will lock thelevelling system
and help protect it from damage during transport.
• Avoid subjecting thelaser level to impacts or shocks. Damage to thelaser level
could affect its accuracy. The accuracy of thelaser level should be tested against
known horizontal and vertical references following any heavy impact or shock.
• Do not leave thelaser level in avehicle for along time. Extreme temperatures or
sudden changes in temperature can affect theprecision of thelaser level.
Care and maintenance
• Always switch theproduct off before cleaning it.
• Clean theproduct using adamp cloth. Use only mild cleaning agents, never
solvents or corrosive chemicals.
• Remove thebatteries and store thelaser level in adry, dust-free environment, out
children’s reach whenever it is not to be used for anextended period.
Troubleshooting guide
Thelaser will not switch on. Check thecapacity of thebatteries and make sure
that they are inserted correctly. Follow themarkings
on thebottom of thebattery compartment.
Thelaser line flashes or doesn’t
shine during self-levelling.
Thelaser level is at too much of anangle
(more than 3°), place it on alevel surface.
Thelaser line is not very visible. • Check thebatteries and replace if necessary.
• Check thelaser window, clean it with asoft
cloth if necessary.
• Ambient light level too high.
ENGLISH
8
Responsible disposal
This symbol indicates that theproduct should not be disposed of with
general household waste. This applies throughout theentire EU. In order
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner. When
recycling your product, take it to your local collection facility or contact
theplace of purchase. They will ensure that theproduct is disposed of in
anenvironmentally sound manner.
Specications
Cross-line laser level
Working range 10 m
Laser line Cross
Laser line width 100 lux, 3 mm at 5 m
Accuracy ± 0.5 mm/m
Self-levelling within 3°
Normal levelling time 5 s
Laser type 635 nm
Laser class Class 2, P < 1 mW
Operating temperature 0−40 °C
Power supply 2 × AAA/LR03 batteries (sold separately).
Operating time Approx. 15 h
Operating temperature 0−40 °C
Material Soft TPE
Tripod thread ¼″
Dimensions 71 × 57 × 69 mm
Weight (incl. batteries) 197 g
Tripod
Height 35–110 cm
Weight 528 g
SVENSKA
9
Krysslaser
Art.nr 41-1747 Modell NLC06
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska
problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
Varning!
• Rikta aldrig laserstrålen mot människor eller djur och rikta inte heller blicken mot
laserstrålen även om du står på längre avstånd.
• Varning! Titta aldrig in ilaserstrålen med ettoptiskt instrument, t.ex. kikare eller
teleskop. Risk för ögonskada.
• Använd inte produkten på eller nära högreflekterande ytor, laserstrålen kan
reflekteras in idina eller andras ögon.
• Lämna inte produkten påslagen utan uppsikt, stäng alltid av det efter avslutat
arbete. Risk finns att andra personer bländas av laserstrålen.
• Om laserstrålen träffar ögonen, blunda och vrid bort huvudet från strålen.
Produkten är endast avsedd för inomhusbruk.
Laserklassicering
Laserklass 2
Laserklass 2-produkter
Varning! Titta inte in ilaserstrålen och rikta den inte mot andra personer eller djur.
Risk för ögonskada.
Varning! Titta aldrig in ilaserstrålen med ettoptiskt instrument, t.ex. kikare eller
teleskop. Risk för ögonskada.
SVENSKA
10
1
6
2
4
3
5
• Se till att inte avlägsna eller skada de säkerhetssymboler och varningar som finns
på produkten.
• Försök aldrig öppna höljet, reparera eller modifiera produktenpå något sätt.
• Reparationer ska utföras av auktoriserad servicepersonal med originalreservdelar.
Om inte så sker, finns risk för allvarlig personskada.
• Använd endast tillbehör som rekommenderats av tillverkaren eller försäljningsstället
• Använd aldrig produkten imiljöer där explosiva ämnen används eller förvaras.
• Skydda produkten mot väta och direkt solljus.
• Förvara produkten utom räckhåll för barn.
Produktbeskrivning
Krysslaserpass
1. Laserfönster
2. Nivelleringsvarning
3. [ON/OFF ] strömbrytare, på/av
4. Batterilucka
5. Laservarningsskylt
6. Stativfäste ¼″
