COBHAM EXPLORER 8100 Manual de usuario

EXPLORER 8100

Quick Guide

IMPORTANT

Observe all safety requirements listed in the

beginning of the User & installation manual,

and install and use the system according to the

guidelines in the User & installation manual.

The User & installation manual is available

from

• the web interface in the EXPLORER 8100 ACU

(see the next section)

• www.cobham.com/satcom (select Service

and support > AVIATOR, EXPLORER,

SAILOR, Sea Tel Service and Support >

Downloads).

Access the web interface

1. Switch on the Antenna Control Unit (ACU).

2. Connect your computer to LAN1 on the back

of the ACU, or your smartphone to the WLAN

interfaceoftheACU(WLANmustrstbeset

up in the web interface using LAN1).

3. Open your Internet browser and enter the IP

address of the ACU. The default IP address is

http://192 .168.0.1.

4. If prompted, enter user name and password. If

you are logging in as guest, enter user name:

guest, password: guest.

5. To access the User & installation manual,

select HELPDESK > Support and click the

link User manual.

Keypad and display

You can use the keypad and display of the ACU

for simple operations and for status information.

See display menus on the back of this guide.

Start the system

1. Switch on the ACU and the VSAT modem.

2. Wait until the LEDs on the front plate of the

ACU show that the system is ready to be

congured:

• Power LED: Green

• Logon LED: Off

• Fail/Pass LED: Flashing green during power-

on self test, after that steady green.

3. In the keypad, press and hold pfor 2 seconds

to deploy the antenna.

4. Wait until the ACU display shows TRACKING.

5. Check that the connected modem is ready.

6. When the modem is ready you can connect

your equipment to the modem and use it to

connect to the Internet via the VSAT satellite

system. For details, refer to the documentation

for your VSAT modem.

Stow the antenna

When you are not using the antenna it must be

stowed.

1. In the ACU keypad, press and hold qfor 2

seconds.

Display menus

98-146768-B

ANTENNA

POINTING

POLARIZATION

GNSS

HEADING

POINTING

ANTENNA STATE

ELEVATION

AZIMUTH

SERIAL NUMBERS

MAIN

PROFILE

ANTENNA

MODEM

EVENTS

OPERATION

SATELLITE

NETWORK

VERSIONS

MODEM

TX ENABLE

RX LOCK

MODEM TYPE

SIGNAL LEVEL

PROFILE

PORT 2 IP

PORT 2 MASK

PORT 3 IP

PORT 3 MASK

PORT 4 IP

PORT 4 MASK

PORT 5 IP

PORT 5 MASK

NETWORK

PORT 1 IP

PORT 1 MASK

DEFAULT GATEWAY

SERIAL NUMBERS

ACU

ANTENNA

POLARIZATION

RX POLARIZATION

TX POLARIZATION

SATELLITE

POSITION

RX FREQUENCY

LNB LO

BUC LO

RX POLARIZATION

TX POLARIZATION

TX FREQUENCY

EVENTS

GNSS

LATITUDE

LONGITUDE

FIX TYPE

Only present for Ku band

OPERATION

DEPLOY

STOW

STOP

START
