Product Manual

9084-OM (V4.0)

Cobalt Digital Inc.

HD/SD-SDI RGB Color Corrector with

YCbCr Video Proc and Frame Sync

Duplication or distribution of this manual and any information contained within is strictly prohibited without the express written

permission of Cobalt Digital Inc. This manual and any information contained within, may not be reproduced, distributed, or

transmitted in any form, or by any means, for any purpose, without the express written permission of Cobalt Digital Inc.

Reproduction or reverse engineering of software used in this device is prohibited.

Disclaimer

The information in this document has been carefully examined and is believed to be entirely reliable. However, no responsibility

is assumed for inaccuracies. Furthermore, Cobalt Digital Inc. reserves the right to make changes to any products herein to improve

readability, function, or design. Cobalt Digital Inc. does not assume any liability arising out of the application or use of any

product or circuit described herein.

Trademark Information

Cobalt®is a registered trademark of Cobalt Digital Inc.

COMPASS™is a trademark of Cobalt Digital Inc.

DashBoard™ and openGear™ are trademarks of Ross Video Limited. Tektronix®is a registered trademark of Tektronix, Inc.

Other product names or trademarks appearing in this manual are the property of their respective owners.

Congratulations on choosing the Cobalt®9084 HD/SD-SDI RGB Color Corrector with YCbCr Video Proc and

Frame Sync. The 9084 is part of a full line of processing and modular conversion gear for broadcast TV

environments. The Cobalt Digital Inc. line includes video decoders and encoders, audio embedders and de-

embedders, distribution amplifiers, format converters, remote control systems and much more. Should you

have questions pertaining to the installation or operation of your 9084, please contact us at the contact

information on the front cover.

9084-OM (V4.0)

Manual No.: 9084-OM

Document

Version: 4.0

Release Date: November 6, 2009

Applicable for

9084 Software

Version: 4.0 / 2740

9084-OM (V4.0) 9084PRODUCTMANUAL i

Table of Contents

Chapter 1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Overview ................................................................................................................ 1-1

9084 Card Software Versions and this Manual...................................................... 1-2

Manual Conventions............................................................................................... 1-3

Warnings, Cautions, and Notes .................................................................. 1-3

Labeling Symbol Definitions...................................................................... 1-4

Safety Summary ..................................................................................................... 1-4

Warnings..................................................................................................... 1-4

Cautions...................................................................................................... 1-4

9084 Functional Description .................................................................................. 1-5

9084 Input/Outputs..................................................................................... 1-5

Color Corrector........................................................................................... 1-7

Video Processor.......................................................................................... 1-7

Frame Sync Function.................................................................................. 1-7

AFD Inserter............................................................................................... 1-7

User Control Interface ................................................................................ 1-8

9084 Rear I/O Modules ............................................................................ 1-10

Video Formats Supported by the 9084..................................................... 1-10

Technical Specifications....................................................................................... 1-11

Warranty and Service Information ....................................................................... 1-14

Cobalt Digital Inc. Limited Warranty....................................................... 1-14

Contact Cobalt Digital Inc.................................................................................... 1-15

Chapter 2 Installation and Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1

Overview ................................................................................................................ 2-1

Installing the 9084 Into a Frame Slot ..................................................................... 2-1

Installing a Rear I/O Module.................................................................................. 2-3

Setting Up 9084 Network Remote Control ............................................................ 2-4

ii 9084 PRODUCT MANUAL 9084-OM (V4.0)

Chapter 3 Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Overview................................................................................................................. 3-1

Control and Display Descriptions........................................................................... 3-1

Function Submenu/Parameter Submenu Overview .................................... 3-2

9084 Card Edge Controls, Indicators, and Display..................................... 3-3

DashBoard™User Interface....................................................................... 3-7

Cobalt®Remote Control Panel User Interfaces .......................................... 3-9

Accessing the 9084 Card via Remote Control...................................................... 3-10

Accessing the 9084 Card Using DashBoard™......................................... 3-10

Accessing the 9084 Card Using a Cobalt®Remote Control Panel ........... 3-11

Checking 9084 Card Information.......................................................................... 3-12

Ancillary Data Line Number Locations and Ranges ............................................ 3-13

9084 Function Submenu List and Descriptions.................................................... 3-14

Video Proc ................................................................................................ 3-15

AFD .......................................................................................................... 3-18

Color Correction ....................................................................................... 3-19

Framesync ................................................................................................ 3-22

Presets ...................................................................................................... 3-25

Color and Video Correction Examples Using the 9084........................................ 3-27

On-Set Monitor Color Correction Example.............................................. 3-27

Miscellaneous Color and Video Correction Examples............................. 3-31

Troubleshooting .................................................................................................... 3-34

Error and Failure Indicator Overview....................................................... 3-34

Basic Troubleshooting Checks.................................................................. 3-38

9084 Processing Error Troubleshooting.................................................... 3-39

Troubleshooting Network/Remote Control Errors.................................... 3-40

In Case of Problems .................................................................................. 3-40

9084-OM (V4.0) 9084PRODUCTMANUAL 1-1

Chapter 1

Chapter 1 Introduction

Overview

This manual provides installation and operating instructions for the

9084 HD/SD-SDI RGB Color Corrector with YCbCr Video Proc and Frame

Sync card (also referred to herein as the 9084).

This manual consists of the following chapters:

•Chapter 1, “Introduction”–Provides information about thismanual

and what is covered. Also provides general information regarding the

9084.

•Chapter 2, “Installation and Setup”–Provides instructions for

installing the 9084 in a frame, and optionally installing a Rear I/O

Module.

•Chapter 3, “Operating Instructions”–Provides overviews of

operating controls and instructions for using the 9084.

This chapter contains the following information:

•9084 Card Software Versions and this Manual (p. 1-2)

•Manual Conventions (p. 1-3)

•Safety Summary (p. 1-4)

•9084 Functional Description (p. 1-5)

•Technical Specifications (p. 1-11)

•Warranty and Service Information (p. 1-14)

•Contact Cobalt Digital Inc. (p. 1-15)

19084 Card Software Versions and this Manual

1-2 9084 PRODUCT MANUAL 9084-OM (V4.0)

9084 Card Software Versions and this Manual

When applicable, Cobalt Digital Inc. provides for continual COMPASS™

card product enhancements through software updates. As such, functions

described in this manual may pertain specifically to cards loaded with a

particular software build. If you received your 9084 and this manual at the

same time, this manual reflects all facets of your card.

This manual (9084-OM (V4.0)) was specifically written for

Software Version: 4.0 / 2740

If your 9084 was purchased earlier than receiving this manual, you can check

the Software Release Number/Software Build Number of your 9084 and see

if it matches the Software Version covered by this manual.

If necessary, the Software Release Number/Software Build Number of your

9084 can be checked by viewing this information as displayed on the Info

submenu on the card-edge display, or by checking the Card Info menu in

DashBoard™. See Checking 9084 Card Information (p. 3-12) in Chapter 3,

“Operating Instructions”for more information.

Proceed as follows if your card’s software does not match this manual:

Card Software earlier than

version in manual Card is not loaded with the latest software. Not all

functions described in this manual may be

available.

If desired, contact Cobalt Digital Inc. to receive the

latest Update software for your card. Software is

typically sent by e-mail.

You can update your card by uploading the new

Update software by going to the

Support>Downloads link at

www.cobaltdigital.com. Then, go to the listing for

your card and download “COMPASS™Firmware

Update Guide”.

Card Software newer than

version in manual A new manual is expediently released whenever a

card’s software is updated and specifications

and/or functionality have changed as compared

to an earlier version (a new manual is not

necessarily released if specifications and/or

functionality have not changed). A manual earlier

than a card’s software version may not completely

or accurately describe all functions available for

your card.

If your card shows features not described in this

manual, you can check for the latest manual (if

applicable) and download it by going to the

Support>Downloads link at

www.cobaltdigital.com.

9084-OM (V4.0) 9084 PRODUCT MANUAL 1-3

Introduction Manual Conventions

Manual Conventions

In this manual, display messages and connectors are shown using the exact

name shown on the 9084 itself. Examples are provided below.

•Card-edge display messages are shown like this:

•Connector names are shown like this: SDI IN

In this manual, the terms below are applicable as follows:

•9084 refers to the 9084 HD/SD-SDI RGB Color Corrector with

YCbCr Video Proc and Frame Sync card.

•Frame refers to the 8310 (or similar) frame that houses the Cobalt®

COMPASS™cards.

•Device and/or Card refers to a COMPASS™card.

•System and/or Video System refers to the mix of interconnected

production and terminal equipment in which the 9084 and

COMPASS™cards operate.

Warnings, Cautions, and Notes

Certain items in this manual are highlighted by special messages. The

definitions are provided below.

Warnings

Warning messages indicate a possible hazard which, if not avoided, could

result in personal injury or death.

Cautions

Caution messages indicate a problem or incorrect practice which, if not

avoided, could result in improper operation or damage to the product.

Notes

Notes provide supplemental information to the accompanying text. Notes

typically precede the text to which they apply.

E201

1Safety Summary

1-4 9084 PRODUCT MANUAL 9084-OM (V4.0)

Labeling Symbol Definitions

Safety Summary

Warnings

Cautions

Attention, consult accompanying documents.

Electronic device or assembly is susceptible to damage from an ESD

event. Handle only using appropriate ESD prevention practices.

If ESD wrist strap is not available, handle card only by edges and avoid

contact with any connectors or components.

Symbol (WEEE 2002/96/EC)

For product disposal, ensure the following:

•Do not dispose of this product as unsorted municipal waste.

•Collect this product separately.

•Use collection and return systems available to you.

! WARNING ! To reduce risk of electric shock do not remove line voltage service barrier cover on frame

equipment containing an AC power supply. NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

CAUTION This device is intended for environmentally controlled use only in appropriate video

terminal equipment operating environments.

CAUTION This product is intended to be a component product of an openGear™ frame. Refer to the

openGear™ frame Owner's Manual for important safety instructions regarding the proper

installation and safe operation of the frame as well as its component products.

CAUTION Heat and power distribution requirements within a frame may dictate specific slot

placement of cards. Cards with many heat-producing components should be arranged to

avoid areas of excess heat build-up, particularly in frames using only convection cooling.

The 9084 has a moderate power dissipation (15 W max.). As such, avoiding placing the

card adjacent to other cards with similar dissipation values if possible.

CAUTION If required, make certain Rear I/O Module(s) are installed before installing the 9084 into the

frame slot. Damage to card and/or Rear I/O Module can occur if module installation is

attempted with card already installed in slot.

CAUTION If card resists fully engaging in rear I/O module mating connector, check for alignment and

proper insertion in slot tracks. Damage to card and/or rear I/O module may occur if

improper card insertion is attempted.

9084-OM (V4.0) 9084 PRODUCT MANUAL 1-5

Introduction 9084 Functional Description

9084 Functional Description

Figure 1-1 shows a functional block diagram of the 9084. The 9084 provides

HD/SD-SDI RGB color correction with frame synchronization that supports

all popular SD and HD video formats including 525i, 625i, 720p, 720f, 1080i,

1080p, and 1080psF. Input video format is auto-detected by the card. The

9084 accepts either an HD SDI input (1.485 Gbit) or an SD SDI input (270

Mbit) and automatically equalizes for cable loss. The 9084 also provides

processing-bypassed reclocked SDI outputs.

Processed video is synchronized to either a frame-wide reference or a local

reference. For further flexibility in resolving system timing problems,

additional fixed delay can be added to the video. Ancillary Data (VANC) is

protected, and is passed from input to output ensuring data is not lost during

the frame sync operation.

9084 Input/Outputs

The 9084 provides the following video inputs and outputs:

•Inputs:

•HD/SD-SDI IN –dual-rate HD/SD-SDI input

•Outputs:

•HD/SD-SDI OUT –four dual-rate HD/SD-SDI buffered video

outputs

•RCK OUT –four dual-rate HD/SD-SDI reclocked buffered video

outputs

19084 Functional Description

1-6 9084 PRODUCT MANUAL 9084-OM (V4.0)

Figure 1-1 9084 Functional Block Diagram

Video

Processing Frame

Sync

Serializer/

Cable Drivers

SDI

OUT

Video Processor

EXT REF

IN (1,2)

Reclock RCK

OUT

Deserialize

HD/SD

SDI IN EQ

9084V4.0BD

AFD

Insertion

YCbCr

Proc YCbCr

Limiting

RGB

Correction

Color Corrector

Tabla de contenidos

Otros manuales de Hardware de computadora de Cobalt Digital Inc

Cobalt Digital Inc

Cobalt Digital Inc BBG-1300-FR Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9229-QS Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9902-2UDX-DI Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1070-QS Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9934-AUD-PRO-DSP Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 3G Fusion 9931-EMDE Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9905-MPx Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9922-FS-DSP Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 3000 Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc BBG-1022-FS Manual de usuario

Cobalt Digital Inc

Cobalt Digital Inc 9902-UDX-FS Manual de usuario

Manuales populares de Hardware de computadora de otras marcas

EMC2

EMC2 VNX Series Manual del propietario

Panasonic

Panasonic DV0PM20105 Manual de usuario

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manual de usuario

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manual de usuario

Raidon

Raidon iT2300 Manual de usuario

National Instruments

National Instruments PXI-8186 Manual de usuario

Hauppauge

Hauppauge WinTV-HVR-2250 Manual de usuario

Kontron

Kontron CP6002 Manual de usuario

Manhattan

Manhattan 702843 Manual de usuario

Aphex

Aphex 230 Manual de usuario

AMD

AMD Phenom II Manual operacional

Intel

Intel NUC 12 Pro Manual de usuario

dbx

dbx Zone Pro 1260 Manual de usuario

Galaxy

Galaxy GHDX2-2430S-24F4D Manual de usuario

Intel

Intel AXXRMFBU4 Manual de usuario

Kontron

Kontron DIMM-PC/MD Manual de usuario

ST X-NUCLEO-SAFEA1B Instrucciones de funcionamiento

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manual de usuario
