Coatmaster Flex Manual de usuario

coatmaster Flex

User Manual

flex.coatmaster.com

Version: 05-2021

coatmaster Flex

Distribution and duplication of this document, and utilization and communication of its contents

other than for legitimate purposes, are not permitted without the express permission of

coatmaster AG. Violations will result in legal action. All rights are reserved in the event of patent

grant or utility model registration (ISO 16016).

Subject to technical changes and printing errors, the values given are approximate and are not to be

understood as legally warranted characteristics. These values may vary according to component

tolerance.

Last update: 05/2021

coatmaster Flex

1Table of contents

1Technical Data ................................................................................................................................. 3

2Customer Requirements and Device Specification ......................................................................... 4

3Applications..................................................................................................................................... 5

4Functionality and Measuring Principle............................................................................................ 6

5Safety and Responsibility ................................................................................................................ 7

5.1 Warning Symbols..................................................................................................................... 7

5.2 Signs and Icons ........................................................................................................................ 8

5.2 Intended Use ........................................................................................................................... 8

5.3 Improper Use........................................................................................................................... 9

5.4 Product Safety ....................................................................................................................... 10

6Delivery Scope ............................................................................................................................... 11

7Set-Up............................................................................................................................................ 12

7.1 Battery................................................................................................................................... 13

7.2 Navigation Panel.................................................................................................................... 14

7.3 Turning the Power On/Off..................................................................................................... 14

7.4 Language Selection................................................................................................................ 14

7.5 Wi-Fi Settings......................................................................................................................... 15

7.6 Activation .............................................................................................................................. 16

7.7 Operation with coatmaster®Local server…………………………………………………………………………..17

8Operating Instructions................................................................................................................... 18

8.1 System Settings ..................................................................................................................... 18

8.2 Main Menu ............................................................................................................................ 21

8.3 Block Menu............................................................................................................................ 22

8.4 Application Menu .................................................................................................................. 23

8.5 Measurement........................................................................................................................ 32

8.6 Data Transfer/Cloud .............................................................................................................. 33

9Troubleshooting and Best Practice................................................................................................ 36

9.1 Error Messages...................................................................................................................... 36

9.2 Error Codes............................................................................................................................ 36

9.3 Frequently Asked Questions (FAQs)...................................................................................... 38

9.4 Hotline ................................................................................................................................... 38

10 Storage and Transportation .......................................................................................................... 38

11 Maintenance and Repair ............................................................................................................... 39

11.1 Replacement of the Inlet Filter.............................................................................................. 39

11.2 Replacement of the Front Glass ............................................................................................ 40

11.3 Cleaning and Care.................................................................................................................. 40

11.4 Warranty ............................................................................................................................... 40

12 API-Interface Description ............................................................................................................. 41

coatmaster Flex

Foreword

Dear Customer,

With the purchase of a coatmaster® Flex, you have acquired a high-quality, precise product. To help

you to work successfully and productively with this device for many years, in this manual we provide

you with some instructions for use. coatmaster AG has made every effort to manufacture a safe and

high-quality device that complies with all applicable regulations. Our strict quality control procedures

ensure high quality standards even for high volume production. Please add your own and treat the

device with care. Should you have any questions regarding the use of the equipment, please do not

hesitate to contact us.

We wish you success and ‘a perfect coating’. 

The Founders Prof. Dr. N. A. Reinke and Andor Bariska

coatmaster AG

1Technical Data

Characteristics

Tolerance/ Description

Measuring distance range

20-150 mm

Measurement angle /

tolerance

±70°

Measuring point size

2 mm2 at 75 mm distance

Measuring range thickness

10–500 µm (depending on coating type)

Standard deviation

Typical < 2% of the thickness1

Measuring time

Typical 300ms (depending on setting for coating thickness)

Storage conditions

-10–50°C max. 80% humidity (non-condensing)

Power supply

Bosch Professional Lithium-Ion battery GBA 18V 3.0 Ah

Number of measurements

Up to 800 measurements per battery charge (3Ah)

Operating conditions

Temperature: 0–35°C, rel. humidity: 10%-75%

Weight (without battery)

1.3 kg

Dimensions

374 x 91 x 203 mm

IP protection type

IP50

Table 1: Technical data

coatmaster Flex

2Customer Requirements and Device Specification

Measuring the coating thickness early in the process is the key to documenting and controlling coating

processes, saving coating material, improving coating quality, and reducing running-in time and scrap.

Coating processes are highly sensitive to changes in environmental conditions; therefore, it is crucial

to have access to a thickness gauge that is easy to handle and works in an industrial environment.

The patented measurement process used by the coatmaster® Flex is non-contact (as opposed to

systems based on magnetic induction or ultrasound) and non-destructive. It can be applied on wet,

powder, and cured coatings, independently of the coating material, thickness, or color (including

white). In contrast to magnetic induction-based systems, the Flex device permits measurement of

coating thickness early in the process, i.e. directly after the application of the coating material, before

drying or curing. This allows to:

•Savings of 10%-30% coating material

•Reducing time for color changes

•Accelerating training of new personnel

•Avoiding cost-intense rejects & reworks

•Documenting coating processes

•Reducing environmental impacts

•Establishing industry 4.0 standards

•Online-connection to ERP-System

coatmaster® Flex is the most advanced measurement gauge for non-contact thickness measurements.

It outperforms any other photothermal, LED/laser-based, and ultrasound systems on the market in all

industrial relevant aspects. It requires minimal calibration and is insensitive to the angle and distance

of measurement. Its superior reliability, user-friendliness, safe usage, cost-effectiveness, precision,

and accuracy is highly appreciated by the major coating-line manufacturers, biggest paint

manufacturers, renowned experts and most importantly by coaters around the globe.

coatmaster Flex

3Applications

The coatmaster® Flex is a flexible and robust handheld device for non-contact

measurement of coatings.

The coatmaster® Flex is unique and versatile and can be used in a wide variety of industries and

industrial sectors:

•Automotive

•Rail

•Aerospace

•Construction

•Furniture

•Profiles

•Wind Power

•Pipelines

•Medical/Technical

The coatmaster® Flex is particularly suitable for the following applications:

Powder paints

Due to control of coating thickness with Flex measurement, up to 30% of the

powder quantity can be saved. Measurement early in the process saves time

and reduces rework rates.

Wet paints

Precise measurements are possible even before drying. The measuring

equipment capability is guaranteed. This saves material and time, and ensures

quality.

Functional coatings

Thickness measurement of functional coatings (i.e. e-coats, adhesives, anti-

corrosive coatings) in wet and dried state. Highly accurate measurement even on

rough surfaces and for soft coatings.

coatmaster Flex

4Functionality and Measuring Principle

The coatmaster® works according to the principle of advanced thermal optics (ATO). The surface of

the coating is heated with a light pulse. After brief heating by a few degrees, the surface is cooled

by heat conduction to deeper areas of the coating and the substrate. The cooling process on the

surface depends on the thermal properties of the coating and the substrate. The thinner the coating,

the faster the surface temperature decreases, providing it has a lower thermal conductivity than

the substrate. The thickness and thermal properties of the coating are derived from the dynamics

of the surface temperature.

Illustration of the measuring principle

① Flash lamp

② Pulsed heat input

③ Coatings

④ Substrate

⑤ IR radiation

⑥ IR sensor

Generally, coatings have a very irregular surface. Powder coatings before curing have an even rougher

surface, but can nevertheless be measured with the coatmaster® Flex. The properties of this roughness

are influenced by various factors, such as pre-treatment, the type and roughness of the substrate, the

type of coating (e.g. particle size, distribution, and chemical composition), and the exact conditions

(temperature distribution, baking time) during baking. The figure below shows a microscopic sketch of

this roughness. The TLT automatically compensates for the roughness described above, using an

optical averaging process. This allows a reliable determination of the coating thickness, even with

changing parameters.

Sketch of surface roughness of a powder coating after curing

① Substrate

② Coating

coatmaster Flex

5Safety and Responsibility

This section provides an overview of all relevant safety features for optimum personal protection

and safe and trouble-free operation. Keep the operating instructions with the safety instructions

so that you can refer to them later.

5.1 Warning Symbols

For your safety, it is important to read and fully understand the following table showing the different

warning signs and their definitions!

Symbol Definition

DANGER

Warning of an immediate danger that, if not avoided, will result in death

or very serious injury.

◇

Measures to avoid the danger.

WARNING

Warning of an immediate danger that, if not avoided, will result in

serious injury.

◇

Measures to avoid the danger.

CAUTION

Indication of a hazardous situation that, if not avoided, may result in minor

or moderate injury.

◇

Measures to avoid the situation.

Warning of optical radiation.

Warning of electrical voltage.

Warning of hazards associated with charging batteries.

CAUTION

Indication of a hazardous situation that, if not avoided, may result in

property damage; however, no action is required with regard to personal

injury.

◇

Measures to avoid the damage.

Table 2: Warning symbols

coatmaster Flex

5.2 Signs and Icons

Symbol Definition

This symbol means that your device meets the safety requirements of all

applicable EU directives.

This symbol means that you may only dispose the device at an approved local

disposal site.

Information: a highlight containing particularly important information for better

understanding.

Table 3: Signs and icons

5.2 Intended Use

The coatmaster® Flex is intended exclusively for the measurement of coating thicknesses.

The device should only be used as a handheld device.

The device should not be mounted on a robot or fixture, or operated for an

extended period of time.

The instrument may only be operated and cleaned by trained personnel. The intended use also

includes compliance with these instructions and the maintenance intervals must be observed.

Have your device repaired only by qualified personnel and only with original spare parts. This

ensures that the safety of the device is maintained.

The device is not approved for operation in environments with potentially explosive

atmospheres.

Keep the device away from rain or moisture. Penetration of water into an electrical appliance

increases the risk of electric shock. Do not place the measurement device in a place where

components could come into contact with corrosive gases or salty air.

Do not block ventilation openings. The ventilation openings prevent the interior of the unit from

overheating.

Remove the battery before cleaning. Do not use solvents for cleaning, to avoid damaging the

housing surface. Use a clean, dry cloth.

In accordance with Directive 2012/19/EU, please take old parts to the appropriate recycling facilities

for proper disposal, reprocessing, and reuse. Never throw electrical equipment into the household

waste! By properly disposing of the electrical appliances, you help to protect valuable resources and

prevent possible negative effects on health and the environment, which could otherwise occur due

to improper waste disposal. Accessories and packaging should also be recycled in an environmentally

friendly manner.

coatmaster Flex

5.3 Improper Use

Use not mentioned above or use that does not comply with the technical specifications, is considered

to be improper use. The operator is solely responsible for any damage caused by improper use.

The following applications are prohibited:

•

Use of the equipment in environments where liquids may get into the device.

•

Introduction of any objects into the coatmaster® Flex or similar devices.

•

Opening of the device, except for cleaning or changing filters and changing the plexiglass

pane. This only applies when the battery is not in place. Opening the device, other than for

standard maintenance operations (see section 11), voids the warranty and the

manufacturer assumes no liability.

The following safety instructions point out dangers of a general nature that may occur when handling

the device. The user must observe all the instructions listed to minimize possible hazards.

Additional warning messages can be found in this manual whenever the actions described could

result in hazards.

Symbol Description

Integrated light source.

The coatmaster® Flex with SpectralBlue contains a Xenon flash lamp. The Evaluation

of the photobiological safety of a Xenon flash light according to IEC-62471:2006

shows that the coatmaster Flex flash lamp falls under the exempt group and thus

does not pose any photobiological hazard.

CAUTION

Device damage may occur if the battery is changed during operation.

Never change the battery during operation, as this can lead to the device being

damaged.

◇

Always switch off the device before changing the battery.

Table 4: Warning – improper use

Otros manuales para Flex

Tabla de contenidos

Otros manuales de Instrumento de medición de Coatmaster

Coatmaster

Coatmaster Atline V4 Manual de usuario

Coatmaster

Coatmaster Flex Manual de usuario

Coatmaster

Coatmaster Flex V2 Manual de usuario

Coatmaster

Coatmaster 3D Manual de usuario

Coatmaster

Coatmaster Flex Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
