Grass Trimmer Cotech 1 hp/0.74 kW
Art.no.: 40-6002 Model: YT9231
Please read the entire instruction manual before using the product and save it for future reference. We reserve
the right for any errors in the text or images and any necessary changes made to technical data. If you have
any questions regarding technical problems please contact our Customer Services (see address on reverse).
Contents
Safety............................................... 3
Product Description......................... 5
Assembly .........................................6
Fuel and Lubrication ........................9
Starting the Engine ....................... 10
Operation ....................................... 12
Care and Maintenance................... 13
Storage............................................15
Troubleshooting Guide ..................15
Disposal ......................................... 16
Specifications ................................ 16
Safety
Product safety symbols and their meaning
Wear protective head gear, protective eyewear/visor and ear defenders.
Wear protective gloves.
Wear safety footwear.
Read the entire instruction manual.
Stones and other debris can be ejected by the trimmer.
Do not permit anyone else to come close to the trimmer when it is in use. Children, pets and
bystanders should keep a distance of at least 15 metres away from the trimmer when it is being used.
The product is only intended for use with trimmer line. Never use a brush cutter blade
or other accessories.
Maximum shaft speed
Caution! Hot surface.
4
ENGLISH
Safety Instructions
1. Wear protective footwear, tight-tting clothes and safety glasses/visor, ear defenders and a helmet.
2. Never use the grass trimmer if you are tired, sick, upset or under the inuence of medication which
causes drowsiness. Do not use the trimmer whilst under the inuence of drugs, alcohol or medicine.
3. Fuel safety
- Always be careful when handling fuel. Open the fuel tank carefully and release any pressure which
might have built up in the tank. Wipe off any spilt fuel and move the grass trimmer at least 3 metres
away from the refuelling location before starting it.
- Remove any sources of ignition, sparks, open ames, lit cigarettes, etc. from the area where the fuel
is mixed, used or stored.
- Do not smoke while refuelling or using the grass trimmer.
4. Do not permit anyone other than the operator to come close to the grass trimmer when it is being started
or used. Children, pets and bystanders should keep a distance of at least 15 metres away from the grass
trimmer when it is being used.
5. Always hold both handles of the grass trimmer rmly with your ngers on one side of the handle and
thumb on the other side, once the engine is running.
6. Keep all body parts away from the trimmer line when the engine is running.
7. Make sure that the trimmer line is not in contact with any object before starting.
8. Only transport the trimmer with the engine switched off.
9. Always inspect the trimmer before starting it. Do not start it if there are worn, missing or damaged parts.
Never use the grass trimmer if it is damaged, incorrectly adjusted or incorrectly assembled.
10. All service other than that mentioned in this instruction manual should be carried out by qualied personnel.
11. Switch off the grass trimmer before laying it on the ground.
12. Be extra vigilant when cutting small bushes or thick grass. They can become stuck in the trimmer head.
13. Keep the handles clean, dry and free from oil or fuel.
14. Only use the trimmer outdoors or in well ventilated areas. Never start the trimmer in a closed room or
building. Exhaust fumes contain carbon monoxide and are dangerous to inhale.
15. Avoid running the trimmer head near small objects which can be ejected. Check the work area is clear of
small stones, debris, etc. before beginning.
16. Always stand below the trimmer if you are using it on a slope. Never use the trimmer on a slope if there
is the slightest risk of you losing your footing, falling or sliding.
17. Keep the trimmer clear of grass cutting build-up and other deposits. Particularly the guard trimmer head
and engine.
18. The grass trimmer must only be used by adults who have read the instruction manual.
19. Use only two-stroke fuel mixed with 2.5% good quality two-stroke oil (40:1) designed for air-cooled two-stroke
engines. Using petrol without the addition of oil can lead to engine damage not covered by the guarantee.
20. Do not use the grass trimmer without the silencer or silencer cover.
21. Hold both handles of the grass trimmer rmly, with your ngers on one side of the handle and thumb
on the other.
22. The silencer becomes extremely hot. Keep your hands and other body parts out of the way.
23. The trimmer head should not be lifted up during work since the trimmer line can injure the user. Work as
close to the ground as possible.
24. The grass trimmer must not be used for any other purpose than for the trimming of lawns and gardens.
25. The grass trimmer must not be used if the guard is damaged or missing.
26. This product must not be altered or used for other tasks since the risk of accident will increase and the
guarantee will not be valid.
27. Do not use the grass trimmer close to ammable gases and liquids since this could cause a re or lead
to an explosion.
5
10
101
102 103
104
105
106
107
108
109
11
12
13
14
16
15
18
19
20 17
ENGLISH
Product Description
1. Trimmer head
2. Trimmer head locking knob
3. Trimmer guard
4. Upper shaft
5. Shaft coupler
6. Lower shaft
7. Loop handle
8. Throttle
9. ON/OFF Switch (1/0)
10. Safety lock
11. Spark plug
12. Fuel tank
13. Air lter cover
14. Pull start handle
15. Primer pump
16. Choke lever
17. Carry strap
18. Trimmer spanner
19. Allen key
20. Spark plug wrench
6
107
105
ENGLISH
Assembly
Assembling the loop handle and the lower shaft
1. Remove the protective rubber cap on the upper shaft.
2. Thread the loop handle (7) onto the shaft and tighten the locking screw.
3. Thread the shaft coupler (5) onto the upper shaft until the screw hole is lined up with the hole in the shaft.
7
105
ENGLISH
4. Tighten the screws and fasten the coupler in place by tightening the clamp using an Allen key.
5. Remove the protective rubber cap on the end of the lower shaft.
6. Press and hold in the release catch on the coupler (5). Insert the lower shaft into the coupler and release
the catch into the desired hole. There are three holes to allow the trimmer head to be set at three
different angles.
7. Lock the shafts together by tightening the locking knob on the coupler.
8
ENGLISH
Mounting the trimmer guard
Warning! The trimmer guard must be mounted correctly in order to protect the user and so that the trimmer
line will be the correct length. The guard contains a blade which automatically cuts off the line to an appro-
priate length when the trimmer head begins rotating.
1. The trimmer head must be taken off before the trimmer guard is mounted.
2. Hold the trimmer head and use your hand or the enclosed spanner to undo the trimmer head nut.
3. Remove the trimmer head from the spindle.
4. Slide the trimmer guard over the shaft and align the holes in the guard with holes in the bracket.
(See g above.)
5. Push in the bolt through the trimmer guard from the side with the hexagonal countersink. Tighten the bolt
using the washer and nut.
6. Reassemble the trimmer head onto the spindle.
9
ENGLISH
Fuel and Lubrication
Caution! Petrol is highly ammable. Avoid smoking near any area where fuel will be handled. Do
not introduce open res, embers or sparks into the area. Switch off the grass trimmer and let it cool
before refuelling it. Refuel outdoors and always move at least 3 metres away from the refuelling site
before starting the trimmer.
Mix petrol (unleaded 95 octane without added ethanol) with a good quality 2-stroke oil intended for air-cooled
2-stroke engines.
Recommended mixture: Petrol/oil 40:1 (2.5 %)
• The engine is designed to be used with unleaded fuel.
• Use at least an 87 rated octane fuel.
• Use unleaded fuel to protect the environment and your health.
• Bad quality fuel or oil can damage seals, fuel pipes or the fuel tank.
Mixing the fuel
N.B. Be precise with the mixture.
1. Measure out the petrol and oil precisely before mixing.
2. Pour a small amount of the petrol into a clean approved fuel container.
3. Pour in all of the oil and agitate the fuel can.
4. Pour in the rest of the petrol and agitate the fuel can for at least a minute. Some oils are difcult to mix. It
is therefore important to agitate the container in order for the oil and petrol to mix thoroughly. The engine
will last longer if the fuel is well mixed, if the fuel is not mixed properly the mixture will be too lean and the
engine may be damaged.
5. Label the fuel can clearly to avoid the risk of misidentication.
6. Fuel containing oil is only intended for 2-stroke engines. Pure petrol is for 4-stroke engines. It is therefore
very important to label fuel containers clearly.
N.B. Do not mix too much fuel; it should be used within 90 days.
Caution! Only use fuel containing oil for 2-stroke engines, using pure petrol without the addition of oil will
inevitably cause engine damage which is not covered by the guarantee.
Fueling the trimmer
1. Let the trimmer cool before refuelling it.
2. Unscrew and remove the fuel cap.
3. Fill with fuel until the tank is roughly 80% full.
4. Replace and tighten the fuel cap and wipe up any spilt fuel on or around the grass trimmer.
10
13 cm
1016
ENGLISH
Starting the Engine
N.B. Pull the starter handle straight out. If you pull at an angle the starter cord will rub on the sleeve and
wear out prematurely. Keep hold of the starting handle after pulling it and allow it to return slowly. Never re-
lease the starter handle completely at full length since it can become entangled and the backlash can break
something on the trimmer.
N.B. See the Troubleshooting section if the trimmer doesn’t start after several attempts.
Starting a cold engine
Cut the trimmer line to a length of 13 cm before starting to reduce the load while
the trimmer warms up.
1. Place the grass trimmer on a level surface.
2. Set the on/off switch to position 1.
3. Set the choke lever (17) to cold start mode (upwards).
4. Press the primer pump (15) 10 times.
5. Hold the upper handle rmly while simultaneously pressing and holding in the safety lock and throttle.
6. Pull the starter handle until you feel some resistance (approx. 100 mm) Pull the starter handle quickly
and smoothly until the engine starts or up to 4 times.
7. Set the choke lever to the open position (downwards) as soon as the engine starts.
