Congratulations on your purchase of the CLA7

Ampliﬁed Powered Neckloop from ClearSounds

Communication(tm). The CLA7 has been devel-

oped to facilitate the use of a cellular or landline

telephone, equipped with a standard 2.5 mm jack,

with a t-coil equipped hearing aid for hands-free

operation.A2.5 mm to 3.5 mm adapter is provided

with the CLA7 so it can be used as an ampliﬁed

audio Neckloop with a variety of devices.

The CLA7 generates an induction (loop) signal that is picked

upbythetelecoilofyourhearingaid(s)(thisoptionisactivated

by setting the hearing aid(s) to the “T” or “MT” position).

The CLA7 is compatible with most cellular phones (you may

need to purchase an adapter connector if your cellular phone

is not equipped with a built-in 2.5 mm jack). We hope it will

give you many years of successful operation.

Please read this User Manual carefully in order to get the

very best results from your CLA7. This will tell you how to

set up the CLA7 correctly and explain all the features to you.

Keep the manual for easy reference.

Please visit our web site at www.clearsounds.com to:

• Register your product

• Download additional manuals and trouble shooting tips

PLEASE SAVE THESE INSTRUCTIONS

Conditions for Use

IMPORTANT SAFETY INSTRUCTIONS

Read and understand the Installation Guide & User Manual.

When using your telephone equipment, basic safety precau-

tions should always be followed to reduce the risk of ﬁre,

electric shock and injury to person, including the following.

WARNING: To avoid the possibility of electrical shock, do not

use this product near water (For example, near a bathtub,

wash basin, kitchen sink or laundry tub, in a wet basement

or near a swimming pool) while in the bathtub or shower or

when you are wet.

WARNING: Avoid using the telephone during electrical

storms. There may be a remote risk of electric shock from

lightning. If the electrical storm is present in your immediate

area, possibility of electrical shock exists.

WARNING: Do not use the phone if you suspect a gas leak

in the area. The phone’s electrical contacts could create a

spark, which could ignite any heavy concentration of leaking

gas.

Important Safety Instructions For Batteries

CAUTION: Risk of explosion if battery is replaced by an

incorrect type. Dispose of batteries according to the instruc-

tions.

To reduce the risk of ﬁre or personal injury – read and follow

these instructions:

1. Use only the approved battery in your CLA7.

2. Donotdispose ofthebatteryin aﬁreasit mayexplode.

Check with local codes for possible special disposal

instructions.

3. Do not open or mutilate the battery. Released electro-

lyte is corrosive and may cause damage to the eyes

and skin. It may be toxic if swallowed.

4. Exercise care in handling batteries in order not to short

the battery with conducting materials such as rings,

bracelets and keys. The battery or conduction material

may overheat and cause burns.

5. Observe proper polarity orientation.

NOTE: Please check that your telephone equipment is

UL/ETL approved before connecting the ClearSounds CLA7

into the headset jack. Please refer to your owners manual or

contact the telephone manufacturer.

IMPORTANT FACTS ON ADAPTER USE

1. If connecting the CLA7 to an audio device requiring

a 3.5mm jack, only use the adapter supplied with the

CLA7. It is a special adapter that connects the audio

output connections and bypasses the microphone

connection.

2. The CLA7 can work with cell phones that have stereo

music capabilities. However you must use an adapter

that converts the 2.5mm connector on the cell phone to

function as standard mono connector. These adapters

are usually available from your cell phone manufac-

turer. (Note: Standard cellphone 2.5mm jacks have

two black bands; stereo 2.5mm jacks that are used

with stereo music have three black bands. You need

to verify with your cell phone provider that the 2.5mm

connector on the cell phone will work with a std mono

hands-free headset. The CLA7 is a standard mono

hands-free device.)

Table of Contents

Introduction Page 2

Safety Instructions Page 3

Table of Contents Page 5

Features & Functions Page 6

Installation Steps Page 7

Installing the batteries Page 7

Low battery indicator Page 8

Making & receiving calls Page 9

A Personal Audio Neckloop Page 10

Troubleshooting Guide Page 10

Maintenance and Care Page 11

Speciﬁcations Page 12

FCC Regulatory Compliance Pages 12 - 13

Warranty and Service Pages 14 - 15

Features & Functions

OFF: LED is off

ON: LED is green

Low battery: LED is Red

Volume Control

Up/Down

Microphone

ON/OFF (green)

& Low battery

indicator (red)

ON/OFF button

2.5 mm telephone

connector plug

Neck Loop

plug

Quick Disconnect

Installation &

Operation Steps

Installation and operation of your ClearSounds™ CLA7

Ampliﬁed Powered Neckloop is easy.

Installing The Batteries

IMPORTANT: The CLA7 needs to be disconnected from the

telephone before installing the batteries.

1. Open the battery compartment door located on the

back of your CLA7 by pulling back the latch.

2. Insert correctly (2) AAA alkaline batteries (included) in

the battery compartment. Be sure to observe battery

polarity as imprinted on the base of the compartment.

(See diagram #1).

3. Snap the battery compartment door back in place.

4. The CLA7 is ready to use.

NOTE: The batteries will have approximately 30 to 40 hours

of use before needing replacement. Battery life will depend

on actual usage and ampliﬁed levels.

DIAGRAM # 1

Installing the batteries

Low Battery Indicator

The low battery indicator monitors the condition of the batteries.This

indicator will turn red to indicate the batteries should be changed.

The indicator will only turn red while in use. Replace batteries as

soon as possible with 2 AAAAlkaline batteries (See diagram #2).

Making And Receiving Calls

Place the wire around your neck and insert the round

connector plug into the Neckloop Quick Disconnect plug,

forming a loop (See diagram #3). IMPORTANT: To have the

Neckloop operate Properly, you will need to be sure the

connection is double clicked.

2. Connect the 2.5 mm plug of the CLA7 into the

telephone’s 2.5 mm headset jack

(See diagrams 4, 5 & 6).

3. Switch your hearing aid to “T” or “MT” mode.

Press the “ON/OFF” button. The green light will turn on.

5. Use your telephone in the normal way (making and

receiving calls). See the phone’s owner’s manual for

instruction.

DIAGRAM #2

Low battery indicator

DIAGRAM #3

Setup of CLA7

6. Since the CLA7 has a built in microphone, you will not

need to hold the phone to your ear, but can use it in

conjunction with a belt clip. Simply keep the phone in

your pocket or place it on a ﬂat surface.

7. During the call, you can adjust the volume of the CLA7

by using the volume control knob located on the bot-

tom of the unit.

8. You can manually adjust the volume level on your

phone if the sound quality is unsatisfactory.

9. On completion of the call, press the ON/OFF button.

The green light will turn off.

10. Reset your hearing aid if needed.

Note: If your phone does not have a 2.5mm jack, an adapter

may be required. Check with the manufacturer of the tele-

phone equipment.

DIAGRAM #6

CLA7 w/CSC50 or CSC50-ER

DIAGRAM #5

CLA7 w/A50 Cordless

DIAGRAM #4

CLA7 w/Cellular

Using your CLA7 as a

Personal Audio Neckloop

Your ClearSounds CLA7 can be

easily used as a 3.5mm ampli-

ﬁed Audio Neckloop, using the

provided 2.5mm to 3.5mm

adapter. Simplyplugthe2.5mm

end of the ClearSounds CLA7

into the 3.5mm adapter, and

then insert the adapter into your

audio jack equipped telephone,

Ipod, CD player, or any device

that has an 8-16 Ohm audio

output through a 3.5mm jack.

Follow the directions on adjust-

ing the volume.

Troubleshooting Guide

No Sound

1. Battery may be dead.

2. Battery may be in backwards.

3. Verify that the CLA7 is turned on.

4. Verify that the phone is turned on.

5. Check if the plug of the CLA7 is plugged all the way

in.
