PROFESSIONAL VACUUM CLEANER
INSTRUCTION MANUAL
BUTLER
VACUUM CLEANER
1200 Watt
Made in Europe
Congratulations for choosing the BUTLER vacuum cleaner.
The vacuum cleaner was created to keep ats, oces, hotels, stores and all big surface areas clean.
Read these instructions carefully before using the vacuum cleaner.
Technical parameters of vacuum cleaner type BUTLER
Power - 1200 W
Supply current 240 V, 50 Hz
Cord - 10 m
Dust bag capacity 10 l
Mains safety (fuse) 16 A
Protection class
No RT interference level (EMC Compliant)
Full SAA approval for Australia and New Zealand
Vacuum cleaner characteristics
suctionhose
vacuum cleaner
suction brush
upholstery nozzle small brush
crevice nozzle
paper bag
Elements of the vacuum cleaner
suction pipes
Prior to the first use you should:
Check that the dust bag is correctly fitted onto the
respective seat
Insert the end of the hose into the cleaner, and twist
to lock it in place.
Insert the handle into the upper end of the suction pipe
Insert the brush nozzle into the lower end of the suction
pipe
Unwind the power-supply cord and pay attention to its
condition. If the cord insulation is damaged, don't use
the cleaner and have it taken to a service agent for
repair
Plug the cord in the mains socket. Make sure the
power supply is 240V
To start, simply switch your vacuum cleaner ON by
pressing down on the (ON/OFF) press button
Using the vacuum cleaner
After work one should:
Switch the unit off and remove the plug from
the wall socket
Do not remove the plug by pulling on the cord,
rather hold the plug and then remove it.
Wrap the cord round the unit for safe storage.
The most important units of the vacuum
cleaner
suction
hose
socket
front
hook
back hook
ON/OFF
button
inlet air filter
lower shield
screw for filter fixing
The vacuum cleaner is compact, yet despite
that it has an impressive 10-litre dust bag.
It is engineered to be very quiet during operation.
(Only 62dB)
The long life motor is located in the upper part of the
cleaner in the cover.
The vacuum cleaner container is made of metal
mounted on solid rubber wheels.
Attachments are also provided to aid cleaning
BUTLER
If the suction strength is reduced and cleaning of the
filter does not help, the filter will have to be replaced
with a new one!
About the vacuum cleaner
The inlet filter is in the lower part of the
cover. It should be cleaned from time to time.
If it is damaged it must be replaced with a new
one.
The foam outlet filter is under the upper lid of the
vacuum cleaner.
Unscrew the three screws and take off the cover to
gain access to this filter.
The filters used in the vacuum cleaner have a very
large surface area for filtering. That is why they
should be cleaned only if the suction strength is
reduced.
The foam filter can be washed in water, but it has to
be dry before putting it back.
Using the vacuum cleaner - foam filter replacement
remove the cover
outlet filter
unscrew
3 screws
Switch the vacuum cleaner off
Remove the hose from the vacuum cleaner
Release the back hook and detach the upper cover
Remove the full dust bag by grasping the cardboard
and remove the bag
Insert a new dust bag by sliding the reinforcing part
of the bag between the ribs at the bottom of the dust
cassette.
Make sure the dust bag is correctly fitted before re-
attaching the suction hose to the cleaner
Make sure you replace the top, upper cover of the
vacuum cleaner before re-connecting the suction
hose to container
Using the vacuum cleaner - replacing the dust bag
The suction hose is a basic element of the vacuum cleaners'
equipment. Its flexibility allows the user to manoeuvre the
equipment very easily. The suction hose handle is connected
to the hose in a way that enables you to twist the suction hose
during operation, preventing the hose from
“bunching” up. There is a manual
suction regulator on the suction hose
handle, which regulates the suction
power.
The suction pipes connect the nozzles and brushes to the
suction hose handle which increases the vacuum cleaners'
working range. Simply connect the 2 pipes together.
Upholstery nozzle is for cleaning surfaces
such as upholstered furniture, window
curtains, mattresses, cushions, etc.
Small brush nozzle is intended for
vacuuming uneven surfaces such as
picture frames or books.
Application of equipment and their assembly
Crevice nozzle, the slim crevice
nozzle enables cleaning areas
which are difficult to access such as
gaps, corners, recesses, etc
Suction brush.This accessory is versatile,
enabling use on carpeted and hard floor areas.
Switching from brush to nozzle is done by simply
pressing on the button on the floor tool. With the
bristles retracted, the floor tool is ready for use on
carpeted surfaces. When pressing the button on
the floor tool extends the bristles,
you are ready to clean
hard floor surfaces.
Caring for your Vacuum Cleaner
Never use the vacuum cleaner for:
Vacuuming ash, cigarettes or matches. Never
vacuum up any hot items whatsoever.
Vacuuming glass, clips, staples or any other sharp
objects.
Vacuuming wet surfaces or surfaces with spills of
water or other liquids. This unit is strictly for dry
dirt pick-up only.
Vacuuming gypsum, cement, stone powders,
plaster dust, concrete dust, powders, etc.
How to take care of your vacuum cleaner
Replace a full dust bag with a new one.
Do not let the dust bag overfill.
Check the filters regularly. Do not let them become
too clogged as this will degrade suction
performance.
Clean only the outside of the vacuum cleaner.
When cleaning the vacuum cleaner, do not
use coarse cleaning agents which could
scratch the housing.
It is best to use a wet, soft piece of cloth
moisturized with a mild cleaning agent to
clean the vacuum cleaner.
Make sure the vacuum cleaner is completely
dry before reusing..
NEVER use the vacuum cleaner if the dust
bag is ripped or the filters are damaged.
This will damage the motor and void your
warranty.
Important Safety Instructions
This vacuum cleaner is not designed for persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance. Children must not use this
appliance. Never vacuum up any liquids whatsoever.
One must not use this appliance if there are any
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
noticeable abnormalities or irregularities. Make sure the
insulation on the power cord is in good condition before
plugging in the unit.
The plug of the cord should be pulled out from a socket
before cleaning the vacuum cleaner.
