Clas Ohlson SP1380-UK Manual de usuario

EnglishSvenskaNorskSuomiDeutsch

Ver. 20130321

Wireless Speakers

Trådlösa högtalare

Trådløse høyttalere

Langattomat kaiuttimet

Funklautsprecher

Art.no Model

18-8027 SP1380-UK

38-2371 SP1380

English

Wireless Speakers

Art.no 18-8027 Model SP1380-UK

38-2371 SP1380

Please read the entire instruction manual before using the product and save it for

future reference. We reserve the right for any errors in text or images and any neces-

sary changes made to technical data. If you have any questions regarding technical

problems please contact Customer Services.

Safety

Warning! Do not open the casing. Certain components within the product’s casing

carry dangerous currents. Contact with these may give you an electric shock.

• Thisproductshouldonlyberepairedbyqualiedservicetechnicians.

• Theproductshouldnotbetakenapartormodied.

• Donotplacetheproductwherethereisariskofitfallingintowaterorotherliquid.

• Shutoffthestandbyfunctionatnightorwhenyoutravelaway.

• Donotcovertheventilationopenings.

• UseonlytheincludedAC/DCmainsadaptor.

• Thisproductisonlyintendedforindooruse.However,itcanbeusedoutdoors

but only on battery power.

Product description

• Wireless loudspeakers for wireless audio transfer.

• ThetransmitterconnectstotheheadphoneorRCAoutputontheTV,DVD,

stereo,computer,etc.

• Autofrequencysearchforeasyconnection.Switchforextrabassamplication.

• Thetransmitterispoweredbytheenclosedmainsadaptor.

• Theremotecontroloperateson6×LR6batteriesperspeaker(notincluded)

or by using the enclosed mains adaptors.

• Range:max.30mline-of-sight.

• Size(speakers):202×158×69mm.

English

The package box contains

1×Basestation

1×Aerial

1×Mainsadaptorforthebasestation

2×Loudspeakers

2×Mainsadaptorsfortheloudspeakers

1×3.5mmstereoplugto6.3mmstereoplugadaptor

1×3.5mmstereo(female)to2×RCAadaptor

1 ×Directions for use

Care and maintenance

• Onlyuseaslightlydampclothwhencleaning.Neverusestrong

cleaning agents or other solvents.

• Removethebatteriesfromthespeakersbeforestoringthem.

• Nevermixdifferenttypesofbatteries.

Disposal

Follow local ordinances when disposing of this product. If you are unsure

abouthowtodisposeofthisproduct,pleasecontactyourlocalauthority.

Specifications

Frequency 863MHz

Mains adaptor, base station In230VAC,50Hz,7W

 Out12VDC,200mA

 Plus(+)onthecentrepin

Protection class II

Mains adaptor, loudspeaker In230VAC,50Hz,70mA

 Out12VDC,500mA

 Plus(+)onthecentrepin

Protection class II

Batteries, loudspeaker LR6(6×)foreachloudspeaker

Input 3.5mmstereoplug

Audio adaptor 3.5mmstereoplugto6.3mmstereoplug(1×)

 3.5mmstereo(female)to2×RCA(1×)

Dimensions, speakers 155×200×70mm

English

Control lamp

Lights when an audio

signal is received via

the audio cable

Wire aerial

Aerial

Control lamp is on when

the mains adaptor is

connected to the base

station and a wall socket

Base station

Buttons and functions

Channel selector

Select desired output

channel (1 or 2)

DC connection for mains

adaptor (12 V DC, 200 mA,

plus (+) on the centre pin)

Audio input

Cable with 3.5 mm stereo plug

English

Wall mounting hole

Speakers

Control lamp is red when

a wireless signal cannot

be found and is green

when there is an active

audio signal

Battery compartment

ON/OFF

Volume control switch

NORMAL / BASS BOOST

Press to increase the bass sound

SCAN

Press to search for wireless signal

from the base station

DC connection for mains adaptor

(12 V DC, 600mA, plus (+) on the centre pins)

Folding supports

English

Installation

1. Unpack all the parts.

2. Feed the aerial over the wire aerial.

Use

1. Findasuitablespotforthebasestation(chooseaspotwhichisnotclosetoaninter-

ferencesourcesuchascordlesstelephones,uorescentlamps,microwaveovens,

etc.).Ifthereisinterferenceinthewirelesstransmission,tryanalternativespot.

2. Placethespeakersinasuitablespot(rangeupto30munimpeded).Theleft

speakerismarked“L”andtheright“R”.

3. Connecttheaudiocablestereoplugtoanaudiooutput:radio,MP3-player,etc.

4. Connect the mains adaptor to the base station and speakers. Please note that

there are 2 adapters for the speakers and one for the base station – do not confuse

themainsadaptorswithoneanother!Insertbatteries(LR6×6)inaccordancewith

the markings in the speakers if you do not have access to a wall socket.

5. Start the playback on the connected audio source and adjust the volume on

the connected audio source. A stronger input signal into the transmitter

will create less background noise in the speakers.Thegreencontrollamp

will come on when the transmitter receives a signal. If the green control lamp

does not come on or go off when music is played, the volume of the audio

source needs to be raised.Thetransmitterwillshutoffafteraminuteifno

signal is received or if the signal is too weak.

6. Switchonbothspeakersbyturningthe[ON/OFF/Volume]knob.

7. PressSCANoncetosearchforradiosignal.Thecontrollightonthespeakers

is red when a signal cannot be found and green when a signal from the base

station is received.

8. Trychangingchannelifthereisinterference.Switchoverto1or2onthebasestation.

9. Adjust the volume.

English

Troubleshooting guide

No sound

• Makesurethespeakersareturnedon.

• Increasethespeakervolumeforloudermusic.

The green lamp on the transmitter does not come on

• Increasethesignaltothetransmitterbyincreasingthevolumeonthesound

source(CD,TV,MP3player).Thetransmitterwillshutoffafteraminuteifno

signal is received or if the signal is too weak.

• Makesurethetransmitterhasaninputsignal(istheaudiosourceturnedon?).

Noise interference

• Ifthetransmitter’ssoundistoolowtherewillbenoisedistortioncomingfromthe

speakers. If one increases the sound on the device connected to the transmitter

(e.g.theTV),youwillreceiveastrongersignaltothetransmitterandaclearer

sound.Thevolumeofthespeakerscanthenbeloweredtogetthesamesound

level as before but with less noise interference.

Points worth bearing in mind!

• Other wireless equipment operating on the same frequency band may

reduce the range of the product.

• The range of all wireless equipment is affected by obstacles between

the transmitter and the receiver (a concrete wall reduces the signal far

more than a plasterboard partition, for example).

If you are having problems with the operation of the system,

try the following solutions

• Switch off any other wireless equipment to check whether it could be causing

the problem.

• Move the wireless equipment and/or reduce the distance, and reduce

thenumber of obstacles (walls, furniture, etc.) between the transmitter

andthe receiver.

Svenska

Trådlösa högtalare

Art.nr 18-8027 Modell SP1380-UK

38-2371 SP1380

Läsigenomhelabruksanvisningenföreanvändningochsparadensedanför

framtidabruk.Vireserverarossförev.text-ochbildfelsamtändringaravtekniska

data.Vidtekniskaproblemellerandrafrågor,kontaktavårkundtjänst(seadress-

uppgifterpåbaksidan).

Säkerhet

Varning!Öppnaintehöljet!Farligspänningnnsoskyddadpåvissakomponenter

inutiproduktenshölje,kontaktmeddessakangeelektriskchock.

• Produktenfårendastreparerasavkvaliceradservicepersonal.

• Produktenfårintedemonterasellerändras.

• Placerainteproduktensåattdenkanfallanerivattenellerannanvätska.

Ställintenågraföremålsominnehållervätskapåproduktent.ex.enblomvas

ellerläskedryck.

• Stängaveventuellstand-byfunktiontillnattenellernärdureserbort.

• Täckinteförventilationsöppningarna.

• Användendastdebifogadenätadaptrarna.

• Produktenärendastavseddförinomhusbruk,högtalarnafårdock

användasutomhus,menendastmedbatteridrift.

Produktbeskrivning

• Trådlösahögtalareförtrådlösöverföringavljud.

• Sändarenanslutstillhörlurs-ellerRCA-uttagetpåtv,dvd,stereo,datoretc.

• Automatiskfrekvenssökningförenkelinkoppling.Omkopplareförextrabasljud.

• Sändarendrivsmedmedföljandenätadapter.

• Högtalarnadrivsmed6×LR6-batterierperhögtalare(säljsseparat)eller

medmedföljandenätadaptrar.

• Räckvidd:Max.30mvidfrisikt.

• Storlekhögtalare:202×158×69mm.

Svenska

Förpackningen innehåller

1 ×Basstation

1 ×Antennspröt

1 ×Nätadaptertillbasstation

2 ×Högtalare

2 ×Nätadaptertillhögtalare

1 ×Övergång3,5mmstereopluggtill6,3mmstereoplugg

1 ×Övergång3,5mmstereo(hona)till2×RCA

1 ×Bruksanvisning

Skötsel och underhåll

• Användendastenlättfuktadtrasavidrengöring,aldrigstarka

rengöringsmedelellerandralösningsmedel.

• Taurev.batterierurhögtalarnavidlångtidsförvaring.

• Blandaaldrigolikatyperavbatterier.

Avfallshantering

Närduskagöradigavmedproduktenskadettaskeenligtlokalaföreskrifter.

Ärduosäkerpåhurduskagåtillväga,kontaktadinkommun.

Specifikationer

Frekvens 863MHz

Nätadapter basstation In230VAC,50Hz,7W

 Ut12VDC,200mA

 Plus(+)påcentrumstift

Skyddsklass II

Nätadapter högtalare In230VAC,50Hz,70mA

 Ut12VDC,500mA

 Plus(+)påcentrumstift

Skyddsklass II

Batterier, högtalare 6×LR6-batteriertillvarjehögtalare

Ingång 3,5mmstereoplugg

Medföljande övergångar 3,5mmstereopluggtill6,3mmstereoplugg

 3,5mmstereo(hona)till2×RCA

Storlek, högtalare 155×200×70mm
