Clas Ohlson DF7710A-GS Manual de usuario
Deep
FRYER
Fritös
Frityrkoker
Friteerauskeitin
Fritteuse
Art.no
18-1511
44-4381
Ver. 20200928
3
English
Deep Fat Fryer
Art. no 18-1511 Model DF7710A-GS
44-4381
Please read theentire instruction manual before using theproduct and then save it for
future reference. Wereserve theright for any errors in text or images and any necessary
changes made to technicaldata. Intheevent of technical problems or other queries,
please contact our Customer Services (see address details on theback).
Safety
• The product must not be used by children under theage of
8years. Theproduct may be used by children aged 8 or over
under adult supervision. Theproduct may be used by per-
sons with reduced physical, sensory or mental capabilities or
persons with alack of experience or knowledge which could
jeopardise their safety, provided they have been instructed in
thesafe operation of theproduct and understand thehazards
involved.
• Keep theproduct and its mains lead out of reach of children
under theage of8.
• Cleaning and user maintenance must not be performed by
children without adult supervision.
• If the mains lead has been damaged, it must only be replaced
by the manufacturer, authorised service facility or qualified
tradesman.
• The product must never be used with atimer or other equip-
ment which turns it on automatically.
• The product is intended for indoor useonly.
• The product should be placed on afirm, level surface with
thehandle positioned in such away as to minimise therisk of
hot oil spills.
• Never immerse theproduct in water or other liquid.
• The product is only intended for normal domestic use as de-
scribed in this instruction manual and in similar environments
such as canteens, offices, and hotels.
4
English
The housing of theproduct can become very hot duringuse.
• Never leave theproduct unattended duringuse.
• Never attempt to put out anoil fire withwater. Unplug
themains lead and smother thefire using afire blanket or
wettowel.
• Ensure that theproduct is used with thecorrect voltage.
Referto therating plate on theproduct.
• The product should only be connected to a220–240 V,
50/60 Hz mains outlet protected by a30 mA residual-current
circuit breaker (RCD).
• Always unplug theproduct from thewall outlet before
cleaning it or when it is not to be used for alongtime.
• Do not open thehousing. Certain unshielded components
inside thehousing carry dangerous voltages. Contact with
these components could result in electricshock.
• Never use theproduct if it is in any way damaged or not
working properly or if themains lead or plug is damaged.
Donot use theproduct if you have dropped it on thefloor
or into water or other liquid.
• Do not pull or carry theproduct by its mainslead. Donot use
thelead as ahandle and make sure that it is not crushed.
Donot pull thelead around sharp corners oredges.
• The product becomes very hot duringuse. Becareful not to
touch any hot parts with your barehands. Nevertouch parts
of theproduct other than thehandle.
• Never use theproduct if your hands are moist orwet.
• Never use theproduct if it iswet.
• Make sure that theparts of theproduct are correctly assem-
bled and that theproduct is switched off before connecting it
to thepower supply.
• Make sure that themains lead does not come in contact with
hot surfaces such as cookerhobs.
• Never move theproduct while it contains hotoil.
5
English
• Never overfill thefrying basket.
• Never use theproduct without oil in thecontainer.
• Only use theincluded accessories.
• Never add water to theoil. Makesure that thefood to be fried
is adry as possible.
• Never attempt to repair or modify theproduct in anyway.
Allrepairs must be carried out by qualified service technicians
using genuine spareparts.
Product description
1. Handle
2. Frying basket
3. Window
4. Lid
5. Filter
6. Power indicator light for
mains operation (red)
7. Control panel
8. Temperature control knob
9. Temperature indicator
(green)
10. Reset button
11. Guide rail
12. Housing
13. Oil container
Before initial use
Wash thefrying basket and container before using them for thefirsttime.
1. Take off thelid and remove thefrying basket from theoil container.
Donot subject it to knocks orblows.
2. Wash thebasket and oil container in warm water and washing-up liquid.
3. Rinse and thoroughly dry all theparts.
Never plug thefryer into themains or switch it on unless theoil container is filled
with asufficient amount of oil for frying. Ensure that thecontrol panel assembly is
mounted correctly. There is asafety cut-off switch on thecontrol panel which must be
pressed in in order for theheating element to becomehot.
1
2
3 4 5
7
11
12
13
10
6
9
8
6
English
Assembly
1. Place theoil container (13) inside
thehousing (12).
2. Slide thecontrol panel assembly
down into theholder on thehousing.
3. Attach thehandle onto
thefrying basket. Firsthook
thehandleon.
4. Then flip thehandle over theside of
thebasket so that it locks intoplace.
Instructions for use
Warning: Hot oil and fat can cause serious burns, be careful.
Always switch thefryer off and unplug it from thewall socket afteruse.
1. Make sure that thetemperature control knob is in turned down
tozero.
2. Remove thelid.
3. Pour2.2–3 litres of anappropriate oil for frying into theoil
container. Adjust thelevel according to what you plan tofry.
4. Smear alittle oil onto theviewing window to prevent it from
fogging up during frying.
5. Refit thelid.
6. Connect theplug to awall socket. Thepower indicator
light will shinered.
7. The green indicator light is lit during warm-up and turns off once theset
temperature has been reached. Ittakes about 15–20 minutes for theoil to reach
operating temperature.
Slide the control
panel down into
the holder on
the housing.
7
English
8. Remove thelid.
9. Lower thefrying basket containing dry food into theoil container.
10. Refit thelid.
11. Once thefood has been fried, turn thetemperature down to zero and unplug
thefryer from thewall socket.
12. Remove thelid. Whenremoving thelid, watch out for hot steam created during
frying. Steamcould scaldyou.
13. Lift out thefrying basket by thehandle and hook it over theside of thehousing.
Lettheoil drain out for approximately 10–30 seconds.
14. Do not move thefryer until theoil has cooled completely.
15. Change theoil after 8–10 uses or when necessary.
Frying tips
• Start by frying at thelowest frying temperature.
• When you fry batches of similar food theoil may cool slightly. Between batches
you should wait 3–5 minutes until thefryer regains thecorrect frying temperature.
Thegreen indicator light turns off once thefryer is ready to beused.
• Food which has been precooked requires higher temperatures but
ashorter frying time compared to food that israw.
• Never fill thefrying basket to more than half-full.
• Never mix different types ofoils.
• Use vegetable oil, maize (corn) oil or olive oil for deep-frying. Wedo not recom-
mend using oil with ashort shelf life such as sunfloweroil.
Frying guide
Foodstuff Temperature (°C) Weight (grams) Frying time (mins)
Fish fillet 150 250 5–6
Battered fish fillet 150 400 6–8
Fish cakes 150 400 6–8
Mushrooms 140 300 6–8
Chicken fillet 180 500 7–10
Roasting joint 170 400 4–10
Sliced meat 170 400 7–10
Chips 190 550 8–10
Prawns 130 250 3–5
Onion rings 140 150 3–4
8
English
Care and maintenance
The frying basket and oil container are dishwashersafe.
Never immerse thecontrol panel, mains lead or plug in water or other liquids.
1. Unplug thefryer from thepower point and make sure that theoil has cooled
(1–2 hours after use) before cleaning thefryer.
2. Remove thebasket from theoil container.
3. Empty thefrying oil into anappropriate storage container.
4. Wash thelid in warm water and washing-up liquid.
5. The exterior of thefryer can be cleaned using aslightly moistenedcloth.
Neveruse awashing-up brush or chemical cleaning agents.
Filtering theoil
1. Remove thebasket from theoil
container and empty thecooled oil
into aplastic bottle or other suitable
container.
2. Filter theoil through acoffee filter
for instance.
Resetting
If for some reason thefryer stops heating, thereason
may be that thesafety cut-off switch has tripped.
To reset theswitch:
1. Unplug themains lead from thewall socket.
2. Let the fryer and theoil cooldown.
3. Lift up thecontrol panel assembly and reset
thesafety cut-off switch by pressing it in using
apointed object such as apen.
4. Refit theparts in thereverseorder.
6. The frying oil may be filtered and
reused but should probably be
changed after every 8–10 uses
or before if necessary. Remove
thefilter cover on thetop of thelid
and check thefilter. Ifit needs to
be washed, remove thefilter and
wash it in warm soapywater.
9
English
Troubleshooting guide
Problem Cause
Steam escapes from
under thelid.
The lid is not shut properly.
The oil spillsover. • The oil level exceeds themaximumlevel.
• The frying basket contains too muchfood.
The fried food is not
crispy on theoutside.
• The food in thebasket is not dry enough.
• The oil temperature is toolow.
• The frying basket contains too muchfood.
Responsible disposal
This symbol indicates that theproduct should not be disposed of with
general householdwaste. Thisapplies throughout theentireEU. Inorder
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner.
Whenrecycling theproduct, take it to your local collection facility or
contact theplace of purchase. Theywill ensure that theproduct is
disposed of in anenvironmentally sound manner.
Specifications
Rated voltage 220–240 V, 50/60 Hz
Power 1800 W
Oil container capacity 3L
Frying basket capacity 700 g
Size (W×D×H) 40×22×23cm
Weight 3kg
10
Svenska
Fritös
Art.nr 18-1511 Modell DF7710A-GS
44-4381
Läs igenom hela bruksanvisningen före användning och spara den sedan för fram-
tidabruk. Vireserverar oss förev. text- och bildfel samt ändringar av tekniskadata.
Vidtekniska problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter
påbaksidan).
Säkerhet
• Produkten får inte användas av barn från 0 till 8 årsålder.
Produkten får användas av barn från 8 år och uppåt ivuxens
närvaro. Produkten får användas av personer med någon
form av funktionsnedsättning, brist på erfarenhet eller
kunskap som skulle kunna äventyra säkerheten, om de har
fått instruktioner om hur produkten på ettsäkert sätt ska
användas och förstår faror och risker som kan uppkomma.
• Håll produkten och dess nätkabel utom räckhåll för barn
under 8år.
• Rengöring och skötsel får inte utföras av barn utan vuxens
närvaro.
• Om nätkabeln skadats får den, för att risk för elektrisk stöt
eller brand ska undvikas, endast bytas av tillverkaren, dess
serviceställe eller av en kvalificerad yrkesman.
• Produkten får inte anslutas tillsammans med entimer eller
annan tidsstyrd utrustning.
• Produkten är endast avsedd för inomhusbruk.
• Placera produkten på ettplant och stabilt underlag och
placera handtagen så att risken för att spilla ut het olja
minimeras.
• Sänka aldrig ner produkten ivatten eller annan vätska.
• Produkten är endast avsedd för normalt bruk ihemmet
på det sätt som beskrivs iden här bruksanvisningen och
iliknande miljöer somt.ex. ipersonalmatsalar, kontor, hotell
och vandrarhem.
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Idiomas:
Otros manuales de Freidora de Clas Ohlson
