OPERATION & MAINTENANCE

INSTRUCTIONS

LS0911

VARIABLE SPEED SCROLL SAW

MODEL NO: CSS400C

PART NO: 6462152

INTRODUCTION

Thank you for purchasing this CLARKE Variable Speed Scroll Saw.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights.

IN THE BOX.

ENVIRONMENTAL PROTECTION

Recycle unwanted materials instead of disposing of them as

waste. All tools, accessories and packaging should be sorted,

taken to a recycling centre and disposed of in a manner which is

compatible with the environment.

1 x Scroll Saw 1 x Spanner for Flexible Drive Collet Nut

1 x Flexible Drive 1 x Blade 133mm x 2.5mm x 15 t.p.i

1 x Blade Guard Assembly 1 x Blade 133mm x 2.5mm x 18 t.p.i.

1 x T-handled 3.0 mm Hex Key 2 x Collets for Flexible Drive; (1 x 3.2 mm, 1 x 2.4 mm)

1 x 2.5 mm Hexagon Key 2 x 'Pin-less' Blade Clamp Adaptors

1 x Locking Pin for Flexible Drive 1 x 64 Piece Accessory Kit for the Flexible Drive

GENERAL SAFETY INSTRUCTIONS

1) WORK AREA

1. Keep the work area clean and well lit. Cluttered and dark areas invite accidents.

2. Do not operate power tools in explosive atmospheres, such as in the presence of

flammable liquids, gases or dust. Power tools create sparks which may ignite the

dust or fumes.

3. Keep children and bystanders away while operating a power tool. Distractions can

cause you to lose control.

2) ELECTRICAL SAFETY

1. Power tool plugs must match the outlet. Never modify the plug in any way. Do not

use adapter plugs with earthed (grounded) power tools. Unmodified plugs and

matching outlets will reduce the risk of electric shock.

2. Do not expose power tools to rain or wet conditions. Water entering a power tool will

increase the risk of electric shock.

3. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the

power tool. Keep the cord away from heat, oil, sharp edges or moving parts.

Damaged or entangled cords increase the risk of electric shock.

4. When operating a power tool outdoors, use an extension cord suitable for outdoor

use. Use of a cord suitable for outdoor use reduces the risk of electric shock.

3) PERSONAL SAFETY

1. Stay alert, watch what you are doing and use common sense when operating a

power tool. Do not use a power tool while you are tired or under the influence of

drugs, alcohol or medication. A moment of inattention while operating power tools

may result in personal injury.

2. Use safety equipment. Always wear eye protection. Safety equipment such as dust

mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate

conditions will reduce personal injuries.

3. Avoid accidental starting. Ensure the switch is in the off position before plugging in.

Carrying power tools with your finger on the switch or plugging in power tools that

have the switch on invites accidents.

4. Remove any adjusting key or wrench before turning the power tool on. A wrench or

a key left attached to a rotating part of the power tool may result in personal injury.

5. Do not overreach. Keep proper footing and balance at all times. This enables better

control of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and

gloves away from moving parts. Loose clothes, jewellery or long hair can be caught

in moving parts.

4) POWER TOOL USE AND CARE

1. Do not force the power tool. Use the correct power tool for your application. The

correct power tool will do the job better and safer at the rate which it was designed.

2. Do not use the power tool if the switch does not turn it on and off. Any power tool that

cannot be controlled with the switch is dangerous and must be repaired.

3. Disconnect the plug from the power source before making any adjustments,

changing accessories, or storing power tools. Such preventive safety measures

reduce the risk of starting the power tool accidentally.

4. Store idle tools out of the reach of children and do not allow persons unfamiliar with

the power tool or these instructions to operate the power tool. Power tools are

dangerous in the hands of untrained users.

5. Maintain power tools. Check for misalignment or binding of moving parts, breakage

of parts and any other condition that may affect the power tools operation. If

damaged, have the power tool repaired before use. Many accidents are caused

by poorly maintained power tools.

6. Keep cutting tools sharp and clean. Well maintained cutting tools with sharp cutting

edges are less likely to bind and are easier to control.

7. Use the power tool, accessories and tool bits etc., in accordance with these

instructions and in the manner intended for the particular type of power tool, taking

into account the working conditions and the work to be performed. Use of the power

tool for operations different from intended could result in a hazardous situation.

5) SERVICE

1. Have your power tool serviced by qualified service personnel using only identical

replacement parts. This will ensure that the safety of the power tool is maintained.

SCROLL SAW SAFETY INSTRUCTIONS

1. Wear safety goggles as protection against flying wood chips and saw dust. In many

cases, a full face shield offers even better protection.

2. A dust mask is recommended to keep saw dust out of your lungs.

3. The scroll saw must be bolted securely to a stand or workbench. If the saw has a

tendency to move during certain operations, bolt the stand or workbench to the

floor.

4. A solid wood workbench is stronger and more stable than a workbench with a

plywood table.

5. This scroll saw is for indoor use only.

6. Do not cut pieces of material which are too small to be held by hand.

7. Clear the work table of all objects except the workpiece (tools, scraps, rulers etc.)

before turning the saw on.

8. Make sure the blades’ teeth are pointing down, toward the table, and that the

blade tension is correct.

9. When cutting a large piece of material, support it at the height of the table.

10. Do not feed the workpiece through the blade too fast. Feed only as fast as the

blade will cut.

11. Keep your fingers away from the blade. Use a push stick as you near the end of the

cut.

12. Take care when cutting a workpiece which is irregular in cross section. Mouldings for

example must lie flat, and not ‘rock’ on the table while being cut. A suitable support

must be used.

13. Switch off the saw, and make sure the blade has come to a complete stop before

clearing sawdust or off-cuts from the table.

14. Make sure there are no nails or foreign objects in the part of the workpiece to be

sawn.

15. Be extra cautious with very large or small, or irregularly shaped workpieces.

16. Set up the machine and make all adjustments with the power OFF, and

disconnected from the supply.

17. DO NOT operate the machine with the covers off. They must all be in place and

securely fastened when performing any operation

18. Be sure to use the correct blade size and type.

19. Use ONLY approved replacement saw blades. Contact your local CLARKE dealer for

advice. The use of inferior blades may increase the risk of injury.

ELECTRICAL CONNECTIONS

Before switching the product on, make sure that the voltage of your electricity supply is

the same as that indicated on the rating plate. This product is designed to operate on

230VAC 50Hz. Connecting it to any other power source may cause damage.

This product may be fitted with a non-rewireable plug. If it is necessary to change the

fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or

damaged, the plug must not be used until a suitable replacement is obtained.

If the plug has to be changed because it is not suitable for your socket, or due to

damage, it should be cut off and a replacement fitted, following the wiring instructions

shown below. The old plug must be disposed of safely, as insertion into a mains socket

could cause an electrical hazard.

If the colours of the wires in the power cable of this product do not correspond with the

markings on the terminals of your plug, proceed as follows.

• The wire which is coloured Blue must be connected to the terminal which is

marked Nor coloured Black.

• The wire which is coloured Brown must be connected to the terminal which is

marked Lor coloured Red.

• The wire which is coloured Yellow and Green must be connected to the

terminal which is marked E or or coloured Green.

We strongly recommend that this machine is connected to the mains supply via a Residual

Current Device (RCD)

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs yourself.

WARNING! Read these electrical safety instructions thoroughly

before connecting the product to the mains supply.

WARNING! The wires in the power cable of this product are

coloured in accordance with the following code:

Blue = Neutral Brown = Live Yellow and Green = Earth

Plug must be BS1363/A approved.

Always fit a 13 Amp fuse.

Ensure that the outer sheath of the cable is firmly held by the clamp

Neutral

(Blue)

Live

(Brown)

Earth

(Green and Yellow)

OVERVIEW

NO DESCRIPTION NO DESCRIPTION

1 Adjustable lamp 9 On/Off switch

2 Blade guard 10 Dust extraction outlet

3 Top blade holder 11 Table tilt lock knob

4 Workpiece pressure plate 12 Angle adjustment scale

5 Sawdust blower nozzle 13 Flexible shaft

6Blade 14Sawtable

7 Table insert 15 Blade tension knob

8 Blade speed regulator 16 Hose (sawdust blower)

MOUNTING THE SCROLL SAW

BOLTING THE SCROLL SAW ONTO A WORKBENCH

1. It is recommended that this tool is securely mounted onto a robust

workbench. Fixings are not provided. Be sure to use equipment of at least

the following size:

• 4 x Hex bolts M8

• 4 x Hex nuts M8

• 4 x Flat washer Ø 8 mm

•Rubbermat

2. We recommend that a rubber fine rib matt 420 x 250 x 3 mm (minimum)

13 mm (maximum) is fixed between the workbench and scroll saw to help

minimise vibrations and noise. This mat is not supplied.

• Suitable rubber matting of various thicknesses is available from your

Clarke dealer.

NOTE: Do not over-tighten the screws. Leave enough give for the rubber

mat to absorb any vibration.

WARNING: DO NOT PLUG SAW INTO MAINS UNTIL THE SAW HAS BEEN

FIRMLY MOUNTED TO WORK SURFACE.

BEFORE USE

CHOOSING THE RIGHT BLADE

NOTE: As a rule, select narrow blades for intricate curve cutting and

wide blades for straight and large curve cutting.

Scroll saw blades wear out and must be replaced frequently for optimum

cutting results.

Scroll saw blades generally become dull after 1/2 hour to 2 hours of cutting,

depending on the type of material and speed of operation.

Best results are achieved with pieces less than one inch (25 mm) thick.

When cutting workpieces thicker than one inch (25 mm), you must guide the

blade into the workpiece very slowly and take extra care not to bend or twist

the blade while cutting.

PINLESS BLADE ADAPTOR

The pinless blade adaptor allows you to use blades that don't have locating

pins at each end of the blade.

1. Adjust one set screw on each

adaptor until it covers

approximately half the hole when

viewed from above

2. Loosen the other set screw just

enough to slide an adaptor onto

each end of the blade.

3. Place the blade and adaptors

into the gauge on top of the

machine to set the blade to the

proper length.

CUTTING AT RIGHT ANGLES TO THE UPPER ARM WHEN USING PINLESS BLADES

• Cutting from the side of the saw will be necessary when your workpiece

exceeds 405mm in length. With the blade positioned for side cutting the

table must always remain in the 0° bevel position.

1. Remove both set screws from each blade adaptor, thread them into the

opposite holes in the blade adaptor perpendicular to the adjustment pin.

BLADE TENSION

• Turning the blade tension knob

counterclockwise decreases

(slackens) blade tension.

• Turning the blade tension knob

clockwise increases (or

tightens) blade tension.

1. Pluck the back straight edge of

the blade while turning the

tension adjusting knob.

• The sound becomes higher pitched as tension increases.

NOTE: Do not over-tension the blade. This will help to prolong the life of

the saw blade.

NOTE: Too little tension may cause the blade to bend or break.

Tabla de contenidos

Otros manuales de Sierra de Clarke

Clarke

Clarke CTS11 Manual de instalación y operación

Clarke

Clarke contractor CON100 Manual de instalación y operación

Clarke

Clarke CLS400 Guía de referencia rápida

Clarke

Clarke CSS16V Manual de instalación y operación

Clarke

Clarke CT4014 Manual de usuario

Clarke

Clarke Woodworker CMS251 Manual de instalación y operación

Clarke

Clarke CCS12 Manual de instalación y operación

Clarke

Clarke WOODWORKER CTS800B Manual de instalación y operación

Clarke

Clarke CTS13L Manual de instrucciones

Clarke

Clarke CMS210 Manual de instrucciones

Clarke

Clarke Woodworker CBS12WC Manual de instalación y operación

Clarke

Clarke CMS250S Manual de instrucciones

Clarke

Clarke CPS160 Manual de instrucciones

Clarke

Clarke Metalworker CBS45MD Manual de instalación y operación

Clarke

Clarke Woodworker CTS14 Manual de instrucciones

Clarke

Clarke CCS305 Manual de instalación y operación

Clarke

Clarke CMS210B Manual de instrucciones

Clarke

Clarke WOODWORKER CBS250 Manual de instalación y operación

Clarke

Clarke Woodworker CMS254 Manual de instalación y operación

Clarke

Clarke Woodworker CTS10PLM Manual de instalación y operación

Clarke

Clarke CSS 400 Instrucciones de funcionamiento

Clarke

Clarke Woodworker CSS400B Manual

Clarke

Clarke CBS 355 Manual

Clarke

Clarke CON14 Manual de instrucciones

Manuales populares de Sierra de otras marcas

RIDGID

RIDGID BS1400 Manual de usuario

ATIKA

ATIKA BWS 400-2 Manual de usuario

RGC

RGC FS20 Manual de usuario

Makita

Makita M2300 Manual de usuario

IMET Spa

IMET Spa BASIC 300 PLUS SHI Manual de usuario

IMET Spa

IMET Spa SIRIO 370 AF-E Manual de usuario

Optimum

Optimum OPTisaw CS 275 Manual de usuario

Makita

Makita BPB180 Manual de usuario

Stihl

Stihl MS 462 C-M Manual de usuario

AEG

AEG TS 250 K Manual de usuario

Meec tools

Meec tools 004665 Manual de usuario

Makita

Makita LS1018L Manual de usuario

Ryobi

Ryobi RCS1400 Manual de usuario

DeWalt

DeWalt DCS391 Manual de usuario

Sealey

Sealey SA72 Manual de usuario

skilsaw

skilsaw SPT88 Instrucciones de montaje

Urrea

Urrea SI810 Dimensiones y guía de instalación

EINHELL

EINHELL BKG 210/1 Manual de usuario
