USER MANUAL MODEL: CY
USER MANUAL: CITIZEN
MODEL: CY
P a g e | 2/8
USER MANUAL MODEL: CY
Setting Up the balance
Balace with Analytical Draft-Shield Chamber
Step 1: Open your new balance and draft shield you will see lock mounted on balance body
and lock plate mounted below draft shield.
Step 2: Put your draft shield in same place and direction guided through RED color lines
marked on this sticker, with gentle hand push & rotate draft shield clockwise as show in figure
Step 3: Push fix both corner hold cover on bottom body of draft shield as shown in figure.
P a g e | 3/8
USER MANUAL MODEL: CY
Place the components listed below inside the chamber in the order given :
Corner Cover, Base plate, Pan Cover, Weighing pan
Location
The Optimun location
The correct location makes an important contribution to the accuracy of the weighing results of high-
resolution analytical and precision balances.
Avoid
•Direct sunlight
•Excessive temperature fluctuations,
•Drafts (Power-----Air Conditioning System, Fans can also cause drafts)
The best position is an a stable bench in a corner protected against drafts as far-possible from doors,
windows, radiators or the ventitation slots of air conditioners.
P a g e | 4/8
USER MANUAL MODEL: CY
Warm Up
Connecting Electronic Peripheral Devices
Make absolutely sure to unplug the balance from DC power before you connect or disconnect a peripheral
device
Warmup Time
To deliver exact results, balance must warm up to operating temperature for as leasted below before the
first weighing operation is carried out.
CY Analytical models: at least 60 minutes.
Key Functionality in simple weighing mode
Switch on & off
Tare, Confirm setting
Abort / Cancel
P a g e | 5/8
USER MANUAL MODEL: CY
Calibrate (Adjust), call Menu
Print Weighing Result
Power ON
Connect DC Adaptor and Power ON the balance
-It will display version number for software
-It will display numeric countdown
-It will display
-The system initialization process will begin with the display indicating the current progress. (INIT
1% to INIT 100%) it will enter stand by mode & display clock.
Stand by mode
-After Power ON and initial test balance will automatically come in stand by mode.
P a g e | 6/8
USER MANUAL MODEL: CY
-Press key to come to basic weighing
-Press key in basic weighing to come back to Stand by Mode
Overview of Menu
In this menu, you can select unit 1, 2, 3 or Application Program, adjust the stability filter, Calibration
choice, Auto Zero Tracking, automatic shutdown and print setting.
Time & Date Setting
In this menu, User can set the clock.
Clock setting consist of 2 settings, They are
TIME : In this submenu user can set the time in hours, minutes & seconds, AM, PM & 24 hrs.
DATE: In this submenu user can set the date, month & Years
P a g e | 7/8
USER MANUAL MODEL: CY
Operating Instructions
Press the PRINT key for 2 sec when coming out from stand by or Power on mode.
SET TIME
-Current Time is displayed with first digit flashing. Flashing digit indicates that digit value or
place can be changed.
-Press Toggle key to change the value of the Flashing digit.
-Press CAL key to shift the flashing digit from Left to Right.
-After proper setting of time in hours, nimutes & seconds respectively for zeroes starting from left,
press tare key
-Press the PRINT key to change the format AM, PM & 24 hrs.
SET DATE
-Press TARE key “date” is display
-Press TARE key, current date is displayed with first digit flashing. Flashing digit indicaters that
digit value or place can be changed.
-Press TGGGLE key to change the value of the Flashing digit.
-Press CAL key to ship the flashing digit from Left to Right
-After proper setting of date in day, month & year respectively for zeroes starting from left,
P a g e | 8/8
USER MANUAL MODEL: CY
-Press TARE key to set the date
